INSTRUCTION MANUAL
INSTRUCTION MANUAL ’11.X
F-11C

F-11C_EN_ninshou
DOCOMO W-CDMA, GSM/GPRS, Wireless LAN System
Thank you for purchasing "docomo SMART series F-11C" mobile terminal.
Before using F-11C, read this manual to ensure safe use and handling.
About manuals for F-11C
The operations of F-11C are described in this manual, " 使いかたガイド (Guide)” (installed in FOMA
terminal) and "Instruction manual (detailed version)" (in pdf format).
･ In this "F-11C INSTRUCTION MANUAL", "F-11C" mobile terminal is usually referred to as "FOMA terminal".
･ The images or illustration used in this manual are examples. They may differ from the actual displays.
･ The images used in this manual assume that Kisekae Tool is set to "White" and Color theme setting is set to
"White".
･ In this manual, "authenticate" indicates the operating procedure for entering the terminal security code in 4-
8 digits (
⇒ P41) or performing fingerprint authentication.
Basic package
･ Unauthorized copying of parts of or this entire manual is prohibited.
･ The contents in this manual, URL and contents are subject to change without prior notice.
Instruction
manual (this
manual)
This manual provides information about screens and operations of basic
functions.
" 使いかたガイド
(Guide) "(installed
in FOMA terminal)
This guide provides overviews and operations of frequently-used functions. (In
Japanese only)
In F-11C Stand-by display,
mef Tool e# Guide e Select a search method
"Instruction
manual (detailed
version)" (in pdf
format)
This manual provides detailed information and operations of all the functions.
(In Japanese only)
<From a PC> This manual can be downloaded from NTT DOCOMO website.
http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html
* The URL and contents are subject to change without prior notice.
Desktop Holder F33
is made ofrecycled
ABS from used
products.
F-11C
(including Back
Cover F62 and
warranty)
Instruction manual
Battery Pack F19 DesktopHolder F33
Compatible options ⇒ PXX

F-11C_EN_ninshouF-11C_EN_ninshouF-11C_EN_ninshou
1
Connect
Basic
Operation
Introduction
Search
Enjoy
Others
More
Convenient
Contents
FOMA terminal ........................... 2
What you can do with F-11C..... 3
Part names and functions ......... 4
Usage styles ............................... 6
Precautions (Always follow these
directions)...............................
7
Handling precautions ................ 16
Waterproof/Dustproof function 21
Before Using ............................... 26
Screen Explanation .................... 29
Character Entry .......................... 33
Sound/Screen Setting .............. 36
Lock/Security............................. 41
Call Telephone............................ 47
Mail.............................................. 56
Phonebook .................................. 60
i-mode/Full Browser/Smart Browser........................................................ 62
i-Channel ..................................... 64
Camera ........................................ 67
1Seg............................................. 69
Music ........................................... 71
i-αppli.......................................... 73
i-motion/Movie.......................... 74
Osaifu-Keitai ............................... 75
i-concier....................................... 76
Convenient tools ........................ 77
Data Management..................... 81
Support ....................................... 87
Appendix ..................................... 94
Index............................................ 112

F-11C_EN_ninshou
2
Introduction
FOMA terminal
･ Because your FOMA terminal uses wireless transmission, it may not function in locations where it is
difficult for radio waves to penetrate, such as tunnels, underground passages and some buildings, in areas
where radio waves are weak, or out of service area. Even when you are high up in a tall building or
condominium and nothing blocks your view outside, your FOMA terminal may not be able to receive or
transmit signals. Also, communication may be interrupted even when the signal meter on your FOMA
terminal indicates there are strong radio waves and you are not moving (traveling).
･ Use your FOMA terminal in a way that does not disturb others in public spaces, crowded locations or quiet
places.
･ Because your FOMA terminal uses radio waves to communicate, it is possible that a third party may
attempt to tap your calls. However, the W-CDMA, GSM/GPRS, Wireless LAN system automatically applies
a confidential communication function to all calls, so even if a third party could somehow tap a call, they
only hear noise.
･ Your FOMA terminal encodes voice communication as digital data. When you are operating your FOMA
terminal while moving to a location subject to weaker radio wave conditions, the transmitted digital data
may not be correctly decoded and as a result the decoded voice may differ somewhat from the actual voice.
･ Maintain a separate record of the data (Phonebook, Schedule, Memo, Recorded messages, Voice memos,
Moving picture memos, etc.) you registered in your FOMA terminal. Note that DOCOMO assumes no
responsibility for any loss of saved contents of data resulting from malfunction, repair, changing of the
model or other handling of FOMA terminal.
･ You are recommended to save important data to microSD card. Using DOCOMO keitai datalink, you can
transfer and save phonebook, mail, schedule and other data to a PC.
･ The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS.
Neither DOCOMO nor the certifier as listed herein makes any representation and warranty as for the
security in the use of SSL/TLS. If the data should be erased, DOCOMO assumes no responsibility for the
loss of any data.
Certifier : VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd.,
SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc., Go Daddy, Inc.
･ This FOMA terminal supports FOMA Plus-Area and FOMA HIGH-SPEED Area.
･ FOMA terminal can be used only via the FOMA network provided by DOCOMO and DOCOMO's roaming
area.

F-11C_EN_ninshou
3
Introduction
What you can do with F-11C
Waterproofness/Dustproofness 21
Waterproofness of IPX5 and IPX8 and
dustproofness of IP5X are provided by firmly
closing the external connection jack cap and
installing the back cover in a locked state.
Quick voice activation 32
Just speaking a keyword of function you want to
use activates the function. It is useful when you do
not know where is a desired function in the menu
or when you want to activate the function
immediately.
使いかたガイド (Guide) 32
Without the instruction manual at your hand, you
can check readily the operations of function you
want to use. By searching from the function list or
entering a keyword, you can view the outline or
operation for the function and also activate the
function. (In Japanese only)
Smart Browser 62
WebKit, adopted by Smartphone etc., enables to
view contents on the Internet comfortably by
touch operation.
i-concier 76
It is a service that Machi-chara (a character on the
stand-by display) supports your life like a butler or
concierge. It stores your various information (area
of residence, memo, schedule, ToruCa,
phonebook, etc.) and offers you information that
matches contents of Memo or Schedule, your
living area or current location, or preferences and
interest at the right time. (In Japanese only)

F-11C_EN_ninshou
4
Introduction
Part names and functions
Part names of F-11C and major functions assigned to each part are as follows.
c
a
b
h
a
b
c
d
f
g
e
i
k
l
m
j
n
d
e
f
k
i
j
r
n
o
q
p
o
s
t
l
m
g
h

F-11C_EN_ninshou
5
Introduction
To use the function with *, press the key for 1
second or more.
a Earpiece
b Display
c Microphone for calling and recording
d Light sensor for sensing the ambient
lightness to adjust the brightness of the
display
e 1Seg antenna used for 1Seg watching
f Sub-display
g Charging light
h Light for opening/closing FOMA terminal,
using camera, etc.
i FOMA antenna is built-in
j Camera
k Fingerprint sensor for registering
fingerprint and authentication
l Infrared data port for infrared
communication or infrared remote control
function
m Speaker
n mark for placing over IC card reader for
Osaifu-Keitai and iC transmission
o Back cover
p Charging jack
q Back cover lever
r Open assist button
s Strap opening
t Jack for charger, earphone, etc.
am Display the menu
ba Display the mail menu, switch text input
modes or check new mail/message
*
cc Display i-Channel or return to the previous
screen
dn Start voice call, switch to hands-free call or
perform quick voice activation
*
e0 - 9 Enter phone number or characters,
or select menu item
f* Enter "*" or voiced/semi-voiced sound, or
start/cancel Public mode (Drive mode)
*
gT Start/Exit i-Widget, or watch 1Seg
*
hU (Search key) Activate Quick search/i-mode
voice search
*
ik Multi-cursor key for moving the cursor
g: Perform an operation
u: Display Schedule, or adjust sound volume
d: Display Phonebook, adjust sound volume
or add a phonebook entry
*
l: Display Received calls
r: Display Redial or start/cancel IC card lock
*
jC Start the still camera shooting
kI Display iMenu or i- α ppli folder
*
lf Exit a running function, or turn ON/OFF the
FOMA terminal by pressing for 2 seconds or
more
m# Enter "#" or punctuation, or start/cancel
Silent mode
*
ns Multitask key for starting another function
during a call or operation, or start/cancel Privacy
view
*
o Side keys
Z Record video, start the still camera shooting
and operate Music player
S Stop the ring alert, vibrator or adjust sound
volume
D Mail/message inquiry, adjust sound volume,
and activate High-pitched alarm

F-11C_EN_ninshou
6
Introduction
* AC adapter uses a common jack.
Connection of Stereo Earphone Set 01 (Optional)
for external connection jack
Stereo Earphone Set 01
AC adapter External
connection jack

F-11C_EN_ninshou
7
Introduction
Precautions (Always follow these directions)
・ Before using your FOMA terminal, or when
necessary, read the precautions below to
ensure safe use and handling. After reading this
manual, keep it carefully.
・ These precautions are intended to protect you
and others around you. Read and follow them
carefully to avoid injury, damage to the product
or damage to property.
・ The signs below differentiate between the
levels of danger that can occur if the product is
not used within the specified guidelines.
・ The symbols below show specific directions.
■ Precautions contain the description below.
Handling FOMA terminal, battery pack, adapter,
desktop holder and UIM (common) .........................8
Handling FOMA terminal ..............................................9
Handling battery pack .................................................11
Handling adapter and desktop holder .......................12
Handling UIM...............................................................13
Handling mobile phones near electronic medical
equipment.................................................................13
DANGER
This sign denotes that
death or serious injury
may directly result from
improper use.
WARNING
This sign denotes that
death or serious injury
may result from
improper use.
CAUTION
This sign denotes that
minor injury or damage
to property may result
from improper use.
This symbol denotes that the action
is prohibited.
This symbol denotes that
disassembling the phone or its
components is not allowed.
Don’t
No disassembly
This symbol denotes that using the
phone or its components with wet
hands is not allowed.
This symbol denotes that using the
phone or its components in a
bathroom or other highly humid
area is not allowed.
This symbol denotes that an
instruction must be obeyed at all
times.
This symbol denotes that the
equipment should be unplugged.
No wet hands
No liquids
Do
Unplug

F-11C_EN_ninshou
8
Introduction
DANGER
Do not use, store, or leave the
equipment in hot areas such as near
flames or in areas under strong direct
sunlight such as inside a vehicle.
May cause fire, burns or injuries.
Do not put the terminal into heating
cooking device such as microwave oven
or high-pressure container.
May cause fire, burns, injuries, electric shock.
Do not disassemble or remodel the
equipment.
May cause fire, burns, injuries, electric shock.
Do not let the terminal get wet with
water, drinking water, urine of pet
animals, etc.
May cause fire, burns, injuries, electric shock.
For waterproofness, refer to ⇒ P21
Use the battery pack and adapter
specified by NTT DOCOMO for your
FOMA terminal.
May cause fire, burns, injuries, electric shock.
WARNING
Do not throw the equipment or give
hard shock to it.
May cause fire, burns, injuries, electric shock.
Keep conductive materials (metal
pieces, pencil lead, etc.) from coming in
contact with the charging jack or
external connection jack. Do not put
those materials inside the terminal.
May cause fire, burns, injuries, electric shock.
Do not cover or wrap the terminal with
a blanket, etc while using or charging.
May cause fire or burns.
Turn FOMA terminal OFF and stop
charging before entering a place such as
a gas station where flammable gases
are generated.
The gas may catch fire.
When using Osaifu-Keitai in a place as a gas
station, turn OFF the terminal before using it.
(When IC card lock is activated, deactivate it
before turning OFF the terminal.)
If the equipment starts giving off a
strange smell, overheats, becomes
discolored or deformed during use,
charging or in storage, immediately
perform the following operations.
･ Remove the power plug from the wall
outlet or cigarette lighter socket.
･ Turn FOMA terminal OFF.
･ Remove the battery pack from FOMA
terminal.
Failure to do so may cause fire, burns, injuries,
electric shock.
CAUTION
Do not leave the equipment on unstable
or sloping surfaces.
May cause injuries.
Do not store the equipment in
extremely humid, dusty or hot areas.
May cause fire, burns, electric shock.
Handling FOMA terminal, battery
pack, adapter, desktop holder and
UIM (common)
Don’t
Don’t
No disassembly
No liquids
Do
Don’t
Don’t
Don’t
Do
Do
Don’t
Don’t

F-11C_EN_ninshou
9
Introduction
Children using the equipment should be
instructed in proper operation by an
adult. Do not allow them to use the
equipment without adult supervision.
May cause injuries.
Store the equipment out of reach of
small children.
May be accidentally swallowed or cause
injuries.
Be careful especially when using FOMA
terminal connected to the adapter
continuously for a long time.
If you use i- α ppli, a videophone call or 1Seg
watching while charging the battery for a long
time, FOMA terminal, battery pack and adapter
may be heated.
Directly touching a hot part for a long time, you
may have redness, itching or rash on your skin,
or it may result in low-temperature burns
depending on your constitution and/or health
condition.
WARNING
Do not direct the infrared data port
toward your eye and transmit signals.
May cause harmful effect on eyes.
Do not direct the infrared data port
toward home electric appliances etc.
equipped with infrared device when
using infrared communication.
May cause an accident because of malfunction
of infrared device.
Do not turn on the light by getting the
lighting part closer to other person's
eyes.
May impair eyesight. And may cause accidents
like injury etc., by dazzling or astounding other
people.
Do not put foreign objects such as liquid
like water, metal pieces or burnable
things into UIM or microSD card slot.
May cause fire, burns, injuries, electric shock.
Do not turn on the light aiming directly
at the driver of the car etc.
May disturb driving and cause an accident.
Turn FOMA terminal OFF in areas where
use is prohibited, such as in airplanes
and hospitals.
Failure to do so may cause electronic equipment
or electronic medical equipment to fail or
malfunction. If the function which automatically
turns the power ON is set, cancel the setting
before turning the power OFF.
When using the phone in a medical facility, be
sure to observe the regulations of the facility. If
you do prohibited act such as using the phone in
an airplane, you will be punished according to
law.
When you talk by setting handsfree or
ring alert is sounding, keep FOMA
terminal away from your ear.
And, when connecting the earphone/
microphone etc. to the FOMA terminal
and play a game or music, adjust the
volume moderately.
Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around you
clearly, it may cause an accident.
Handling FOMA terminal
Do
Do
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Do
Do

F-11C_EN_ninshou
10
Introduction
If you have weak heart, be careful when
setting the Vibrate alert (vibration) or
alert volume setting.
May cause harmful effect on heart.
When you use electronic medical
equipment, check with the equipment
manufacturer to determine how the
device is affected by radio waves before
using.
May cause harmful effect on electronic medical
equipment etc.
Turn FOMA terminal OFF near high-
precision electronic control equipment
or electronic equipment using low-
power signals.
Failure to do so may cause the equipment to fail
or malfunction.
* Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or defibrillators,
other electronic medical equipment, fire alarms,
automatic doors and other automatic control
equipment.
Users wearing implanted pacemakers or defibrillators
or other electronic medical equipment should check
with the manufacturer or sales outlet about the effect
of radio frequencies on the equipment.
When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.
Surfaces of display and camera lens are made of
plastic panels and they are structured for the
glass not to scatter, however, if you mistakenly
touch broken or exposed parts, you may be
injured.
To sound the high-pitched alarm,
always keep FOMA terminal away from
your ears.
Failure to do so may cause hearing defect.
CAUTION
Do not swing FOMA terminal by
antenna or its strap.
May cause accident such as injury to yourself or
others by hitting.
Do not use damaged FOMA terminal.
May cause fire, burns, injuries, electric shock.
When using the motion tracking or
motion sensor, check the safety around
you, hold FOMA terminal firmly, and do
not shake it unnecessarily.
May cause accident such as injuries.
If the display part is accidentally broken
and the liquid crystal leaks out, do not
make the substance contact with your
skin of face or hands.
May cause loss of sight or skin problems.
If the liquid crystal gets into your eyes or mouth,
rinse it with clean water and see a doctor
immediately.
And, if the liquid adheres to skin or clothing, use
alcohol etc. to wipe it off, then wash with soap.
To use the terminal in car, check with
automobile manufacturer or dealer to
determine how the device is affected by
radio waves before using.
In rare cases, using the phone in some vehicle
models can cause the vehicle's electronic
equipment to malfunction. In that case, stop
using the terminal immediately.
Mobile phones can give some users skin
problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.
⇒
"Material list (P14)"
Do
Do
Do
Do
Do
Don’t
Don’t
Don’t
Don’t
Do
Do

F-11C_EN_ninshou
11
Introduction
When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.
May cause accident such as injuries.
When watching the display, take a
certain distance from the display in a
fully bright place.
May reduce visual acuity.
■ Check that the battery type matches the type
displayed on the battery pack label.
DANGER
Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like a
metal necklace.
May cause the battery pack to ignite, burst, heat
or leak.
Check the orientation of battery pack to
install it to FOMA terminal, and do not
try to force the battery pack onto FOMA
terminal if you are having trouble
installing it.
May cause battery pack to ignite, burst, heat or
leak.
Do not throw the battery pack into the
fire.
May cause battery pack to ignite, burst, heat or
leak.
Do not nail the battery pack, hit with a
hammer or step on it.
May cause battery pack to ignite, burst, heat or
leak.
If the battery pack's fluid etc. contacts
eyes, immediately flush the eyes with
clean water and see a doctor right
away. Do not rub the eyes.
May cause loss of sight.
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to falling, never use it.
May cause battery pack to ignite, burst, heat or
leak.
If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.
The vapors from leaking battery pack fluid may
ignite or explode.
Be careful not to let your pet bite the
battery pack.
May cause battery pack to ignite, burst, heat or
leak.
CAUTION
Do not discard old battery packs
together with other garbage.
May cause igniting or environmental
destruction. Tape the terminals of old battery
packs to insulate them, and then bring them into
a sales outlet such as docomo Shop. If your local
municipality has a battery recycling program,
dispose of them as provided for.
Handling battery pack
Display Battery type
Li-ion 00 Li-ion battery
Do
Do
Don’t
Don’t
Don’t
Don’t
Do
Don’t
Do
Do
Don’t

F-11C_EN_ninshou
12
Introduction
Do not use or charge a wet battery pack.
May cause battery pack to ignite, burst, heat or
leak.
If fluid etc. leaks out from the battery
pack, do not make the fluid contact with
your skin of face or hands.
May cause loss of sight or skin problems.
If the fluid etc. put into your eyes or mouth, or
contacts skin or clothes, immediately flush the
contacted area with clean water.
If the fluid put into the eyes or mouth,
immediately see a doctor after flushing.
WARNING
Do not use the adapter cord if it gets
damaged.
May cause fire, burns, electric shock.
Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.
May cause fire, burns, electric shock.
Always use the DC adapter with a
negative-ground vehicle. Do not plug it
into a positive-ground vehicle.
May cause fire, burns, electric shock.
When it starts to thunder, do not touch
adapter.
May cause electric shock.
Do not short the charging jack while it is
connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.
May cause fire, burns, electric shock.
Do not place heavy objects on the
adapter cord.
May cause fire, burns, electric shock.
When you insert and remove AC
adapter from power outlet, do not
contact a metal strap or other metal
objects with the jack.
May cause fire, burns, electric shock.
Do not touch the adapter cord, desktop
holder or outlet with wet hands.
May cause fire, burns, electric shock.
Only use with the specified power
source and voltage.
When charging FOMA terminal
overseas, use AC Adapter for global use.
If incorrect voltage is used, this may cause fire,
burns or electric shock.
AC adapter : AC100V
DC adapter : 12 or 24V DC (specific for negative
ground vehicle)
AC adapter for global use : Between 100V and
240V AC (Connect to the AC outlet for internal
household use)
If the DC adapter's fuse blows, replace it
only with the specified fuse.
May cause fire, burns, electric shock. For the
specified fuse, see the instructions that come
with the DC adapter.
Wipe off any dust that accumulates on
the power plug.
Failure to do so may cause fire, burns, electric
shock.
Handling adapter and desktop
holder
Don’t
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
No wet hands
Do
Do
Do

F-11C_EN_ninshou
13
Introduction
When you connect the AC adapter to an
outlet, firmly connect to the outlet.
Failure to do so may cause fire, burns, electric
shock.
When you disconnect the adapter from
the outlet or cigarette lighter socket, do
not pull the adapter cord with excessive
force. Instead, hold the power plug to
disconnect.
May cause fire, burns, electric shock.
Always remove the power plug from
the outlet or cigarette lighter when not
using the adapter for an extended
period.
Failure to do so may cause fire, burns, electric
shock.
Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.
Failure to do so may cause fire, burns, electric
shock.
Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.
Failure to do so may cause fire, burns, electric
shock.
CAUTION
Be careful of the cut surface when
removing UIM.
May cause injuries.
■ These precautions are based on the guidelines
produced at the Electromagnetic Compatibility
Conference Japan, regarding the protection of
electronic medical equipment from radio
waves emitted by mobile phone units.
WARNING
Obey the following rules inside medical
facilities.
･ Do not bring FOMA terminal into operating
rooms (ORs), intensive care units (ICUs) or
coronary care units (CCUs).
･ Turn FOMA terminal OFF in hospital wards.
･ Turn FOMA terminal OFF in hospital lobbies
and corridors if electronic medical equipment
could be nearby.
･ If the medical facility has specified zones
where use or possession of mobile devices is
prohibited, obey those instructions.
･ If the function to automatically turn ON the
power is set, cancel the setting before turning
the power OFF.
Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
Wearers of implanted pacemakers or
defibrillators must carry and use FOMA
terminal at least 22 cm away from the
implanted device.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
Handling UIM
Do
Do
Unplug
Unplug
Unplug
Do
Handling mobile phones near
electronic medical equipment
Do
Do
Do

F-11C_EN_ninshou
14
Introduction
When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.
FOMA terminal's signals may affect the
performance of electronic medical equipment.
Material list
Part Material Surface
treatment
Exterior
case
Movable
part Display
PC resin UV hard
coating
Movable
part Rear
surface
PA-GF resin UV hard
coating
Fixed part
Keypad
PA-GF resin UV hard
coating
Fixed part
Battery
PC+ABS
resin
UV hard
coating
Back cover PC+ABS
resin
UV hard
coating
Back cover
lock lever
POM resin None
Back cover
lock plate
Stainless
steel
None
Back cover
(body)
Stainless
steel
None
Back cover
(gasket)
Silicon
rubber
None
Display panel Hardened
glass
Shatterproof
film
Do
Camera lens Camera
panel
High heat
resistance
transparent
material ( シ
ルプラス
®
)
UV hard
coating
Camera ring
(Color:
BLACK,
RED)
ABS resin Chrome-plating
Camera ring
(Color:
WHITE)
Acrylate
resin
None
Light lens PC resin None
Side keys PC resin UV hard
coating
Keypad PC resin UV hard
coating
External
connection
jack cap
Body PC resin UV hard
coating
Flexure Elastomer
resin (TPE)
None
Water stop PC resin None
Water stop
rubber
Silicon
rubber
None
Charging
jack
Contacts Stainless
steel
Gold plating
Attaching
holder
section
LCP resin None
External connection jack Stainless
steel
Tin plating
Facing sheet around
keypad
PET resin UV hard
coating
Part Material Surface
treatment

F-11C_EN_ninshou
15
Introduction
Movable
part/Rear
surface
Facing panel ABS resin UV hard
coating
Corner pad Elastomer
resin (TPEE)
None
Screw sheet Polyester
film
None
Screw (battery install
recess)
Stainless
steel
None
Battery install recess face PC board Gold plating
Battery
contacts
Battery
contacts
connector
PPS resin None
Battery
contacts
Beryllium
copper
Gold plating
(base : Ni-Pd
plating)
Battery pack Battery pack PC resin None
Contacts Beryllium
copper
Gold plating
Fingerprint sensor Flexible PC
board
None
UIM tray POM resin None
Part Material Surface
treatment

F-11C_EN_ninshou
16
Introduction
Handling precautions
・ F-11C is waterproof/dustproof, however, do not allow
water or dust to seep into FOMA terminal and do not
allow accessories or optional devices to get wet or let
dust attach.
- Battery pack, adapter, UIM are not waterproof/
dustproof. Do not use in a bathroom or other highly
humid area or do not let rain attached. Or putting the
terminal on your body, humidity of sweat may cause
internal corrosion and malfunction. Note that
malfunctions, which are determined to be caused by
water as result of inspections, are not covered by the
warranty. Since these conditions are outside the scope
of the warranty, a repair, if at all possible, is charged.
・ Clean FOMA terminal with a dry soft cloth (such as a
cloth for eyeglasses).
- Rubbing it roughly with a dry cloth may scratch the
display.
- Drops of water or dirt left on the display may cause
stains.
- If FOMA terminal is wiped with alcohol, paint thinner,
benzine or detergent, the printing may disappear or
color may fade.
・ Clean the jack occasionally with a dry cotton swab
etc.
- If the jack is soiled, connection gets worse and it may
cause power to be turned off or insufficient battery
charge, so clean the jack with a dry cotton swab etc.
Also, be careful never to damage the jack when
cleaning it.
・ Do not place FOMA terminal near an air-conditioner
outlet.
- The rapid change in temperature may cause
condensation, causing internal corrosion and
malfunction.
・ When using, be careful not to subject excessive force
to FOMA terminal or the battery.
- If FOMA terminal is crammed into a brimming bag or
placed in a pocket and sat on, display, internal PCBs or
battery pack may be damaged or malfunction. And, if
external devices are plugged into the external
connection jack (earphone/microphone jack), the
breakage of the connector or malfunction may result.
・ Do not rub or scrape the display with a metal piece
etc.
- It may scratch the display, causing malfunction or
damage.
・ Carefully read the separate instructions that come
with the battery pack and adapter.
・ Do not press the surface of the touch panel strongly or
operate it with sharp objects such as a nail, a ballpoint
pen and a pin.
- It may damage the touch panel.
・ Avoid extreme temperature.
- Use FOMA terminal where the temperature ranges
between 5 and 40 ℃ (limited to the temporary use in a
bathroom etc. when temperature is above 36 ℃ ) and
humidity ranges between 45 and 85%.
・ FOMA terminal may affect land-line phones, TVs or
radios in use nearby, so use it as far as possible from
these appliances.
・ Maintain a separate record of the data you saved in
your FOMA terminal.
- If the data is deleted, DOCOMO assumes no
responsibility for the loss of any data.
・ Do not drop FOMA terminal or subject it to shocks.
- May cause malfunction or damage.
・ Do not plug external devices into the external
connection jack (earphone/microphone jack) at a
slant, or do not pull it forcibly while it is plugged.
- May cause malfunction or damage.
General
FOMA terminal

F-11C_EN_ninshou
17
Introduction
・ Do not close FOMA terminal with the strap etc. held
inside.
- May cause malfunction or damage.
・ It is normal for FOMA terminal to become warm
during use or charging. Continue to use it.
・ Do not leave FOMA terminal with the camera in areas
under strong direct sunlight.
- May cause discoloring or burn-in of materials.
・ Use FOMA terminal with the external connection jack
cap closed.
- Dust and/or water brought into FOMA terminal cause
troubles.
・ Do not use FOMA terminal with the back cover
removed.
- May cause removal of battery pack, malfunction or
damage.
・ Do not put extreme thick sticker on the keypad face.
- May cause malfunction, damage or erroneous
operation.
・ Do not put label or sticker on the back side of display.
- Label or sticker may be hooked when opening/closing
FOMA terminal and may cause malfunction or
damage.
・ Do not rotate the display with FOMA terminal closed.
- It may scratch the part around the display and keypad,
and it may cause malfunction or damage.
・ Do not put strong impact on the fingerprint sensor or
scratch its surface.
- It may cause malfunction of fingerprint sensor and
disable authentication operation.
・ Clean the fingerprint sensor with a dry soft cloth (such
as a cloth for eyeglasses).
- If the fingerprint sensor is dirty or water is sit on its
surface, the sensor cannot read fingerprints, and it may
cause decrease authentication performance or
malfunction.
・ While microSD card is being used, do not take the
card out and do not turn off FOMA terminal.
- May cause data loss or malfunction.
・ Do not bring magnetic cards etc. close to FOMA
terminal nor clip it by FOMA terminal.
- Magnetic data in cash cards, credit cards, telephone
cards, floppy disks, etc. may be erased.
・ Do not bring magnetized objects close to FOMA
terminal.
- Bringing strong magnetism close may cause a
malfunction.
・ The battery pack is a consumable part.
- Replace the battery pack if FOMA terminal has
extremely short operation time on a full charge,
though it may vary by operating conditions. Purchase
a new battery pack of the specified type.
・ Charge the battery in an area within the proper
ambient temperature range (5-35
℃ ).
・ The operation time provided by the battery pack
varies by the operating environment and battery
pack's deterioration.
・ The battery pack may swell out as it comes to near the
end of its lifetime depending on the usage conditions,
but it is not a problem.
・ Be careful especially about the following points when
preserving the battery pack.
- Keeping under the state of the full charge (right after
charging ends)
- Keeping under the state of the empty charge (too
exhausted to turn on FOMA terminal)
They may cause the battery pack performance to be
degraded or its lifetime to be shortened.
A recommended battery level to keep the battery pack
is the battery icon in 2 cells or in 40 % of remaining
battery level as a guide.
Battery pack

F-11C_EN_ninshou
18
Introduction
・ Charge the battery in an area within the proper
ambient temperature range (5-35
℃ ).
・ Do not charge the battery in the areas below.
- In areas of excessive humidity, dust or vibrations
- Near land-line phones or TVs/radios
・ It is normal for the adapter to become hot while
charging. Continue to use it.
・ When using the DC adapter for charging, keep the
vehicle engine running.
- The vehicle's battery could become flat.
・ When using an outlet with a mechanism preventing
unplugging, follow the handling instructions for that
outlet.
・ Do not give strong shock. Do not deform the charging
jack.
- Doing so may cause malfunction.
・ Do not use excessive force to install/remove UIM.
・ Note that DOCOMO assumes no responsibility for
malfunctions occurring as the result of inserting and
using UIM with another IC card reader/writer.
・ Always keep UIM ICs clean.
・ Clean UIM with a soft, dry cloth (such as a cloth for
eyeglasses).
・ Maintain a separate record of the data you saved in
UIM.
- If the data is deleted, DOCOMO assumes no
responsibility for the loss of any data.
・ To preserve the environment, bring the old UIM to a
sales outlet such as docomo Shop.
・ Take care not to scratch, touch accidentally or short
IC.
- May cause data loss or malfunction.
・ Do not drop UIM or subject it to shocks.
- May cause malfunction.
・ Do not bend UIM or place heavy objects on it.
- May cause malfunction.
・ Do not install UIM into FOMA terminal with a label or
sticker put on.
- May cause malfunction.
・ This FOMA terminal is equipped with the security
features, that are compliant with Bluetooth standards
for communication via Bluetooth. However,
depending on the settings, there may not be enough
security. Be aware of security risks when using
Bluetooth.
・ DOCOMO assumes no responsibility for any
information which may be leaked during
communication via Bluetooth.
・ You can use headset, handsfree, audio, keyboard,
dial-up connection, data transfer, serial port, image
transfer or health devices with FOMA terminal. An
audio/video remote control may be available with an
audio device (only Bluetooth compatible devices).
・ Frequency bands
Frequency bands used by FOMA terminal Bluetooth
function are as below.
a 2.4 : Radio equipment that uses the 2400 MHz band.
b FH : The modulation is the FH-SS method.
c 1 : The expected interference distance is 10 m or
shorter.
d : All bandwidths between 2400 MHz
and 2483.5 MHz are used, and the bandwidth used by
mobile object identification devices cannot be
avoided.
Adapter
UIM
Bluetooth
®
devices
ab
d
c
2.4FH1
