PRODUCT HANDBOOK
The Prestige Lectern
Sound Floor Lectern
MODEL #711

INTRODUCTION
The Prestige Lectern - Model 711
A beautifully handcrafted podium that commands a dignified presence. Wide reading surface illuminated by a recessed
fluorescent lamp; also features surface mounted digital timepiece. Self-contained solid-state multimedia amplifier offers
three mics and one line for CD / Tape play. Now also includes wireless options built-in. Two line out jacks provide expansion
possibilities for additional speakers and tape recording; and sound may be customized via the full range tone controls. Unit
moves easily on four concealed easy roll casters; two locking. Colors: Walnut, Light Oak, Medium Oak or Mahogany.
Dimensions: 52”H x 26”W x 20”D.
CARE OF YOUR CABINET
All exterior and interior exposed surfaces are veneer covered as well as edges in matching patterned melanine material.
To refresh the appearance, wipe the surface with a cloth soaked lightly in furniture oil. Avoid speaker grill area.
Your cabinet will look as good as new.
TECHNICAL SPECIFICATIONS
Power Output . . . . . . . . . . . . 50W RMS at 10%THD
Mic. . . . . . . . . . . . . . . . . . . . . Electret Condenser (2)
Aux . . . . . . . . . . . . . . . . . . . . 150 mV>220K
Frequency . . . . . . . . . . . . . . . 100HZ-25KHZ
Response. . . . . . . . . . . . . . . . +3dB
Power Supply . . . . . . . . . . . . 110-120V ohms DC 10.8 12V
Fuse . . . . . . . . . . . . . . . . . . . . 2A normal
Output . . . . . . . . . . . . . . . . . . 8 ohms
Wireless Frequency . . . . . . . . 187,8275 MHZ 187,190MHZ
ACCESSORIES
Handheld mic; clip-on mic; gooseneck; Shockmount mic holder; digital clock
Oklahoma Sound
2
Manufacturers Warranty
Our Lecterns undergo the most rigid and exacting tests for superior quality and performance before leaving the factory.
Oklahoma Sound Corporation warrants this product to be free from defective material and workmanship on the
electronic product speakers and microphones for five years from the date of resale by an authorized Oklahoma Sound
distributor. Oklahoma Sound will replace defective parts and repair malfunctioning products under this warranty
when the defect occurs under normal installation and use, provided the unit is returned to our factory via prepaid
transportation after direct authorization and approval by Oklahoma Sound. is warranty provides that examination
of the returned product must disclose in our judgement, a manufacturing defect. is warranty does not extend to
any product which has been subject to misuse, neglect, accident, improper installation, or where the serial number
has been removed or defected and is given in lieu of any other warranty implied or expressed and will not cover any
consequential damages.

3
THE PRESTIGE LECTERN · MODEL 711
700 SERIES WIRELESS AMPLIFIER OPERATING INSTRUCTIONS
Operating Precautions
Before operating the amplifier, be sure you fully understand all instructions and features of the amplifier. DO NOT turn ampli-
fier on until all input and output connections have been made. NEVER replace fuses unless power is off.
Microphone Input Connection
The microphone input accepts 1/4” phone jack. Do not position microphone next to or facing speakers. This may cause
acoustic feedback.
Wireless Operation
Turn on the power on both the wireless receiver and wireless mic., making sure both are set to matching channels,
either “A” or “B”.
Auxiliary Input
One auxiliary input is provided for radio tuner, tape recorder, CD player or multi-media equipment. Output level is adjusted
by the auxiliary volume control.
Tone / Equalization Controls
The Low and High frequency controls are similar to the bass and treble controls found on most stereo systems. Optimum
tone is achieved by first setting both knobs halfway; adjust Low and High frequency controls to suit environment.
Auxiliary / Line Out
Connect additional speaker line to navy line out connector of the amplifier. For maximum power transfer and to avoid ampli-
fier overload, be sure that the total impedance of the speaker line matches the output impedance setting on amplifier. Be
sure that speaker terminals are not shorted together by speaker line connecting cables. Can also be used for a recording
device.
Power Supply 12V DC Operation
Connect a 12 volt rechargeable battery 5 amp (not included) to the battery input connector located on the panel of the
amplifier (using 6' battery cable). Note the positive line is equipped with an in-line fuse, as this is the only polarity identifier.
Be sure that the positive line (in-line fuse) is connected to the positive pole of the battery (Red terminal) and the negative line
(no fuse) is connected to the negative pole (Black terminal). When lectern is plugged into a standard wall outlet, the battery
will automatically recharge. Green indicator light illuminates during recharge mode.
Precautions
• Set Mic volume control on lowest when turning unit on.
• Ensure correct polarity for D.C. supply connections.
• Reverse connection will blow the fuse and may damage internal circuitry.
• Always replace fuse with specied rating.
Removal and Installation of Amplifier
If your amplifier has to be removed for servicing — follow these simple steps:
1) Disconnect A/C wall plug.
2) Remove 4 side screws two on each side panel under amp top.
3) Disconnect speaker wire at rear of amplifier.
4) Pack it into a strong box with ample cushioning and return to factory.
5) To install new amplifier reverse the above procedure.

OPTIONAL / ADDITIONAL EQUIPMENT
Your lectern includes two corded microphones.
For complete freedom of movement, use any of these wireless systems.
HAND-HELD WIRELESS MIC / LWM-5
This wireless hand-held mic uses a 9-volt battery. Select channel A or B
to eliminate outside frequency interruption. Move freely up to 200 ft. away!
TIE-CLIP LAVELIER WIRELESS MIC / LWM-6
Includes pocket-size transmitter with a clip-on mic. Uses a 9-volt battery. Select channel A or B
to eliminate outside frequency interruption. Move freely up to 200 ft. away!
HEADSET WIRELESS MIC / LWM-7
Includes pocket-size transmitter with a headset mic. Uses a 9-volt battery. Select channel A or B
to eliminate outside frequency interruption. Move freely up to 200 ft. away!
12V LANTERN STYLE RECHARGEABLE BATTERY / #PS12V
12V 5 amp rechargeable battery pack w/included cable
connects to any of our lecterns for battery power. 20 hr life.
Oklahoma Sound
For these products, please contact your dealer or Oklahoma Sound.
OKLAHOMA SOUND
149 Entin Road, Clifton, NJ 07014
Tel [phone] • Fax [phone]
www.oklahomasound.com • email: [email protected]
