OMC-131 True wind display Users’ manual
V1.14
Page 2 TDC-April-2017
Index
INDEX..............................................................................................................................................2
1. GENERAL ...................................................................................................................................4
2. INSTALLATION ..........................................................................................................................6
2.1. MECHANICAL............................................................................................................................................6
2.2. ELECTRICAL.............................................................................................................................................6
2.2.1 General system layout....................................................................................................................6
2.2.2 Power supply settings.....................................................................................................................7
2.2.3 Connections ....................................................................................................................................8
2.2.4 I/O Ports ........................................................................................................................................9
2.2.5 Input jumper settings Port 1............................................................................................................9
2.2.6 Output jumper settings....................................................................................................................9
2.2.7 Jumper settings port 2 –4.............................................................................................................10
2.2.8 Serial input Port 1: Wind sensor (Portside) input ........................................................................11
2.2.9 Serial input Port 2: Wind sensor (Starboard) or speed log (VHW) input .....................................11
2.2.10 Serial input Port 3: Gyro (HDT) or combined heading & speed (VHW).....................................11
2.2.11 Serial input Port 4: GPS (GGA & VTG)....................................................................................12
2.2.12 Serial input output Port 5............................................................................................................13
2.2.13 Analogue input output Port 6......................................................................................................14
3. COMMISSIONING.....................................................................................................................16
3.1 WIND SENSORS RELATIVE WIND INFORMATION..........................................................................................16
3.2 TRUE WIND INFORMATION........................................................................................................................17
3.3 COMMUNICATION AND PORTS ..................................................................................................................18
3.3.7 Message format ............................................................................................................................19
3.4 FUNCTIONS VIA FRONT PANEL..................................................................................................................20
3.4.1 Units and averaging settings........................................................................................................20
3.4.2 Lamp test.......................................................................................................................................20
3.4.3 Gust reset......................................................................................................................................20
3.4.4 Vessel Heading & Speed information............................................................................................20
3.4.5 Status led’s GPS & Gyro ...............................................................................................................20
4. MAINTENANCE ........................................................................................................................21
5. SETTING UP PROCEDURE.....................................................................................................22
5.1 INPUT DEVICE .........................................................................................................................................23
5.2 SET OUTPUT DEVICE ...............................................................................................................................26
5.3 SET AVERAGE OF CHANNELS ...................................................................................................................27
5.4 SET OPTIONS..........................................................................................................................................27
5.5 ALL SETTINGS .........................................................................................................................................28
