OKIDATA OL400e Series Installation and operating instructions

Application Note
532 Fellowship Rd. Mount Laurel, NJ 08054 an OKI AMERICA company FAXABLE FACTS 800-654-6651
609-235-2600 Fax: [phone] OKILINK II Support BBS: 609-234-5344
Document #: Date: 02/05/96 Category: Application
Title: Control Codes for the OL400e / OL410e / OL410e-PS
Replaces Doc #:
Product Model: OL400e, OL410e, OL410e-PS
This document contains the complete command set for the OL400e, OL410e and the OL410e/PS (PCL
Mode) printer emulations. Usually these codes will be transparent to the user. We include the command
set for those software applications which require you to enter printer commands to select printer features.
About the Escape Sequences
In the sequences below, ESC represents the escape character (decimal 27,
hexadecimal 1B). The letters l and O are printed in italics to distinguish them
from the numbers 1 and 0.
The spaces in the font command sequences were added for legibility. Do not
enter them as part of a command.
In all font-related escape sequences the character `` ( '' is used to indicate
primary font characteristics. You should substitute the character`` ) '' for a
secondary font.
The font commands below include the escape sequences that specify all of each
font's characteristics. In some cases the entire sequence is not necessary to
change fonts, but if you shorten the sequence, keep two things in mind, in
order to avoid unexpected results:
Make sure that the new font you requested (bold or italic, for
example) is available.
Remember that a higher priority font characteristic will override a
lower priority one.
Escape sequences with the same beginning characters can be combined. To do
this, change the final letter of the first sequence from upper case to lower case
and omit the common characters. For example, combining proportional
spacing ESC(s1P with 10 point character height ESC(s10V results in
the following:
ESC(s1p10V
Keep in mind that there should only be one uppercase letter in a combined
sequence, and that uppercase letter must come at the end of the sequence. Also
remember that the commands are executed in the order in which they are
given.

Commands Specific to OL400e (HP LaserJet Series IIP)
OL400e Function Command Notes
Select common character pitch ASCII: ESC & k # S Dec: 27
38 107 # 83 #=0: 10 cpi #=2: 16.66 cpi #=4: 12 cpi
Primary font default ASCII: ESC ( # @ Dec: 27 40
# 64 #=0 or 1: makes default symbol set active for primary
font in current orientation
#=2: causes printer to
re-evaluate best font choice for
current specified primary font
and primary symbol set in
current orientation.
#=3: makes primary font the
default font in the current
orientation
Secondary font default ASCII: ESC ) # @ Dec: 27 41
# 64 #=0: makes default symbol set the set for secondary font in
current orientation
#=1: makes secondary symbol
set same as default primary
font in current orientation
#=2: makes secondary symbol
set same as current primary
symbol set in current
orientation
#=3: selects default secondary
font in current orientation
Specify primary font symbol
set ASCII: ESC ( # `ID' Dec: 27 40 35 `ID' #=01 through 39 (see Symbol Set Selection Commands table
below). ID=D, E, F, G, I, J, K,
M, N, Q, S, U, Y, Z, depending
on font to be engaged.
Specify secondary font symbol
set ASCII: ESC ) # `ID' Dec: 27 40 35 `ID' n=01 through 39 (see Symbol Set Selection Commands table
below). ID=D, E, F, G, I, J, K,
M, N, Q, S, U, Y, Z, depending
on font to be engaged.
Specify primary font character
spacing ASCII: ESC ( s # P Dec: 27 40 115 # 80 #=0: fixed (default) #=1: proportional
#=-1: compressed proportional
Specify secondary font
character spacing ASCII: ESC ) s # P Dec: 27 41 115 # 80 #=0: fixed (default) #=1: proportional
#=-1: compressed proportional
Specify primary font character
pitch ASCII: ESC ( s # H Dec: 27 40 115 # 72 #=characters per inch (cpi). Default is 10 cpi.

Specify secondary font
character pitch ASCII: ESC ) s # H Dec: 27 41 115 # 72 #=characters per inch (cpi). Default is 10 cpi.
Specify primary font character
height ASCII: ESC ( s # V Dec: 27 40 115 # 86 #=point size (default is 12 pt.)
Specify secondary font
character size (height) ASCII: ESC ) s # V Dec: 27 41 115 # 86 #=point size (default is 12 pt.)
Specify primary font character
style ASCII: ESC ( s # S Dec: 27 40 115 # 83 #=0: upright (default) #=1: italic
Specify secondary font
character style ASCII: ESC ) s # S Dec: 27 41 115 # 83 #=0: upright (default) #=1: italic
Specify primary font weight ASCII: ESC ( s # B Dec: 27 40
115 # 66 #=-7 to +7 #=-1 to -7: light
#=0: normal (default)
#=+1 to +7: bold
Specify secondary font weight ASCII: ESC ) s # B Dec: 27 41
115 # 66 #=-7 to +7 #=-1 to -7: light
#=0: normal (default)
#=+1 to +7: bold
Specify primary font typeface ASCII: ESC ( s # T Dec: 27 40
115 # 84 #=0: like Line Printer #=1: like Pica
#=2: like Elite
#=3: line Courier
#=4: like Helv
#=5: like Times Roman
#=6: like Gothic #=7: like Script
#=8: like Prestige
#=90: like Caslon #=10: like
Orator
#=11: like Presentations
#=14: like Swiss 721
#=15: like Dutch 801
#=17: like Optima
#=1 or 19: like Cooper Black
#=20: like Coronet Bold
#=21: like Broadway
#=22: like Bauer Bodoni Black
Condensed #=24: like Century
Schoolbook #=25: like
University Roman

Specify secondary font type
face ASCII: ESC ) s # T Dec: 27 41 115 # 84 #=0: like Line Printer #=1: like Pica
#=2: like Elite
#=3: like Courier
#=4: like Helv
#=5: like Times Roman
#=6: like Gothic
#=7: like Script
#=8: like Prestige
#=90: like Caslon
#=10: like Orator
Specify font ID ASCII: ESC * c # D Dec: 27 42
99 # 68 #=0 (default) to 32,767
OL400e Font Commands
OL400e Font Printer Command
Courier 12 point ESC(8U ESC(s 0p 10h 12v 0s 0b 3T
Courier 12 point bold ESC(8U ESC(s 0p 10h 12v 0s 3b 3T
Courier 12 point italic ESC(8U ESC(s 0p 10h 12v 1s 0b 3T
Courier 10 point ESC(8U ESC(s 0p 12h 10v 0s 0b 3T
Courier 10 point bold ESC(8U ESC(s 0p 12h 10v 0s 3b 3T
Courier 10 point italic ESC(8U ESC(s 0p 12h 10v 1s 0b 3T
Line Printer 8.5 point ESC(8U ESC(s 0p 16.66h 8.5v 0s 0b 0T
Swiss 14.4 point bold (B) ESC(0U ESC(s 1p 14.4v 0s 3b 4T
Swiss 14.4 point bold (F) ESC(8U ESC(s 1p 14.4v 0s 3b 4T
Dutch 10 point (B) ESC(0U ESC(s 1p 10v 0s 0b 5T
Dutch 10 point bold (B) ESC(0U ESC(s 1p 10v 0s 3b 5T
Dutch 10 point italic (B) ESC(0U ESC(s 1p 10v 1s 0b 5T
Dutch 10 point compressed (B) ESC(0U ESC(s -1p 10v 0s 0b 5T
Dutch 10 point compressed bold (B) ESC(0U ESC(s -1p 10v 0s 3b 5T
Dutch 10 point compressed italic (B) ESC(0U ESC(s -1p 10v 1s 0b 5T mm
OL400e Font Printer Command
Dutch 10 point (F) ESC(8U ESC(s 1p 10v 0s 0b 5T
Dutch 10 point bold (F) ESC(8U ESC(s 1p 10v 0s 3b 5T
Dutch 10 point italic (F) ESC(8U ESC(s 1p 10v 1s 0b 5T
Dutch 8 point (B) ESC(0U ESC(s 1p 8v 0s 0b 5T

Dutch 8 point compressed (B) ESC(0U ESC(s -1p 8v 0s 0b 5T
Dutch 8 point (F) ESC(8U ESC(s 1p 8v 0s 0b 5T
HP 12 point ZIP code ESC(15Y ESC(s 1p 12v 0s 0b 0T
USPS 9.1 point ZIP code, portrait orientation ESC(2X ESC(97Y ESC(s 0p 21.06h 9.1v 0s 0b
0T
USPS 9.1 point ZIP code, landscape orientation ESC(12X ESC(97Y ESC(s 0p 21.06h 9.1v 0s
0b 0T
USPS 45.1 point FIM bar, portrait orientation ESC(1X ESC(98Y ESC(s 0p 18.75h 45.1v 0s
0b 0T
USPS 45.1 point FIM bar, landscape orientation ESC(11X ESC(98Y ESC(s 0p 18.75h 45.1v 0s
0b 0T
USPS 64.6 point Stamp Here, portrait
orientation ESC(3X ESC(99Y ESC(s 0p 1.18h 64.6v 0s 0b 0T
USPS 64.6 point Stamp Here, landscape
orientation ESC(13X ESC(99Y ESC(s 0p 1.18h 64.6v 0s 0b 0T
Commands Specific to OL410e (HP4 LaserJet Series III Commands LaserJet Series III)
Font Commands
ID# Resident Fonts Command Sequence
00 Courier ESC(8U ESC(s 0p #h 0s 0b 4099T
01 Courier bold ESC(8U ESC(s 0p #h 0s 3b 4099T
02 Courier italic ESC(8U ESC(s 0p #h 1s 0b 4099T
03 Courier Italic Bold ESC(8U ESC(s 0p #h 1s 3b 4099T
04 CG Times ESC(8U ESC(s 1p #v 0s 0b 4101T
05 CG Times Bold ESC(8U ESC(s 1p #v 0s 3b 4101T
06 CG Times Italic ESC(8U ESC(s 1p #v 1s 0b 4101T
07 CG Times Bold Italic ESC(8U ESC(s 1p #v 1s 3b 4101T
08 Univers ESC(8U ESC(s 1p #v 0s 0b 4148T
09 Univers Bold (scalable) ESC(8U ESC(s 1p #v 0s 3b 4148T
10 Univers Italic ESC(8U ESC(s 1p #v 1s 0b 4148T
11 Univers Bold Italic ESC(8U ESC(s 1p #v 1s 3b 4148T
12 Line printer (bitmap) ESC(8U ESC(s 0p 16.66h 8.5v 0s 0b
0T

OL410e Feature Command Notes
OL410e Unique Commands
Down load LCD message ESC/d#W[data]
PostNet Check Digit Print ESC/b#W[data]
Begin multiple collated copies ESC/m#S
End multiple collated copies ECS/m#E
Specify copy mark ESC/m#M
Port lockout/ resume(TRAP) ESC/i#L
Auto Emulation(TRAP) ESC DEL#
Select 600dpi class graphics ESC*t600R
Download 600dpi class bitmap Font Header=20
Set 600dpi class positioning ESC&m600D
PCL V Compacted Graphics
Temporary X offset ESC*b#X # must be a multiple of 8;
max.value, #3200
Transfer raster graphics ESC*b#W #decimal ASCII number
Full graphics mode ESC*b0M
Select graphics mode 1 ESC*b1M
Select graphics mode 2 ESC*b2M
Select graphics mode 3 ESC*b3M
OL410e Feature Command Notes
PCL V Vector Graphics
Commands
Select PCL mode, specify
cursor and palette ESC%#A #0: use previous cursor and palette;
#1: use current HPGL/2 pen
and palette
Select HPGL/2 mode, specify
cursor and palette ESC%#B #0: use previous HPGL/2 pen and palette;
#1: use cur- rent PCL cursor
and palette
HPGL/2 horizontal size in
inches ESC*c#K #0.01 to 32,767.99 inches
HPGL/2 vertical size in inches ESC*c#L #0.01 to 32,767.99 inches

Anchor point at PCL cursor ESC*c0T
HPGL/2 horizontal window size
in decipoints ESC*c#X #0.01 to 32,767.99 inches
HPGL/2 vertical window size in
decipoints ESC*c#Y #0.01 to 32,767.99 inches
Reset PCL and HPGL/2 ESCE
Set PCL rotation in 90
increments ESC&a#P #0,90,180, or 270; #0: return to current default
Select transparency pattern ESC*c#T #0: solid black;
#1: solid white;
#2: current pattern; N3: current
cross-hatch pat- tern.
Select advanced graphics
source transparency ESC*L#N #0: transparent; #1: opaque
Select advanced graphics
pattern transparency ESC*L#0 #0: transparent; #1: opaque
HPGL/2 Commands
Backspace BS
Backspace HT
Line Feed LF
Carriage Return CR
Shift-in SI
Shift-out SO
Space SP
OL410e Feature Command Notes
End label code ETX
Inverse line feed:TRAP VT
Arc absolute AA x,y,arc,chd; xx coordinate; yy coordi- nate;
arcdegree of arc,
pos:counterclockwise,
neg:clockwise; chdchord
angle.
Anchor point AC x,y; Range of x, y is -67,108,863 to
67,108,863

Alternate text definition AD knd,val...,knd, val; kndintegers 1 to 7; knd1: char.
set specified and val-
32,767.9999 to 32,767.9999;
knd2: font spacing specified
and val0 or 1; knd3: font pitch
specified and val0 to
32,767.9999; knd4: font height
specified and val0 to
32,767.9999; knd5: do not use
this value; knd6: font stroke
weight and val- 7, -3, 0, 3, 7;
knd7: type- face specified and
val0 to 32,767.9999
Arc relative AR x,y,arc,chdp; xx coordinate, yy coordi- nate;
range of x and y is -67,108,863
to 67,108,863; arcdegree of
arc; chdchord angle
Arc absolute-three point AT xi,yi,xe,ye,chd; xiintermediate x coordi- nate,
yiintermediate y coor- dinate,
xeend x coor- dinate, yeend y
coordi- nate, chdchord angle;
range of xi, yi, xe, and ye is
-67,108,863 to 67,108,863
Character fill mode CF fm,ep;
Circle CI r, chd; xirradius of circle, chdchord
angle; range of r is
-67,108,863 to 67,108,863
OL410e Feature Command Notes
Character plot CP sp, lin; spnumber of char. spaces,
linnumber of char. lines; range
of sp and lin is -32,767.999 to
32,767.999
Set default values DF;
Direction absolute DI run,ris; runrun, risrise; range of run
and rise is -32,767.999to
32,767.999
Direction relative DR run,ris; runrun, risrise; range of run
and rise is -32,767.999 to
32,767.999
Define label terminator DT t,mod; t1 to 127, excluding 0, 10, 27,
59; mod0: label is printable;
mod1: label is not printable

Define variable text path DV pat,lin; pat0: text path is hori- zontal to
the right; pat1: text path is
vertical down; pat2: text path is
horizon- tal to the left; pat3:
text path is vertical up; lin0 or 1
Rectangle edge absolute EA x,y; xx coordinate, yy coordi- nate;
range of x and y is -67,108,863
to 67,108,863
Edge Polygon EP;
Rectangle edge relative ER x,y; xx coordinate, yy coordi- nate;
range of x and y is -67,108,863
to 67,108,863
Extra space ES wid, ht; Range of wid (width) and ht
(height) is -32,767.999 to
32,767.999
Wedge edge EW r,sa,sw,chd; rradius, sastart angle,
swsweep angle, chdchord
angle
Primary font by ID FI id; 3 id0 to 2048
Secondary font by ID FN id; id0 to 2048
Fill polygon FP;
Fill type FT typ,o1,o2; typ1 to 4, 10, 11; o10 to
32,767.999; o245 to -45
OL410e Feature Command Notes
Initialize IN n; n0 or 1
Input scaling points IP P1x,P1y,P2x,P2y; P1x0 to 10365 (letter) or
11040 (A4); P1y0 to 7962
(letter) or 7721 (A4); P2x0 to
10365 (letter) or 11040 (A4);
P2y0 to 7962 (letter) or 7721
(A4)
Input relative P1 and P2 IR P1x,P1y,P2x,P2y; P1x, P1y, P2x, P2y
-32,767.999 to 32,767.999
Input window points IW Xlo,Ylo,Xhi,Yhi; Xlo, Ylo, Xhi, Yhi -67,108,863
to 67,108,863

Line attributes LA knd,val...,knd,val; When knd1, val1: butt ends,
2: square ends, 3 triangular
ends, 4: round ends; when
knd2: val1: mitered joins, 2;
mitered/ beveled joins, 3:
triangular joins, 4: round joins,
5: bev- eled joins, 6: no join
applied; when knd23: val0 to
32,767.999
Label text LB c...ct c10, 13, 32 to 256, t is
previously defined by the DT
command
Line type LT typ,len,mod; typ-8 to 8, len0 to 32,767.999,
mod0 or 1
Label origin LO n; n1 to 19, excluding 10
Number of pens NP n; n2, 4, or 8
Plot absolute PA x1,y1...; Range of x1 and y1 is -
67,108,863
Pen down PD x1,y1...,xn,yn;
Polygon encoded PE flg val... x y; Range of flg is : or 7
Page advance PG n; n-32,767 to 32,767
Polygon mode PM n;
Plot relative PR x1,y1...,xn,yn;
Pen up PU x1,y1...,xn,yn;
OL410e Feature Command Notes
Pen width PW wid,pen; wid-32,767.999 to 32,767,
pen0: command ignored,
pennumber set then cur- rent
pen is used
Rectangle absolute filled RA x,y; xx coordinate, yy coordi- nate;
range of x and y is -67,108,863
to 67,108,863
User defined raster fill RF ind,wid,ht,pix...; ind1 to 8; wid8, 16, 32, or 64;
ht8, 16, 32, or 64; pix0 to
76,108,863
Rotate coordinate system RO ang; ang0, 90, 180, 270
Replot RP n; n1 to 32,767
Rectangle relative filled RR x,y; xx coordinate, yy coordi- nate;
range of x and y is -67,108,863
to 67,108,863

Relative arcThree point RT xi,yi,xe,ye,chd xiintermediate x coordinate,
yiintermediate y coordinate,
xeend x coordinate, yeend y
coordinate, chdchord angle;
range of xi, yi, xe, and ye is -
67,108,863 to 67,108,863; chd
is chord angle
Alternate character set SA n; ndecimal ASCII number
Bitmap font enable SB n; n0: bitmap fonts cannot be
selected; n1: bitmap fonts can
be selected
Scale input window points SC Xlo,Xhi,Ylo,Yhi,typ, lef,bot;
OL410e Feature Command Notes
Standard font definition SD knd,val...,knd,val; kndintegers 1 to 7; knd1: char.
set specified and val
-32,767.9999 to 32,767.9999;
knd2: fixed spacing speci- fied
and val0 or 1; knd3: font pitch
specified and val0 to
32,767.9999; knd4: font height
specified and val0 to
32,767.9999; knd5: do not use
this value; knd6: font stroke
weight and val -7, -3, 0, 3, 7;
knd7: type- face specified and
val0 to 32,767.9999
Character size absolute SI wid,ht; wid-32,767.9999 to
32,767.9999, ht -32,767.9999
to 32,767.9999
Character slant SL tan; tan-32,767.9999 to
32,767.9999
Symbol mode SM chr; ChrASCII characters with
decimal codes from 33 to 58,
60 to 126, 161, 254
Select pen SP n; n2,4,or 8, 0:cancel pen se-
lection
Character size relative SR wid, ht; wid-32,767.9999 to
32,767.9999, ht -32,767.9999
to 32,767.9999
Standard character set SS;
Screened vectors SV scr,shd,ind; scr1, 2,10, or 11; shd0 to
100% shading; ind0 to cur-
rent value; type1 or 2: solid fill,
10: shading, 11: user defined
pattern

Transparent data TD mod; mod1: transparent mode, 0:
opaque mode
Transparency mode TR Mode
User defined line type UL typ,gap...,gap; typ1 to 8, and -1 to -8; gap0 to
32,767.9999
Wedge with fill WG r,sa,sw,chd; rradius, sastart angle,
swsweep angle, chdchord
angle
Pen width unit selection WU typ
Commands used by OL400e and OL410e
OL400e/410e Function Command Notes
Carriage return ASCII CR Dec: 13
Backspace ASCII BS Dec: 08
Line feed ASCII LF Dec: 10
Half line feed ASCII: ESC = Dec: 27 61
Form feed ASCII FF Dec: 12
Font Characteristics
Select primary character set ASCII SI Dec: 15
Select secondary character set ASCII SO Dec: 14
Page Formatting
Set print orientation ASCII: ESC & l # O Dec: 27 38
108 # 79 #=0: portrait (default) #=1: landscape
Select paper size ASCII: ESC & l # A Dec: 27 38
108 # 65 #=1: executive (710) #=2: letter (811)
#=3: legal (814)
#=4: legal (813)
#=80: monarch envelope
(3.887)
#=81: business envelope
(4.139)
#=90: international DL (110
mm 220 mm)
#=91: international C5 (162
mm 229 mm)
Set page length ASCII: ESC & l # P Dec: 27 38
108 # 80 #=number of lines
OL400e/410e Feature Command Notes

Set top margin ASCII: ESC & l # E Dec: 27 38
108 # 69 #=number of lines
Set left margin ASCII: ESC & a # L Dec: 27 38
97 # 76 #=number of columns
Set right margin ASCII: ESC & a # M Dec: 27
38 97 # 77 #=number of columns
Clear left and right margins ASCII: ESC 9 Dec: 27 57
Set line spacing in lines per
inch(lpi) ASCII: ESC & l # D Dec: 27 38 108 # 68 #=lines per inch (lpi): must be 1, 2, 3, 4, 6 (default), 8, 12, 16,
24, or 48
Set text length ASCII: ESC & l # F Dec: 27 38
108 # 70 #=number of lines
Horizontal tab ASCII HT Dec: 9
Set horizontal motion index
(HMI) ASCII: ESC & k # H Dec: 27 38 107 # 72 set in increments
Set horizontal cursor position
(decipoints) ASCII: ESC & a # H Dec: 27 38 97 # 72 set in increments
Set horizontal cursor position
(dots) ASCII: ESC * p # X Dec: 27 42 112 # 88 set in increments
Set vertical motion index (VMI) ASCII: ESC & l # C Dec: 27 38
108 # 67 set in increments: 0 # 126
Move cursor vertically to line
indicated (VMI unit) ASCII: ESC & a # R Dec: 27 38 97 # 82 #=number of lines: if value of # is negative, movement is
relative to current cursor
position; if value of # is
positive, movement is
absolute.
OL400e/410e Feature Command Notes
Specify vertical cursor position
(decipoints) ASCII: ESC & a # V Dec: 27 28 38 97 # 86 set in increments: if value of # is negative, position is upward,
relative to current cursor
position; if value of # is
positive, position is downward,
relative to current cursor
position.
Specify vertical cursor position
(dots) ASCII: ESC * p # Y Dec: 27 42 122 # 89 set in increments: if value of # is negative, movement is up; if
value of # is positive,
movement is down.
Move to indicated column ASCII: ESC & a # C Dec: 27
38 97 # 67 #=number of column
Push (save) cursor position ASCII: ESC & f 0 S Dec: 27 38
102 48 83

Pop (recall) cursor position ASCII: ESC & f 1 S Dec: 27 38
102 49 83
Downloadable Fonts
Primary downloaded font
designation (ID) ASCII: ESC ( # X Dec: 27 40 # 88 32#128
Secondary downloaded font
designation (ID) ASCII: ESC ) # X Dec: 27 41 # 88 32#128
Specify ASCII value for
character to be defined ASCII: ESC * c # E Dec: 27 42 99 # 69 #=0 (default) to 255
Font/character control ASCII: ESC * c # F Dec: 27 42
99 # 70 #=0: delete all fonts #=1: delete all temporary fonts
#=2: delete current font
#=3: delete current character
code
#=4: make font temporary
#=5: make font permanent
#=6: copy/assign current font
OL400e/410e Feature Command Notes
Create font ASCII: ESC ) s # W [font data]
Dec: 27 41 115 # 87 #=number of bytes of font data to follow
Down load character ASCII: ESC ( s # W [character
data] Dec: 27 40 115 # 87 #=ASCII value of character
Raster Graphics Commands
Specify raster graphics density ASCII: ESC * t # R Dec: 27 42
116 # 92 #=number of dots per inch: 75 (default), 100, 150, or 300
Begin raster graphics mode ASCII: ESC * r # A Dec: 27 42
114 # 65 #=0: begin at left margin #=1: begin at present cursor
position
Tranfer raster graphics data ASCII: ESC * b # W [data]
Dec: 27 42 98 # 87 #=number of bytes of data to follow
End raster graphics mode ASCII: ESC * r B Dec: 27 42
114 66
Advanced Graphics
Commands
Specify advanced graphics
horizontal size (dots) ASCII: ESC * c # A Dec: 27 42 99 # 65 #=number of dots
Specify advanced graphics
horizontal size (decipoints) ASCII: ESC * c # H Dec: 27 42 99 # 72 set in increments
Specify advanced graphics
vertical size (dots) ASCII: ESC * c # B Dec: 27 42 99 # 66 #=number of dots

Specify advanced graphics
vertical size (decipoints) ASCII: ESC * c # V Dec: 27 42 99 # 86 set in increments
Specify advanced graphics
print pattern ASCII: ESC * c # P Dec: 27 40 99 # 80 #=0: black rule #=2: gray scale
#=3: predefined pattern
OL400e/410e Feature Command Notes
Specify pattern ID ASCII: ESC * c # G Dec: 27 40
99 # 71 #=1% to 100% if gray scale is selected, 1 to 6 if predefined
pattern is selected, as follows:
#=1: horizontal rules
#=2: vertical rules
#=3: diagonal rules, slanted to
right
#=4: diagonal rules, slanted to
left
#=5: fine dots
#=6: coarser dots
Macros
Specify macro ID ASCII: ESC & f # Y Dec: 27 38
102 # 89 #=0 to 32,767
Macro control function ASCII: ESC & f # X Dec: 27 38
102 # 88 #=0: start macro definition #=1: stop macro definition
#=2: execute current macro
#=3: call curent macro
#=4: auto macro overlay on
#=5: auto macro overlay off
#=6: delete all macros
#=7: delete all temporary
macros
#=8: delete current macro
#=9: make macro temporary
#=10: make macro permanent
Miscellaneous Commands
Master reset ASCII: ESC E Dec: 27 69
Self test ASCII: ESC z Dec: 27 122
Specify paper input ASCII: ESC & l # H Dec: 27 38
108 # 72 #=0: eject page #=1: upper tray feed (de- fault) #=2:
manual feed #=3: envelope,
manual feed
OL400e/410e Feature Command Notes
Underline mode on ASCII: ESC & d # D Dec: 27
38 100 68 #=0: fixed underline on #=3: floating underline on
Underline mode off ASCII: ESC & d @ Dec: 27 38
100 64

Specify number of copies ASCII: ESC & l # X Dec: 27 38
108 # 88 #=1 to 99
Begin multiple copies ASCII: ESC / m # S Dec: 27 47
109 # 83 #=number of copies, 0 to 99
End multiple copies ASCII: ESC / m E Dec: 27 47
109 69
Set skip over perforation ASCII: ESC & l # L Dec: 27 38
108 # 76 #=0: off #=1: on (default)
End of line wrap ASCII: ESC & s # C Dec: 27
38 115 # 67 #=0: on #=1: off (default)
Line Termination ASCII: ESC & k # G Dec: 27
38 107 # 71 #=0 (default): CR=CR, LF=LF, FF=FF #=1: CR=CR + LF,
LF=LF, FF=FF #=2: CR=CR,
LF=CR + LF, FF=CR + FF
#=3: CR=CR+LF, LF=CR + LF,
FF=CR + FF
Display Function On ASCII: ESC Y Dec: 27 89
Display Function Off ASCII: ESC Z Dec: 27 90
Transparent mode ASCII: ESC & p # X [data]
Dec: 27 38 112 # 88 #= number of bytes of data to follow
PostNet ZIP check digit
calculation and bar code
printing
ASCII: ESC / b # W [data] Dec:
27 47 98 # 87 [data] #=number of bytes of data to follow
OL400e/410e Symbol Sets Command Menu Display
Roman 8 ESC(8U Roman 8
ECMA-94 LATIN 1 ESC(0N ECMA-94
IBM PC (USA) ESC(10U PC-8
IBM Danish/Norwegian ESC(11U PC-8 DN
HP Code ESC(12U PC-850
Legal ESC(1U Legal
IRV ESC(2U ISO-2
United Kingdom ESC(1E ISO-4
US ASCII ESC(0U ISO-6
Swedish ESC(3S ISO-10
Swedish/Finnish ESC(0S ISO-11

JIS ASCII ESC(0K ISO-14
Italian ESC(0I ISO-15
Portuguese ESC(4S ISO-16
Spanish ESC(2S ISO-17
German ESC(1G ISO-21
French ESC(0F ISO-25
Chinese ESC(2K ISO-57
Danish/Norwegian ESC(0D ISO-60
Norwegian ESC(1D ISO-61
French ESC(1F ISO-69
IBM Portuguese ESC(5S ISO-84
IBM Spanish ESC(6S ISO-85
German ESC(0G ISO-21
Spanish ESC(1S Spanish
Oki Roman Extension ESC(0E RomanEx
Oki Dutch ESC(90D Dutch
Oki Swedish 1 ESC(91S Swedsh1
Oki Swedish 2 ESC(92S Swedsh2
Oki Swedish 3 ESC(93S Swedsh3
Oki Code Page 437 ESC(2038Z IBM-437
OL400e/410e Symbol Sets Command Menu Display
Oki Code Page 850 ESC(19U IBM-850
Menu Display Oki Code Page 860 ESC(2037Z
IBM-860 Oki Code Page 863 ESC(2036Z
IBM-863 Oki Code Page 865 ESC(2035Z
IBM-865 IBM PC Set 1 ESC(8Q
PCSet1 Oki PC Extension ESC(9Q
PCExtUS PC Extension Danish ESC(2033Z
PCExtDN PC Set 2 US ESC(2034Z
PC2 US PC Set 2 Danish ESC(2032Z
PC2 D/N HP ZIP Code ESC(15Y

HP ZIP USPS ZIP Code ESC(97Y
USPS ZIP USPS FIM Bar ESC(98Y
USPS FIM USPS Stamp Here ESC(99Y
USPS STP OL410e Symbol Sets Command
Menu Display Symbol Sets Specific
to OL410e Ventura Math
ESC(6M VNMath Ventura Int
ESC(13J VNInt'l Ventura US
ESC(14J VN US PostScript Math
ESC(5M PS Math PostScript Text
ESC(10J PS Text HP Math 8
ESC(8M Math-8 HP Pi
ESC(15U Pi Font Microsoft Publ
ESC(6J MS Publ Windows
ESC(9U Windows Desktop (Type Dir)
ESC(7J DeskTop Code Page 852 East Europe
ESC(17U PC 852 Windows 3.1 Turkish
ESC(2043Z Win Tur Windows 3.1 East Europe
ESC(9E Win Ltn2 CWI Hungarian
ESC(2044Z CWI Hun Code Page 857 Turkish
ESC(2040Z PC 857 Windows 3.1 Cyrillic
ESC 9R Win Cyr Code Page 866 Cyrillic 2
ESC(3R PC 866 Window 3.1 Greek
ESC(2042Z Win Grk Code Page 869 Greek
ESC(2041Z PC 869 Code Page 855 Cyrillic 1
ESC(2031Z PC 855
OL400e/410e Symbol Sets Command Menu Display
Roman 8 ESC(8U Roman 8
ECMA-94 LATIN 1 ESC(0N ECMA-94

IBM PC (USA) ESC(10U PC-8
IBM Danish/Norwegian ESC(11U PC-8 DN
HP Code ESC(12U PC-850
Legal ESC(1U Legal
IRV ESC(2U ISO-2
United Kingdom ESC(1E ISO-4
US ASCII ESC(0U ISO-6
Swedish ESC(3S ISO-10
Swedish/Finnish ESC(0S ISO-11
JIS ASCII ESC(0K ISO-14
Italian ESC(0I ISO-15
Portuguese ESC(4S ISO-16
Spanish ESC(2S ISO-17
German ESC(1G ISO-21
French ESC(0F ISO-25
Chinese ESC(2K ISO-57
Danish/Norwegian ESC(0D ISO-60
Norwegian ESC(1D ISO-61
French ESC(1F ISO-69
IBM Portuguese ESC(5S ISO-84
IBM Spanish ESC(6S ISO-85
German ESC(0G ISO-21
Spanish ESC(1S Spanish
Oki Roman Extension ESC(0E RomanEx
Oki Dutch ESC(90D Dutch
Oki Swedish 1 ESC(91S Swedsh1
Oki Swedish 2 ESC(92S Swedsh2
Oki Swedish 3 ESC(93S Swedsh3
Oki Code Page 437 ESC(2038Z IBM-437
OL400e/410e Symbol Sets Command Menu Display
Oki Code Page 850 ESC(19U IBM-850

Menu Display
Oki Code Page 860 ESC(2037Z IBM-860
Oki Code Page 863 ESC(2036Z IBM-863
Oki Code Page 865 ESC(2035Z IBM-865
IBM PC Set 1 ESC(8Q PCSet1
Oki PC Extension ESC(9Q PCExtUS
PC Extension Danish ESC(2033Z PCExtDN
PC Set 2 US ESC(2034Z PC2 US
PC Set 2 Danish ESC(2032Z PC2 D/N
HP ZIP Code ESC(15Y HP ZIP
USPS ZIP Code ESC(97Y USPS ZIP
USPS FIM Bar ESC(98Y USPS FIM
USPS Stamp Here ESC(99Y USPS STP
OL410e Symbol Sets Command Menu Display
Symbol Sets Specific to
OL410e
Ventura Math ESC(6M VNMath
Ventura Int ESC(13J VNInt'l
Ventura US ESC(14J VN US
PostScript Math ESC(5M PS Math
PostScript Text ESC(10J PS Text
HP Math 8 ESC(8M Math-8
HP Pi ESC(15U Pi Font
Microsoft Publ ESC(6J MS Publ
Windows ESC(9U Windows
Desktop (Type Dir) ESC(7J DeskTop
Code Page 852 East Europe ESC(17U PC 852
Windows 3.1 Turkish ESC(2043Z Win Tur
Windows 3.1 East Europe ESC(9E Win Ltn2
CWI Hungarian ESC(2044Z CWI Hun
Code Page 857 Turkish ESC(2040Z PC 857
Windows 3.1 Cyrillic ESC 9R Win Cyr
