OFM Mesa Series User manual

H
10x35mm Screw
4 Units
B
Side Panel Legs
2 Units
C
Pedestal
2 Units
D
Privacy Panel
1 Unit
F
Center Drawer
1 Unit
J
Allen Wrench
1 Unit
L
Corner
Leg Bracket
4 Units
G
6x55mm Screw
8 Units
I
6x16mm Screw
12 Units
Assembly Notes:
During assembly, hand tighten screws only. When all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this desk as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model 66360 Mesa Series Double Pedestal Teacher’s Desk
Parts Listing
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919-303-6389 (voice)
[email protected]
01.13.2014
STOP
Assembly Instructions
Tools Needed: Phillips Head Screwdriver
Please read all instructions before assembly. Assembly will require 2 people.
Step 1: Align Side Panel Legs (B) with the support rail on the underside of the Desk Top (A).
Place Corner Leg Bracket (L) in holes on support rail, and insert 10x35mm Screw (H)
through bracket and into legs. Tighten using Allen Wrench (J). Align Drawer
Runners (E) with holes in underside of the Desk Top (A). Attach using 6x16mm
Screws (I) and Phillips Head Screw Bit (K).
Step 2: Attach Pedestals (C) to underside of Desk Top (A) by aligning screw holes in
Pedestals with holes in Desk Top, and inserting 6x55mm Screws (G) to secure.
Tighten using Phillips Head Screw Bit (K) or screwdriver.
Step 3: Attach Pedestals (C) to Side Panel Legs (B) by inserting
6x16mm Screws (I) through pedestal wall and into legs.
Tighten using Phillips Head Screw Bit (K) or screwdriver.
Step 4: Attach Privacy Panel (D) to Pedestals (C) by inserting 6x16mm
Screws (I) through sides of Pedestals (C) and into side of
Privacy Panel (D).
Step 5: Flip the desk right side up using at least two people. Insert the
Center Drawer (F) backwards, as shown, aligning it with the
Drawer Runners (E). Push Center Drawer (F) all the way in to
secure.
A
Desk Top
1 Unit
E
Drawer Runners
2 Units
K
Phillips Head
Screw Bit
1 Unit
3
C
I
4
C
D
I
K
5
F
A
EE
J
L
H
B
I
1
G
B
A
2
C

66000 Series How to Remove the Pedestal Drawers
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919-303-6389 (voice)
[email protected]
03.12.2014
STOP
Drawer Removal Instructions
Please read all instructions before you begin.
All Pedestal Drawers must be removed before attaching the Pedestal to a desk.
Step 1: Stand in front of the pedestal and open the drawer you wish to remove.
Pull drawer all the way out until met with resistance.
Step 2: With both hands, place fingers underneath the open drawer on each side near the
drawer release/locking lever (highlighted below) like you would be picking up the drawer.
Keep hold of the drawer and using just your pointer finger on your right hand and your
thumb on your left hand, simultaneously push the lever UP on the right side
and push DOWN on the left side. While continuing to hold both levers in
the correct pushed position, pull the drawer out.
Step 3: To put the drawer back in, simply align the
rails on the drawer with the tracks on
the pedestal unit and push in.
Place hands here
on each side
of drawer
Push release lever
UP with index finger
on right side.
Push release lever
DOWN with thumb
on left side.
