Oasis Quasar PWEBQ User manual

QUASAR Hands-Free Bottle Filler
UVC-LED WATER TREATMENT
Model PWEBQ and PWF2EBQ (retro fit)
and P*EBQ Family of Drinking
Fountains/Bottle Filler combo
Installation Instructions
The Hands-Free Bottle Filler mounts directly above Versacooler®I and II
products. If the cooler electrical outlet does not have two useable plugs, an
outlet splitter will need to be used.
If installed onto a refrigerated cooler, chilled water can be dispensed through
the Bottle Filler. Otherwise, room temperature water will be dispensed.
The Bottle Filler is shipped partially assembled.
On the combo units, the cooler is plumbed and ready to attach to the Bottle
Filler.
When completed, the finished assembly will look like this:
1
Water Coolers
OR

Ø3/8” pilot drill and either a step drill bit up to 7/8” diameter that will drill
through SS top or 7/8” diameter punch die (retrofit version only)
ØElectric drill; wrench for punch die
ØSmall tubing cutter for copper tube
Ø1/4“ nut driver
Ø# 2 Phillips screw driver
Ø#15 torx bit driver
38” of ¼ OD plastic
tubing with 19” of
sponge tubing
insulation (included
with “Quasar Bottle
Filler ready” coolers)
What’s Included:
Tools required:
Section 1: Getting Started
Rubber
Gasket
2
Installation
instructions
Quick connect tee
fitting
Snap bushings 7/8”
and 1½”
Quasar Hands-Free
Bottle Filler
Top C ap
Versafilter II
remedi
filter
The Versafilter II and remedi filter are only
included in the PWF2EBQ model.

Oasis PWEBQ: Versacooler® II Models PAC, P8AC with Hands-Free Bottle Filler
Section 2: Rough In Drawing
3

Oasis PWEBQ: Versacooler® II Split Level Models with Hands-Free Bottle Filler
Section 2: Rough In Drawing
* On split level models, the Bottle Filler must be mounted on the
low unit in order to meet ADA guidelines.
4

A: Drilling hole in the top for water line connection.
1. Disconnect power by UNPLUGGING unit. It might be necessary to remove
the front panel to get access to the power.
2. Turn OFF water supply to the unit. It might be necessary to remove the
front panel to access the water stop valve.
3. Place hole template onto cooler top so it is aligned with the left side of unit
and wall. SEE NEXT PAGE FOR TEMPLATE
4. Mark hole location
5. Remove top from unit.
Section 3A: Installation
Note: Proceed to Section 3B Step 5 “Final steps for both product families” if
the cooler is purchased “Quasar Bottle Filler or VersaFiller ready”.
5
Template
Mark hole location.
6. Using a step drill bit or 7/8” punch die, make a 7/8” hole through top. You
may want to drill a pilot hole to get these started.
7. Install snap bushing into hole to protect tubing from being cut.
Drill
Install bushing
5
Remove top from cooler by
removing six, #15 torx head screws
on sides of top.

PLACE THIS EDGE AGAINST WALL
ALIGN THIS EDGE WITH LEFT EDGE OF COOLER TOP
USE THIS TEMPLATE TO MARK THE
HOLE LOCATION ON COOLER TOP
3-1/4” from edge of paper
2-1/8”
from
edge of
paper
Mark this center point on the top. Remove the top from the cooler. Then create a 7/8” diameter hole through the top at the marked center point (step drill bit or punch die).
6

Section 3B: Installation
7
VersaCooler to Quasar Bottle Filler Plumbing Diagram
OPTIONAL
VERSAFILTER II
OPTIONAL
FILTER BOTTLE FILLER
SOLENOID
VALVE UV LED
VERSACOOLER
INLINE
STRAINER,TUBE,
AND REDUCER FTG.
PROVIDED WITH
FOUNTAIN.
BUILDING
INLET WATER

Section 3B: Installation
8
Two VersaCoolers to Quasar Bottle Filler Plumbing Diagram
BOTTLE FILLER
SOLENOID
VALVE UV LED
OPTIONAL
VERSAFILTER II
OPTIONAL
FILTER
VERSACOOLER VERSACOOLER
T-FITTING
INLINE
STRAINER,TUBE,
AND REDUCER FTG.
PROVIDED WITH
FOUNTAIN.
BUILDING
INLET WATER

B: Connecting the water line
Section 3B: Installation
For the single “Bottle Filler ready” cooler, the tube to connect to the Bottle
Filler is found inside the access panel (the compressor compartment). This
tube supplies cold water from the cooling tank to the Bottle Filler.
¼” OD tube to connect
to Versafiller
Note: If you are retrofitting the Bottle Filler to an existing
cooler, follow the instructions starting on page 11.
For split level “Bottle Filler ready” coolers, the tube to plumb in the Bottle
Filler is packaged in the dummy unit.
Remove tube from bag.
First, remove plug from
fitting on tank drain
Next, insert end of
tube into fitting.
9

Go to Step 5 “Final steps for both product families:”
The tee and tube to the Bottle Filler are packaged with the PWEBQ unit.
One branch of the tee will supply the valve on the dummy unit, the other
branch of the tee will connect to the Bottle Filler.
If a filter is being installed, cut a piece of tubing about 3” long to insert
optional flow switch right after filter and before tee. This allows Bottle
Filler counter to accurately calculate amount of water passing through
filter.
Tube to connect valve
on dummy unit
Tube to connect
Bottle Filler
Tube to connect chilled
water to dummy unit
and Bottle Filler
10

1. With the cooler top removed, find the tube going from the cooling
tank outlet to the valve. The TEE fitting (supplied) will need to
connect between the cooling tank and valve.
Outlet Tube (insulated plastic)
Valve
P8AC family
Outlet Tube (insulated copper)
Valve
P8AM family
If the cooling tank is non-pressurized, then go to the “Pressurizing the
cooling tank” addendum section. Otherwise, proceed to step 1 below.
Non-pressurized units are single units made since December of 2009.
Refer to the schematic below to identify the system that you have.
PRESSURIZED
COOLING
TANK
Cooling
tank
Water
valve/
regulator
Supply
Water
NON-
PRESSURIZED
COOLING TANK
Cooling
tank
Water
valve/
regulator
Supply
Water
To retrofit the Versafiller to an existing unit, follow the
instructions below:
11

2. Disconnect tubing from the
elbow on the valve.
3. Using the 38” piece
of tubing provided,
cut 6” and install it
on the end of the
TEE. Install the
remaining tubing
onto the branch of
the TEE. Connect
the other end of the
TEE to the tank
outlet tubing (tube
that was
disconnected from
the elbow).
32” tubing
6” tubing
4. Route the TEE and
tubing under the
waste drain and
connect the 6” length
to the water valve
elbow.
TEE
Go to Step 5 “Final steps for both product families:”
Water
valve
elbow
Section 3B: Installation: For the P8AC Version: Versacooler II
12

2. Remove tar tape from
the insulation on the
outlet tube.
Remove tar tape
3. Pull back insulation and cut
the copper tube with a
tubing cutter. Cut where
there is at least 1 inch of
straight tubing on each side
of the cut.
4. Install TEE fitting by
connecting the copper
tubing to each end. Then
install the 32” piece of
plastic tubing to the TEE
branch.
32” plastic
tubing
(supplied)
Section 3B: Installation: For the P8AM Version: Versacooler I
13

Section 3B: Installation: Final steps for both product families:
14
5. Feed tube up through the top and attach the top to the cooler.
TIP: For the P8AM, it is easier to
connect the outlet tube to the bubbler if
the front nose is removed.
To solenoid valve inlet.

Section 3C: Installation
C: Mounting the frame to the wall
1. Place rubber gasket on top of the cooler so it is centered left/right
and against the wall.
15
2. Set the wall frame onto the gasket. Center it left/right and push it against
the wall and mark hole locations for wall fasteners. The gasket will set
the frame at the proper height.
Use mounting slots that
will provide the proper
securing location.
Make sure to pull
the plastic tubing
up through the hole
in the frame.
Rubber Gasket
3. Secure frame to the wall with fasteners (not provided). Pull plastic
tubing up through the hole in the frame.
Connects to the
solenoid valve
inlet.

4. Slide sponge tubing insulation over water line. Connect the tubing to
the INLET of the solenoid on the back of the Hands-free Bottle Filler
assembly.
Connect tube
to inlet of the
valve
Plastic tubing
Section 3C: Installation
Sponge tubing
insulation
16

5. Install bottle filler tether with the steps below.
Section 3D: Installation
17
Attach the tether line assembled to the bottle
filler dispense bracket to the cleat on the
mounting frame.
1. 2.
3. 4.
Push loop through hole. Put loop around one side
of the cleat.
Pull loop around other
side of the cleat. Pull tight.
D: Attaching the Tether

18
The tether keeps the bottle filler secured to the frame when changing the
filter, if installed. Make sure the tether is installed properly to avoid
accidental damage to the unit.
Section 3: Installation
6. Before the Bottle Filler cabinet is set into place, feed the terminals on
the power supply power cord and the long green ground wire through
the bushing on the cooler top.
7. Connect male terminals on the bottle filler power supply to female
terminals on power cord. Make sure that the power cord is firmly
connected to the power supply.
8. Attach the long green ground wire to cooler power cord ground located
on cooler frame or to electrical box ground.

9. MAKE SURE the cabinet fits into the groove in the rubber gasket on
both sides and front of the wrapper.
Bottle
Filler
cabinet
Groove in the gasket
Section 3: Installation
19
See next page to secure Bottle Filler assembly to frame
with torx screws.

Section 3D: Installation
10. Attach Bottle Filler assembly to the frame using two (2) torx screws.
Remove the Top Cap and two (2) torx screws used for mounting.
11. Plug bottle filler cord into the electrical outlet. The bottle filler will
auto-calibrate and be set up specifically for that installation. Refer to
the program guide on next page for further programming. Access
programing Pushbutton through top of Bottle Filler.
12. Turn ON water supply and check for leaks. Place a container in the
alcove to release any trapped air from the system.
13. If everything works correctly, place the Top Cap back on the Bottle
Filler and the two (2) torx screws to fasten it in place. Otherwise,
calibrate the sensor per the instructions on the next page.
Insert bottle
INSTALLATION COMPLETE
20
Torx screw
Torx screw
