NTT docomo Card Keitai KY-01L User manual

Card Keitai
KY-01L
INSTRUCTION MANUAL
'18.11

About the KY-01L
INSTRUCTION MANUAL
Operations and settings of each
function are explained.
It can be downloaded from NTT
DOCOMO website.
( https://www.nttdocomo.co.jp/
english/support/trouble/manual/
download/ky01l/index.html )
* The latest information can be
downloaded. The URL and contents
are subject to change without prior
notice.
Note
⿟Reproduction or reprint of all or
part of this manual without prior
permission is prohibited.
Introduction
Thank you for your purchase of "KY-01L".
For proper use, read this manual carefully before and while you use the KY-01L.

Notations used in operation
steps
Button operation and selection of
icons and items displayed on the
screen are notated in the following
manner.
Notation Operation
Press the
power button
for 1 second
or more.
Press the power
button on the top of
the terminal for 1
second or more.
In the home
screen,
[Settings] ▶
[Display &
sound] ▶
[Wallpaper].
In the home screen, tap
[Settings], then in the
next screen displayed
tap [Display & sound],
and then again in the
next screen displayed
tap [Wall Paper].
Information
⿟Display examples and illustrations
used in this manual are just
images for explanations and may
be different from actual screens
or products.
⿟In this manual, the easier
procedure is described for the
functions and settings which
have multiple operating
procedures.
⿟Please note that "KY-01L" is
called "the terminal" in this
manual.
⿟This manual describes operation
for terminal settings at time of
purchase.
1
Contents/Precautions

Supplied Accessories
⿟KY-01L main unit
⿟取扱説明書(Instruction Manual)
(in Japanese only)
⿟SIM eject tool (sample)
You can also check and purchase
optional items (sold separately) for
the terminal at DOCOMO Online
Shop.
( https://www.mydocomo.com/
onlineshop/options/index.html )
（in Japanese only）
2Contents/Precautions

Contents
Supplied Accessories .......................... 2
Using the Terminal ................................ 5
Safety Precautions (Always follow
these directions) .................................... 8
Handling Precautions ........................ 33
Items to Check and
Settings Before Use
Part Names and Functions ............. 48
docomo nano UIM Card .................... 50
Charging ................................................. 55
Turning Power On/Off ....................... 59
Home Screen........................................ 62
Basic Operation ................................... 63
Notification LED .................................. 68
Status Bar ............................................. 69
Notification Panel ............................... 71
Text Entry .............................................. 72
Phone
Making/Answering Calls .................. 77
In-Call Operations ............................... 82
Received Calls History/
Dialed Calls History ........................... 83
Display for Missed Calls ................... 86
Call Settings ......................................... 86
About Network Services .................. 86
Phonebook ............................................ 86
SMS/Web
Messaging (SMS) ............................... 90
Emergency Alerts ............................... 94
Web .......................................................... 96
3
Contents/Precautions

Apps
Calendar .............................................. 101
Clock ..................................................... 103
Calculator ........................................... 106
Notepad............................................... 107
Terminal Settings
Displaying the Settings Menu .... 108
Network ............................................... 108
Display & Sound ............................... 124
Device .................................................. 127
Date & Time ...................................... 134
About Phone ...................................... 135
File Management
Internal Storage Structure ........... 136
File Display ......................................... 136
Connecting to a PC
Connecting to a PC ........................ 138
Appendix/Index
Troubleshooting (FAQ) ................... 139
Warranty & After-Sales Service.. 146
System Updates .............................. 152
Main Specifications ........................ 157
Certification & Conformance ....... 160
Specific Absorption Rate (SAR)
of Mobile Phones ............................. 160
Export Control Regulations .......... 163
Intellectual Property ....................... 163
SIM-Unlocking ................................... 169
Index ..................................................... 170
4Contents/Precautions

Using the Terminal
⿟The terminal supports LTE,
W-CDMA, and WLAN-based
systems.
⿟Because a terminal operates using
radio frequencies, it cannot be
used inside a tunnel, underground,
in a building or other locations
where radio waves do not reach, in
locations with weak radio wave
condition, or out of LTE/ FOMA
service area. The services may not
be available on the upper floors of
high-rise apartments or buildings,
even if there are no obstructions
around you. On occasion, your
calls may be disconnected even in
areas with strong radio wave
condition, even if you are not
moving, or even if there are
4-signal icon on the terminal's
display.
⿟Because the terminal uses radio
waves, interception by a third party
is always a possibility. However,
with LTE/W-CDMA methods, the
terminal automatically supports
privacy functionality for all calls, so
even if a third party intercepts a
call with a receiving unit, it is only
heard as noise.
⿟The terminal operates on radio
frequencies by converting voice
into digital signals. If a caller
moves into an area of poor radio
wave condition, the digital signal
may not be restored accurately,
5
Contents/Precautions

and the voice received in the call
may differ slightly from the actual
voice.
⿟You should periodically note down
data you have saved in the
terminal or store it to an external
recording medium such as a PC.
Please note that the we shall not
be liable for any loss of saved data
due to malfunction, repairs, model
changes, or other handling of the
terminal.
⿟Similar to a PC, depending on the
accessed site, the terminal may
become unstable in operation, or
personal information saved in the
terminal may be transmitted via
the Internet and used improperly.
For this reason, please thoroughly
check the source and operating
conditions of any site before using
it.
⿟The terminal is designed to
perform some communication
automatically, including
communication to check for the
latest software version and for
maintaining connection with the
server. In addition, the packet
communication large data volumes
can incur expensive fees, so it is
strongly recommended to
subscribe to Packet Pack/packet
flat-rate service.
⿟Depending on the applications or
service you use, packet
communication charge may be
applied even in Wi-Fi®
communication.
6Contents/Precautions

⿟If the terminal has only a small
amount of free space, running
applications may not operate
properly. If free space is low, delete
stored data.
⿟The terminal is designed to
perform some communication
automatically, including
communication to check for the
latest software version and for
maintaining connection with the
server. In addition, the packet
communication large data volumes
can incur expensive fees, so it is
strongly recommended to
subscribe to Packet Pack/packet
flat-rate service.
⿟When a license agreement screen
etc. appears, follow the onscreen
instructions.
⿟Applications and service contents
are subject to change without
prior notice.
⿟The terminal supports only
sp-mode, mopera U and Business
mopera Internet. Other providers
are not supported.
⿟For details on usage charge, refer
to NTT DOCOMO website.
⿟DOCOMO is not liable to any
failures or malfunctions for
commercially available optional
equipment.
■ Characteristics of electronic
paper
The terminal’s display uses
electronic paper using
electrophoretic ink technology.
7
Contents/Precautions

⿟Since the surface of the display
reflects light in the surrounding
environment, it is easy to read
even with only a small amount of
light, and the brighter the location,
the easier it is to read.
⿟The electronic paper does not use
a backlight, and so the display
may not be visible in a dark place.
⿟It takes a very small amount of
time for the screen to switch
displays. In a low-temperature
environment (0°C or lower), the
display switching may be slow or
may stop. This is the normal
operation of the electronic paper.
Safety Precautions
(Always follow these
directions)
■For safe and proper use of the
terminal, please read the "Safety
Precautions" prior to use. After
reading the precautions, keep this
manual in a safe place for later
reference.
■ALWAYS observe the safety
precautions since they intend to
prevent personal injury or
property damage.
■The following symbols indicate
the different levels of injury or
damage that may result if the
guidelines are not observed and
the terminal is used improperly.
8Contents/Precautions

DANGER
Failure to observe
these guidelines may
"immediately result in
death or serious
injury(*1)".
WARNING
Failure to observe
these guidelines may
"result in death or
serious injury(*1)".
CAUTION
Failure to observe
these guidelines may
result in minor injury(*2)
and property
damage(*3).
*1 Serious injury: This refers to loss
of sight, injury, burns (high- and
low temperature), electric shock,
broken bones, injuries with
residual aftereffects from
poisoning, etc., and injuries
requiring hospital admission for
treatment or long-term hospital
attendance as an outpatient.
*2 Minor injury: This refers to injuries,
burns (high- and low-temperature),
electric shock, etc. that do not
require hospital admission for
treatment or longterm hospital
attendance as an outpatient.
*3 Property damage: This refers to
extended damage to buildings,
furniture, livestock, pets, etc.
9
Contents/Precautions

■The following symbols indicate
specific directions.
Dont
Indicates prohibited actions.
Nodisassembly
Indicates not to disassemble.
Noliquids
Indicates not to use where
it could get wet.
Nowethands
Indicates not to handle with
wet hands.
Do
Indicates compulsory actions in
accordance with instructions.
Unplug
Indicates to remove the
power plug from the outlet.
1. Handling the Terminal,
Adapter, docomo nano
UIM Card (Common)
DANGER
Dont
Do not use, store or leave
the equipment in locations
subject to high temperature
or accumulation of heat (e.g.
by the fire, near a heater,
under a kotatsu or bedding,
in direct sunlight, in a car in
the hot sun).
Doing so may cause fire,
burns, injury, electric shock,
etc.
10 Contents/Precautions

Dont
Do not put the equipment in
or place near microwave
ovens, cooking appliances
such as IH cooking heaters,
or high pressure containers
such as pressure cookers.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Dont
Do not splash sand, soil or
mud, or do not directly place
the equipment on them.
Also, do not touch the
equipment with hands with
sand etc. adhered.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Dont
Do not charge the terminal
when it is wet with liquids
such as water (drinking
water, sweat, seawater, urine
of pet animals, etc.).
Do not charge in a bathroom
or other place exposed to
water.
Doing so may cause fire,
burns, injury, electric shock,
etc.
11
Contents/Precautions

Dont
Do not subject the terminal to strong
pressure or break the terminal.
Especially when bringing the terminal
putting in a pocket of clothes, do not let
the terminal hit against surroundings or
being put between the objects.
Doing so may cause fire, burns, injury,
etc. because of damage of the
internal battery.
* The following are examples that you
should be careful of:
• Sitting or squatting with the terminal
put in a pocket of trousers or skirt
• Catching an outer wear in the doors
or the door of car with the terminal
put in the pocket
• Stepping on the terminal on a soft
object such as a sofa, bed, or
bedding, or on a floor
Dont
Do not attempt to remove
the built-in battery in the
terminal.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Nodisassembly
Do not disassemble or modify
the equipment.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Noliquids
Do not let the equipment get
wet with liquids such as
water (drinking water, sweat,
seawater, urine of pet
animals, etc.).
Doing so may cause fire,
burns, injury, electric shock,
etc.
12 Contents/Precautions

Noliquids
Do not allow liquids such as
water (drinking water, sweat,
seawater, urine of pet
animals, etc.) to get inside of
the charging jack or the
external connection jack.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Do
Use optional devices
specified by NTT DOCOMO.
Using a device other than
specified may cause fire,
burns, injury, electric shock,
etc.
WARNING
Dont
Do not subject the equipment
to strong force, impacts, or
vibration such as letting it
fail, stomping or throwing it.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Dont
Do not allow conductive
materials (such as metal
objects and pencil lead) to
come into contact with the
charging jack or external
connection jack or dust to
get inside it.
Doing so may cause fire,
burns, injury, electric shock,
etc.
13
Contents/Precautions

Dont
Do not cover or wrap the
equipment with a cloth or
bedding in use or while
charging.
Doing so may cause fire,
burns, etc.
Do
If charging does not finish
after specified time has
elapsed, stop charging.
Failure to do so may cause
fire, burns, injury, etc. due to
overcharge etc.
Do
Power off the terminal before
you step into a place where
flammable gas generates
such as gas stations, or a
place where dusts are
generated. Stop charging if
you charge the battery.
Using the terminal in a place
where flammable gas
generates may cause
explosion, fire, etc.
14 Contents/Precautions

Do
If you notice anything
unusual about the equipment
such as an unusual odor,
abnormal noise, smoke
generation, overheating,
discoloration or deformation
while using or charging, or
during storage, perform the
following measures.
• Remove a power plug from a
power outlet or accessory
socket.
• Power off the terminal.
Failure to do so may cause
fire, burns, injury, electric
shock, etc. if you do not
follow the instructions above.
CAUTION
Dont
Do not use damaged
equipment.
Doing so may cause fire,
burns, injury, etc.
Dont
Do not place on an unstable
or inclined platform. Be
careful especially when
vibrator is set.
Doing so may cause the
device to fall etc. and cause
injury.
Dont
Do not use or keep in a place
that is very humid, dusty, or
subject to high temperature.
Doing so may cause fire,
burns, electric shock, etc.
15
Contents/Precautions

Dont
If children use the terminal,
parents or guardians should
give them the proper
instructions for use and do
not allow them to use the
terminal in the wrong way.
Failure to do so may cause
injury.
Dont
Keep the equipment out of
the reach of babies and
infants.
Doing so may cause
accidental ingestion, injury,
electric shock etc.
Do
Note that the temperature may
increase when the terminal is
used continuously or while
charging. Be careful not to
unintentionally have continued
contact, such as by placing the
equipment in a clothing pocket
or falling asleep.
The temperature of the terminal
or adapter may increase with
long-term use (apps, calling,
data communication, etc.) or
charging. If you are directly in
contact with warmed part for a
long time, it may cause a
redness of skin, itch, rash,
low-temperature burn etc.
depending on your physical
condition.
16 Contents/Precautions

2. Handling the Terminal
DANGER
Dont
Do not throw the terminal
into fire or apply heat.
Doing so may cause fire,
burns, injury, etc.
Dont
Do not subject to excessive
force, such as piercing with a
sharp object (such as a nail),
striking with a hard object
(such as a hammer), or
stepping on it.
Doing so may cause fire,
burns, injury, etc.
Do
If the internal substance
enters your eyes, mouth,
etc., quickly rinse with clean
water and consult a doctor
immediately.
Failure to do so may cause
blindness, medical problem,
etc. due to effects of the
internal substance of the
terminal etc.
WARNING
Dont
Do not watch a repeatedly-
blinking screen for a long
time.
Doing so may cause cramp,
loss of consciousness, etc.
17
Contents/Precautions

Dont
Do not let foreign matter
such as water or other liquid
(drinking water, sweat,
seawater, pet urine, etc.),
pieces of metal (cutter
blades, staples, etc.), or
flammable objects enter the
docomo nano UIM card tray
in the terminal.
Do not insert the docomo
nano UIM card in the wrong
position or direction.
Doing so may cause fire,
burns, injury, electric shock,
etc.
Do
Power off the terminal or put
it in Airplane mode before
boarding an airplane.
Use of mobile phones on
board is restricted.
Follow the instructions of
each airline.
The radio wave from the
terminal may adversely affect
on-board electronic
equipment.
Prohibited acts related to
mobile phone usage on an
airplane may be punished by
law.
18 Contents/Precautions
