OfficeSource PLT147T User manual

Remove all wrapping materials, including staples & packing straps before you start to assemble.
Check to be sure that you have all parts and hardware.
Keep all hardware parts out of reach of children.
Do not tighten all screws/bolts until all completely assembled.
Place all wooden parts on a clean , soft surface to prevent the parts from being scratched.
IMPORTANT NOTE :
PAGE 1 OF 4
OPTION 1
These instructions apply to all models shown below.
ASSEMBLY INSTRUCTION FOR BULLET TOP
REV 1 PLT147T_AI
OPTION 2
A
E
B
F
A
C
B
D

KLIX CAM INSTRUCTIONS
Insert the cam with the arrow
pointing towards the hole in the
edge.
Line up Cam Lock,
turn clockwise.
1 2
Insert the Cam Lock into Klix
Cam. Turn Klix Cam to lock.
3
A
TOP PANEL
+
PAGE 2 OF 4
+
DA
COMPONENTS :
REV 1
END PANEL
B
++
SMALL MODESTY
C D
+
METAL LEG
++
Housing Cap Long
2 Pcs
Cam Lock
6 Pcs
B1
Klix Cam
6 Pcs
B2 B3 B5 B6 B7
D2
Adjustable Glide
2 Pcs
6 Hole L-Bracket
5 Pcs
Screw #6 x 58"
30 Pcs
JCBC
M6 x 15mm
4 Pcs
M4 x 65
Allen-Key
1 Pc
HARDWARE:
Hardware pack with PLTEP36
Hardware pack with PL142-A1
PLT147T PLTEP36 PL142-A1 MS725
PLT147T PLTEP36 PL4706FMP MS725E
TOP PANEL END PANEL FULL MODESTY METAL LEG
E F
ASSEMBLY INSTRUCTION FOR BULLET TOP
D1
B8
M4 x 65
Allen-Key
1 Pc
Hardware pack with MS725
F2
JCBC
M6 x 15mm
4 Pcs
M4 x 65
Allen-Key
1 Pc
F5F1
JCBC
M3.5 x 16mm
4 Pcs
Hardware pack with MS725E
F3
System 5
KD Fitting
3 Pcs
F4
Klix Cam
3 Pcs
Housing Cap Short
4 Pcs
B4
PLT147T_AI
Housing Cap
2 Pcs
Cam Lock
2 Pcs
C1
Klix Cam
2 Pcs
C2 C3 C4 C5 C6 C8
Adjustable Glide
2 Pcs
Hole Plug 8mm
6 Pcs
D-Nuts cap m6
6 Pcs
M4 x 65
Allen-Key
1 Pc
C7
Hole Plug 15mm
2 Pcs
C9
Dowel M8X30
4 Pcs

PAGE 3 OF 4
REV 1
C
A
B
A
C
B
1
2
B7
B6
Attach the L-Brackets (B6) to Top
Panel (A), Side Panel (B) and Side
Center Panel (C) as shown. Tighten
Screws (B7) securely.
Attach the Small Modesty Panel (C)
and Side Panel (B) to Top Panel(A) by
using Cam Lock (B1/C1) and Klix Cam
(B2/C2).
D1
Attach the Metal Leg (D) to Top Panel
(A) with JCBC Bolts (D1).
D
1
Attach the Full Modesty Panel (E)
to Side Panel (B) by using Cam
Lock (B1) and Klix Cam (B2).
E
B
OPTION 1
OPTION 2
ASSEMBLY INSTRUCTION FOR BULLET TOP
PLT147T_AI

PAGE 4 OF 4
REV 1
4 5
B4/C4
Screw Adjustable Glide (B4/C4)
into bottom of Side Panel (B) and
Modesty Panel (C/E).
B3/B4/C3
Attach Housing Cap(B3/B4/C3) to
all Klix Cam(B2/C2) by pushing
neck thought center of cam.
E
B
2
F
A
E
B
3
F2
Attach the Metal Leg (F) to
Top Panel (A) with JCBC
Bolts (F2).
F
ASSEMBLY INSTRUCTION FOR BULLET TOP
Attach the Metal Leg (F) to Full
Modestry Panel (E) by using System 5
KD Fitting (F3) and Klix Cam (F4).
F1
Secure Metal Leg (F) with
Screws (F1).
F1
B7
B6
PLT147T_AI
Attach the L-Brackets (B6) to Top
Panel (A), Side Panel (B) and Full
Modesty Panel (E) as shown.
Tighten Screws (B7) securely.
