U s e r ’s m a n u a l
NDR-BA6104
NDR-BA6208
NDR-BA6416

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
2
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of following directives and national
regulations implementing the directives:
 Electromagnetic compatibility EMC 2004/108/EC.
 Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well
as 75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European Directive on Waste Electrical and Electronic
Equipment (2002/96/EC) and further amendments. By ensuring this product is disposed of correctly,
you will help to prevent potential negative consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance
may not be treated as household waste. It shall be handed over to the applicable collection point for the
waste electrical and electronic equipment for recycling purpose. For more information about recycling
of this product, please contact your local authorities, your household waste disposal service or the shop
where you purchased the product.
RoHS Directive 2002/95/EC
Concerning for human health protection and friendly environment, we assure that our products falling
under RoHS Directive regulations, regarding the restriction of the use of hazardous substances in
electrical and electronic equipment, were designed and manufactured in compliance with mentioned
regulation. Simultaneously, we claim that our products were tested and do not contain hazardous
substances exceeding limits which could have negative impact on human health or natural
environment.
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed
for self installation in households by individuals without technical knowledge.
The manufacturer is not responsible for defects and damages resulted from improper or inconsistent
with user’s manual installation of the device in the system.
IMPORTANT SAFEGUARDS AND WARNINGS

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
3
ATTENTION!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT PROVISIONED FOR THE GIVEN
PRODUCT IN ITS USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE
PRODUCT, OR THAT ARISES FROM THE NORMAL APPLICATION OF THE PRODUCT, ITS
MANUFACTURER MUST BE CONTACTED OR THE RESPONSIBILITY OF THE
MANUFACTURER FOR THE RESULTS OF SUCH AN ACTION SHELL BE EXCLUDED.
1. The installation of this device should be made by a qualified service person or a professional safety
system installer.
2. Device mustn’t be placed in places where ventilating holes are partially or fully covered.
3. User’s interference inside the device is not allowed and is unnecessary as it does not have any
systems which require adjusting or which are suitable for self-repair. You mustn’t dismantle the
recorder or remove any single fastening screws. If any repairs are necessary contact the service.
The device must be take care of and protected against any mechanical damage.
4. The device has to be protected against humidity and dust. In case the recorder had a contact with
water react immediately: switch off the power supply and contact the authorised Novus service. If
the device gets dirty it might get damaged or electrocute someone.
5. The device can only be cleaned with a damp cloth after the power supply has been switched off.
Avoid strong detergents (liquids and sprays). Mild detergents can be used if the recorder becomes
very dirty.
6. Power supply unit cords and signal cords should be laid in a way that eliminates the risk of
mechanical damage; special attention should be paid to the plug. Be careful not to overload sockets
and extension cords so that there is no fire.
7. To avoid devices’s damage vision and control signals should be equipped with systems protecting
against disturbances, over voltage and atmospheric discharge that are in compliance with Polish
regulations. It is also advised to use ground loop isolators.
8. The device mustn’t be used in conditions which do not fulfil operating requirements as far as power
supply, relative humidity or air temperature are concerned.
9. You cannot allow any metal objects get inside the recorder. It might cause serious damage. If a
metal object gets inside the device contact the authorised Novus service immediately.
10. The manufacturer does not bear responsibility for damage or loss of data stored on HDDs or other
media occurred during the usage of the product.
Attention!
Technical changes reserved without prior notice and printing errors possible.
IMPORTANT SAFEGUARDS AND WARNINGS

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
4
1. FOREWORD INFORMATION
1.1. Main characteristics
 Quadruplex: simultaneous recording, live monitoring, playback or backup and networking
 Linux-based operating system
 Real-time display
 1080p HDMI socket
 Recording speed up to 25 FPS per channel
 H.264 compression
 Recording resolution: 960 x 576, 720 x 576, 720 x 288, 360 x 288
 Advanced schedule recording & motion detection functions
 Pre-alarm & post-alarm functions
 Audio recording
 PTZ control directly from the device or via the network
 Control protocols: N-Control, Pelco-D, Pelco-P and other
 Supports remote control by NV-KBD70, NV-KBD50 and NV-KBD30 keyboards
 Supports up to 2 SATA HDDs (for NDR-BA6416 and NDR-BA6208 ) or 1 SATA HDD (for
NDR-BA6104)
 S.M.A.R.T function
 Backup onto USB Flash Memory through USB port & via the network
 Backup as *.AVI files
 Advanced search of recorded images (by time or event)
 Networking (live monitoring, playback, archiving & alarm event e-mail notification, changing
DVR’s settings via the IE web browser)
 Dual stream; two independent network streams (SUBSTREAM and MASTERSTREAM) for
each channel
 Software: CMS application for remote administration, live monitoring and recorded data search,
NMS for live monitoring ,recorded data search and integration with NOVUS IP cameras.
B-viewer (soon) application for remote administration, live monitoring and recorded data search.
 User friendly, multi-lingual graphical user interface
 Mobile platforms supported
 Mask function
 Event log
 Snapshot function exporting current frame to the .jpg file
 Supports settings import/export
 IP addresses filtering function
 PC mouse control (in-set included)
 12 VDC (100 ~ 240 VAC/12 VDC PSU in-set included)
FOREWORD INFORMATION

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
5
1.2. NDR-BA6104, NDR-BA6208 and NDR-BA6416 recorder’s technical data
FOREWORD INFORMATION
Model NDR-BA6104 NDR-BA6208 NDR-BA6416
Operation Mode Quadrupleks
Operating
System Linux
Video Input 4 x BNC 8 x BNC 16 x BNC
Video Output Main (split screen, full screen, sequence): 1 x BNC, 1 x VGA, 1 x HDMI
Spot (full screen, sequence): 1 x BNC
Alarm Input 4 8 16
Alarm Output 1 relay
Audio Input 4
Audio output 1
Recording speed Up to 100 fps (960 x 576) Up to 200 fps (960 x 576) Up to 400 fps (960 x 576)
Compression H.264
Recording
Resolution 360 x 288, 720 x 288, 720 x 576, 960 x 576
Recording Mode Time-lapse, Event Alarm, Motion detection, Schedule
Display Speed Up to 100 fps (real time) Up to 200 fps (real time) Up to 400 fps (real time)
Display Screen 1, 4, sequence, digital zoom of a
selected screen area: 4x
1, 4, 6, 8, 1+5, 1+7, sequence,
digital zoom of a selected
screen area: 4x
1, 4, 6, 8, 16, 1+5, 1+7,
1+12, sequence, digital
zoom of a selected screen
area: 4x
Motion Detection 22 x 15 grid, with sensitivity defined individually for each channel
Video Loss
Detection Yes
Schedule
Recording individual settings for: each day, each camera, possibility of combining individual recording modes
Recorded Data
Search By date/time, events (Alarm, Motion detection)
Event History
Log Yes
Time
Synchronization Automatic time synchronization with NTP server
HDD Supports 1 HDD SATA Supports up to 2 HDD SATA
Backup HDD or USB Flash Memory through USB port, through the
network
DVD (option), HDD or USB Flash Memory through USB
port, through the network,
External Ports 1 x Ethernet - RJ-45 interface, 10/100/1000 Mbit/s, 2 x USB 2.0 - for Flash Memory and PC mouse,
1 x RS-485 - for PTZ cameras or PTZ keyboard
PTZ Control Directly from the device or via the network
Protocol N-Control, Pelco-D, Pelco-P and others
Control Front panel, NV-KBD70, NV-KBD50 and NV-KBD30 keyboards, IR remote control (included),
Network , USB PC mouse (included)
Menu Multi-lingual On Screen Display (OSD)
Software CMS, B-viewer (soon),Internet Explorer, Super Live Pro (iPhone, Android, BlackBerry),
Pocket Camera (Windows Mobile, Symbian)
User
Authorization Creation of user accounts with varying privileges, password protection
Power Supply 12 VDC (100~240 VAC/12 VDC PSU in-set included)
Power
Consumption max. 25 W with HDD max. 40 W with 2 HDDs
Operating
Temperature 0°C ~ 50°C
Relative
Humidity 10% ~ 90% (non-condensing)
Dimensions
(mm) 300 (W) x 65 (H) x 270 (D) 430 (W) x 65 (H) x 300 (D)
Weight 2 kg (without HDD) 4 kg (without HDD)

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
6
1.3. Package contents
Unpack the device carefully. After unpacking, please ensure that package contains the following items:
If any of the elements has been damaged during transport, pack all the elements back into the original
packaging and contact your supplier.
WARNING!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning on the device immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
Mouse
Short user’s
manual
Screws
FOREWORD INFORMATION
Power cord
Power supply
12VDC
HDD SATA
cables
NDR-BA6208,NDR-BA6416 IR remote control
(NDR-BA6208,
NDR-BA6416 )
CD with a full version of user’s
manual and software tools
NDR-BA6104 DVR
IR remote control
(NDR-BA6104)

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
7
2. STARTING THE DEVICE
2.1. Electrical connection and other rear panel elements of NDR-BA6104 DVR
1. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-
amplifiers
2. ALARM IN: 4 alarm inputs, which may be set either as normally open (N.O.) or normally
closed (N.C.). In order to detect the alarm, signal should last for minimum
0.5sec .
3. ALARM OUT: Alarm relay output (NO, COM), max. load capacity of the outputs is
0,5A/125VAC and 1A/30VDC.
4. GND: Grounding
5. VIDEO IN: 4 video inputs for connecting video signal sources to the DVR.
6. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
7. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
8 LAN: RJ-45 connector port for connecting to the local network and internet.
9. USB: USB 2.0 port for external Flash memory and mouse connection.
10. DC12V: 12V DC power socket for connecting included power adaptor.
11. RS-485: One RS-485 bus port for connecting external keyboard or PTZ cameras
(RS485: A+, B-)
12. AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
13. VIDEO OUT: Main monitor connector BNC.
14. SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
Note: OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from
VGA to HDMI or BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
1 2 3 4 5 7
14
6 8 9 10
12 13
11

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
8
2.2. Electrical connection and other rear panel elements of NDR-BA6208 DVR.
1. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
2. GND: Grounding
3. RS-485: RS-485 bus port for connecting external keyboard or PTZ cameras
(K/D: A+, B-)
4. ALARM OUT: Alarm relay output (NO, COM), max. load capacity of the outputs is
0,5A/125VAC and 1A/30VDC.
5. ALARM IN: 8 alarm inputs, which may be set either as normally open (N.O.) or normally
closed (N.C.). In order to detect the alarm, signal should last for minimum
0.5sec .
6. VIDEO IN: 8 video inputs for connecting video signal sources to the DVR.
7. HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
8. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
9. LAN: RJ-45 connector port for connecting to the local network and internet.
10. USB: USB 2.0 port for external Flash memory and mouse connection.
11.DC12V: 12V DC power socket for connecting included power adaptor.
12.FAN: Cooling fan, do not cover!
13.AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
14.VIDEO OUT: Main monitor connectors,
15.SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
16.POWER SWITCH: DVR power switch.
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
HDMI or BNC, please press and hold the ESC button for 5sec.
STARTING THE DEVICE
1 2 3 4 5 6 7 8 9 10 11 12
13 14 15 16

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
9
STARTING THE DEVICE
14
2.3. Electrical connection and other rear panel elements of NDR-BA6416 DVR.
1. POWER SWITCH: DVR power switch.
2. ALARM OUT: Alarm relay output (NO, COM), max. load capacity of the outputs is
0,5A/125VAC and 1A/30VDC.
3. AUDIO IN: Audio (mono) inputs for connecting microphones with pre-amplifiers
4. VIDEO OUT: Main monitor connector.
5. VIDEO IN: 16 video inputs for connecting video signal sources to the DVR.
6. VGA: Main monitor connector, VGA type. Please use signal cable provided with
the monitor when using aforementioned connection type.
7. DC12V: 12V DC power socket for connecting included power adaptor.
8. GND: Grounding
9. ALARM IN: 16 alarm inputs, which may be set either as normally open (N.O.) or normally
closed (N.C.). In order to detect the alarm, signal should last for minimum
0.5sec .
10.AUDIO OUT: Audio out port for connecting local speaker with pre-amplifier.
11.SPOT OUT: SPOT monitor output, allowing to display any camera/sequence of cameras
full screen.
12.RS-485: RS-485 bus port for connecting external keyboard or PTZ cameras
(K/D: A+, B-)
13.HDMI MONITOR: Main monitor connectors, use the HDMI cable to connect to a 1080p 60Hz
(1920x1080) monitor.
14.USB: USB 2.0 port for external Flash memory and mouse connection.
15.LAN: RJ-45 connector port for connecting to the local network and internet.
16.FAN: Cooling fan, do not cover!
Note:
OSD menu will be displayed on the VGA monitor by default. To switch the OSD display from VGA to
HDMI or BNC, please press and hold the ESC button for 5sec.
1 2 3 4 5 6
7 8 9 10 11 12 13 15 16 14

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
10
2.4. HDD mounting
NDR-BA6104 support up to 1 internal SATA HDD. NDR-BA6416 DVR and NDR-BA6208 supports
up to 2 internal SATA HDDs.
WARNING!
In order to find information regarding the compatible models of HDDs and their maximum
capacities, please contact Novus distributor or check the information presented at
www.novuscctv.com. AAT HOLDING Company is not responsible for any problems resulting
from using not recommended hard drives.
The list of compatible HDDs contains all the HDDs that can be used with a given DVR including
HDDs designed for office use - so called desktop disks. However, due to the fact that reliability of
the recording process and data safety are paramount factors of any CCTV system, we strongly
advise to use HDDs designed for continuous (24/7) operation.
In order to mount HDD, please unscrew the screws as depicted below, then please remove the DVR's
cover first by sliding into the rear-end and then lifting it.
NDR-BA6104:
NDR-BA6416,NDR-BA6208:
WARNING!
Prior to removing cover of the DVR please unplug the power cord first! If the NVR is powered
up, please shutdown the DVR's system using LOGOUT & SHUTDOWN menu, prior to
unplugging the power.
STARTING THE DEVICE

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
11
After removing top cover of the DVR, please mount the HDD to the DVR bottom using included
screws (4 pieces for each HDD), and connect power and signal cables.
NDR-BA6104
NDR-BA6416 and NDR-BA6208 :
After connecting an HDD(s), please put the top cover onto the DVR and turn the device on in order to
check the operation of particular components and to format the HDDs.
WARNING!
You need to format disks if they were used in a different device. All data saved on HDD prior to
format will be lost. Mounted HDDs should be the same model.
STARTING THE DEVICE

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
12
Recording capacity calculate table:
“Total Recording capacity” = “Used space per hour (MB/h)” × “recording time” × “channel numbers”
For instance: computing space for 4 x cameras that are to record in WD1 with Lowest video quality, 25
fps framerate and 30-day recording capacity requires the calculation below:
Total Recoding capacity =338 (mb/h) X 24(hours/day) X30(days) X4(channels)=973440MB~ 970GB
2.5. Turning on the power
Connect power cord to the DVR to start the unit. Initialization lasts for approximately 60 seconds.
During this time executing any device functions and pressing any buttons is prohibited. To shut the
device down please use its menu.
Note:
OSD menu will be displayed on the VGA monitor default. To switch the OSD display from BNC to
VGA, please press and hold the ESC button.
STARTING THE DEVICE
DVR Resolution Frame Rate
Totally(FPS) Video Quality Bit Rate (Mbps)
Used
Space
(MB/h)
NDR-BA6104
NDR-BA6208
NDR-BA6416
WD1
(960x576) 30
Highest 2.5 1125
Higher 2 900
Medium 1.75 788
Low 1.5 675
Lower 1 450
Lowest 0.768 338
NDR-BA6104
NDR-BA6208
NDR-BA6416
D1
(720x576) 30
Highest 2 915
Higher 1.5 712
Medium 1 468
Low 0.768 297
Lower 0.512 241
Lowest 0.256 112

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
13
3. RECORDER’S OPERATION
3.1. Front panel description
NDR-BA6104 :
NDR-BA6416 and NDR-BA6208 :
1. LED: LEDs indicating DVR’s status:
- Power - power supply indicator - Net - network operation
- HDD - HDD operation indicator - Play - playback
- Backup - archiving data - REC - recording
2. NUMERICAL BUTTONS: channel selection buttons. Pressing them displays a picture from a
video channel currently associated with that button. In order to select channels
10 ~ 16 please press “10+” and 0~6 next.
3. MENU pressing the MENU button enters recorder’s settings menu (after correct login).
Menu functions are detailed in the following chapters of this manual.
In PTZ control mode button is used to increase value of a particular field.
4. BACKUP pressing the button allows you to enter the backup menu.
In PTZ control mode button is used to decrease value.
5. REC pressing the REC button starts recoding of all camera channels. Enabling panic
starts simultaneous recording on all camera channels.
In PTZ control mode button is used for FOCUS adjustment.
6. REW Consecutive presses in playback mode switch playback speed between RWx8,
RWx16, RWx32, FFx1.
7. SEARCH pressing this button allows you to enter the search playback menu.
RECORDER’S OPERATION
1
2
3
2 4
8
10 9 7
11
5 6 1 12
13
12
1
5 6 8 9 3 4 10
13 11

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
14
8. PLAY / PAUSE pressing the PLAY during “live” mode enters playback mode. Subsequent
pressing pauses the playback.
In PTZ control mode button is used for IRIS adjustment.
9. FF Consecutive presses in playback mode switch playback speed between FFx1,
FFx2, FFx4, FFx8, FFx16, FFx1/4, FFx1/2.
In PTZ control mode button is used for SPEED adjustment.
10. ESC / STOP Pressing the button either exits menu or moves to a higher-level menu. When
pressed during playback, leaves playback mode. Holding the ESC switches
OSD menu displaying between VGA and BNC outputs.
11. NAVIGATION BUTTONS: navigate through DVR menu and change values of particular
parameters
12. IR DETECTOR IR remote controller receiver. Do not cover.
13. USB USB 2.0 port for backing up the recordings either to external HDDs or Flash
drives. Length of connecting cable should not exceed 30 cm;
3.2. Controlling via USB mouse
DVR features the possibility of controlling the DVR using an USB mouse connected to the USB port.
Functions described below are available in „live” mode.
Double-clicking on any camera in 2x2, 3x3 and similar display modes switches the display to full-
screen mode. Subsequent double-click returns to previous display mode.
During configuration, selection of particular options is performed via the left mouse button.
Depending on DVR operating mode, pressing right mouse button hides current menu or returns to
previous menu.
3.3. Controlling via IR remote controller
An IR remote controller is shipped together with the NDR-BA6416 ,NDR-BA6208 and NDR-BA6104
DVRs. Range is dependent on the battery level and varies from a few to a few tens of meters.
If an ID number of the remote controller equals 0 any DVR can be controlled. If two or more DVRs
utilize same ID they will be controlled simultaneously.
To change ID of the DVR please enter the MAIN MENU / SETUP / BASIC / SYSTEM and enter Device
ID ranging from 0 to 65535. Current ID number may be checked under the MAIN MENU /
INFORMATION / SYSTEM.
To change current ID number of the remote (Note available for NDR-BA6104 remote, ID is fixed to 0):
 point the remote in general direction of the DVR,
 select and press the “8” channel selection button twice
 set the ID of DVR ranging from 0 (default) to 65535
 press ENTER on the remote to confirm changes.
RECORDER’S OPERATION

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
15
Note:
If remote controller is not used for a some time, its ID will be automatically changed to 0.
Description of IR remote controller function:
RECORDER’S OPERATION
Turns the DVR off
REC Enable manual records
0-9, -/-- Selects camera or enters numbers
MULTI Changes display mode.
NEXT Swith to next split screen mode
SEQ Starts sequence display
AUDIO Audio menu
SWITCH Swith Main Screen between BNC, VGA or
HDMI
◄►▲▼ Navigates around the DVR menu or con-
trols PTZ camera movements
ENTER Confirm the choise or setup
MENU DVR menu
EXIT Exit current interface
PTZ, FOCUS, IRIS,
ZOOM PTZ camera control
PRESET, CRUISE,
TRACK Run PTZ camera action
WIPER, LIGHT Enable PTZ camera equipment
CLEAR Back to previous interface
INFO Displays information menu
Playback navigation, changing direction
or playback speed
SNAP Snaphshoot
SEARCH Starts search
CUT Set up markers for Backup
BACKUP Starts Backup
ZOOM Digital zoom of image
PIP Starts picture in picture mode

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
16
NV-RCDVRB-II remote controller is shipped together with the NDR-BA6104 DVR
Remote controller ID is fixed to 0.
Description of IR remote controller function:
RECORDER’S OPERATION
REC Enable manual records
SEARCH Starts search
MENU DVR menu
EXIT Exit current interface
ENTER Confirm the choise or setup
◄►▲▼ Navigates around the DVR menu or con-
trols PTZ camera movements
ZOOM Digital zoom of image
PIP Starts picture in picture mode
Play/Pause/Stop/Previous
Section/Next Section/Rewind/Fast For-
ward
MULTI Changes display mode.
NEXT Swith to next split screen mode
SEQ Starts sequence display
INFO Displays information menu

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
17
4. RECORDER’S MENU
DVR features multi-layered, on-screen displayed menu used for setting the device up.
Multi-lingual OSD is displayed using one of the following languages: English, Polish, Spanish,
Slovak, Czech, Turkish, Dutch, Russian, Italian, French, Greek and other.
In order to access the DVR settings menu, please press the MENU button or select MENU from
additional menu called by pressing the right mouse button..
4.1. Startup wizard
Prior to using DVR for the first time, initial setup is strongly advised. That includes setting parameters
such as time and date, language version, camera, audio, remote control, record mode, network and
password.
A wizard is displayed after device start-up, in order to facilitate setup:
Navigate around the menu using arrow buttons or USB mouse.
To confirm your choice, to enter sub-menus and edit value fields use ENTER button or left mouse
click.
To leave setup mode or to leave sub-menus/value editing use the EXIT button or right mouse click.
Click the Exit button or press the ESC button on the front panel to escape from a start up menu
wizard. Go to MAIN MENU / SETUP / BASIC / SYSTEM menu and check off Startup Wizard if you
don't want to show the wizard menu next time system is loaded.
Setting Device, Language, Date time format, Time Zone and Date and Time other settings. Click Next
button to display the next setup window.
RECORDER’S MENU

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
18
This window allows user to configure network settings such as; HTTP Port, Server Port, IP Address,
Subnet Mask, Gateway, Preferred and Alternate DDNS Server. Alternatively, select the Obtain an IP
address automatically to get address from DHCP Server.
Click the Next button to display next setup window, depicted below:
In this window you can setup recording Resolution for all channels (WD1 / D1 / HD1(2 CIF) / CIF
resolutions available), recording speed (FPS) and Quality for each channel separately.
Remaining FPS displayed below informs about available framerate.
After setup, click the NEXT button to go to next setup window.
RECORDER’S MENU

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
19
For proper recorder operation, please format the installed HDD using this window.
Additional information like HDD Size, Free space etc. are also available here.
When HDD formatting is complete, click the Finish button to end setup wizard and open the LOGIN
window.
4.2. Menu operating
To navigate or access DVR menus, you should log in first. The Login screen, depicted below,
appears:
Type in the username and password by pressing the appropriate combination of channel number
buttons or using a mouse and the virtual keyboard, then confirm it with LOGIN button.
Default password of admin account is 123456. For safety reasons, it is recommended to change
default user name and password.
Press the Cancel button to exit the LOGIN window. Cameras are then displayed on the screen but no
access to the DVR setup menu is given.
RECORDER’S MENU

NDR-BA6104,NDR-BA6208,NDR-BA6416
User’s manual ver.1.0
All rights reserved © AAT Holding sp. z o.o.
20
To disable LOGIN window display during next start-up, please go to the MAIN MENU / BASIC /
SYSTEM and check off the Password Check.
To prevent unauthorized access, it is recommended to log out when you leave the screen. In the
monitoring screen, click MENU in the bottom left corner and select LOG OFF.
To shutdown NVR you should click MENU in the bottom left corner of the screen and press
SHUTDOWN, or press the POWER button on the remote control.
Detailed information about configuration of recorders available in full version of user's manual
located on the attached CD-ROM and at the www.novuscctv.com website
Note:
If you turn off the system in an abnormal manner such as removing the power cord while the system
is in operation, the disk may acquire or increase the numbers of bad sectors, causing data loss and
shortened life cycle of the disk.
4.7. Setting English language.
The procedure presented below shows how to go back to the English language in the NOVUS DVRs
menu in case of selecting any other language by mistake.
1. To open main menu press the MENU button on the DVR’s front panel, and select the first
position.
2. Next, select the first position.
RECORDER’S MENU
