NuTone HE Series Instruction Manual

INSTALLATION AND OWNER GUIDE FOR 40355, 40455 AND VT9W WALL CONTROLS
WARNING
ITIS RECOMMENDED TO WEAR SAFETY GLASSES AND GLOVES WHILE PERFORMING
THESE INSTRUCTIONS. ALWAYS DISCONNECT THE UNIT BEFORE MAKING ANY
CONNECTIONS. FAILURE TO DISCONNECT POWER COULD RESULT IN ELECTRIC
SHOCK OR DAMAGE TO THE WALL CONTROL OR ELECTRONIC MODULE INSIDE
THE UNIT.
!
CAUTION
FAILURE TO COMPLY WITH THE FOLLOWING CAN CAUSE ERRATIC OPERATION OF
THE UNIT AND/OR THE WALL CONTROL:
NEVER INSTALL MORE THAN ONE X-TOUCH MAIN WALL CONTROL PER UNIT.
MAKE SURE THAT THE WIRES DO NOT SHORT-CIRCUIT BETWEEN THEMSELVES
OR BY TOUCHING ANY OTHER COMPONENTS ON THE WALL CONTROL. AVOID
POOR WIRING CONNECTIONS. TOREDUCE ELECTRICAL INTERFERENCE (NOISE)
POTENTIAL, DO NOT RUN WALL CONTROL WIRING NEXT TO CONTROL CONTACTORS
OR NEAR LIGHT DIMMING CIRCUITS, ELECTRICAL MOTORS, DWELLING/BUILDING
POWER OR LIGHTING WIRING, OR POWER DISTRIBUTION PANEL.
WALL CONTROL INSTALLATION
WALL CONTROL COMPATIBILITY
REFER TO THE WALL CONTROL COMPATIBILITY CHART INCLUDED WITH THIS WALL CONTROL.
UNPLUG THE VENTILATION UNIT FROM POWER SOURCE.
CUT A2 7/8” X1 3/8” HOLE IN AWALL, AT ACONVENIENT
LOCATION FOR THE WALL CONTROL. ROUTE THE CABLE FROM
THE UNIT TO THIS HOLE.
NOTE: DIMENSIONS SHOWN ARE FOR AN INSTALLATION
WITHOUT WALL BOX.
TEMPORARILY PLACE THE SWITCH OVER THE HOLE AND MARK
BOTH MOUNTING SCREW HOLE POSITIONS.
REMOVE THE SWITCH, DRILL BOTH SCREW HOLES (3/16” Ø)
IN WALL AND INSERT WALL ANCHORS (INCLUDED).
STRIP THE END OF THE CABLE TO ACCESS THE 4 WIRES.
STRIP THE END OF EACH WIRE. USING ASMALL BLADE
SCREWDRIVER, CONNECT EACH WIRE TO ITS CORRESPONDING
TERMINAL, ON THE BACK OF THE WALL CONTROL: YELLOW
WIRE TO “Y”, BLACK WIRE TO “B”, RED WIRE TO “R”,
AND GREEN WIRE TO “G”.
MOUNT THE WALL CONTROL TO THE WALL.
P
LUG THE VENTILATION UNIT AND TEST THE WALL CONTROL
OPERATION.
VC0167A
Ø 3/16”, typ.
Y
B
G
R
VE0347
VC0168
WALL CONTROL USE
IFTHE BACKLIGHT IS NOT ILLUMINATED, PRESSING ON MODE,
% HUM OR TURBO KEY WILL ACTIVATE IT. THE BACKLIGHT
REMAINS ILLUMINATED FOR 10 SECONDS AFTER THE LAST KEY IS
PRESSED (NO MATTER THE KEY).
BACKLIGHT
OR
% HUM
MODE
TURBO



OR
WALL CONTROL USE (CONT’D)
MODE

PRESS THE MODE KEY TO CHOOSE THE OPERATION MODE OF THE
VENTILATION UNIT (EXCEPT TURBO MODE).
OPERATING MODE WILL THEN APPEAR ON LCD SCREEN
(STANDBY, RECIRC, 20 min/h, CONT, SMART).
OPERATING MODES
STANDBY
PUT THE UNIT ON STAND-BY MODE, SO IT WILL ONLY RESPOND TO
OVERRIDE WALL CONTROLS (IF PRESENT). ONLCD SCREEN, ONLY
THE HOUSE IS VISIBLE SHOWING THE CONTROL IS POWERED ON.
THIS IS THE FACTORY SET DEFAULT MODE.
RECIRC
AIR IS RECIRCULATED INSIDE THE HOUSE ON HIGH SPEED.
20 MIN/H
THE VENTILATION UNIT EXCHANGES AIR INTERMITTENTLY ON AONE
HOUR CYCLE AS FOLLOWS: OFF FOR 40 MIN. (OR RECIRCULATION
FOR 40 MIN. ON LOW OR HIGH SPEED, SEE BACK PA G E ) AND THEN
EXCHANGE AIR DURING 20 MIN. ON LOW SPEED. REPEAT CYCLE
AFTER THE 20 MIN. OF AIR EXCHANGE.
CONT
AIR IS EXCHANGED WITH THE OUTDOORS AT THE MINIMUM BLOWER
SPEED.
CONT
SMART
AIR EXCHANGE IS MANAGED ACCORDING TO INDOOR HUMIDITY MEASURED BY THE WALL
CONTROL AND OUTDOOR TEMPERATURE. INSMART MODE, THE SMART ICON APPEARS
AS WELL AS THE CURRENT OPERATING MODE CALLED BY SMART (SEE BELOW).
CONT
TURBO
TURBO MODE
CALLED BY
SMART MODE
CONT MODE
CALLED BY
SMART MODE
20 MIN/HMODE
CALLED BY
SMART MODE
ECO MODE
CALLED BY
SMART MODE
(SEE NOTE)
STANDBY
MODE
CALLED BY
SMART MODE
NOTE: THE ECO MODE SET THE UNIT OPERATION TO STANDBY FOR 50 MINUTES (OR IN
RECIRC MODE FOR 50 MINUTES; SEE SETTINGS SECTION) AND THEN EXCHANGE AIR
DURING 10 MINUTES ON LOW SPEED. THIS MODE IS EXCLUSIVELY ACTIVATED BY
SMART MODE.
THE CHART BELOW SHOWS THE OPERATING MODES CALLED BY SMART MODE, ACCORDING
TO THE INDOOR HUMIDITY PERCENTAGE AND THE OUTDOOR TEMPERATURE.
From -35°C
to -25°C
From -25°C
to -15°C
From -15°C
to -5°C
From -5°C
to 5°C
From 5°C
to 15°C
From 15°C
to 25°C
From 25°C
to 35°C
80%
70%
60%
50%
30%
20%
40%
CONT
TURBO
VG0100A
*
OUTDOOR TEMPERATURE
INDOOR HUMIDITY LEVEL
* THIS AREA REPRESENTS STANBY MODE.
ERROR CODES
ERROR CODES SOLUTION
A 2-DIGIT ERROR
CODE (E1, E2,
ETC.) IS DISPLAYED
ON WALL CONTROL
SCREEN.
• ENSURE THAT THE COLOR CODED WIRES HAVE BEEN
CONNECTED TO THEIR APPROPRIATE PLACE.
• ENSURE THAT THE WIRES ARE CORRECTLY CONNECTED.
• PRESS AND HOLD SIMULTANEOUSLY FOR 8 SECONDS ON
% HUM, MODE AND TURBO KEYS TO RESET THE WALL
CONTROL. THE USER PREFERENCES WILL HAVE TO BE RESET.
A 3-DIGIT ERROR
CODE (E21, E22,
ETC.) IS DISPLAYED
ON WALL CONTROL
SCREEN.
• PROBLEM WITH THE VENTILATION UNIT.
CONTACT YOUR INSTALLATOR.
A 10-SECOND
COUNTDOWN IS
DISPLAYED ON WALL
CONTROL SCREEN.
• WAIT UNTIL THE END OF THE COUNTDOWN, WITHOUT
PRESSING ANY KEY.
21760 REV. 02
NOTE: IFTHE BACKLIGHT IS NOT ILLUMINATED, PRESS ON ANY KEY TO ACTIVATE THE
WALL CONTROL.

INSTALLATION AND OWNER GUIDE FOR 40355, 40455 AND VT9W WALL CONTROLS
FUNCTIONS
THE TURBO ICON IS FLASHING DURING THE 4-HOUR CYCLE. TO
EXIT THIS FUNCTION BEFORE THE END OF ITS 4-HOUR CYCLE, PRESS
ON TURBO OR MODE KEY; THE UNIT WILL GET BACK TO ITS
PREVIOUS OPERATION MODE.
TURBO
TURBO FUNCTION
TURBO

PRESS THE TURBO FUNCTION KEY TO TURN THE UNIT ON AIR
EXCHANGE IN HIGH SPEED DURING 4 HOURS, THEN, THE UNIT WILL
GET BACK TO ITS PREVIOUS OPERATION MODE.
3 sec.
THE TURBO ICON APPEARS AND STAY CONTINUOUSLY. TOEXIT
THIS TURBO MODE, PRESS ON TURBO OR MODE KEY; THE
UNIT WILL GET BACK TO ITS PREVIOUS OPERATION MODE.
PRESS AND HOLD THE TURBO FUNCTION KEY DURING 3 SECONDS
TO TURN THE UNIT ON AIR EXCHANGE IN HIGH SPEED CONTINUOUSLY.
DEHUMIDISTAT FUNCTION
CONT
THE DEHUMIDISTAT FUNCTION HAS BEEN CREATED TO MANAGE THE
INDOOR RELATIVE HUMIDITY EXCESS. WHEN THE ACTUAL HOME
RELATIVE HUMIDITY PERCENTAGE (RH %) DETECTED IS OVER
THE SET VALUE, DROPS APPEARS ON SCREEN AND THE CONTROL
OVERRIDES THE CURRENT MODE,TURNING ON THE UNIT ON HIGH
SPEED EXHANGE UNTIL THE INDOOR RELATIVE HUMDITY % SET IS
REACHED. THE UNIT THEN RETURNS TO ITS PREVIOUS OPERATION
SETTING. REFER BELOW TO FIND OUT HOW TO SET THE INDOOR
RELATIVE HUMIDITY %.
TURBO
TURBO

INALL MODES EXCEPT
STANDBY AND SMART,
PRESS THE % HUM KEY TO
ENABLE THE DEHUMIDISTAT
FUNCTION.

% HUM
CONT
THE ACTUAL
HOME RH %
LEVEL APPEARS
ON SCREEN
(ENABLED).
HOW TO ENABLE AND DISABLE THE DEHUMIDISTAT FUNCTION:
CONT
PRESS ONCE MORE
ON THE % HUM KEY
TO DISABLE THE
DEHUMIDISTAT
FUNCTION.
THE ACTUAL
HOME RH% LEVEL
DISAPPEARS FROM
SCREEN (DISABLED).

% HUM
PRESS AND HOLD
THE % HUM KEY
FOR 3 SECONDS.
3 sec.
THE ACTUAL
RH% LEVEL
APPEARS ON
SCREEN. DEFAULT
VALUE: 44%
PRESS THE % HUM KEY
TO CHANGE THE VALUE.
LOWER VALUE: 30%.
HIGHER VALUE: 56%.
THE VALUE CHANGES
BY 2% INCREMENTS.
TOEXIT THIS SETING
MENU, PRESS AND HOLD
THE % HUM KEY FOR
3 SECONDS OR
WAIT 10 SECONDS.
HOW TO SET THE INDOOR RELATIVE HUMIDITY (RH %) LEVEL

% HUM

% HUM
3 sec.

% HUM
SETTINGS
SETTINGS (CONT’D)
HOW TO SET THE UNIT OPERATION IN THE REMAINING 40 MINUTES ON
20 MIN/HMODE AND HOW TO SET THE UNIT DEFROST CYCLE TYPE
PRESS AND HOLD THE MODE KEY
FOR 3 SECONDS.
MODE

3 sec.
THE SMALL TRIANGLE
AND TWO LINES FLASH TO
SHOW STANDBY (DEFAULT
CONFIGURATION SETTING).
THE LCD SCREEN WILL SHOW ONE OF THESE CONFIGURATIONS:
OR
CONT
RECIRCULATION ARROWS
TURN WHILE THE SMALL
TRIANGLE AND rE FLASH,
CONT LABEL APPEARS TO
SHOW RECIRCULATION
ON LOW SPEED.
OR
TURBO
RECIRCULATION ARROWS
TURN WHILE THE SMALL
TRIANGLE AND rE FLASH,
TURBO LABEL APPEARS TO
SHOW RECIRCULATION
ON HIGH SPEED.
MODE

TURBO

OR
USE MODE OR TURBO KEY TO
SEE ALL 3 CONFIGURATIONS.

% HUM
PRESS % HUM KEY TO ACCEPT
CHOSEN CONFIGURATION AND GO
TO SETTING DEFROST CYCLE TYPE.
THE LCD SCREEN WILL SHOW ONE OF THESE DEFROST CYCLE TYPES:
Sd (STANDARD)
APPEARS OVER SNOWFLAKE
ICON (DEFAULT CYCLE
SETTING). WHEN NEEDED,
THE UNIT WILL PERFORM
DEFROST CYCLE ON HIGH
SPEED.
NOTE:THIS IS THE DEFROST
TYPE USED FOR THE DATA
PUBLISHED BY HVI AND
ENERGY STAR®.
OR
PL (PLUS) APPEARS OVER
SNOWFLAKE ICON. USE
THIS CYCLE IN COLD REGION
(OUTDOOR TEMPERATURE
-27°C [-17°F] AND
LOWER). WHEN NEEDED,
THE UNIT WILL PERFORM
DEFROST CYCLE ON HIGH
SPEED ON ALONGER
PERIOD OF TIME.
OR
dI (DISCRETION) APPEARS
OVER SNOWFLAKE ICON.
WHEN NEEDED, THE
DEFROST CYCLE WILL BE
PERFORMED ON THE SAME
SPEED THAN THE UNIT
VENTILATION SPEED. (E.G.:
IF THE UNIT IS SET ON
TURBO, THE DEFROST
CYCLE WILL BE DONE ON
HIGH SPEED, AND IF THE
UNIT IS SET ON CONT, THE
DEFROST CYCLE WILL BE
DONE ON LOW SPEED.
LCD SCREEN ALTERNATES BETWEEN THE
HOUSE WITH CIRCLED ARROWS AND THE HOUSE
WITHOUT ARROW. THE NUMBERS UNDER THE
HOUSE ARE THE SOFTWARE VERSION NUMBER.
PRESS % HUM KEY OR
WAIT 10 SECONDS TO EXIT
USER SETTING MENU.
MODE

TURBO

OR
USE MODE OR TURBO KEY TO
SEE ALL 3 DEFROST CYCLE TYPES.

% HUM
PRESS % HUM KEY TO ACCEPT
CHOSEN DEFROST CYCLE TYPE
AND GO TO SOFTWARE VERSION
DISPLAY.

% HUM
PROTECTION MODE
THIS ICON APPEARS TO SHOW WHEN THE VENTILATION
UNIT IS IN PROTECTION MODE. THIS SPECIAL MODE HAS
BEEN CREATED TO PROTECT THE VENTILATION UNIT FROM
SPECIFIC CONDITIONS (E.G.: OUTDOOR TEMPERATURE
COLDER THAN -25°C). THERE IS NO ACTION TO BE TAKEN
WHEN THIS ICON APPEARS, IT WILL DISAPPEAR BY ITSELF.
MAINTENANCE INDICATOR
CONT
THIS ICON FLASHES WHEN IT IS TIME TO PEFORM THE
MAINTENANCE. REFER TO THE VENTILATION UNIT USER
GUIDE.
ONCE THE UNIT MAINTENANCE IS DONE, PRESS SIMULTANEOUSLY
ON BOTH MODE AND TURBO KEYS TO RESET THE
MAINTENANCE INDICATOR. THIS WILL ERASE THE ICON FROM THE
SCREEN.
MODE

TURBO

AND
