OFM 161-MWBC User manual

Attention:Do not tighten the screws until all of them are in right positions
1 / 4
A x4 M6X15
B x16 M6X25
C x4
D x1
OR
2
1
1
1
1
2
3
Model No.161-MWBC
aX2
Tip-Over Restraint Kit
bX4 dX2
cX2
fX2
35mm length
60mm length
eX2 gX2

1
2
2 / 4
C x4
A x4
B x16
2
OR
2PCS
C
B
B
2
1
1
1
1
1
1
1
1
2
2
2
2
OR
A
A
33

3 / 4
WARNING!
Serious injury or death can occur due to furniture tip-over.
To reduce the risk of furniture tip-over:
-ALWAYS install provided tip-over restraint.
-NEVER put heavy items on top of this product.
-NEVER allowchildren to climb, stand, or hang on this furniture.
-ALWAYS have heaviest items placedon lowest shelves.
Tip-Over Restraint
Tip-Over Restraint Hardware Kit
Wood Stud
Illustra on
Drywall
Illustra on
Masonry
Illustra on
abcd
(Length 35mm) ef ( Length 60mm)
FOR Drywall Anchor Only
g
Drywall Anchor
WALL ANCHORING GUIDE:
Your wall material and furniture type will determine the wall anchoring hardware that best fits your use.
Wall Material Types: The guide below helps you to determine your wall material and the correct steps to affix the
tip over restraint to your wall material.
Drywall or plaster with available wood stud: (Hardware needed: a, b, d, e)
1. Mark the attachment point(s) at the appropriate height and positioned over wood stud(s).
2. Drive screw directly into the wood stud(s) at your mark(s).
3. Follow the appropriate visual instructions below.
Drywall without available wood stud: (Hardware needed: a, b, e, f, g)
1. Mark the attachment point(s) at the appropriate height.
2. Drill 10 mm (3/8) pilot hole(s) through the wall at your mark(s).
3. After drilling hole, insert drywall anchor completely.
4. Insert screw. Turn screw clockwise until snug
5. Follow the appropriate visual instructions below. Do not over-tighten.
Masonry: (Hardware needed: a, b, c, d, e)
1. Mark the attachment point(s) at the appropriate height.
2. Drill 8mm (5/16) pilot hole(s) into the wall at your mark(s).
3. Drive your anchoring hardware into the hole(s).
4. Follow the appropriate visual instructions below. Do not over-tighten.
If your wall material is not listed here, you have any questions regarding wall anchor hardware, or you need
assistance with locating a wood stud, please consult your local hardware retailer.
3

Wall
4
4 / 4
wall
b
a
e
In Masonry
wall
c
d
b
e
In Drywall
wall
g
f
be
