NTC NT59 User manual

Руководство по эксплуатации
Вибротрамбовка NT
NTC STAVEBNÍ TECHNIKA spol. s r.o.
Jiřinková 120, 552 03 Česká Skalice
Czech Republic
NT59, NT65, NT68, NT-70H
Tel.: + 420 491 452 184 E-
mail: [e-mail] www.ntc-vibro.by
Представительство в РБ
Tel.: + 375 44 737 23 37
e-mail: [email protected]

Vibratory tampers Operation manual
page 2 issued 05/2014
ES/EU PROHLÁŠENÍ O SHODĚ (originál)
EC/EU Declaration of conformity (original)
Prohlašujeme, že zařízení definované níže uvedenými údaji je ve shodě s požadavky níže uvedených NV a směrnic
We declare that the trough below mentioned specifications defined equipment complies with requirements of below cited Directives
NTC STAVEBNÍ TECHNIKA spol. s r.o.
Jiřinková 120, Česká Skalice 552 03
Výrobce (manufacturer):
Sídlo firmy (legal address):
IČ (identification number):
63221152
Osoba pověřená sestavením a NTC STAVEBNÍ TECHNIKA spol. s r.o.
uchováváním technické dokumentace:
(person in charge of assembling
and storing technical documentation)
Název (model): VIBRAČNÍ PĚCH / VIBRATORY TAMPER
Typ (type):
NT 59, NT 65 N,NT68, NT 70H
Výrobní číslo (serial number)
Popis (description):
Vibrační pěch se používá pro hutnění ve výkopech. Díky rázovému účinku a vysoké úderové síle je vhodný i pro
hutnění obtížně zhutnitelných zemin, jako jsou jíly. Pohon vibračního pěchu je zajištěn čtyřdobým jednoválcovým
motorem HONDA (čistý výkon: 2,6 kW) nebo dieselovým motorem HATZ (výkon 3,4 kW).
Vibratory tamper is used mainly for compaction in trenches. Due to the high impal force, the tamper is suitable
even for compaction of heavy soils, such as Clar. The machine is driven with four-stroke single-cylinder engine
HONDA (net power 2,6 kW)or diesel engine HATZ (power 3,4 kW).
Všechna příslušná ustanovení,
která výrobek splňuje
(The product meets all relevent provisions)
Strojní zařízení – směrnice 2006/42/ES; NV 176/2008 Sb.
Machinery Directive 2006/42/EC
Emise hluku –směrnice 2000/14/ES; NV 9/2002 Sb.
Noise Emission 2000/14/EC
Elektromagnetická kompatibilita – směrnice 2014/30/EU; NV 117/2016 Sb.
Electromagnetic Compatibility Directive 2014/30/EU
Harmonizované technické normy a ISO 3744, ISO 11202, EN 292-1/2, EN 294
technické normy:
(The harmonized technical standards
and technical standards)
Použitý postup na posouzení shody: Na základě směrnice 2006/42/ES příloha VIII
(To theckonformity assessment Pursuant to the Machinery Directive 2006/42/EC Annex VIII
applied procedure)
Naměřená hladina akustického výkonu: LWA = 95 dB
(Measured sound power level)
Garantovaná hladina akustického výkonu: LWA = 105 dB
(Guaranteed sound power level)
Poznámka: Veškeré předpisy byly použity ve znění jejich změn a doplňků platných v době vydání tohoto prohlášení bez jejich citování.
Note: All regulations were applied in wording of later amendments and modifications valid at the time of this declaration issue without any citation of them.
Místo a datum vydání: Osoba zmocněná k podpisu za výrobce:
Place and date of issue: Signed by the person entitled do deal in the name of producer:
ČeskáSkalice, 01.01.2012
Jméno (Name): Funkce (Grade) Podpis (signature)
Ing. Petr Ratsam jednatel společnosti (Company Executive)

Vibratory tampers Operation manual
page 3 issued 05/2014
1. SAFETY INSTRUCTIONS
Vibratory tampers NT are powerful compaction
machines.
Read and understand the operation manual
before using starting the machines.
Pay special attention to the safety instructions.
These safety instructions must be maintained all
the time, otherwise these may arise a danger to
health of the operator or other people.
1.1. General Instruction
1. Requirements for qualification of the
operator:
The vibratory tampers must be operated
by trained, reliable operators, of age
above 18. The operator must read and
understand the safety instructions, the
regulations valid for the respective jobsite
and valid technological procedure. This
should be proved by getting operator’s
signature.
The operator is obliged to use suitable
working dress, safety gloves and firm
boots with hard tip. Do not wear loose or
torn clothes, chains or jewelry which
could be caught by moving parts of the
machine.
The operator is obliged to use safety
goggles and ear protection.
2. The vibratory tampers may be used only for
compaction jobs in accordance with this
operation manual.
1.2. Hygienical Data
Machine type
NT 59
NT 65 N
NT 68
NT 70H
Sound power level LWA [dB]
95
95
95
95
Guaranteed sound power level LWA [dB]
105
105
105
105
Accelaration transmitted to the hand [m/s2]
5,9
6,1
6,7
6,8
1. Because of the noise level, the operator is
obliged to use ear protection effective for
the noise level 90 dB.
2. Work with the machine must be interrupted
regularly, the breaks should last at least 10
min. Total time of work with the machine
should not exceed 10 minutes per working
shift. The technological procedures should
be arranged accordingly.
3. The operator should not be exposed to
excessive noise or vibrations during the
breaks.
4. Should the machine be used to longer time
than specified in point 2 above, the local
hygienical authority should be consulted.
5. Within residential areas, the machine can be
used only from 6 a.m. to 6 p.m.
1.3. Inspection
1. Do not remove any safety devices (covers
etc.) from the machine.
2. Check all controls and safety devices prior
to starting.
3. If any failures which affect operational
safety are found during the work, the
operator must stop the machine
immediately.
1.4. Operation
Before starting:

Vibratory tampers Operation manual
page 4 issued 05/2014
1. Check the machine thoroughly, repair all
failures before starting the engine. If the
failures cannot be repaired at the jobsite, do
not operate the machine.
2. Check the fuel system for leaking. Dripping
fuel poses fire hazard.
Starting and operation:
3. When starting the engine, take stable
position and held the grip firmly.
4. The controls must be in good order.
5. The operator must not leave from his
position when the engine is running.
6. Stop the engine before interrupting the
work. When parking the machine, secure it
from falling.
7. Stop the engine before refueling. Avoid
contact between fuel and hot parts of the
engine. Let the engine to cool down first.
8. Keep the fuel tank tightly closed. Close the
fuel tap when not in operation. Drain the
fuel before transporting the machine for
longer distances.
DANGER! Leaking fuel tank and distribution
may cause explosion. Replace these parts
immediately if damaged.
Jobsite:
9. No bystanders are allowed within the
operational range of the machine. Especially
children should be kept in safe distance.
10. No don operate the machine in areas with
explosion danger.
11. If operated in closed spaces (halls, tunnels,
deep digs), there should be ensured
sufficient ventilation.
12. High care should be paid at the edges of
digs, heaps or slopes in order to avoid
falling down.
13. Held and guide the machine with high care
in order to avoid hands injury caused with
contact with an obstacle.
14. Do not smoke, do not use naked flame. Do
not work close to flammables or in
explosion danger areas.
15. Avoid touching hot parts. The exhaust
silencer and other parts of the engine are
very hot during operation and touching them
can cause serious burns.
1.5. Maintenance and Service
1. Do not remove any covers or other safety
devices. In case this must be done because
of service, install all the parts back before
starting.
2. Use genuine spare parts only. Do not carry
out any modifications without prior written
approval of the manufacturer.
3. Stop the engine before servicing the
machine.
1.6. Transport and Storage
1. When loading and transporting the machine
fasten the machine properly on the carrier.
2. The vibratory tamper is to be transported in
upright position or laid on the face side
(with engine upwards). These positions are
also suitable for storing.
3. Prior to long-term storage: Conserve the
machine, cover it and store it at safe, dry and
ventilated place.
1.7.Testing
It is recommended to test the machine by
authorized service at least once a year or more
often if used under heavy conditions.
If necessary, carry out repairs of all possible
failures.
1.8. List of safety signs used in the machine

Vibratory tampers Operation manual
page 5 issued 05/2014
At the designated types of machinery, vibratory rammer, type NT 59, NT 65 N,NT 68 and NT 70H in
accordance with the Act No. 22/1997 Coll. as amended, on technical requirements for products placed
stickers symbols safety signs, symbols and informative descriptions of the design and
implementation determine the technical norm.
In the following different types of labels represented in the design, they are placed on the appropriate
machine. For each individual symbol, and the sticker is attached text explaining its significance.
1.
Hazard warning sign, a symbol No.
B.3.1 (exclamation mark) before
operating the machine warns of
danger.
Information for operators on how to
proceed with the repair, cleaning or
adjusting machines. Label, the
symbol No. B.2.5 commands guide
wear while working with the
machine muffs to protect hearing
2.
7.25 No sticker marks according to
ISO 6405-1
(the symbol indicates hinging point, ie
the place at which the machine can be
lifted)
3.
Sticker „LAY THE VIBRATORY
TAMPER DOWN ON THE RIGHT
SIDE ONLY“
4.
Sticker containing information about
the type of fuel intended for the
engine machine
5.
Sticker indicating the data value of
the noise emission, which was for
machinery vibration tamper detected
by examination carried out under the
terms of GO No. 9 / 2002.
6.
Sticker indicating the need to tighten
the screws on the heel luck.

Vibratory tampers Operation manual
page 6 issued 05/2014
2. DESCRIPTION
2.1. Definition of Vibratory Tamper
Vibratory tamper is a compaction machine,
which executes fast repeating blows to the soil
which is compacted.
During compaction, distances between soil
particles get shorter, specific weight of the soil
increases and water contained in the soil is
pushed out.
Vibratory tampers are suitable for compaction
of backfills at digs, compaction of foundations,
etc.
2.2. Working Principles
The vibratory tamper is driven by a gasoline or
diesel, air cooled engine.
Torque from the engine is transmitted through a
centrifugal clutch to the gear mechanism of the
tamper, which converts rotation of the engine to
rectilinear movement of piston.
A strong spring located in the lower part of the
tamper transfers the force from the piston onto
the tamper foot.
2.3. Prior to Starting
1. The gear mechanism of the tamper is
lubricated by oil bath.
2. Prior to starting, check oil level in the sight
glass at the rear side of the tamper. If there
is no visible oil level, add oil. Use engine
oil, class SAE 10W-30, 15W-40, SE, SF or
better.
3. Add gasoline (either lead or lead-free) into
the fuel tank. Do not use mixture with oil for
4-stroke engines!
Check oil level in the engine. If necessary,
add engine oil, class SAE 10W-30, 15W-40
or better. Oil shortage can cause serious
damage to the engine. See also the engine
manual.
4. Check all bolts and nuts. Connections which
get loose from the vibrations may cause
serious problems. Therefore, re-tighten the
bolts properly.
5. Regularly clean the machine, especially
around the starter and the foot.
2.4. Technical Data
Model
Dimensions l x
w x h (mm)
Weight (kg)
Dimensions
of the
tamping foot
(mm)
Amplitude
(mm)
Compacting
force (kN)
Blows per
minute
NT 59
620x360x1070
58
285x345
50-85
10-11
600-700
NT 65 N
750x370x1030
64
285x345
50-85
11-12
600-700
NT 68
750x410x1070
68
285x345
50-85
12-13
600-700
NT-70H
750x400x1200
70
285x345
50-85
16-18
600-700
2.5. Engines
The NT 59 and NT 65 N tampers is equipped with gasoline four-stroke engine HONDA GXR120,
power 2,6kW.
The NT 68 tamper is equipped with gasoline four-stroke engine HONDA GX 120 , power 2,6 kW.
The NT 70H tamper is equipped with diesel engine HATZ 1B20, power 3,4 kW.

Vibratory tampers Operation manual
page 7 issued 05/2014
3. OPERATION
3.1. Starting
1. Turn the fuel tap down. Turn the ignition
switch to position „ON“.
2. At cold engine:
Close the choke. Set up the throttle lever
into position „OFF“.
At warm engine or high ambient
temperature:
Turn the choke lever into the middle
position or leave it fully open. Adjust the
throttle lever slightly above zero.
3. Hold the starting grip and pull a little, until
slight resistance is felt. From this point pull
vehemently. Do not release the grip then, but
return it into the basic position.
4. After the engine gets started, move the
choke lever slowly into the basic position.
Let the engine to warm up at idle speed for
3-5 minutes.
Check, whether there is no gasoline leaks
and whether there is no unusual noise.
5. If the engine does not get started after
several attempts, remove the sparkling plug
and check, whether it emits proper
sparkling. In case the plug is wet from fuel
or dirty, clean or replace it. Rotate the
engine several times before mounting the
plug back, to flush out excessive fuel.
3.2. Operation
1. Set up full throttle quickly to increase the
engine speed. The centrifugal clutch gets
engaged and the temper starts working.
Do not mode the lever slowly - that would
cause irregular operation of the tamper,
which may cause damage to the clutch,
springs and the foot.
2. When the rammer begins to operate, set the
frequency of strikes fine throttle adjustment.
Pech works most effectively when the
engine speed, which are shown on luck.
Unnecessary increase in speed is no longer
any increase in compaction force.
Conversely, resulting resonance reduces
compaction force and causing damage
3. At cold weather, the oil in the tamper foot is
mode dense and causes higher resistance of
the moving parts. This may cause slightly
irregular operation. In such a case it is
recommended to warm up the machine
before working by repeated increasing and
decreasing the engine speed.
4. The tamper foot is a highly durable
structure. However in case that rockfill
should be compacted, it is highly
recommended to put a layer of soil on the
top, in order to ensure even distribution of
compaction effort.

Vibratory tampers Operation manual
page 8 issued 05/2014
5. The tamper is designed to move forward
during operation. The forward speed can be
increased by pushing the handle down.
6.Work with the rammer quick stop moving the
throttle to "OFF"
3.3. Turning Off The Engine
1. After operation, let the engine to idle for 3-5
minutes to cool down. Then turn off the
engine by switching off the ignition.
2. Always remember to close the fuel tap.
3.4. Maintenance And Storage
DANGER!
! Flammable liquid. When refueling stop
the engine, do not smoke and do not allow
any work with naked flame or sparkling
around the machine.
! Moving parts. Stop the engine before
commencing maintenance or repairs at
the machine. The moving parts may cause
serious injury.
! Hot parts. Let the engine to cool down
before commencing maintenance or
repairs.
Daily maintenance:
Clean the machine, especially the engine and the
points of inspection. If necessary, clean the air
filter. Check and re-tighten all bolted
connections. Check the machine for oil or fuel
leaks.
Every 50 hours of operation:
Clean the air filter. (In case of operation under
extremely dusty condition, clean it daily.)
Check the sparkling plug and adjust the gas
between the contacts to 0,6-0,7 mm.
The machine is equipped with electronic
ignition that requires no adjustments.
Every 300 hours of operation:
Remove and clean the fuel filter cap. Clean all
parts of the machine and tighten the bolts and
nuts as needed.
Drain oil from the tamper foot. Add new engine
oil SAE 10W-30, 15W-40 (roughly 0,6l –NT
59 or 0,8l –NT 65 N and NT 68) up to the
middle of the sight glass.
Oil should reach the mid-sight glass. The first
oil change should be made after the initial 50
hours of operation.
Cleaning of the air filter by NT 59 (daily):
Every 10 hours, clean air filter. If the rammer is
working in a dusty, clean the filter 2x a day.
Urethane foam is first cleaned in paraffin and
dried, then dipped in motor oil before
installation, and squeezes the excess oil. Details
are given in the instructions for operating the
engine.
Cleaning of the air filter by NT 65 Nand
NT 68 (daily):
Remove the cartridge from the cleaners to the
top of the engine. Foam of detergent in the

Vibratory tampers Operation manual
page 9 issued 05/2014
wash, let dry and lightly oil Fill. Before
installing squeeze out excess oil.
Paper filters blown clean with compressed air
from the inside liner.
If the cartridge is very dirty or damaged, replace
it.
Storage:
Store the machine in upright position, after the
engine gets cooled.
If the machine must be stored in horizontal
position, place it always on the front or right-
hand side. Tighten the fuel tank cap properly
and check, whether the fuel does not leak. Drain
the fuel tank if necessary.
NOTE!
Lower the tamper always on the front or
right-hand side (with the fuel tank cap up).
Long-term storage:
Drain the fuel tank and the carburetor. Remove
the sparkling plug and put several drop of
engine oil into the cylinder. Turn the engine
several times, so that oil covers evenly all parts.
Clean the tamper and wipe it with a cloth dipped
in clean oil.
Store the machine at a safe, dry and shaded
place and cover it for protection against dust.
4. TROUBLESHOOTING
4.1. Difficult To Start
Fuel is in the tank, the plug does not sparkle.
- spark plug gap is bridged
- carbon sediments on the spark plug
- loose plug connector
- short circuit due to water
- improper distance of the electrodes
- short-circuited starting
Fuel is in the tank, the plug sparkles.
- clogged exhaust silencer
- wrong fuel
- clogged air filter
- dirty carburetor
Insufficient compression
- faulty window seals
- piston ring broken
- piston / cylinder excessively worn out
- loose sparkling plug
No fuel in the carburetor
- no fuel in the tank
- fuel tap closed
- dirty fuel filter
- clogged ventilation of the fuel tank
- air bubble in the fuel hose
- seized needle in the carburetor
- faulty membrane
- wrong carburetor adjustment
- dirty carburetor
4.2. Insufficient Engine Power
Low engine power
- dirty air filter
- air bubble in the fuel hose
- dirty nozzles in the carburetor
- carbonized exhaust silencer
- low compression (see above)
- improperly adjusted distance between
electrodes of the sparkling plug
- faulty sparkling plug
- wrong fuel
Engine overheating
- carbonized combustion compartment
- carbonized exhaust silencer
- wrong sparkling plug (unsuitable temp.
value)
Unstable engine speed
- dirty speed governor
- faulty governor spring
- failure at the fuel supply
- engine is getting false air
Faulty recoil starter
- dirty starter mechanism
- return spring broken
- damaged ratchets
Tamper does not regularly - blows are too slow

Vibratory tampers Operation manual
page 10 issued 05/2014
- Engine speed too low
- damaged speed governor
- improper volume of oil in the foot
- worn out centrifugal clutch
- faulty main spring
4.3. Spare Parts
All spare parts are available from:
NTC STAVEBNÍ TECHNIKA spol. s r.o.
Jiřinková 120
552 03 Česká Skalice
When ordering the spare parts, please note the type and serial number of the machine, which is stamped
on the nameplate of the machine.
4.4. Maintenance Schedule
Before starting
- Check fuel level
- control of lubrication oil sight glass (if the machine is in a horizontal position, the sight glass is filled
with oil)
- Check the engine oil
regurarly
- tightenning the screws, nuts, etc.
- cleaning the engine from dust
every 5 hours
- check air filter
every 25 hours
- check spark plugs
- control of foot rammer
every 50 hours
- replacement air filter
- changing the oil in the leg rammers (after no more than 300 hours of work!)
every 100 hours
- replacing the spark plugs
- engine oil
every 300 hours
- full service at the manufacturer or authorized service

Vibratory tampers Operation manual
page 11 issued 05/2014
5. WARRANTY
5.1. Warranty Period
The warranty period is 12 months from commissioning of the goods, unless otherwise stated in the sales
contract.
5.2. Warranty Terms
The supplier warrants the goods as follows:
The supplier will repair or replace parts which prove to be defective due to faulty material,
manufacturing failure, improper assembly, etc.
Warranty limitation
This warranty does not cover failures caused by the user, namely by unsuitable or inadequate operation,
lack of maintenance, unauthorized modifications, improperly done repairs, use of non-genuine spare
parts, or use under extremely heavy conditions.
This warranty also does not cover failures caused by utilizing of other than recommended fuel or oil.
The warranty does not relate to wear parts, such as filters, sparkling plugs, tamper foot, etc. and does not
relate to wear adequate to the working hours the machine has passed.
