SIDE LENSES ARE
NOT
REMOVABLE
L1D HOUSING
(SHOWN)
REMOVABLE 2-PART
BALLAST COVER
LAMPS
(ORDER SEPARATELY)
CENTER LENS
(SHIFT-N-REMOVE)
MOUNTING
BRACKET
MAINTAIN THE
BALLAST CAVITY
WITH TWO PHILLIPS
HEAD SCREWS
WIRE ACCESS
COVER
COVER TABS
HINGE ON
THIS FACE.
REMOVABLE 2-PART
BALLAST COVER.
MAINTAIN BALLAST CAVITY WITH
TWO PHILLIPS HEAD SCREWS
GENTLY GRASP CENTER LENS BY
SIDES AND SHIFT TO ONE END.
PULL THE EXPOSED END DOWN.
REMOVE THE LENS ONCE
LIP CLEARS HOUSING.
ONE K.O. ON THE
TOP OF LUMINAIRE
WIRE ACCESS COVER TYP. OF TWO K.O.'S
MAINTAIN WITH ONE PHILLIPS HEAD SCREW
WIRING INSTALLATION:
1. WARNING - ELECTRICAL SHOCK or FIRE - Disconnect power.
2. Wire per all National and Local electrical codes.
Accessible ceiling option
; remove wire access cover and
connect power feed conduit make proper electrical connection and re-install wire access cover.
Inaccessible ceiling option
; Remove 2-part ballast cover, remove top K.O. and connect power feed conduit
via top K.O. Make proper electrical connection and re-install ballast cover.
LAMP INSTALLATION, MAINTENANCE and CLEANING:
1. WARNING - ELECTRICAL SHOCK or FIRE - Disconnect power.
2. Gently grasp center lens by the sides and shift to one end. Pull the exposed end down and remove lens.
3. Install appropiate lamp and re-install the lens.
4. Clean - Wipe down luminaire with a clean damp rag.
5. Connect power and make sure luminaire works properly.
INSTALLATION and MAINTENANCE INSTRUCTIONS Series SOTTILE 1X1 (L1D)
10770 East 51st Ave, Denver, CO 80239 Phone (303)287-9646 Fax (303)287-0316
WARNINGS
RISK OF ELECTRICAL SHOCK OR FIRE - DISCONNECT POWER DURING INSTALLATION / SERVICING.
READ ALL INSTRUCTIONS COMPLETELY BEFORE STARTING INSTALLATION.
INSTALL & WIRE IN ACCORDANCE TO ALL NATIONAL & LOCAL CODES BY A CERTIFIED ELECTRICIAN.
FIXTURE MAY BE SHARP - HANDLE WITH CARE.
LET FIXTURE COOL BEFORE MAINTENANCE.
(PI-L1D-001-A)
PAGE 1 OF 2
EXPLODED VIEW
LUMINAIRE POWER DISCONNECT
CODE COMPLIANT, FACTORY
INSTALLED POWER DISCONNECT
Input Side Daisy Chain
Conductor Types:
Power Side - solid / stranded
19 strands (MIN.)
Ballast Side - 18 AWG solid
WIRING INSTALLATION - NON-INSULATED CEILING
LAMP INSTALLATION, MAINTENANCE and CLEANING
TWO CEILING GRID
SUPPORT BRACKETS
PRY GRID HOOK OUT
TIE BACK HOLE
TIE WIRE BY OTHERS
(TYP. 4X)
CEILING GRID
(BY OTHERS)
FOUR HOLES AND TWO BRACKETS ARE
PROVIDED FOR EXTRA SUPPORT FOR
MOUNTING LUMINAIRE
ADEQUATE BLOCKING / SUPPORT STRUCTURE
AND MOUNTING HARDWARE (PROVIDED BY OTHERS)
FOUR HOLES ARE PROVIDED FOR MOUNTING LUMINAIRE
MAINTAIN THE
BALLAST CAVITY
WITH TWO PHILLIPS
HEAD SCREWS
LAMP
(ORDER SEPARATELY)
CENTER LENS
(SHIFT-N-REMOVE)
DETAIL VIEW SEE
7 FOR EXPLANATION
1/4" (MIN)
FROM LUMINIRE
TO OPENING
1 9/16"
FROM CEILING TO
MOUNTING HOLES
REFER TO THE OPENING
DIMENSIONS FOR INSIDE TO
INSIDE OF BLOCK DIM.
BLOCKING
BY OTHERS
SIDE VIEW
CEILING
1. WARNING - ELECTRICAL SHOCK or FIRE - Disconnect power.
2. Cut ceiling tile to rough opening dimensions.
3. Clean hands before handling the luminaire or use clean gloves.
4. Careful not to damage lenses gently grasp center lens by the sides and shift to one end.
Pull the exposed end down and remove the lens.
5. Remove lamp if applicable to expose ballast cover. Access ballast cavity by removing two
phillips head screws. Remove cover assembly out of the center of luminaire.
6. Lift luminaire into ceiling location. Using (4) holes provided, mount luminaire in desired location
to adequate blocking or support structure. Hardware and blocking by others.
7. Reinstall ballast cover with provided phillips head screws. Make sure cover tabs hinge into holes
on the non angled side of housing. Install appropiate lamp and re-install the lens.
8. Clean - Wipe down luminaire with a clean damp rag.
9. Connect power and make sure luminaire works properly.
1. WARNING - ELECTRICAL SHOCK or FIRE - Disconnect power.
2. Cut ceiling tile to rough opening dimensions.
3. Clean hands before handling the luminaire or use clean gloves. Careful not to damage lenses. Lift luminaire into grid tile location.
4. Provided pry out grid hooks to center and secure luminaire over ceiling grid support bracket.
5. Secure luminaire per all codes. Holes are provided for tie back to structure (tie wire by others).
6. Provided mounting brackets for added mounting support on grid tile.
7. Clean - Wipe down luminaire with a clean damp rag.
8. Connect power and make sure luminaire works properly.
INSTALLATION and MAINTENANCE INSTRUCTIONS Series SOTTILE 1X1 (L1D)
10770 East 51st Ave, Denver, CO 80239 Phone (303)287-9646 Fax (303)287-0316
GRID CEILING INSTALLATION - NON-INSULATED CEILING
INACCESSIBLE CEILING INSTALLATION - NON-INSULATED CEILING
(PI-L1D-001-A)
PAGE 2 OF 2
ROUGH OPENING DIMENSIONS:
1X1
= 12-1/2" X 12-1/2"
ROUGH OPENING DIMENSIONS:
1X1
= 12-1/2" X 12-1/2"
