DEMO908JL16
Demonstration Board
for Freescale
MC68HC908JL16 Family
(32-Pin SDIP)
User’s Manual
Revision 1.0
Copyright © 2006 SofTec Microsystems®
DC01037
4 / 33
4 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
We want your feedback!
SofTec Microsystems is always on the look-out for new ways to improve its Products and
Services. For this reason feedback, comments, suggestions or criticisms, however small,
are always welcome.
Our policy at SofTec Microsystems is to comply with all applicable worldwide
safety and EMC/EMI regulations. Our products are certified to comply to the
European New Approach Directives and the CE mark is applied on all our
products.
SofTec Microsystems
E-mail (general information): [e-mail]
E-mail (marketing department): [e-mail]
E-mail (technical support): [e-mail]
Web: http://www.softecmicro.com
Important
SofTec Microsystems reserves the right to make improvements to the inDART-One In-Circuit Programmer/Debugger, its
documentation and software routines, without notice. Information in this manual is intended to be accurate and reliable.
However, SofTec Microsystems assumes no responsibility for its use; nor for any infringements of rights of third parties which
may result from its use.
SOFTEC MICROSYSTEMS WILL NOT BE LIABLE FOR DAMAGES RESULTING FROM LOSS OF DATA, PROFITS, USE
OF PRODUCTS, OR INCIDENTAL OR CONSEQUENTIAL DAMAGES, EVEN IF ADVISED OF THE POSSIBILITY
THEREOF.
Trademarks
SofTec Microsystems is a registered trademark of SofTec Microsystems, Spa.
Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
Microsoft and Windows are trademarks or registered trademarks of Microsoft Corporation.
PC is a registered trademark of International Business Machines Corporation.
Other products and company names listed are trademarks or trade names of their respective companies.
5 / 33
5 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 3
Contents
1Introduction 5
1.1 Overview 5
1.2 Package Contents 5
1.3 Supported Devices 5
1.4 Recommended Reading 5
1.5 Getting Technical Support 6
2Hardware Features 7
2.1 Demonstration Board Features 7
3Software Setup 9
3.1 Overview 9
3.2 Host System Requirements 9
3.3 Installing CodeWarrior Development Studio 9
3.4 Installing SofTec Microsystems Additional Components 10
4Hardware Setup 11
4.1 First Connection 11
4.2 Power Supply 13
5Operating Modes 15
5.1 Overview 15
5.2 Standalone Mode 15
5.3 Host Mode 15
6Application Tutorial 17
6.1 Overview 17
6.2 Step-by-Step Tutorial 17
7Summary of Jumper and Connector Settings 19
7.1 Jumpers 19
7.2 Connectors 20
8Troubleshooting 25
8.1 USB Driver Problems 25
6 / 33
6 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
7 / 33
7 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 5
1 Introduction
1.1 Overview
The DEMO908JL16 Demonstration board has been designed for the evaluation,
demonstration and the debugging of the Freescale MC68HC908JL16 microcontroller.
The DEMO908JL16 can be used as a standalone application, or via its built-in USB-to-MON08
bridge, or together the Freescale Student Learning Kit (Freescale code: MCUSLK) through an
external 28-pin I/O Header female connector.
1.2 Package Contents
The DEMO908JL16 package includes the following items:
 The DEMO908JL16 evaluation board;
 A USB cable;
 The SofTec Microsystems “System Software” CD-ROM;
 The CodeWarrior Development Studio Special Edition CD-ROM;
 This user’s manual.
1.3 Supported Devices
The DEMO908JL16 Demonstration Board supports the following devices:
 MC68HC908JL16 family;
 And any future pin-to-pin compatible device.
1.4 Recommended Reading
 Freescale HC08 microcontroller-specific datasheets;
 DEMO908JL16 Schematic.
8 / 33
8 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
Introduction
Page 6
1.5 Getting Technical Support
Technical assistance is provided to all customers. For technical assistance, documentation
and information about products and services, please refer to your local SofTec Microsystems
partner.
SofTec Microsystems offers its customers a technical support service at
[e-mail].
9 / 33
9 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 7
2 Hardware Features
2.1 Demonstration Board Features
The DEMO908JL16 board features:
1. An MCU section containing:
 An MC68HC908JL16 microcontroller (in 32-pin SDIP package, already
programmed with a demo application—in addition, you can also use any other pin-
to-pin-compatible device);
 One clock sources: a 9.8304 MHz crystal, selectable via the “OSC ENA” jumper.
2. A power supply section containing:
 A 12 V DC Power Supply Input Connector;
 Power input selection jumpers for selecting the input voltage input source:
o 12 V DC input connector;
o USB connector;
o I/O header connector.
3. A built-in “USB TO MON08” section which allows the host PC to communicate with the
microcontroller through a standard USB interface. USB 2.0 is fully supported. When
using an external in-circuit debugger (via the “MON08” connector), the “USB TO
MON08” circuitry must be bypassed by removing all of the J402 jumpers.
4. A Reset section containing a Reset push-button connected to the MCU Reset pin.
5. An input section containing:
 Two push-buttons together with jumpers to connect/disconnect them to/from the
PTA0 and PTA1 pins of the microcontroller;
 A potentiometer, together with a jumper to connect/disconnect it to/from the
PTD3/ADC8 pin of the microcontroller.
6. An output section containing two high-efficiency (low-current) LEDs together with two
jumpers to connect/disconnect them to/from the PTD4 and PTD5 pins of the
microcontroller.
10 / 33
10 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
Hardware Features
Page 8
7. An RS-232 section providing one RS-232 channel connected to the microcontroller’s
SCI serial communication interface. The microcontroller’s PTD6/TxD and PTD7/RxD
lines are used by the RS-232 channel.
8. An accelerometer section featuring a Freescale MMA7260Q sensor. All of the sensor’s
input/output lines are connected to the microcontroller via jumpers.
1
23
4
5
6
78
The DEMO908JL16 Demonstration Board
11 / 33
11 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 9
3 Software Setup
3.1 Overview
i
Note:before connecting the Demonstration Board to the PC, it is
recommended that you install all of the required software first (see
below), so that the appropriate USB driver will be automatically found by
Windows when you connect the Demonstration Board.
The Demonstration Board requires that both CodeWarrior Development Studio Special Edition
and SofTec Microsystems Additional Components be installed in the host PC.
i
Note: CodeWarrior Development Studio for HC(S)08 must be installed
first.
3.2 Host System Requirements
The Demonstration Board is controlled by CodeWarrior Development Studio. The following
hardware and software are required to run the CodeWarrior user interface together with the
Demonstration Board:
 A 200-MHz (or higher) PC compatible system running Windows 98, Windows 2000 or
Windows XP;
 128 MB of available system RAM plus 1 GB of available hard disk space;
 A USB port;
 CD-ROM drive for installation.
3.3 Installing CodeWarrior Development Studio
To install the CodeWarrior Development Studio Special Edition, insert the CodeWarrior CD-
ROM into your computer’s CD-ROM drive. A startup window will automatically appear. Follow
the on-screen instructions.
12 / 33
12 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
Software Setup
Page 10
3.4 Installing SofTec Microsystems Additional
Components
The SofTec Microsystems Additional Components install all of the other required components
to your hard drive. These components include:
 The Demonstration Board’s USB driver;
 The software plug-in for CodeWarrior;
 Examples;
 Demonstration Board’s user’s manual;
 Demonstration Board’s schematic;
 Additional documentation.
To install the SofTec Microsystems Additional Components, insert the SofTec Microsystems
“System Software” CD-ROM into your computer’s CD-ROM drive. A startup window will
automatically appear. Choose “Install Instrument Software” from the main menu. A list of
available software will appear. Click on the “Additional Components” option. Follow the on-
screen instructions.
i
Note: to install the Additional Components on Windows 2000 or Windows
XP, you must log in as Administrator.
13 / 33
13 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 11
4 Hardware Setup
4.1 First Connection
The Demonstration Board is connected to a host PC through a USB port. Connection steps
are listed below in the recommended flow order:
1. Install all the required system software as described in the previous section.
2. Make sure the “POWER SEL1” jumper is in the “USB” position.
3. Insert one end of the USB cable into a free USB port.
4. Insert the other end of the USB cable into the USB connector on the Demonstration
Board.
5. The first time the Demonstration Board is connected to the PC, Windows recognizes the
instrument and starts the “Found New Hardware Wizard” procedure, asking you to
specify the driver to use for the instrument. On Windows XP (SP2) the following dialog
box will appear.
Select the “No, not this time” option and click the “Next >” button.
6. The following dialog box will appear.
14 / 33
14 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
Hardware Setup
Page 12
Click the “Next >” button.
7. Depending on your Windows settings, the following warning may appear.
i
Note: this warning is related to the fact that the USB driver used by
the Demonstration Board is not digitally signed by Microsoft, and
Windows considers it to be potentially malfunctioning or dangerous
for the system. However, you can safely ignore the warning, since
every kind of compatibility/security test has been carried out by
SofTec Microsystems.
Click the “Continue Anyway” button.
8. Windows will install the driver files to your system. At the end of the installation, the
following dialog box will appear.
15 / 33
15 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 13
Click the “Finish” button to exit from the “Found New Hardware Wizard” procedure.
9. The Demonstration Board’s USB driver is now installed on your system.
4.2 Power Supply
The Demonstration Board can be powered in three ways:
 12 V DC input connector;
 USB connector;
 I/O header connector.
Two jumpers (“POWER SEL1” and “POWER SEL2”) specify which power source to use.
These two jumpers work together, as detailed in the table below. Care must be taken in setting
these jumpers appropriately. Please refer to the following table for details.
16 / 33
16 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
Hardware Setup
Page 14
“POWER SEL1” “POWER SEL2” Configuration Selected
“USB” “3V3 OUT” Power supply taken from the USB connector. 3.3 V
supplied to the pin 1 of the I/O header (J103). Default
configuration.
“5V IN” *** Forbidden. ***
Removed Power supply taken from the USB connector.
“UNREG” “3V3 OUT” Power supply taken from the power supply connector
(J301). 3.3 V supplied to the pin 1 of the I/O header
(J103).
“5V IN” *** Forbidden. ***
Removed Power supply taken from the power supply connector
(J301).
Removed “3V3 OUT” *** Forbidden. ***
“5V IN” Power supply taken from the pin 1 of the I/O header
(J103).
Removed *** Forbidden. ***
17 / 33
17 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 15
5 Operating Modes
5.1 Overview
The Demonstration Board can work in two modes: “standalone” mode and “host” mode.
5.2 Standalone Mode
In standalone mode, no PC connection is required. The microcontroller is factory programmed
with a sample application.
To run the built-in example:
 Ensure that the “OSC ENA”, “PTD5 ENA”, “PTD4 ENA”, “PTD3 ENA”, “PTA1 ENA” and
“PTA0 ENA” jumpers are inserted.
 Ensure that all of the accelerometer enable jumpers (“PDT2”, “PTD1”, “PTD0”, “PTA7”,
“PTA5” and “PTA4”) are inserted.
 Power on the Demonstration Board through either the 12 V DC plug-in power supply or
the 28-pin I/O Header connector, and make sure that the “POWER SEL1” and “POWER
SEL2” jumpers select the appropriate power source (see chapter “4.2 Power Supply” for
details).
 The green “POWER” LED on the board should turn on.
 Press the “SW0” push-button. Then, by rotating the potentiometer, you affect the results
of the A/D conversion, which in turn varies the blinking frequency of the “LED1” and
“LED2” LEDs.
 Press the “SW1” push-button. Then, by rotating the board around its x, y or z axes, you
affect the accelerometer reading along that axis, and the “LED1” and “LED2” LEDs turn
on, off or blink depending on the board’s position.
5.3 Host Mode
In host mode the program execution is controlled by the host PC through the “USB” connector.
You can use the PC to debug the application by, for example, executing the program step by
step and watching how the microcontroller registers vary, using the provided CodeWarrior
Development Studio.
18 / 33
18 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
Operating Modes
Page 16
i
Note: all of the HC08 family devices feature a monitor code resident in
ROM which, through a serial communication line, allows the programming
and the in-circuit debugging of the user application. The monitor code is
executed in “monitor mode”; the user application is executed in “user
mode”. To enter the monitor mode some microcontroller lines must be
properly driver (for further details please refer to the microcontroller’s data
sheet).
The USB TO MON08 INTERFACE section groups the circuitry needed to
generate the required signals to enter the monitor mode and
communicate with the host PC’s USB port. In particular, to enter the
monitor mode, the “USB TO MON08 INTERFACE” circuitry:
 Generates a high-level voltage signal (VTST) on the IRQ pin of the
microcontroller;
 Generates a high-level voltage and an appropriate reset signal on
the RST pin of the microcontroller;
 Drives the microcontroller’s VDD on and off, with specific timing, in
order to enter the monitor mode;
 Handles a single-wire, bi-directional serial communication line on a
specific pin of the microcontroller.
To work in host mode (using the built-in USB to MON08 interface):
 Make sure that all of the jumpers in the “USB to MON08” section are inserted.
 Make sure that the “POWER SEL1” jumper is in the “USB” position.
 Connect the host PC to the board through the provided USB cable.
19 / 33
19 / 33

Distributor of NXP Semiconductors: Excellent Integrated System Limited
Datasheet of DEMO908JL16 - BOARD DEMO FOR MC908JL16
Contact us: [email protected] Website: www.integrated-circuit.com
DEMO908JL16 User's Manual
Page 17
6 Application Tutorial
6.1 Overview
This section will provide a step-by-step guide on how to launch your first project and get
started with the CodeWarrior for HC(S)08 user interface.
6.2 Step-by-Step Tutorial
The sample application is the same as the one described in the “Standalone Mode” section
above.
1. Ensure that the Demonstration Board is connected to the PC (via the USB cable) and
that the board is powered.
2. Make sure that all of the Demonstration Board jumpers are set to their factory position
(see chapter “7.1 Jumpers” for details)
3. Start CodeWarrior for HC(S)08 Development Studio by selecting it in the Windows Start
menu.
4. From the CodeWarrior main menu, choose “File > Open”. Select the “Demo.mcp”
workspace file that is located under the “\Program Files\SofTec Microsystems\
DEMO908JL16\CodeWarrior Examples\C\Demo” directory. Click “Open”. The Project
Window will open.
5. The C code of this example is contained in the “main.c” file. Double click on it to open
it.
6. From the main menu, choose “Project > Debug”. This will compile the source code,
generate an executable file and download it to the demo board.
7. A new debugger environment will open. From the main menu, choose “Run >
Start/Continue”. The program will be executed in real-time.
8. From the main menu, choose “Run > Halt”. The program execution will stop. The next
instruction to be executed is highlighted in the Source window.
9. From the main menu, choose “Run > Single Step”. The instruction highlighted in the
Source window will be executed, and the program execution will be stopped immediately
after.
10. From the main menu, choose “Run > Start/Continue”. The application will restart from
where it was previously stopped.
Congratulations! You have successfully completed this tutorial! You can continue to
experiment with the CodeWarrior user interface and discover by yourself its potentialities. For
an in-depth guide of all of the user interface features, select “Help > CodeWarrior Help” from
CodeWarrior Development Studio’s main menu.
20 / 33
20 / 33
