Nyne Professional Series ADS15 Installation and operating manual

All registered and unregistered trademarks are property of their respective owners.
© 2015 Nyne Multimedia Inc. All rights reserved.
Designed and tuned in Silicon Valley, California
EN
ADS15
All-in-one Bluetooth
®
Portable PA System
USER MANUAL and
SAFETY GUIDE
Printed in ChinaV1.0-415
TECH SUPPORT: 805.751.4812
www.nyne.com/supportcenter
PROFESSIONAL SERIES
ADS15
All-in-one Bluetooth
®
Portable PA System
USER MANUAL and
SAFETY GUIDE
PROFESSIONAL SERIES
ADS15-UM-draft-v1.0.indd 1-2 3/16/2015 12:34:59 PM

All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or
by any means, including photocopying, recording, or other electronic or mechanical methods, without the
prior written permission of NYNE Multimedia Inc.
All other trademarks and trade names are those of their respective owners.
Copyright © 2015 NYNE Multimedia Inc.
TABLE OF CONTENTS
INTRODUCTION----------------------------------------------------------------------------------- 2
SUPPORT ------------------------------------------------------------------------------------------- 2
THIS PACKAGE CONTAINS------------------------------------------------------------------- 3
IMPORTANT SAFETY INFORMATION TO THE USER--------------------------------- 4
INSTALLATION SAFETY PRECAUTIONS------------------------------------------------- 5
BEFORE YOU START ------------------------------------------------------------------------- 7
POWER CONNECTIONS ----------------------------------------------------------------------- 9
GETTING STARTED -----------------------------------------------------------------------------10
TRIPOD STAND SETUP ------------------------------------------------------------------------11
ADS15 I/O AUDIO CONNECTIONS----------------------------------------------------------13
FM OPERATION-----------------------------------------------------------------------------------14
USB/SD MEDIA OPERATION -----------------------------------------------------------------15
BLUETOOTH OPERATION --------------------------------------------------------------------16
STREAMING MUSIC -----------------------------------------------------------------------------17
AUX-INPUT OPERATION-----------------------------------------------------------------------18
MICROPHONE OPERATION ------------------------------------------------------------------19
EQ OPERATION-----------------------------------------------------------------------------------20
EXPANDING THE SYSTEM --------------------------------------------------------------------21
TROUBLE SHOOTING GUIDE----------------------------------------------------------------22
DIMENSIONS---------------------------------------------------------------------------------------22
SPECIFICATIONS---------------------------------------------------------------------------------23
ADS15-UM-draft-v1.0.indd 5-6 3/16/2015 12:34:59 PM

23
ENGLISH
ENGLISH
1 - ADS15 Bluetooth 15” Amplified Speaker System
1 - Tripod Speaker Stand
1 - Wired Microphone
1 - AC Power Cord
1 - User Manual / Safety Guide
1 - Warranty Card
ADS15 Professional Series


Professional
This User Guide contains important information that will help
you get the most from your NYNE ADS15 professional loudspeaker.
Please take a moment to read through these instructions carefully
so you will know how to safely setup and operate your model
properly.
After you have finished reading these instructions, keep this
document in a safe place for future reference.
THIS PACKAGE CONTAINS
SUPPORT
For the latest information about this product visit www.nyne.com
TECH SUPPORT: 805.751.4812
www.nyne.com/supportcenter
ADS15-UM-draft-v1.0.indd 2-3 3/16/2015 12:35:03 PM

45
ENGLISH
ENGLISH
IMPORTANT SAFETY INFORMATION TO THE USER IMPORTANT SAFETY INFORMATION TO THE USER


materials
WEEE NOTICE







































operable




ADS15-UM-draft-v1.0.indd 4-5 3/16/2015 12:35:04 PM

67
ENGLISH
ENGLISH
INFORMATION TO THE USER
FCC COMPLIANCE STATEMENT





This transmitter must not be 

























CAUTION!!


BEFORE YOU START
To avoid potential shock, be sure to disconnect the
main power cord from the AC source before setting
up the system. Failure to do so may result in a shock
hazard, fire or malfunction.
CAUTION!!

INSTALLATION SAFETY PRECAUTIONS
 is not responsible for the misuse of its












NO TOOLS NEEDED
ADS15-UM-draft-v1.0.indd 6-7 3/16/2015 12:35:04 PM

89
ENGLISH
ENGLISH
BEFORE INSTALLING THIS PRODUCT
BEFORE INSTALLING THIS PRODUCT
IMPORTANT SAFETY PRECAUTIONS











/ 6m














instruments
MAIN ON/OFF POWER SWITCH
IEC AC MAINS INPUT SOCKET
VOLTAGE MAINS SWITCH
POWER CONNECTIONS





CAUTION!!


110/120
220/240
USE ONLY WITH 250V FUSE
POWER
AC LINE INPUT
100~240V
50/60Hz 2A 27OW
O
R ADDITIONAL INFORMATION
3.15A FUSE REPLACEMENT
! CAUTION !
DO NOT USE IN
WET OR DAMP
ENVIRONMENT
! ATTENTION !
NE PAS UTILISER
EN MILIEU HUMIDE
VOLTAGE SELECT
CONFORMS TO
ANSI/UL STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 NO. 60065
RISQUE DE CHOC ÉLECTRIQUE
NE PAS OUVRIR
110/120
220/240
USE ONLY WITH 250V FUSE
3.15A FUSE REPLACEMENT
VOLTAGE SELECT
ADS15-UM-draft-v1.0.indd 8-9 3/16/2015 12:35:05 PM

10 11
ENGLISH
ENGLISH



Tips:
!! WARNING !!


 
TRIPOD STAND SETUP
TRIPOD STAND SETUP



surface











TRIPOD STAND SETUP
Assemble the stand safety clamp and anti-slip rubber feet
Lay down the ADS15 in a horizontal position
Insert the stand into the 35mm standard cup located on the
bottom of the ADS15 cabinet, adjust the extension bar to the
desired height and firmly tighten the thumb screws
Slowly lift the ADS15 to the vertical position
1
2
3
INSERT
4
ADS15-UM-draft-v1.0.indd 10-11 3/16/2015 12:35:13 PM

12 13
ENGLISH
ENGLISH
MEDIA VOLUME
BASS
TREBLE
LEVEL LEVEL
POWER LIMIT
SERIES
1
2
3
4
5
6
7
8
9
MEDIA MAIN CONTROLLER DISPLAY
MODE
PLAY/PAUSE
STOP
REPEAT
PREVIOUS TRACK / VOL -
NEXT TRACK / VOL +
USB PORT
SD CARD SLOT
GETTING STARTED
GETTING TO KNOW YOUR
ADS15 MEDIA CONTROLLER
6 72 3
19
5
4
8
GETTING STARTED
10
11
12
13
14
15
16
MIC INPUT LEVEL
3.5mm AUXILIARY INPUT
AUXILIARY INPUT LEVEL
RCA AUXILIARY INPUT
EQ TREBLE
EQ BASS
CLIP LIMIT INDICATOR
GETTING TO KNOW YOUR
ADS15 I/O AUDIO CONNECTIONS
12 13
15
17
18
19
20
21
22
POWER INDICATOR
MEDIA VOLUME CONTROL
XLR MIX OUTPUT
XLR AUXILIARY INPUT
XLR MIC INPUT
TRS MIC INPUT
17
16
14
18
1920
21
22
11
10
MU LT I- FO RMAT MEDIA PLAYER
5VDC
ADS15-UM-draft-v1.0.indd 12-13 3/16/2015 12:35:15 PM

14 15
ENGLISH
ENGLISH
FM TUNER OPERATION
1) Press the 2MODE button to select to the FM RADIO MODE
2) To select the previous station, press the  6button
3) To advance stations, press the NEXT TRACK 7button
4) To AUTO STORE the strongest stations in your area, press the PLAY 3button
5) To recall AUTO STORED stations press the 
FM VOLUME CONTROL
1) To lower the FM  press and hold 6button
2) To raise the FM  press and hold 7button
3) Turn the  rotary controller to a comfortable level
FM OPERATION
MEDIA PLAYER OPERATION
1) Insert the USB drive or  media, the MEDIA PLAYER will automatically start
2) Press the 3PLAY/PAUSE once to start playing music or press the PLAY button
from your device touch screen, press again to PAUSE
3) To STOP playback and return to the beginning of the media list press the STOP
4button
4) To select the previous song, press the  6button
5) To skip or advance songs, press the NEXT TRACK 7button
MEDIA VOLUME CONTROL
1) To lower the MEDIA  press and hold 6button
2) To raise the MEDIA VOLUME press and hold 7button
3) Turn the  rotary controller to a comfortable level
USB/SD MEDIA OPERATION

Tips:
MULTI-FORMAT MEDIA PLAYER
5VDC
USB PORT
NOT FOR
CHARGING
6 72 3
MULTI-FORMAT MEDIA PLAYER
5VDC
USB PORT
NOT FOR
CHARGING
6 72 3
9
5
4
8
MEDIA VOLUME
MEDIA VOLUME
USB port is for

ADS15-UM-draft-v1.0.indd 14-15 3/16/2015 12:35:16 PM

16 17
ENGLISH
ENGLISH
PAIRING & DISCOVERING A NEW BLUETOOTH CONNECTION
1) Press the 2MODE button to select to the BLUETOOTH MODE
2) The ADS15 is NOW in pairing mode:
ANDROID users:
a. Go into the Settings Menu of your device
b. Enter the Bluetooth Menu and press SCAN
c. “NYNE ADS15” will now be displayed under 
d. If prompted, enter passcode: “0000”
iOS users:
a. Go into the Settings Menu of your iOS device
b. Enter the Bluetooth Menu
c. “NYNE ADS15” will now be displayed
d. If prompted, enter passcode: “0000”
3) If the ADS15 is not seen, repeat the above steps to refresh the “Device List”
NFC SIMPLE PAIRING FOR ANDROID USERS
1) Make sure you NFC function is enabled on your device
2) Tap on the NFC tag located on the side panel of the ADS15


Tips:
BLUETOOTH OPERATION
MEDIA CONTROLLER BLUETOOTH OPERATION
1) Press the 3PLAY/PAUSE once to start playing music or press the PLAY button
from your device touch screen, press again to PAUSE
2) To select the previous song, press the  6button
3) To skip songs or advance, press the NEXT TRACK 7button
BLUETOOTH MEDIA VOLUME CONTROL
1) To lower the BLUETOOTH MEDIA  press and hold 6button
2) To raise the BLUETOOTH MEDIA VOLUME press and hold 7button
3) Turn the BLUETOOTH  rotary controller to a comfortable level
STREAMING MUSIC

Turn the BLUETOOTH volume level on

Tips:
MULTI-FORMAT MEDIA PLAYER
5VDC
USB PORT
NOT FOR
CHARGING
2
MU LT I- FO RMAT MEDIA PLAYER
5VDC
USB PORT
NOT FOR
CHARGING
6
37
Nyne ADS15
