Instruction Manual
Shaker, Light Duty, SHLD0415AL
Shaker, Light Duty, SHLD0403DG
Shaker, Light Duty, SHLD0415DG
Shaker, Light Duty, SHLDMP03DG
EN - English ......... 1
FR - Français ......... 12
ES - Español ......... 24
IT - Italiano ......... 36
DE - Deutsch ......... 48
PT - Português ......... 60
NL - Nederlands ......... 72
NO - Norsk ......... 76
DA - Dansk ......... 80
SV - Svenska ......... 84
FI - Suomi ......... 88
HU - Magyar ......... 92
PL - Polski ......... 96
CZ - Czech .........100
KR - Korean .........104
JP - Japanese .........116
Revision 6
2/13/2020
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

7ඉඊඔඍ඗ඎ&඗ඖගඍඖගඛ
Package Contents . . . . . . . . . . . . 1
Service Information . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . 2
Maintenance & Servicing . . . . . . . . . . . . 2
Environmental Conditions . . . . . . . . . . . . 2
Equipment Disposal . . . . . . . . . . . . . . . 2
Safety Instructions . . . . . . . . . . . . 3
Standards & Regulations . . . . . . . . . . . . 3
Digital Control Panel . . . . . . . . . . . . 4
Orbital Shaker Specifications . . . . . . . . . . . . 5-6
Digital Microplate Shaker Specifications . . . . . . . . . . . . 7-8
Digital Microplate Operating Instructions . . . . . . . . . . . . 9-10
Analog Operating Instructions . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . 11
3ඉඋඓඉඏඍ&඗ඖගඍඖගඛ
Digital Orbital Shaker or Digital Microplate Shaker or Analog Shaker
Non-skid rubber mat (Orbital Shaker only)
Power Cord
Instruction manual
Warranty card
1
EN
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Upon receiving the Ohaus Orbital/Microplate Shaker, check to ensure that no damage
has occurred during shipment. It is important that any damage that occurred in
transport is detected at the time of unpacking. If you do find such damage the carrier
must be notified immediately.
After unpacking, place the Orbital/Microplate Shaker on a level bench or table, away
from explosive vapors. Secure to an immovable work surface by pressing down on the
four (4) corners of the unit, creating a strong suction to the work surface ('2127
place on a bench mat). Ensure that the surface on which the unit is placed will
withstand typical heat produced by the unit. Always place the unit on a sturdy work
surface.
The Orbital/Microplate Shaker is supplied with a power cord that is inserted into
the IEC connector on the back of the unit first, then it can be plugged into a properly
grounded outlet. The 120V unit plugs into a 120 volt, 50/60 Hz source. The 230V unit
plugs into a 230 volt, 50/60 Hz source.
0ඉඑඖගඍඖඉඖඋඍ຺6ඍකඞඑඋඑඖඏ
The Orbital/Microplate Shaker is built for long, trouble-free, dependable service. No
lubrication or other technical user maintenance is required. However at least every
three (3) months you should:
• Unplug the unit.
• Remove any accumulated dirt from the base and tray.
• Check all accessible items to make sure they are properly tightened.
The unit should be given the care normally required for any electrical appliance. Avoid
wetting or unnecessary exposure to fumes. Spills should be removed promptly. '2
127 use a cleaning agent or solvent on the front panel which is abrasive or harmful
toplastics,noronewhichisflammable.Alwaysensurethepowerisdisconnectedfrom
the unit prior to any cleaning. If the unit ever requires service, contact your Ohaus
representative.
2SHUDWLQJ&RQGLWLRQVIndoor use only.
*For use in CO2 environments, incubators or cold rooms.
*Temperature: -10 to 60°C (14 to 140°F)
Humidity: maximum 80% relative humidity, non-condensing
Altitude: 0 to 6,562 ft (2000 M) above sea level
1RQ2SHUDWLQJ6WRUDJH
*Temperature: -20 to 65°C (-4 to 149°F)
Humidity: maximum 80% relative humidity, non-condensing
Installation Category II and Pollution Degree 2 in accordance with IEC 664.
$YRLG FROG VWDUWV Unit is not designed to start after being in a cold room
environment.Bringunitintocoldroomfromaroomtemperatureenvironment,operate
and remove unit from cold room as soon as operation is complete.
(඙ඝඑ඘ඕඍඖග'එඛ඘඗ඛඉඔ
This equipment must not be disposed of with unsorted waste. It is your responsibility to
correctly dispose of the equipment at life-cycle-end by handing it over
to an authorized facility for separate collection and recycling. It is also
your responsibility to decontaminate the equipment in case of biological,
chemical and/or radiological contamination, so as to protect the persons
involved in the disposal and recycling of the equipment from health
hazards.
For more information about where you can drop off your waste of equipment, please
contact your local dealer from whom you originally purchased this equipment. By doing
so,you willhelptoconserve naturalandenvironmentalresourcesand youwillensurethat
your equipment is recycled in a manner that protects human health.
,ඖඛගඉඔඔඉගඑ඗ඖ (ඖඞඑක඗ඖඕඍඖගඉඔ&඗ඖඌඑගඑ඗ඖඛ
2
EN
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Please read the entire instruction manual before operating the Orbital/Microplate
Shaker.
:$51,1*'2127 use the Orbital/Microplate Shaker in a hazardous
atmosphere or with hazardous materials for which the unit was not designed.
Also, the user should be aware that the protection provided by the equipment
may be impaired if used with accessories not provided or recommended by
the manufacturer, or used in a manner not specified by the manufacturer.
Always operate unit on a level surface for best performance and maximum
safety.
'2127 lift unit by the tray.
&$87,21 To avoid electrical shock, completely cut off power to the unit
by disconnecting the power cord from the unit or unplug from the wall outlet.
Disconnect unit from the power supply prior to maintenance and servicing.
Spills should be removed promptly. '2127 immerse the unit for cleaning.
'2 127 operate the unit if it shows signs of electrical or mechanical
damage.
Earth Ground - Protective Conductor Terminal
Alternating Current
Compliance to the following standards and regulations is indicated by the corresponding mark
on the product.
Mark Standards and Regulations
OHAUS Corporation declares that the SHLD series shakers comply with directives
2011/65/EU, 2014/30/EU, 2014/35/EU and standards EN 50581, EN 61010-1, EN
61010-2-051, EN 61326-1.
This product complies with directive 2012/19/EU. Please dispose of this product in
accordance with local regulations at the collecting point specified for electrical and
electronic equipment.
EN 61326-1
CAN/CSA C22.2 61010-1, CAN/CSA C22.2 61010-2-051
UL 61010-1, UL 61010-2-051
Global Notice
Warning: This is a Class A product. In a domestic environment this product may cause radio interfer-
ence in which case the user may be required to take adequate measures.
Canada Notice
This Class A digital apparatus complies with Canadian ICES-003.
FCC Notice
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial envi-
ronment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
Changes or modifications not expressly approved by Ohaus Corporation could void the user’s authority
to operate the equipment.
6ඉඎඍගඡ,ඖඛගකඝඋගඑ඗ඖඛ 6ගඉඖඌඉකඌඛ຺5ඍඏඝඔඉගඑ඗ඖඛ
3
EN
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

The front panel of the Orbital/Microplate Shaker contains all the controls and displays
needed to operate the unit.
$6WDQGE\ EXWWRQVWDQGE\ LQGLFDWRU OLJKW The standby indicator light
will illuminate when the unit is plugged in. The unit will be in standby mode. Press
the standby button to activate the speed and time functions. The standby indicator
light will shut off and the speed display and time display will illuminate. Press the
standby button again and the unit will once again be in standby mode.
%6SHHGGLVSOD\ Displays the speed of the shaker. & Up/down arrows for set-
point control. On/off button starts/stops shaking function. ' The speed indicator
light will be illuminated when the unit is shaking.
(7LPHGLVSOD\ Displaysaccumulated time(continuousmode)orhowmuchtime
is remaining (timed mode). The display range is from 0 to 9,999 minutes in one (1)
second increments. The display will indicate minutes and seconds until the timer
reaches 99 minutes and 59 seconds (99:59), then the display will automatically
display minutes up to 9,999.
) Up/down arrows for set-point control. On/off button starts/stops the time function.
'එඏඑගඉඔ&඗ඖගක඗ඔ3ඉඖඍඔ
%
)
&
'
$
(
