I N T R O D U C T I O N
We’re born of an ever-burningdrive to
innovate. We believe that just because
somethingis good doesn’t mean it’s as good
as it can be. We’re always exploring,always
pushing forward. We enable athletesto
perform and advancewhat is possiblein sport
and everydaylife. From the birth of the brand,
cycling and endurance have always been an
integralpart of our DNA.
LEARN MORE AT
.com
T E C H B O O K

RADAR PACE is smart eyewear featuring a voice activated, real
time coaching system.
COACH: Virtual coach that‘s with you every step of your
training journey and tells you what to do. Just like a real
coach, RADAR PACE™ tells you what to do, knows what
you did and tells you what to do next
TRAINING PLANS: custom training programs for running
and cycling based on sports science*
ANALYZES DATA: Gathers and interprets all of your data:
knows what / how you’re doing**
DYNAMIC ADJUSTMENT: Dynamically adjusts your training
program based on your compliance
CALIBRATION: Calibrates training based on your performance
– learns about you over time to provide feedback specific to you
VOICE ACTIVATED USER INTERFACE: A user interface that
keeps you focused and gives you live feedback Just ask how
you’re doing.
OAKLEY SPORT PERFORMANCE: Maintains Oakley’s high
standardof optics, Prizm lenses, fit, lightweight, and
aerodynamic design for high speed conditions.
I N T R O D U C T I O N
K E Y S E L L I N G P O I N T S
T E C H B O O K
*Requires connection to mobile device & installation of Radar Pace App. **Requires connection
to external sensor not included with Radar Pace

RADAR PACE™ is a real-time voice activated coaching system. It creates a training
program, tracks your performance and coaches you in the moment. Powered by
Intel NLP (natural language processing), it's like having a trainer with you whenever
you're running or cycling, a mentor that gives you the help and motivation you
need to take performance to a whole new level.
LARGE TORIC LENS DESIGN
Optimized upper peripheral view
PLUTONITE®LENS MATERIAL
Optical clarity and 100% UV protection
O MATTER™FRAME MATERIAL
Light weight and durable for all day comfort
T E C H N I C A L F E A T U R E S
PAIRS TO EXTRENAL SENSORS USING INTEL TECHNOLOGY
Tracks your performance and coaches you in the moment
INTERNAL SENSORS
Collects and analyzes your performance data
MICROPHONE ENABLED
Communicate with the system in a more natural way
TOUCH PAD ON TEMPLES
Control functions with simple taps and swipes
C O N N E C T I V I T Y
WATER / SWEAT RESISTANT

T E C H B O O K
T O U C H P A D C O N T R O L S
The touch pad on the temples lets you control functions with simple taps and
swipes. You can adjust the volume, control music and calls from your paired
phone, and more.
M U S I C C O N T R O L S
•Pause or Play music: Single Tap
•Next song: Double Tap
•Previous song: Triple Tap
•Fast Forward: Double Tap and Hold
•Rewind: Triple Tap and Hold
C A L L C O N T R O L S
•Answer call: Single Tap
•End call: Double Tap
•End currentcall and switch to incoming or on-
hold call: Hold and Release
•Switch back and forth betweenincoming call and
currentcall: Single Tap (A single tap puts the
current call on hold and answers the
incoming call. Each single tap after that
switches between the two calls, placing one
on hold.)
S I R I / G O O G L E N O W
•Activate Siri or Google Now: Hold and Release
V O L U M E C O N T R O L S
•Increase volume: Swipe forward
•Decrease volume: Swipe backward

AUDIO
•In-ear booms
TOUCH PANEL
•Phone control
•Music player
control
•Siri / Google
Plus control
POWER
•Power button
•USB charge
VOICE CONTROL
•Microphone Array
Compatible with iOS & Android
Touch Panel activates Siri &
Google Now
P R O D U C T S P E C S
R E C O M M E N D E D A C C E S S O R I E S
•RUNNING: HEART RATE MONITOR
•CYCLING: HEART RATE MONTIOR
POWER METER + CADENCE
T E C H B O O K

LEARN MORE AT
.com
T E C H B O O K
I N T R O D U C T I O N
C O M P E T I T O R D I F F E R E N C E S

AUDIO
•In-ear booms
TOUCH PANEL
•Phone control
•Music player
control (MFI
compliant)
POWER
•Power button
•USB charge
VOICE CONTROL
•Microphone Array
Compatible with iOS & Android
Touch Panel activates Siri &
Google Now
I N T E R N A L S E N S O R S
•Accelerometer
•Gyroscope
•Pressure
•Humidity
•Proximity
C O N N E C T I V I T Y
•ANT+
•Bluetooth LE
•Bluetooth
W A T E R R E S I S T A N T
•IPX5
P R O D U C T S P E C S
R E C O M M E N D E D T E C H
•RUNNING: HEART RATE MONITOR
•CYCLING: HEART RATE MONTIOR
POWER METER + CADENCE
T E C H B O O K

T E C H B O O K
P R O D U C T S P E C S
I N T E R N A L S E N S O R S
A C C E L E R O M E T E R
G Y R O S C O P E
Axis-based motion sensing.
Used in a range of devices (i.e. shoe pods, belt-clip
pedometers, smartphone fitness/game apps)
Measures when your foot is in contact with the
ground and how many steps you take based on
vibration.
Gives an idea of how far you ran and how fast.
Similar to an Accelerometer, except that it measures
angular movements.
Primarily used for navigation and the measurement
of angular velocity.
P R E S S U R E
P R O X I M T Y
Measures atmospheric pressure, especially altitude.
Determines when you are running or cycling uphill.
Stride Rate (Acc. & Gyro) + Elevation = Hill gradient
Sensor that measures when you are wearing Radar
Pace.
While wearing, allows for complete voice control of
the system
When not wearing Radar Pace. It will turn off the
device.
