UNPACKING
After unpacking unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing,
or damaged parts. If any damage is observed, a shipping
damage claim must be filed with the carrier. DO NOT use
OEMTOOLS™ Manual Fluid Evacuator if broken, bent,
cracked or damaged parts (including labels) are noted. Any
Manual Fluid Evacuator that appears damaged in any way,
operates abnormally or is missing parts should be removed
from service immediately. If you suspect that the Manual
Fluid Evacuator was subjected to a shock load (a load that
was dropped suddenly, unexpectedly, etc.), immediately
discontinue use until it has been checked by a factory
authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 24936
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
MANUAL FLUID EVACUATOR
2 GALLON (8 L)
1
11/18
2018 OEMTOOLS™
The following safety information is provided as a guideline to help you operate your Manual Fluid Evacuator under the safest
possible conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions
are not known or not followed. The following safety instructions are to provide the user with the information necessary for safe
use and operation. Please read and retain these instructions for the continued safe use of your Manual Fluid Evacuator. Failure
to follow instructions listed below may result in serious injury. In addition, make sure that anyone who uses the equipment
understands and follows these safety instructions as well.
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues
arising from modification. We strongly recommend that this product is not modified and/or used for any application other than that
for which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first
contacted customer service to determine if it can or should be performed on the product.
WARNING:This product can expose you to chemicals, including DEHP and lead, which are known to the State of
California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Explanation of Safety Signal Words
WARNING:Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES:Provide clarity and helpful information.
WARNING

2
Operating Instructions and Parts Manual 24936
11/18
2018 OEMTOOLS™
MANUAL FLUID EVACUATOR
2 GALLON (8 L)
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn the tool’s
applications and limitations, as well as potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark work areas
invite accidents.
3. Keep children away. All children should be kept away from the
work area. Never let a child handle a tool without strict adult
supervision.
4. DO NOT operate this tool if under the influence of alcohol or drugs.
Read warning labels on prescriptions to determine if your judgment
or reflexes are impaired while taking drugs. If there is any doubt,
DO NOT attempt to operate.
5. Use safety equipment. Eye protection should be worn at all times
when operating this tool. Use ANSI approved safety glasses.
Everyday eyeglasses are NOT safety glasses. Dust mask, non-skid
safety shoes, hard hat or hearing protection should be used in
appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-ties, rings,
bracelets or other jewelry may present a potential hazard when
operating this tool. Keep all apparel clear of the tool.
7. DO NOT overreach. Keep proper footing and balance at all times
when operating this tool.
8. Check for damage. Check your tool regularly. If part of the tool is
damaged, it should be carefully inspected to make sure that it can
perform its intended function correctly. If in doubt, the part should
be repaired. Refer all servicing to a qualified technician. Consult
your dealer for advice.
9. Keep away from flammables. DO NOT attempt to operate this tool
near flammable materials or combustibles. Failure to comply may
cause serious injury or death.
10. Store idle tools out of the reach of children and untrained persons.
Tools may be dangerous in the hands of untrained users.
11. Maintain tools with care.
12. Keep tools dry and clean.
13. Properly maintained tools are less likely to bind and are easier to
control. DO NOT use a damaged tool. Tag damaged tools “DO NOT
USE” until repaired.
14. Check for misalignment or binding of moving parts, breakage of
parts, and any other condition that may affect the tool’s operation.
15. If damaged, have the tool serviced before using. Many accidents
are caused by poorly maintained tools.
16. Use only accessories that are recommended by the manufacturer
for your model. Accessories that may be suitable for one tool may
become hazardous when used on another tool.
17. Tool service must be performed only by qualified repair personnel.
Service or maintenance performed by unqualified personnel could
result in a risk of injury.
18. When servicing a tool, use only identical replacement parts. Use
of unauthorized parts or failure to follow maintenance instructions
may create a risk of injury.
19. Maintain a safe working environment. Keep the work area well lit.
Make sure there is adequate surrounding workspace. Keep the
work area free of obstructions, grease, oil, trash, and other debris.
DO NOT use this product in a damp or wet location.
SAFETY RULES & INSTRUCTIONS FOR
THIS PRODUCT
1. Maintain labels and nameplates on this product. These carry
important information. If unreadable or missing, contact
OEMTOOLS
™
for a replacement.
2. Keep the handle dry, clean, and free from brake fluid, oil, and grease.
3. Before use, read and understand all warnings, safety precautions,
and instructions as outlined in the vehicle manufacturer’s service
manual. It is beyond the scope of this manual to properly describe
the correct procedure and test data for each vehicle.
4. Always perform vehicle service in a properly ventilated area. Never
run an engine without proper ventilation for its exhaust. Stop work
and take necessary steps to improve ventilation in the work area
if you develop momentary eye, nose, or throat irritation as this
indicates inadequate ventilation.
5. Engine parts that are in motion and unexpected movement of a
vehicle can injure or kill. When working near moving engine parts,
wear snug fit clothing and keep hands and fingers away from moving
parts. Keep hoses and tools clear of moving parts. Always stay clear
of moving engine parts. Hoses and tools can be thrown through
the air if not kept clear of moving engine parts. The unexpected
movement of a vehicle can injure or kill. When working on vehicles
always set the parking brake or block the wheels.
6. Be alert for hot engine parts to avoid accidental burns.
7. If you drove your car recently, fluids could be very hot. Allow at
least 2 hours before you handle any fluids. Oil and coolant burns
are very dangerous.
8. Avoid accidental fire and/or explosion. DO NOT smoke near engine
fuel and battery components.
9. Never remove the cap from the radiator or expansion tank while the
engine is at operating temperature.
10. Always allow the engine to cool before removing the radiator cap or
expansion tank cap. The cooling system is under pressure. Failure to
allow the engine to cool before attempting to remove the cap could
result in serious injuries.
11. The warnings, precautions, and instructions discussed in this manual
cannot cover all possible conditions and situations that may occur.
The operator must understand that common sense and caution are
factors which cannot be built into this product, but must be supplied
by the operator.
12. For safety purposes and the prevention of damage to expensive
components, it is advised that the user understand basic automotive
repair and have a working knowledge of automotive systems.
13. We believe the information contained herein to be reliable. However,
general technical information is given by us without charge and the
user shall employ such information at his own discretion and risk. We
assume no responsibility for results or damages incurred from the
use of such information in whole or in part. Always refer to specific
instructions and technical information supplied by vehicle manufacturer.
14. The manufacturer declines any and all responsibility for damage
to vehicles or components if said damage is the result of unskillful
handling by the operator or of failure to observe the basic safety rules
set forth in the instruction manual.
15. Used oil, antifreeze, brake fluid and transmission fluid contain
chemical compounds that can be harmful to humans and animals.
When managed properly, used oil may again be of beneficial use.
Used oil may be blended and recycled as a heating or industrial fuel
and also may be re-refined and made into new lubricants. Persons
who perform maintenance on their own vehicles are responsible
for managing the used fluids in a manner that is protective of
human health and the environment and to follow all local laws and
regulations concerning their disposal.
DISPOSAL
At the end of the useful life of the Manual Fluid Evacuator, dispose of
the components according to all local, state, and federal regulations.

3
Operating Instructions and Parts Manual 24936
11/18
2018 OEMTOOLS™
MANUAL FLUID EVACUATOR
2 GALLON (8 L)
PURPOSE
The OEMTOOLS™ 24936 Manual Fluid Evacuator is designed for
the extraction of all types of engine, transmission and lubricating oils
from cars, motorcycles, marine engines and industrial machinery. Also
suitable for low viscosity fluid such as water or coolant.
PRODUCT SPECIFICATIONS
Reservoir Capacity 2 Gallon (8 L)
Operation Manual/Pneumatic
Application Lubricating Oils, ATF, Coolant, Brake Fluid,
Water, Other Low Viscosity Fluids
SPECIFIC SAFETY INSTRUCTIONS
AND WARNINGS
CAUTION:This equipment is intended for professional use only
and only for the applications specified in in this manual.
CAUTION:DO NOT attempt to extract fluids at temperatures
greater than 175°F (80°C).
CAUTION:This equipment is designed for servicing a variety of
vehicles; however, differences in makes and models may not allow this
equipment to be used as intended by the manufacturer. DO NOT attempt
to force this equipment to fit an application for which it was not designed.
CAUTION:In addition to the guidelines set by this manual,
always follow the manufacturer provided vehicle maintenance manual
prior to attempting service of any kind.
WARNING:DO NOT use this equipment with gasoline or other
flammable liquids or with fluids at temperatures above 175°F (80°C).
WARNING:Keep away from open flames or excessive heat.
WARNING:To extract certain fluids, the vehicle may need to
be lifted. Practice extreme caution when using lifting equipment, and
ensure that the proper lifting equipment is utilized.
WARNING:Prior to inserting the extraction hoses into
any dipstick tube/fluid reservoir, ensure that the extraction hoses
are clean of any residual fluids. This could cause contamination,
potentially leading to system failure.
WARNING: This system creates a vacuum, thus creating
pressurized fluid. While operating, ensure secure fittings and always
check the system pressure prior to disconnecting any hose.
ASSEMBLY
The Main Extraction Reservoir is fully assembled.
1. Remove the unit and all pieces from the packaging.
2. Refer to the parts list to ensure all pieces are present.
3. Press the Main Suction Hose into the receiving hole on the
Reservoir Cap. Press in until snug against the cap. The O-Ring will
hold the Main Suction Hose in place during operation.
4. Ensure that the Reservoir Lid is properly secured to the Reservoir.
PREPARING FOR OPERATION
1. Park the vehicle on a level surface, free from obstruction. Put the
vehicle in park or neutral; apply the parking brake.
2. If extracting oil, start the engine and allow the engine to idle until it
has reached normal operating temperature. Turn the engine off.
NOTE:If extracting coolant, DO NOT follow Step 2. Allow the engine
to cool completely before proceeding.
EXTRACTING OIL THROUGH THE DIPSTICK TUBE
1. Insert the Dipstick Tube Adapter into the vehicle’s dipstick tube until
it reaches the bottom of the oil pan.
NOTE:DO NOT bend the Dipstick Tube Adapter while inserting the
adapter into the dipstick tube.
2. Connect the Main Suction Hose to the inserted Dipstick Tube Adapter.
NOTE:Ensure that the hose connections are tight to prevent leakage
during the extraction process.
3. Press the Main Suction Hose into the Reservoir Cap as described in
the assembly instructions.
NOTE:Ensure that the Vacuum Release Plug is fully inserted in the
lower receiving hole prior to operation. If the Vacuum Release Plug is
not inserted, a vacuum will not be created.
4. Pump the Evacuator Handle several times to create a vacuum. The
oil will flow through the Suction Hose Assembly into the Reservoir
until it has all been extracted OR until maximum reservoir capacity
has been reached.
5. Disconnect the Main Suction Hose from the Dipstick Tube Adapter.
6. Disconnect the Main Suction Hose from the Reservoir Cap. Pour
the used oil from the Reservoir into a suitable container. Dispose of
used oil in accordance with federal, state and local regulations.
EXTRACTING COOLANT FROM A RADIATOR
OR EXPANSION TANK
WARNING: DO NOT remove the cap from the radiator or
expansion tank while the engine is at operating temperature. This
system is under pressure and could cause serious injury. ALWAYS
allow the engine to cool completely prior to removing the radiator
cap or expansion tank cap.
1. See “Preparing for Operation” instructions above. Allow the engine
to cool completely.
2. Remove the radiator or expansion tank cap.
3. Insert the appropriate diameter Suction Hose Adapter into the
radiator or expansion tank until it reaches the bottom.
NOTE:DO NOT bend the Suction Hose Adapter while inserting the
Hose Adapter into the radiator.
4. Connect the Main Suction Hose to the inserted Suction Hose Adapter.
NOTE:Ensure that the hose connections are tight to prevent leakage
during the extraction process.
5. Press the Main Suction Hose into the Reservoir Cap as described in
the assembly instructions.
NOTE:Ensure that the Vacuum Release Plug is fully inserted in the
lower receiving hole prior to operation. If the Vacuum Release Plug is
not inserted, a vacuum will not be created.
6. Pump the Evacuator Handle several times to create a vacuum.
The coolant will flow through the Suction Hose Assembly into the
Reservoir until it has all been extracted OR until maximum reservoir
capacity has been reached.
7. Disconnect the Main Suction Hose from the Suction Hose Adapter.
8. Disconnect the Main Suction Hose from the Reservoir Cap. Pour the
used coolant from the Reservoir into a suitable container. Dispose of
used coolant in accordance with federal, state and local regulations.
EXTRACTING BRAKE FLUID FROM THE
MASTER CYLINDER
1. See “Preparing for Operation” instructions above.
2. Clean the exterior of the master cylinder and master cylinder cap to
prevent dirt and debris from entering the master cylinder when the
cap is removed.

4
Operating Instructions and Parts Manual 24936
11/18
2018 OEMTOOLS™
MANUAL FLUID EVACUATOR
2 GALLON (8 L)
3. Insert the appropriate diameter Suction Hose Adapter into the
master cylinder reservoir.
NOTE:DO NOT bend the Suction Hose Adapter while inserting the
hose adapter into the reservoir.
4. Connect the Main Suction Hose to the inserted Suction Hose Adapter.
NOTE:Ensure that the hose connections are tight to prevent leakage
during the extraction process.
5. Press the Main Suction Hose into the Reservoir Cap as described in
the assembly instructions.
NOTE:Ensure that the Vacuum Release Plug is fully inserted in the
lower receiving hole prior to operation. If the Vacuum Release Plug is
not inserted, a vacuum will not be created.
6. Pump the Evacuator Handle several times to create a vacuum. The
brake fluid will flow through the Suction Hose Assembly into the
Reservoir until it has all been extracted OR until maximum reservoir
capacity has been reached.
7. Disconnect the Main Suction Hose from the Suction Hose Adapter.
8. Disconnect the Main Suction Hose from the Reservoir Cap. Pour the
used brake fluid from the Reservoir into a suitable container. Dispose
of used coolant in accordance with federal, state and local regulations.
EXTRACTING POWER STEERING FLUID FROM
THE POWER STEERING FLUID RESERVOIR
1. See “Preparing for Operation” instructions above.
2. Clean the exterior of the power steering fluid reservoir and
reservoir cap to prevent dirt and debris from entering the master
cylinder when the cap is removed.
3. Insert the appropriate diameter Suction Hose Adapter into the
master cylinder reservoir.
NOTE:DO NOT bend the Suction Hose Adapter while inserting the
Hose Adapter into the reservoir.
4. Connect the Main Suction Hose to the inserted Suction Hose Adapter.
NOTE:Ensure that the hose connections are tight to prevent leakage
during the extraction process.
5. Press the Main Suction Hose into the Reservoir Cap as described in
the assembly instructions.
NOTE:Ensure that the Vacuum Release Plug is fully inserted in the
lower receiving hole prior to operation. If the Vacuum Release Plug is
not inserted, a vacuum will not be created.
6. Pump the Evacuator Handle several times to create a vacuum. The
power steering fluid will flow through the Suction Hose Assembly
into the Reservoir until it has all been extracted OR until maximum
reservoir capacity has been reached.
7. Disconnect the Main Suction Hose from Suction Hose Adapter.
8. Disconnect the Main Suction Hose from the Reservoir Cap. Pour
the used power steering fluid from the Reservoir into a suitable
container. Dispose of used coolant in accordance with federal, state
and local regulations.
PARTS LIST
MAINTENANCE
1. Always store the Manual Fluid Evacuator in a well-protected
area where it will not be exposed to inclement weather, corrosive
vapors, abrasive dust, or any other harmful elements.
2. Keep the Manual Fluid Evacuator clean for better and safer
performance.
3. Inspect Reservoir, Hoses, Caps, Gaskets, Seals, Gauge and Adapters
periodically and, if damaged, replace them.
4. Rinse the evacuator reservoir, pump, adapter, and tubes with clean
solvent or engine degreaser, and allow them to dry thoroughly.
OEMTOOLSTM ONE YEAR WARRANTY
For up to one year from the date of purchase of this OEMTOOLS™ product, if you find any defect in material or workmanship (through normal usage), return it to the place of
purchase or to OEMTOOLS™ for repair or replacement at our discretion. In order to obtain this service, send the product and proof of purchase (transportation pre-paid) to:
OEMTOOLS™ Q.A. Dept, 3580 E. Raines Road #3, Memphis, TN 38118.
We will not be responsible for lost or damaged goods during transportation; please insure your package. If our inspection verifies the defect, we will either repair or replace the
product, or we may elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but if
we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS™ does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™ will not provide any warranty for products subjected to
abnormal use. Abnormal use includes (but is not limited to) abuse, accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover
bits, blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits, files, and batteries as necessary. OEMTOOLS™
reserves the right to make any changes in construction or design at any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS™ makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of one year from the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential damages arising from the use of our product.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY IS
EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific
legal rights, and you may also have other rights, which vary from state to state.
Don’t forget to register your new OEMTOOLS™ product at www.oem-tools.com.
Figure Description
A Extraction Reservoir
BExtraction Reservoir
Cap
C
Main Suction Hose
Receiving Hole
D Main Suction Hose
E Dipstick Tube Adapter
F Suction Hose Adapter
G Manual Pump Handle
H Base
I
Vacuum Release Plug
(not shown)
A
H
E
D
B
F
C
G
