Oasis MAXXFILL FLEX User manual

User Guide
Please read this instruction manual before using your water dispenser.
CONVERTIBLE BOTTOM LOAD/POU
HOT AND COLD WATER DISPENSER
MODEL: BXM1SHS
By:
MAXXFILL FLEX

2
IMPORTANT SAFEGUARDS pg 3
GROUNDING INSTRUCTIONS pg 3
TECHNICAL SPECIFICATIONS pg 4
PRODUCT DIAGRAM pg 4
INSTALLATION pg 5
PREPARING THE WATER DISPENSER FOR USE pg 5
INITIAL SETUP pg 5
ADJUSTING THE SIPHON TUBE FOR SMALLER BOTTLES pg 6
OPERATION pg 6
PREPARING THE COOLER FOR BOTTLE-LESS (POU) DISPENSE pg 7-8
ADDING FILTRATION pg 9
CLEANING AND MAINTENANCE pg 10-12
TROUBLESHOOTING pg 13-14
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference.
(2) this device must accept any interfererence received, including
interferences that may cause undesired operation.
TABLE OF CONTENTS

3
Purchasing an Oasis Water Dispenser was a GREAT choice!
This unique design offers the benets of:
• No more struggling to lift heavy water bottles!
• No more spills during water bottle installation!
• No more unsightly bruised or battered recycled water bottles!
Please read the enclosed operating instructions carefully and retain this booklet for future reference. We have carefully
engineered your water dispenser to provide years of enjoyment and trouble-free operation.
• This dispenser is equipped with a grounded power cord plug for your safety.
• Do not operate this (or any other appliance) with a damaged power cord. Be sure that the plug is fully inserted
into the GFCI outlet and that no other appliance is plugged into the same outlet.
• Do not run the power cord over carpeting or other heat insulators, and do not cover it. Avoid laying the cord in
  hightrafcareas,andneversubmergeitinwater.
• Donotuseanextensioncordasitmayoverheat,increasingtheriskofre.
• Ifthesupplycordisdamaged,contactOasisoraqualiedelectriciantoreplaceitbeforepluggingitin.
• Never turn the dispenser upside down. If the dispenser has been resting on its side for a long period of time,
place the it in the upright position for approximately 12 hours before using.
• Forusewithupto5gallon(19liter)waterbottlesorlters.
• Never allow children to dispense hot water without proper and direct supervision.
• Always use known and microbiologically-safe bottled water.
• Keep your dispenser in a dry place away from direct sunlight.
• Do not use this dispenser outdoors.
• Neverputanythingammableclosetothedispenser.
• Leave a minimum clearance of 6 in (15 cm) in back and on both sides of the dispenser for proper ventilation.
• Alwaysinstallyourdispenseronaleveloor.
• Wait 5 minutes before restarting the dispenser after turning it off.
• Always unplug the dispenser before servicing.
• Regular cleaning of your dispenser is required to maintain your warranty.
• Please follow the cleaning instructions outlined in this manual and clean the dispenser every 6 months.
• To provide additional protection from the risk of shock, this dispenser MUST be connected to a ground fault
circuit interrupter (GFCI) outlet at all times. Use of an extension cord will void any warranties.
• This appliance must be grounded. Improper use of the grounding plug can result in a risk of electric shock,
causing serious injury and possibly death.
• This appliance is equipped with a power cord having a grounding wire with a grounding plug and must be
connected into a properly-grounded, polarized outlet.
• Consultaqualiedelectricianifthegroundinginstructionsarenotcompletelyunderstood,orifdoubtexistsas
to whether the appliance is properly grounded. If the wall outlet is a standard, 2-prong outlet, it is your
personal responsibility and obligation to have it replaced with a properly-grounded, 3-prong wall outlet.
• Do not under any circumstances cut or remove the third (ground) prong from the power cord plug.
• Do not use an adapter plug with this appliance.
IMPORTANT SAFEGUARDS
GROUNDING INSTRUCTIONS

4
FRONT BACK
LED INDICATOR
WATER SUPPLY
SWITCH (BLACK)
HOT WATER
DISPENSE
BUTTON
COLD WATER
DISPENSE BUTTON
WATER
DISPENSE
POINT
DRIP TRAY
HOT WATER
SWITCH
(RED)
COOLING
SYSTEM
SWITCH
(GREEN)
HOT TANK
DRAIN VALVE
AND CAP
COLD TANK
DRAIN VALVE
AND CAP
POWER
CORD
LOWER
CABINET
DOOR
WATER BOTTLE
(NOT INCLUDED)
WATER BOTTLE CAP
WITH SIPHON TUBE
WATER IN
BULKHEAD CONDENSER
COILS
TECHNICAL SPECIFICATIONS
PRODUCT DIAGRAM
NIGHT
LIGHT
COLD CONTROL
RATED VOLTAGE 115V - 60Hz HOT WATER/HR 0.9 GAL (3.5 L)
HEATING POWER 460W COLD WATER/HR 1.7 GAL (6.5 L)
COOLING POWER/CURRENT 95W/1.5A HOT WATER TEMP. RANGE 165°F - 194°F
COOLANT R134a 43g

5
1. After unpacking, wipe dispenser with soft cloth.
2.Placethedispenseronahard,atsurface,makingcertainitislevel.Thedispensershouldnotbeplacednear 
direct sunlight or any other source of heat.
3. It is best to place the dispenser in an area with good air circulation. Make sure there is at least 6 in (15cm) of
clearance in back and on both sides of the dispenser for proper ventilation.
WARNING: The hot and cold tank drain plugs on the back of the dispenser may loosen during shipping. Securely
tightenthedrainplugbeforestartingthedispenser.Aloosedrainplugmayleak,causingoordamage.
This model is different from a traditional water dispenser with the water bottle upside down on the top. Instead, the water
bottle is placed upright in the lower cabinet with a pump drawing the water up to the dispenser.
IMPORTANT:
• Clean the top of the water bottle before installing.
• Alwayswashyourhandsrstbeforehandlingthewaterbottlecap.
• Avoid handling the siphon tube. If necessary, remove the tube, wash with soapy water and rinse thoroughly
before reinstalling into the water bottle cap.
• Much like a new refrigerator with an ice maker or water dispenser, it is recommended to run 1 to 2 gal (3.8 to 7.6 L)
ofwaterthroughthesystembeforetherstuse.
IMPORTANT: MAKE SURE THE DISPENSER IS NOT PLUGGED INTO AN ELECTRICAL OUTLET AND THAT BOTH
THE COOLING SYSTEM AND HOT WATER SWITCHES ARE OFF.
1. Open the lower cabinet door.
2.Placefullwaterbottleonoorinfrontofthedispenser.Removetheplastic
cap from the mouth of the bottle.
3. Insert the siphon tube into the mouth of the water bottle and press the
waterbottlecaprmlyoverthemouthofthebottle.
4. Slide the siphon tube down until it reaches the bottom of the bottle.
5. Slide the bottle inside the cabinet and close the lower cabinet door.
6. Plug the dispenser into a grounded GFCI power outlet. The water pump will
turnonforseveralminutestollthecoldandhottanks.
7. Once the pump has stopped, place a container under the water dispense
pointandpressthehotwaterdispensebuttonuntilwaterowsfreely.
8. Turn ON both the cooling system and hot water switches located on the
back of the dispenser. If you are not going to use hot water, turn the hot
water switch OFF to conserve energy.
9.Thersttimethedispenserisused,youwillhavetowaitatleast1hourfor
cold water and 15 minutes for hot water.
NOTE: If there is not a secure connection between the water bottle cap and the water bottle cap elbow connector, the
water pump will operate but water will not dispense. Make sure this connection is secure.
NOTE: Please wait until the water pump stops running before using the dispenser. If the water tanks
are not full, water will not dispense.
INSTALLATION
PREPARING THE WATER DISPENSER FOR USE AS A BOTTLED WATER SYSTEM
INITIAL SET-UP FOR A BOTTLED WATER SYSTEM

Fig. 1 Fig. 2
HOT WATER
DISPENSE BUTTON
COLD WATER
DISPENSE BUTTON
HOT WATER
SAFETY LOCK
6
Your new water dispenser features a water bottle cap with siphon tube that can accommodate up to 5 gallon
(19 liter) water bottle.
Thewaterbottlecapandsiphontubeassemblyisshippedinitsdefaultcongurationforusewithastandard5gallon
(19 liter) bottle. For proper operation, make sure the collar of the water bottle cap is sealed tightly to the neck of the
bottle. (Fig. 1)
Raise or lower the siphon tube to the proper depth into the bottle. (Fig. 2)
The water dispenser has 3 indicator lights on the front panel.
• When the indicatorlightison,thedispenserhasnishedchillingwaterinthecoldtank.
• When the indicator light is on, the water bottle is empty and needs to be replaced.
• When the indicatorlightison,thedispenserhasnishedheatingwaterandisreadytodispense.
Using the Water Dispenser
• To dispense HOT water, slide the red safety lock to the left and press the hot water dispense button
all the way down.
• To dispense COLD water, press the cold water dispense button all the way down.
ADJUSTING THE SIPHON TUBE FOR SMALLER BOTTLES
OPERATION

Water-In Bulkhead
Water Source Line
(1/4”Tubing)
7
Yourcoolercanbeusedwithadirectwaterlineconnectionandltrationsystem.Theltrationsystemcanbeinstalled
prior to the water dispenser or can be installed inside the cabinet behind the door.
1. Locate the Water Inlet Bulkhead at the back of the unit. Remove the plug and insert the water source tubing (1/4”)
into the bulkhead. Ensure the water line is secure.
PREPARING THE WATER SYSTEM FOR USE AS A BOTTLE-LESS (POU) WATER DISPENSER
WATER TUBE CONNECTION/
DISCONNECTION PROCEDURES
Fig. A
NOTE: Do not use water that
is microbiologically unsafe or
of unknown quality without
adequate disinfection before or
after the system
1. To connect, push tube
through collet ring into body.
2. Tube must sit fully past
o-ring.
3. To disconnect, hold collet
ring against body and pull
tube out.

HOT
COLD
BOTTLE
POU
WATER SUPPLY
SWITCH HOT WATER
SWITCH
COLD WATER
SWITCH
8
1. Locate the water supply switch on the back of the unit near the top. Switch the unit to POU.
2. Turn on the water supply to the unit and check for leaks.
IMPORTANT! Make sure both cooling system and hot water switches are off.
INITIAL SET-UP FOR A BOTTLE-LESS SYSTEM
3. Plug the dispenser into a grounded GFCI power outlet. An internal solenoid valve will turn on for several
minutestollthecoldandhottanks.
4. Once the solenoid valve has stopped, place a container under the water dispense point and press the
hotwaterdispensebuttonuntilwaterowsfreely.
5. Turn ON both the cooling system and hot water switches located on the back of the dispenser. If you are
not going to use hot water, turn the hot water switch OFF to conserve energy.
6.Thersttimethedispenserisused,youwillhavetowaitatleast1hourforcoldwaterand15minutesfor
hot water.
7. Refer to the OPERATION step on page 6.
NOTE: Please allow the several minutes for solenoid valve to operate and ll up the water tanks
before using the dispenser. If the water tanks are not full, water will not dispense.

IN
OUT
3. Locate the coil of tubing on the inside of the
cabinet on the right side. Remove the elbow
ttingandsetitaside.
4.Insertthewater-inlineintothelterinletof
thelterheadandtheninsertthewater-out
lineintothelteroutlet.Ensurebothlinesare
securelytted.
Note: Refer to your lter or lter
instructions to nd the inlet and outlet for
your chosen lter.
9
YourOASIScoolerhastheoptiontobettedwithvariousltrationoptions(notincluded).
1. Turn off the water supply and then dispense water into a cup to relieve pressure. Unplug the unit.
2.Inserttheltermountingbracket(notincluded)betweenthecondensercoilsfromtheoutsideandsetto 
thedesiredheight.Ensurethatthelterishighenoughtobepulledoutfromthelterheadandremoved.
Onceset,useappropriatescrewstoattachthelterheadtothebracket.
Note: The hardware to mount the lter head to the unit is not included.
5. Turn the water source back on and reconnect power.
ADDING FILTRATION (OPTIONAL)

10
Formaximumefciencyandperformance,yourwaterdispenserrequirescleaningonaregularbasis(ie.every6
months). Regular cleaning will prevent potential growth of bacteria and will maintain a hygienic environment.
Never use harsh chemicals or abrasive cleaners.
Cleaning the Outside of the Water Dispenser
The outside of the dispenser may be wiped clean with a cleaning solution product or a mild soap and water mixture and
a soft cloth. Rinse thoroughly with clean water and dry.
Cleaning the Drip Tray
The drip tray should be emptied and cleaned regularly to remove spotting and any mineral deposits.
To remove the drip tray, lift the tray upward, dislodging it from the guides. Drain and clean with cleaning solution or a
mild soap and water mixture. For tough deposits, add vinegar and let it soak until the deposits loosen. Then wash, rinse
and dry throughly. Replace the grill on the drip tray and slide it onto the guides.
Cleaning the Condenser
Vacuumorsweepawaythedustfromthecondensercoils.Thiswillimprovecoolingandefciency.
Cleaning The Waterways
IMPORTANT: TURN OFF THE HOT AND COLD WATER SWITCHES BEFORE PERFORMING THIS PROCEDURE.
1. Make sure the power cord is plugged into an electrical outlet.
2.Openthelowercabinetdoor,pullthebottleforwardoutofthedispenserandplaceontheoor.
3. Remove the water bottle cap and siphon tube from the bottle and hang on the hook located on the inside of the
lower cabinet door. Be sure to keep the door open so that the water pump does not run. For bottle-less cleaning, re
peatthisprocedurebutipthewatersupplyswitchto“BOTTLE”duringthisprocedure.
4. Drain the cold reservoir by placing a container under the water dispense point and pressing the cold dispense
buttonuntilwaterstopsowing.Discardwater.
5. Using a clean container, mix 8 cups (2 L) of white vinegar with 8 cups (2 L) of hot water. Place the container inside of
the bottle storage compartment. Insert the siphon tube into the cleaning solution, keeping the container
upright, and close the lower cabinet door. The water pump will start automatically and run for several minutes to
draw the cleaning solution into the dispenser reservoirs. Once the pump has stopped, dispense 0.5 cups (0.12 L) of
water from each of the 2 dispense buttons. Allow the cleaning solution to sit inside the dispenser for 20 minutes.
6. Place a container under the water dispense point and press the hot and cold water dispense buttons
untilthecleaningsolutionstopsowing.Discardcleaningsolution.Thepumpwillcontinuetooperatefor
approximately30seconds,followedbyaashingyellowbottleemptylight.
7. Using a container, drain the remaining cleaning solution from the internal hot and cold tanks by unscrewing the hot
tank drain cap located at the back of the dispenser. Discard the cleaning solution. Re-install the hot tank drain cap.
Repeatforcoldtankdrain.RefertoPage11and12,“DrainingtheReservoirs”fordetailedinstructions.
8. Flush out the cleaning solution by repeating Steps 5-7 using 16 cups (4 L) of fresh hot water (no cleaning solution).
The cleaning process is now complete.
9.ReplacethewaterbottleoriptheswitchbehindtheunitbacktoPOU.(SeeINITIALSET-UP)
NOTE: To conserve energy when not using the dispenser for a long period of time, unplug the dispenser and drain the
reservoirs.
CLEANING AND MAINTENANCE

1. Turn off the hot tank with the red switch in the back of the unit. Dispense hot water from the water dispense point
until the temperature drops to a safe level to avoid the risk of scalding. This will empty the heated water from the
tank and replace it with cool water.
11
Draining the Reservoirs
IMPORTANT: UNPLUG THE DISPENSER BEFORE PERFORMING THIS PROCEDURE.
3. Press both dispense buttons until water no longer comes out.
IMPORTANT: Collect the water in a container, not the drip tray.
2. Remove the water bottle from the unit.

Hot Tank Drain
Cold Tank Drain
Drain Cover
Drain Cap
Drain Plug
Drain Plug
12
6. Once drained, reverse the steps in step 5 and re-install the cold tank drain assembly. To drain the hot
tank, repeat step 5 with the hot reservoir drain.
5. Remove the cold tank drain cover, then unscrew the drain cap. Ensure that your container is directly
4. Place a container beneath the cold tank drain valve on the back of the dispenser.
Note: It is recommended that
the bucket be held up under
the drain when the rubber
plug is pulled.
belowthedrain,thenpullthesiliconedrainplugfromthedrainline.Waterwillowoutoftheline
immediately upon plug removal.

13
PROBLEM POSSIBLE CAUSE SUGGESTION
Water does
not dispense.
Dispenser is unplugged. Plug the dispenser into a grounded
GFCI power outlet.
Main power supply is o. Re-establish main power supply.
The lower cabinet door is open. Close door and allow time for
pump to ll the reservoirs.
The water bottle is empty. Replace water bottle.
(See INITIAL SETUP)
The connection between the water
bottle cap and the water bottle
cap connector is not secure.
Properly secure connection.
System has malfunctioned. Remove water bottle and unplug
the dispenser. Contact dealer.
Cold water does
not dispense.
Cooling system switch is OFF. Turn cooling switch ON.
Too much cold water consumed
in a short period of time. Wait 15 minutes for the water to cool.
The ventilation around the
dispenser is insucient.
Provide at least 15 cm (6 in) of clearance
on all sides of the dispenser.
System has malfunctioned. Remove water bottle and unplug
the dispenser. Contact dealer.
Hot water does
not dispense.
Hot water switch is OFF. Turn hot water switch ON.
Too much hot water has been
consumed in short period of time. Wait 15 minutes for the water to heat.
System has malfunctioned. Remove water bottle and unplug
the dispenser. Contact dealer.
Dispenser is noisy
during operation.
The dispenser is not level. Place the dispenser on a level, at surface.
Dispenser is touching other objects. Move dispenser away from other objects.
Water leaks from the
water dispense point.
The buttons are stuck down. Check for foreign objects in the button area.
The water dispense point
has been damaged.
Contact Oasis Customer Service.
1-800-646-2747
Water is dripping out
of the dispenser and
onto the oor.
The hot and/or cold tank drain caps are
not fastened properly.
Tighten the drain cap.
If the seal inside the drain cap is torn
or damaged then replace with a new one.
The connection between the water
bottle cap and the water bottle
cap connector is not secure.
Properly secure connection.
The hot or cold water tank is leaking. Remove water bottle and unplug
the dispenser. Contact dealer.
The water being
dispensed has
a strange taste.
This is not uncommon
with new dispensers.
The taste usually goes away after
the rst bottle has been used.
Dispenser requires cleaning. Clean the siphon tube and waterways.
(See CLEANING AND MAINTENANCE)
TROUBLESHOOTING (BOTTLE)

14
PROBLEM POSSIBLE CAUSE SUGGESTION
Water does
not dispense.
Dispenser is unplugged. Plug the dispenser into a grounded
GFCI power outlet.
Main power supply is o. Re-establish main power supply.
The lower cabinet door is open. Close door and allow time for the
solenoid valve to ll the reservoirs.
Strainers are clogged. Remove strainers and clean.
Water supply switch is in the wrong
position.
Make sure that the water supply switch is set to
the correct water supply position.
Cold water does
not dispense.
Cooling system switch is OFF. Turn cooling switch ON.
Too much cold water consumed
in a short period of time. Wait 15 minutes for the water to cool.
The ventilation around the
dispenser is insucient.
Provide at least 15 cm (6 in) of clearance
on all sides of the dispenser.
System has malfunctioned. Turn o water supply valve and unplug
the dispenser. Contact dealer.
Water supply switch is in the wrong
position.
Make sure that the water supply switch is set to
the correct water supply position.
Hot water does
not dispense.
Hot water switch is OFF. Turn hot water switch ON.
Too much hot water has been
consumed in short period of time. Wait 15 minutes for the water to heat.
System has malfunctioned. Turn o water supply valve and unplug
the dispenser. Contact dealer.
Water supply switch is in the wrong
position.
Make sure that the water supply switch is set to
the correct water supply position.
Dispenser is noisy
during operation.
The dispenser is not level. Place the dispenser on a level, at surface.
Dispenser is touching other objects. Move dispenser away from other objects.
Water leaks from the
water dispense point.
The buttons are stuck down. Check for foreign objects in the button area.
The water dispense point
has been damaged.
Contact Oasis Customer Service.
1-800-646-2747
Water is dripping out
of the dispenser and
onto the oor.
The hot and/or cold tank drain caps are
not fastened properly.
Tighten the drain cap.
If the seal inside the drain cap is torn
or damaged then replace with a new one.
The hot or cold water tank is leaking. Turn o water supply valve and unplug
the dispenser. Contact dealer.
The water being
dispensed has
a strange taste.
This is not uncommon
with new dispensers.
The taste usually goes away after
the rst several gallons have been used.
Dispenser requires cleaning. Clean the waterways.
(See CLEANING AND MAINTENANCE)
Filter is old or water supply is tainted. Replace lter and check water supply line for
taste.
TROUBLESHOOTING (BOTTLE-LESS)

15

OASIS INTERNATIONAL
222 East Campus View Blvd.
Columbus, OH 43235
CONVERTIBLE BOTTOM LOAD/POU
HOT AND COLD WATER DISPENSER
www.oasiscoolers.com
1-800-646-2747
OASIS is a registered trademark of LVD Acquisition, LLC dba Oasis International
©2021 LVD Acquisition, LLC 030099-647 Rev A Date: 05/2021
