Oliver 623 Operation instructions

0623S20000-CVR
Grand Rapids, Michigan, U.S.A. 49504-5298
USER’S OPERATING AND INSTRUCTION MANUAL
MODEL 623 & 623-N
HAND BUN / ROLL
DOUGH DIVIDER

0623S20007 0-1
INDEX
Section Description Document No. Page No.
SAFETY INSTRUCTIONS --------------------------------------0623S20008 --------------------------- 1-1
DESCRIPTION/SPECIFICATIONS ---------------------------0623S20009---------------------------- 2-1
Description -------------------------------------------------------------------------------------------------- 2-1
Specifications----------------------------------------------------------------------------------------------- 2-1
INSTALLATION INSTRUCTIONS ---------------------------- 0623S20010 --------------------------- 3-1
Container Inspection ------------------------------------------------------------------------------------- 3-1
Ventilation and Clearances ----------------------------------------------------------------------------- 3-1
Initial Set-up ------------------------------------------------------------------------------------------------ 3-1
OPERATING INSTRUCTIONS -------------------------------- 0623S20011 --------------------------- 4-1
Before You Start------------------------------------------------------------------------------------------- 4-1
Basic Operations------------------------------------------------------------------------------------------- 4-1
MAINTENANCE ---------------------------------------------------0623S20012 --------------------------- 5-1
Cleaning ----------------------------------------------------------------------------------------------------- 5-1
Lubrication--------------------------------------------------------------------------------------------------- 5-2
MODEL 623 DOUGH DIVIDERS------------------------------ 0623S20013 --------------------------- 6-1
Drawing ------------------------------------------------------------------------------------------------------ 6-1
Parts List ---------------------------------------------------------------------------------------------------- 6-2
WARRANTY ------------------------------------------------------- GEN 050816
WARRANTY PROCEDURE------------------------------------ GEN 050817
RETURNED PARTS POLICY --------------------------------- GEN 050818

0623S20008 1-1
GENERAL SAFETY INSTRUCTIONS
WARNING
IT IS ESSENTIAL THAT ALL OPERATORS AND MAINTENANCE PERSONNEL
OBSERVE THE FOLLOWING SAFETY PRECAUTIONS. IMPROPER
INSTALLATION, MAINTENANCE, OR OPERATION OF THIS EQUIPMENT
COULD CAUSE SERIOUS INJURY.
1. Read this manual before attempting to operate your dough divider. Never allow an
untrained person to operate or service this unit.
2. Observe all caution and warning labels affixed to the machine.
3. Use only proper replacement parts.
4. Wear proper, personal, protective, safety equipment.
5. Do not wear loose fitting clothes or jewelry while operating the machine.
6. Keep hands away from moving parts of the machine while it is operating.
7. In addition to these general safety instructions, please follow the more specific safety
instructions in the rest of this operating and instruction manual.
WARNING
DO NOT USE FOR OTHER THAN ORIGINALLY INTENDED PURPOSE.

0623S20009 2-1
DESCRIPTION/SPECIFICATIONS
Description
The Oliver Models 623 and 623-N Hand Dough Dividers are designed to separate a pre-
weighed amount of dough into 16 or 36 portions of equal weight with the greatest of
ease at an affordable price.
The dividing knife that is used to cut the dough is made from electroless nickel plated
steel, which gives years of use without corrosion. Each machine comes with a 13-inch
stainless steel pan.
Specifications
Space Requirements, (Shown with Standard Options):
Model 623 & 623-N (All Dimensions are Approximate)
Shipping Weight – 150 lbs. (approximate)
Net Weight – 135 (approximate)

0623S20010 3-1
INSTALLATION INSTRUCTIONS
Container Inspection
Inspect the container for visible and/or concealed damage, if the equipment or container
seems to be damaged make a note on the shipping documents such as “Damaged” or
“Open” and notify the freight company asking for an inspection. Remember, the receiver
is responsible for filing damage claims. In such a situation you must retain all the
packaging until the inspection is complete to verify the damage and thus lessen the
chances that your claim will be denied.
CAUTION
ANY STAND, COUNTER OR OTHER MOUNTING SURFACE MUST BE
CAPABLE OF SUPPORTING THE MACHINE’S WEIGHT.
Select a location for your heat sealer which has a substantial mounting surface. Refer to
the general space requirements page to ensure sufficient operating area.
Ventilation/ Clearances
Sanitary standards for food packaging areas require a clean, adequately lighted and
ventilated room. Before the first use of your heat sealer, select a surface with a
sufficient amount of clearance from the front and the back of the machine and a
minimum of (2) two inches per side.
Initial Set-up
Take some time get familiar with the basic components for you heat sealer. The
illustration below

0623S20011 4-1
OPERATING INSTRUCTIONS
NOTE
THE STAINLESS STEEL PAN MAY NEED TO BE COATED WITH A
RELEASING AGENT, (NON-STICK SPRAY, BAKING GREASE,
FLOUR, ETC.), PRIOR TO PLACING THE DOUGH IN THE PAN.
Basic Operation
•Before dividing the dough, the dough should be scaled out to the desired weight.
Do this by choosing the size of the portions you would like to yield (refer to table
4-1). Place the dough into the stainless steel pan and push the dough firmly
along the bottom edge, flattening it by hand.
•Once the dough has been hand flattened in the pan, place the pan under the
main plate and blade components.
•Compress the dough completely by pulling down on the operating handle to its
furthest extent.
•After the dough has been compressed, allow the handle to return to its resting
position and then pull the top lever towards you, (this will release the knives), and
then pull down on the operating handle to divide the dough.
•After the dough has been cut, allow the handle to return to its resting position and
release the top lever.
•Remove the pan from under the main plate and remove the evenly divided
pieces of dough from the pan.
You may now repeat the process to make additional divisions.
TABLE 4-1
Use the formula in the table to determine the initial weight of the dough, where:
S = Size of the portions wanted (in ounces)
A = Amount of pieces the knife can divide (36 or 16)
W = Weight of initial piece of dough
W = S x A ÷ 16 (oz. / lb.)

0623S20012 5-1
MAINTENANCE
NOTE
REMEMBER NORMAL MAINTENANCE WILL INCREASE THE LIFE OF THE
MACHINE. IT IS ALSO A GOOD TIME TO INSPECT THE MACHINE FOR DAMAGED
OR WORN COMPONENTS, WHICH MAY LATER CAUSE PROBLEMS.
NOTE
INSERT THE QUICK PIN IN THE GUIDE BAR TO IMMOBLEIZE THE DIVIDING
HEAD BEFORE ATTEMPTING TO CLEAN OR SERVICE THE UNIT.
CLEANING
General
Use a mild detergent solution or spray cleaner on all exterior surfaces as necessary.
Daily
CAUTION
FREQUENT CLEANING OF THE MAIN PLATE AND KNIFE
ARE REQUIRED TO PREVENT DAMAGE TO THE KNIFE.
At the end of the day remove the T-pin so that the arch assembly can be tipped to one
side for easier cleaning. It is best to have two people tip the arch assembly, one lifting
and one catching. After the arch is opened for cleaning actuate the operating handle to
extend the main plate and knife assembly.
Begin cleaning by dislodging particles of hardened dough with compressed air, a stiff
bristle brush, or a plastic scraper.
CAUTION
NEVER USE WIRE BRUSHES AS DAMAGE TO THE SURFACE
PLATING OF THE CONTACT SURFACES MAY RESULT.
Those particles which can not be removed using the above procedure should be
softened using a spray bottle containing water, or by applying small amounts of
vegetable or mineral oil. Once softened remove these particles with a cloth, stiff bristle

0623S20012 5-2
MAINTENANCE (CON’T)
brush or plastic scraper. Clean all cracks, crevices and surfaces of the main plate.
Rinse with a light spray of clean water or a damp cloth and dry.
Using the top lever, release the blades from the main plate exposing the knife. Clean
the knife using the same cleaning methods as described above.
LUBRICATION
NOTE
ALWAYS USE FOOD APPROVED LUBRICANTS WHEN
GREASING OR OILING THIS MACHINE
Monthly
Most lubrication should be done monthly and should be completed with the normal
cleaning. Following is a list of things which should be greased or oiled.
1. Monthly, (weekly for machines experiencing heavy usage), guide posts to the left
and right.
2. Grease the gear on the end of the operating handle and the rack gear it meshes
with.
3. Add a few drops of food approved oil to each of the oilers located around the pivot
for the operating handle on the top of the machine.

0623S20013 6-1
MODEL 623 & 623-N DOUGH DIVIDERS

0623S20013 6-2
MODEL 623 & 623-N DOUGH DIVIDER PARTS LIST
ITEM NO PART DESCRIPTION PART NUMBER
001 Plate-Base 0623-0006
007 Arch 0623-0007
008 Pin-Removable 0623-0005
009 Pin-Stationary 0623-0014-1
010 Oiler-Ball 5133-6071
011 Ring-Retainer 5840-1668
012 Bar-Guide 0623-0004
015 Handle-Gear 0623-0002-1
016 Pin-Pinion 0623-0013
017 Kit-Pin & Lanyard 5835-7801K
020 Handle-Operating 0623-0011
021 Weight-Balance 0623-0012
023 Lever-Top 0623-0010
026 Spring-Torsion 7030-0022
027 Pan-Dough 0623-0015
101 Knife-36 Part 0623-0001
101 Knife-16 Part (Not Shown) 0623-0001-001
102 Assembly-Gear Shaft 36 Part 0623-0003
102 Assembly-Gear Shaft 16 Part (Not Shown) 0623-0003-001
103 Pin-Spring 1/4 x 3/4 STST 5835-6842
104 Plate-Main 36 Part 0623-0008
104 Plate-Main 16 Part (Not Shown) 0623-0008-001
105 Plate-Cover 36 Part 0623-0009
105 Plate-Cover 16 Part (Not Shown) 0623-0009-001
FOR SERVICE PARTS CALL OLIVER PRODUCTS @ 800-253-3893

GEN 050816
WARRANTY
PARTS
Oliver Products Company (Oliver) warrants that if any part of the equipment (other than a
part not manufactured by Oliver) proves to be defective (as defined below) within one year
after shipment, and if Buyer returns the defective part to Oliver within one year, Freight
Prepaid to Oliver’s plant in Grand Rapids, MI, then Oliver, shall, at Oliver’s option, either
repair or replace the defective part, at Oliver’s expense.
LABOR
Oliver further warrants that equipment properly installed in accordance with our special
instructions, which proves to be defective in material or workmanship under normal use
within one (1) year from installation or one (1) year and three (3) months from actual
shipment date, whichever date comes first, will be repaired by Oliver or an Oliver Authorized
Service Dealer, in accordance with Oliver’s published Service Schedule.
For purposes of this warranty, a defective part or defective equipment is a part or equipment
which is found by Oliver to have been defective in materials workmanship, if the defect
materially impairs the value of the equipment to Buyer. Oliver has no obligation as to parts
or components not manufactured by Oliver, but Oliver assigns to Buyer any warranties
made to Oliver by the manufacturer thereof.
This warranty does not apply to:
1. Damage caused by shipping or accident.
2. Damage resulting from improper installation or alteration.
3. Equipment misused, abused, altered, not maintained on a regular basis, operated
carelessly, or used in abnormal conditions.
4. Equipment used in conjunction with products of other manufacturers unless such use is
approved by Oliver Products in writing.
5. Periodic maintenance of equipment, including but not limited to lubrication, replacement
of wear items, and other adjustments required due to installation, set up, or normal wear.
6. Losses or damage resulting from malfunction.
The foregoing warranty is in lieu of all other warranties expressed or implied AND OLIVER
MAKES NO WARRANTY OF MERCHANTABILITY OR FITNESS FOR PURPOSE
REGARDING THE EQUIPMENT COVERED BY THIS WARRANTY. Oliver neither
assumes nor authorizes any person to assume for it any other obligations or liability in
connection with said equipment. OLIVER SHALL NOT BE LIABLE FOR LOSS OF TIME,
INCONVENIENCE, COMMERCIAL LOSS, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.

GEN 050818
RETURNED PARTS POLICY
This policy applies to all parts returned to the factory whether for warranted credit,
replacement, repair or re-stocking.
Oliver Products Company requires that the customer obtain a Return Material Authorization
(RMA) number before returning any part. This number should appear on the shipping label
and inside the shipping carton as well. All parts are to be returned prepaid.Following this
procedure will insure prompt handling of all returned parts.
To obtain an RMA number contact the Repair Parts Deptartment toll free at [phone].
Parts returned for re-stocking are subject to a RE-STOCKING CHARGE.
Thank you for your cooperation,
Repair Parts Manager
Oliver Products Company

GEN 050818
RETURNED PARTS POLICY
This policy applies to all parts returned to the factory whether for warranted credit,
replacement, repair or re-stocking.
Oliver Products Company requires that the customer obtain a Return Material Authorization
(RMA) number before returning any part. This number should appear on the shipping label
and inside the shipping carton as well. All parts are to be returned prepaid.Following this
procedure will insure prompt handling of all returned parts.
To obtain an RMA number contact the Repair Parts Deptartment toll free at [phone].
Parts returned for re-stocking are subject to a RE-STOCKING CHARGE.
Thank you for your cooperation,
Repair Parts Manager
Oliver Products Company
