Numatic HT 1840 User manual

Warning! Read instructions before using the machine
Original Instructions
TT 1840G
HT 1840
SCRUBBER DRYER
www.numatic.co.uk

2
20
21
19
Machine Overview
1
3
4
56
7
810
12
13
14
15
16
17
112
9
2
22
18
1 Operator control panel 12 Vacuum hose
2On / O󰀨 Lever 13 Separator
3 Waste water tank 14 Clean-water ller cap
4 Clean water tank 15 Clean-water level indicator
5Brush deck 16 Clean-water tank ll point
6Squeegee blades 17 Top tank (waste water) drainage hose
7 Floor-tool retaining knobs 18 On / O󰀨 Switch
8Clean-water on / o󰀨 tap 19 Vacuum Switch
9 Clean-water emptying cap 20 Pump Switch
10 Rear moving wheels 21 Power Light
11 Floor-tool vacuum hose 22 Handle Position lever

3
Fill using a hose, bucket or a suitable container. (Fig 5).
Please read before commencing any operation.
After the removal of all the packaging, carefully open and check the contents. !
Using the handle position lever, move the handle into the
upright position. (Fig 1).
Fit the Brush / Pad (Fig 2).
Swing the oor tool carrier from
behind the brush. (Fig 3).
Use the two locking knobs tted to the oor tool, secure to the
oor tool to the oor tool carrier. (Fig 4).
Fill the clean-water tank to a Max of 18 litres
(see page 5)
For operation and cleaning controls
(see page 9)
Quick Set-Up Guide
!
0L
Tip the machine.
(see Page 4)
1
2
3
4
5

4
Machine Set-Up
5L
0L
0L
Fitting the brushes
Slide the brush / pad under the brush deck (Fig 6).
Featuring the Nulock brush system.
The brush is tted simply by pushing and twisting to lock in place, making tting and removal a simple process.
Fit the brush / pad onto the Nulock drive chuck, twist to lock
the brush / pad in place (Fig 7).
Only use manufacturer supplied brushes.
This machine requires a 400mm brush or a 360mm pad.
Safety gloves are recommended for the changing of used brushes.
Tipping the Machine
6
7

5
Note: Great care must be taken to ensure that contaminants (leaves,hair, dirt, etc)
are not allowed to enter the clean-water tank during the lling process.
If using a bucket or similar, ensure it is always clean and free from debris.
Machine Set-Up
Fitting the Floor Tool
The oor tool has been designed for quick tting, allowing easy squeegee blade replacement and a safety knock-o󰀨
feature if the oor tool gets snagged, whilst in transit.
Note: It is easier to t the oor-tool if the weight of the machine is resting on the brush.
Ensure the brush is tted rst.
Note: The lever moves upward and backward motion to lock the oortool in the raised position.
The oor tool carrier can be
raised and locked from moving
by operating the locking lever,
upwards and backwards.
This lever can be found next to
the lower section of the handle.
Unlock and swing the oor tool
carrier to the side of the machine
(Fig 8).
8
Filling the clean-water tank
The HT1840 & TT1840 are
equipped with a large 18 litre
clean water tank allowing large
areas to be cleaning in a single
ll.
To ll the clean water tank,
remove the ller cap (Fig 10).
Fill using a hose, bucket or a
suitable container. (Fig 11).
10
11
Secure to the carrier using the
two knobs tted to the oor tool
carrier (Fig 9) - (Fig 9a).
Do not over tighten the retaining
knobs.
9
9a

6
Control of Substances Hazardous to Health (COSHH)
For best results use a non-foaming type of chemical, dilute to the manufacturer’s specication.
For further guidance on hazardous substances refer to health and safety instructions online.
Visit http://www.hse.gov.uk/ for UK information.
Water Flow Adjustment
Located on the left of the machine is the On / O󰀨 water tap
(Fig 14 / 15).
Pre-cleaning advice.
Important
Do not operate machine unless the Operator Manual has been read and fully understood.
!!
Before performing the cleaning operation, place out
appropriate warning signs and sweep or dust-mop the oor (Fig 16).
WHEN HANDLING AND MIXING CHEMICALS
Always ensure that chemical manufacturer’s safety guidelines are followed.
Only use chemicals recommended for use in auto scrubber-dryers.
!
Numatic part (629044) Wet Floor sign
(available if required)
Machine Set-Up
Fill Level Indicator
Fill the clean water tank to a maximum of 18 litres, including cleaning chemicals if required.
Follow chemical manufacturing guide lines.
Use the ll indicator
(Fig 12). Showing the clean water tank full (Fig 13a).
Showing the clean water tank empty
(Fig 13).
12
13
13a
14
15
16

7
Moving the machine
CAUTION
When moving or lifting the HT 1840 / TT 1840, follow the national safety guidelines on lifting.
! !
When the bottom tank (clean water) is full the machine can be
tilted to a maximum of 450(Fig 19).
When the top tank (waste water) is full the machine can be
tilted to a maximum of 100 for transporting to dumping area
(Fig 18).
CAUTION
Ensure both tanks are empty before attempting to lift the machine.
! !
Transport the machine by tilting back on to the main transit
wheels (Fig 17).
Weight of empty machine 38.5Kg (85 lbs) (Fig 20).
Machine Set-Up
17
18
19
20

8
Note: Care must be taken to reduce speed when cornering or when manoeuvring around obstacles.
Note: The lever moves upward and backward motion to lock the oor tool in the raised position.
Machine Operation
Pre-scrub mode
The HT1840 & TT1840 have been designed to cope with a variety of oor types and di󰀨erent levels of soiling.
On heavily soiled oors use a ‘double scrub’ technique.
First pre-scrub the oor with the oor tool in the raised position (Fig 21), allow the chemical time to work, then scrub
the area a second time with the oor tool lowered.
To raise the oor-tool, ensure the oor tool carrier is central to the machine (Fig 22).
Lift the lever near the base of the handle and lock into position (Fig 23).
21
22
23
The clean-water / chemical mix
is dispersed via ‘THRU-FEED’
system. The waste water is then
retrieved by the oor tool
Overlap the scrubbing path by
10cm to ensure an even clean
(Fig 24).
If streaking occurs, wipe the oor
tool blades clean (Fig 25).
Floor tool in use
24
25

9
Setting the cleaning controls
Note: The Pump Switch will only function when the Brush is in operation.
Ensure your HT1840 / TT1840 machine has been plugged into a suitable power supply.
Select the desired function using the ON / OFF switches tted to the handle.
Vac Switch Pump Switch
1 1
To start: hold down either trigger and press the yellow start button once
2
20.020.0
B
C
D
1
ST_Numatic_A4.slddrt 20030224
A
2 1
4
B
A
5
6
3
3
4 5
6
C
D
THIS DRAWING IS COPYRIGHT AND IS THE PROPERTY OF NUMATIC INTERNATIONAL LTD. AND MUST
NOT BE USED WITHOUT THEIR KNOWLEDGE NOR COMMUNICATED TO ANY PERSON OR COMPANY.
TITLE:-
DIMNs IN
MILLIMETERS
NOT
TO
SCALE
FINISH:-
ITEM No(s):-
DRG No:-
TOLERANCES:-
(UNLESS OTHERWISE STATED)
DRAWN:
DATE:
APPD:
REVISION:
CHANGE DETAIL:
Numatic
INTERNATIONAL LTD
THIRD ANGLE PROJECTION
STRESS RELEIF ARTWORK ASM
-
RVT
-
-
-
MATERIAL:-
27/05/2009
DRW-21826
PRINT
SIZE
A4
LINEAR: 0 DECIMAL PLACE = +/- 1.0mm
1 DECIMAL PLACE = +/- 0.25mm
2 DECIMAL PLACES = +/- 0.05mm
ANGULAR:-
+/- 0.5 DEGREE
THE EXAMPLE SHOWN DETAILS THE METHOD USED FOR
IDENTIFYING CRITICAL (INSPECTION) DIMENSIONS WHERE APPLICABLE
MILLFIELD ROAD, CHARD, SOMERSET
TA20 2GB ENGLAND
A01
-
TOOL NUMBER:
WEIGHT:
All components must be ROHS compliant.
Internal Code:
DEV
Provisional
20.020.0
B
C
D
1
ST_Numatic_A4.slddrt 20030224
A
2 1
4
B
A
5
6
3
3
4 5
6
C
D
THIS DRAWING IS COPYRIGHT AND IS THE PROPERTY OF NUMATIC INTERNATIONAL LTD. AND MUST
NOT BE USED WITHOUT THEIR KNOWLEDGE NOR COMMUNICATED TO ANY PERSON OR COMPANY.
TITLE:-
DIMNs IN
MILLIMETERS
NOT
TO
SCALE
FINISH:-
ITEM No(s):-
DRG No:-
TOLERANCES:-
(UNLESS OTHERWISE STATED)
DRAWN:
DATE:
APPD:
REVISION:
CHANGE DETAIL:
Numatic
INTERNATIONAL LTD
THIRD ANGLE PROJECTION
STRESS RELEIF ARTWORK ASM
-
RVT
-
-
-
MATERIAL:-
27/05/2009
DRW-21826
PRINT
SIZE
A4
LINEAR: 0 DECIMAL PLACE = +/- 1.0mm
1 DECIMAL PLACE = +/- 0.25mm
2 DECIMAL PLACES = +/- 0.05mm
ANGULAR:-
+/- 0.5 DEGREE
THE EXAMPLE SHOWN DETAILS THE METHOD USED FOR
IDENTIFYING CRITICAL (INSPECTION) DIMENSIONS WHERE APPLICABLE
MILLFIELD ROAD, CHARD, SOMERSET
TA20 2GB ENGLAND
A01
-
TOOL NUMBER:
WEIGHT:
All components must be ROHS compliant.
Internal Code:
DEV
Provisional

10
ALWAYS ENSURE THAT THE POWER SUPPLY IS DISCONNECTED,
PRIOR TO ANY MAINTENANCE OPERATION.
! !
After use, empty waste water tank using
emptying hose and ush out with clean
water. A
Remove the two hoses and disconnect the
separator from the machine (Fig 26). Undo
the separator restraining strap (Fig 26a) and
lift o󰀨 the separator. The separator has a
sealing rubber which should be examined at
every clean down (Fig 27).
Rinse using clean water.
Note:
Avoid over tightening the clean water draining cap.
The HT1840 & TT1840 have been designed with ease of use in mind, this included easy stripping down and cleaning.
Remove the two lters clipped into the separator and ush with clean water (Fig 28)(Fig 29).
Replace by tting the rear of the lter rst then clipping the front to lock in place (Fig 30) (Fig 31).
Once emptied the top waste water tank can simply be lifted o󰀨. (Fig 32).
The clean water tank can be drained via the yellow cap tted to the left
hand side of the machine. The cap has a rubber seal and might require a
spanner to remove. (Fig 33).
A
Regular Maintenance
26
26a
27
28
29
30
31
32
33
