Office Star Products Pro-Line II 8000 User manual

8000 / 8001
EXECUTIVE LEATHER CHAIR
OPERATING INSTRUCTIONS
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and
knobs are securely tightened.
3. Check that all bolts screws and knobs are tight every
three months or as needed.
4. Do not overturn back tilt knob when decreasing
tension.
5. Dispose of packing material properly. Do not use
plastic cover as head covering. It may cause
suffocation.
6. Do not use chair as a stepladder.
7. Use this chair for its intended purpose only.
8. Use mild detergent only for cleaning.
LIMITED WARRANTY
Pro-Line II chairs are warranted* from the date of purchase against failure due to material and workmanship as follows:
 •Lifetimeoncomponentpartsincludingpneumaticcylinder,controlmechanism,baseandcasters.
 •3Yearsonupholsteryfabricandfoamagainstwearanddeterioration.
Tomakeawarrantyclaim,contactPartsDepartment.Providemodelnumberanddescriptionoftheproblemandobtainreturnauthorization.
Atit’soptionOfceStarProductswill:
 (a)Supplycompatiblecomponentsofcurrentmanufacture.
 (b)Repairthecustomer’scomponent.Thecustomermustprepayfreightonanycomponentsreturnedtothefactory.
  ReturnfreightoncomponentsstillinwarrantywillbepaidbyOfceStarProducts.
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or
consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a five
year warranty on all parts applies. Fabric and foam is warranted for one year. Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrights
whichvaryfromstatetostate.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts
are damaged or missing. Our Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail
parts@officestar.net, by Fax [phone], or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00
p.m. Pacific Time.
FEATURES
• SEAT HEIGHT ADJUSTMENT
To raise seat remove pressure from seat and lift lever
(1). To lower seat height sit on chair and lift lever (1).
NOTE: It is normal for chair to slightly lower under body
weight.
• LOCKING TILT ADJUSTMENT
For individual comfort, this chair has been equipped
with an adjustment that will allow the user to change
the tension of the tilting feature. Turn knob (2)
clockwise to increase tension and counter-clockwise
to decrease or ease the tension. To lock return chair
to the upright position and push lever (1) in.
To unlock pull lever (1) out.
NOTE: Be careful not to loosen back tilt adjustment
knob completely.
8001
(not shown)
12

8000 / 8001
EXECUTIVE LEATHER CHAIR
ASSEMBLY INSTRUCTIONS
©OfceStarProductsJanuary2012
PA R T QTY
1. Base .......................1
2. Casters .....................5
3. Pneumatic Cylinder ............1
4. Mechanism ..................1
5. Seat Cushion .................1
6. Back Assembly ...............1
7. Backrest Screw ...............4
8. Arm (8L & 8R) ................2
9. Arm Screw ...................4
10. Mechanism Screw ............4
11. Flat Washer .................4
12. Back Support (Pre Installed) ....1
13. Allen Wrench (not shown) ......1
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 InsertveCasters(2)intoBase(1),pushharduntilyoufeelorheartheCaster(2)snapintoplace.InsertPneumaticCylinder(3)intoBase(1).
STEP 2 AttachBackSupport(12)torearofSeatCushion(5)usingfourFlatWashers(11)andfourBackrestScrews(7).AlignholesinArms(8L&8R)with
holesofSeatCushion(5)andBackAssembly(6).SecureArms(8L&8R)usingtwoArmScrews(9)foreachArm(8).
FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (13).
STEP 3AttachMechanism(4)toSeatCushion(5)witharrowtowardsfrontofchairusingfourMechanismScrews(10).
FULLY TIGHTEN ALL SCREWS USING ALLEN WRENCH (13). PlaceassembledseatonPnuematicCylinder(3)andapplydownwardpressure.
ATTENTION: MAKE SURE ALL SCREWS ARE FULLY TIGHTENED BEFORE USING CHAIR.
6
9
3
2
1
12
5
8R
11
7
10
4
8L
