OLG AgileMotion+ 90 Workstation User manual

Assembly Instructions
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions
2
Components
2 x Worktop
2 x Worktop Support 1 x Workstop Support 2 x Rail Plate 5 x Levelling Foot 1 x Power Supply 1 x Handset1 x Short Motor Cable
1 x Medium Motor Cable
1 x Long Motor Cable
2 x End Leg 1 x Corner Leg 2 x Feet 4 x Rail Sets
AgileMotion+ 90° Workstation
8 - M8 x 25 28 - M8 x 10 16 - ST5.0 x 23 16 - ST8.0 x 20 2 - ST4.2 x 16 2 - ST3.5 x 16

AgileMotion+ 90° Workstation Assembly Instructions 3
Assembly Instructions
8 - M8 x 10
AgileMotion+ 90° Workstation
STEP 1:

AgileMotion+ 90° Workstation Assembly Instructions
4
STEP 2:
Assembly Instructions
4 - M8 x 10
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions 5
STEP 3:
Assembly Instructions
16- M8 x 10
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions
6
STEP 4:
Assembly Instructions
8 - M8 x 25
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions 7
Assembly Instructions
STEP 5:
16- ST8.0 x 20
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions
8
STEP 6:
Assembly Instructions
16 - ST5.0 x 23
90°
30mm
30mm
=
=
= =
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions 9
Assembly Instructions
STEP 6a:
120°
30mm
=
30mm
=
= =
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions
10
STEP 7:
Assembly Instructions
2 - ST4.2 x 16
2 - ST3.5 x 16
Long Motor Cable
Medium Motor Cable
Short Motor Cable
Long Motor Cable
Medium Motor Cable
Short Motor Cable
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions 11
Assembly Instructions
Complete:
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions
12
Directions For Use
IMPORTANT
Please carefully read the assembly manual and direction for use prior to instalment, use and maintenance of the table frame to gain a complete understanding of its contents. It provides you with
important information about the safety, use, installation and maintenance of the table.
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL ASSEMBLY, SAFETY AND OPERATION INSTRUCTIONS REGARDING THE USE OF THIS PRODUCT MAY RESULT IN SERIOUS BODILY INJURY.
SAFETY
•The table must be used in a safe manner. Inappropriate use may cause damage to the table and/or cause bodily harm to the user or persons nearby.
•Do not tamper with electrical components as this may lead to serious bodily harm.
•Only connect the electric table frames to the prescribed mains power voltage
•Do not use the table frame to lift people.•Please retain this operation manual and pass it on to any future owner.
USAGE
•The height-adjustable table is designed for use in dry work environments only.
•The table height is infinitely adjustable within its height range so that it can be set to the user’s most ergonomic working height. The user should seekprofessional help to establish their
optimum working height.
•The table has been designed as a devise to elevate the users work surface and associated office peripherals. Do not use the table frame for any otherpurposes than that which it has been
designed for. Any other use is at user’s own risk!
•Do not crawl, lie or move around under the table frame, and do not sit or stand on the table frame.
•CHILDREN should only use the table when supervised by adults.
•Liability: The manufacturer accepts under no circumstances warranty claims or liability claims for damages arising from improper use or handling of thetable frame other than that de
scribed in this operation manual.
SET-UP AND INSTALLATION
Assemble the table frame according to the assembly instructions on pages 3 - 9.
•Place the table in a safe distance from window frames, radiators, furniture etc. so that persons cannot become trapped.•Level the table with the adjustable feet ensuring that the table is
stable.
•Check that no cables can get jammed.
•Connect the table to the 110 or 230 VAC power outlet.
The table is now ready for use.
AgileMotion+ 90° Workstation

AgileMotion+ 90° Workstation Assembly Instructions 13
M4 memory key.
Adjust using keys. Press M4 for 5s to remember position
Directions For Use
MAINTENANCE
•The table does not require any maintenance by the user
•The table is only to be cleaned with a wrung cloth.
TECHNICAL DATA
Height Range: 635-1290mm including worktop
Speed: ~30mm/s
Input Voltage: 90-230V AC 50-60Hz, 300VA
Output Voltage: 24V DC Max.10A
Duty Cycle: 10% max. 2min on/18min off
LCD Screen
M3 memory key.
Adjust using keys. Press M3 for 5s to remember position
M2 memory key.
Adjust using keys. Press M2 for 5s to remember position
M1 memory key.
Adjust height using keys. Press M1 for 5s to remember position.
Down key.
Press to move down. Release when desired position is reached
Up key.
Press to move up. Release when desired position is reached.
AgileMotion+ 90° Workstation
