Office Star Products SPACE FLEX 88 Series User manual

WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and
knobs are securely tightened.
3. Check that all bolts screws and knobs are tight every
three months or as needed.
4. Dispose of packing material properly. Do not use
plastic cover as head covering. It may cause
suffocation.
5. Do not use chair as a stepladder.
6. Use this chair for its intended purpose only.
7. Use mild detergent only for cleaning.
LIMITED WARRANTY
SPACE®chairs are warranted* from the date of purchase against failure due to material and workmanship as follows:
 •Lifetimeoncomponentpartsincludingpneumaticcylinder,controlmechanism,baseandcasters.
 •3Yearsonupholsteryfabricandfoamagainstwearanddeterioration.
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or
consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a five
year warranty on all parts applies. Fabric is warranted for one year. Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrightswhichvary
fromstatetostate.
To make a warranty claim, contact Parts Department via e-mail parts@officestar.net, by Fax [phone], or toll free parts
number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacic Time. Provide model number and description of the
problem and obtain conrmation number. At it’s option Ofce Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer’s component.
It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight on components
covered by warranty will be paid by Ofce Star Products.
FEATURES
• PNEUMATIC SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and lift lever
(1). To lower seat height sit on chair and lift lever (1).
NOTE: It is normal for chair to slightly lower under
body weight.
• 2-TO-1 SYNCHRO TILT ADJUSTMENT
For individual comfort, this chair has been equipped
with an adjustment that will allow the user to change the
tension of the tilting feature. Turn knob (2) clockwise
to increase tension and counter-clockwise to decrease
or ease the tension. To lock return chair to the upright
position, push lever (1) in. To unlock pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment knob
completely.
• ARM HEIGHT ADJUSTMENT
 Toadjustarmheight,liftlever(3)toallowthearmstomoveupor
downfreely.Releaselever(3)oncethedesiredheightisreached.
• ARM PAD ADJUSTMENT
 Toslidearmpadforwardsorbackwards,pressbutton(4)inand
slidearmpadtodesiredpostion,releasebutton(4)tolock
 intoposition.
88 SERIES
SPACE FLEX™ MANAGER’S CHAIR
OPERATING INSTRUCTIONS
1
2
3
4

PART QTY
1. Base ....................1
2. Casters ..................5
3. Pneumatic Cylinder .........1
4. Seat Plate ................1
5. Seat Cushion ..............1
6. Back Assembly . . . . . . . . . . . . 1
7. Arms (7L & 7R) . . . . . . . . . . . . 2
8. Arm Screws ...............6
9. Allen Screws ..............3
10. Seat Plate Screws . . . . . . . . 4
11. Back Support (pre-installed) . 1
12. Allen Wrench .............1
10
12
8
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 InsertveCasters(2)intoBase(1),pushharduntilyoufeelorheartheCaster(2)snapintoplace.
STEP 2 AlignholesofArms(7L&7R)withholesofSeatCushion(5),secureArms(7L&7R)usingthreeArmScrews(8)foreachArm,
FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (12).
STEP 3AttachSeatPlate(4)toSeatCushion(5)withthearrowtowardsthefrontofthechair,usingfourSeatPlateScrews(10),
FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (12).
STEP 4 AttachBackSupport(11)toSeatPlate(4)usingthreeAllenScrews (9),FULLY TIGHTEN ALL SCREWS
USING ALLEN WRENCH (12).
STEP 5 InsertPneumaticCylinder(3)intoBase(1),placetheassembledseatontopofPneumaticCylinder(3)andapplydownwardpressure.
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
©OfceStarProductsJune2008
5
6
3
1
1
7L
7R
11
9
12
x3
x3
x4
2
STEP 1 STEP 2 STEP 3
STEP 4 STEP 5
x3
5
8
x5
12
4
4
88 SERIES
SPACE FLEX™ MANAGER’S CHAIR
ASSEMBLY INSTRUCTIONS
