Olympus EyeTrek Insight EI-10 User manual
Thank you for purchasing this Olympus product.
To ensure your safety, please read this instruction manual
before use, and keep it handy for future reference.
Smart Glasses
EI-10
Instruction Manual
02
Table of Contents................................................ 02
Warnings and Precautions................................. 03
Warnings 04
Precautions 07
Precautions for using wireless
functions (Bluetooth, Wireless LAN) 09
Before Use ........................................................... 11
Unpacking the box contents 11
Names and functions of components 12
Charging the batteries 13
Inserting and replacing batteries 14
How to Wear the Device ..................................... 15
Basic Operations................................................. 16
Turning On/O the Power.................................. 17
Turning on the power 17
Turning o the power 17
Sleep mode 17
Turning on/o the display 18
Home Screen....................................................... 20
Displayed information 20
Operation procedure 21
Initial Applications ............................................. 22
Image Viewer 22
Video Player 22
Camera 23
Video Recorder 24
Function Checker 25
QR Code Settings 29
Brightness 29
Settings 30
Connection to Computer.................................... 31
Connecting to computer via Micro-USB cable 31
Internal storage folders 32
QR Code Operations ........................................... 33
QR Code Generator 33
Wireless LAN settings 34
Other operations 35
Troubleshooting ................................................. 36
Frequently Asked Questions ............................. 37
Development Environment ............................... 39
Specications...................................................... 40
Optional Accessaries
(sold separately)
................ 41
Trademarks / Third Party Software ................... 43
Table of Contents
03
Warnings and Precautions
• The Olympus EyeTrek is designed as a hands-free business solution through a head
mounted display that can facilitate communications between parties, display real time
information, record or playback audio and video content, and use various applications that
can improve work eciencies in a commercial or industrial environment. Use this product
only for the intended purpose.
• The EyeTrek visual display should be used only with safety glasses, prescription glasses, or
other eye protection that will prevent the EyeTrek visual display from coming into contact
with the user’s eye. Use only the enclosed attachments to secure the visual display to the
glasses or eye protection you are wearing. Do not focus so much on the visual display that
you become distracted from your surroundings. If you have any questions about how to
use the product safely, contact Olympus customer support.
• This device is not intended to be used in the performance of critical activities requiring
continuous connectivity involving health and safety, including but not limited to
emergency healthcare, war time applications and processes, or crisis management.
• This device should not be used as a primary source to hold and save data.
• Reprinting a part of or entire section of this manual without permission is prohibited.
• Screens and illustrations used in this manual are only the images. Therefore, they may be
dierent from actual screens or products.
• The contents of this manual are subject to be revised without a prior notice.
• READ ALL INSTRUCTIONS, WARNINGS, AND PRECAUTIONS BEFORE USING THIS PRODUCT.
AFTER READING, KEEP THESE MATERIALS FOR LATER REFERENCE.
04
▎Warnings
PRODUCT USERS
• Do not use if you are under 16 years of age.
• Do not use if you are in poor physical condition.
• Do not use if you have heart disease, high blood pressure, or other heart problems.
• Do not use if you are tired or have diculty sleeping.
• Do not use under the inuence of drugs or alcohol.
• Do not use if you have a history of photosensitivity.
• Do not use if you have a visual eld disorder, alignment disorder, or eye movement disorder.
• Do not use if you have ever experienced convulsive or epileptic ts.
• Do not use if you have ever experienced a stroke, vertigo, migraines, or mental disorder.
• Do not use if you have ever experienced loss of consciousness from light ashes or oscillations.
• Do not use if you are pregnant.
• Do not use if you have personal medical devices such as an implanted pacemaker,
debrillator, or hearing aids.
USE CONDITIONS FOR THE PRODUCT
• If you wear safety glasses, helmet, or other protective equipment, the product may not t
securely. Do not use this product if it prevents you from properly wearing protective
equipment such as safety glasses, hard hats, helmets, dust masks, or respirators. If you
cannot nd safety equipment that can be worn and used properly along with the product,
do not use this product.
• Use of the product can obscure your vision, aect your balance, and increase your reaction
time. Do not allow product use to distract you. Before wearing or using, conrm that the
surrounding environment is safe. Do not wear or use the product near physical obstacles
or fragile objects.
• Do not use in any setting in which there is a risk of falling, such as on a bus or train, or in
any other setting in which you cannot safely use the product.
• Do not use while operating work-related equipment such as forklifts, cranes, or tractors.
• Do not use while operating personal transportation devices such as automobiles,
motorcycles, bicycles, skateboards, or hoverboards.
• Do not use this product if you may encounter sudden or unexpected movements.
05
• Do not look at the sun or other strong lights while using this product.
• Do not use this product continuously for more than one hour without taking a 10-minute
break.
• Do not use this device at an excessive volume. Otherwise, hearing loss can occur and you
may not be able to hear important sounds around you, such as alarms, horns, and sirens.
USE ENVIRONMENT WARNINGS
• Do not use product anywhere where the use of such devices are prohibited.
• Do not operate the product in temperatures below 5 °C(41 °F) or above 35 °C(95 °F).
• Do not store the product in temperatures below 0 °C(32 °F) or above 40 °C(104 °F).
• Do not operate or store the product in locations with high humidity or excessive dust.
• Do not use in storm conditions involving thunder or lightning.
• Other electronic systems and devices may operate in the same frequency range as this
product. These include, but are not limited to, microwave ovens, household appliances,
medical and scientic instruments, and RFID equipment. Do not use near medical devices
or any other electrical equipment that may be adversely aected by the radiofrequency
emissions of the product. Please see “FCC Notice”below for further details on FCC
compliance.
PRODUCT CARE WARNINGS
• Do not leave this product in a closed automobile or in other places under direct sunlight
for extended periods of time.
• Do not immerse product in water or otherwise allow product to get wet. Do not use or
leave the product in very moist or humid places. Do not use the product if it has
condensation or if your hands are wet.
• Do not attempt to disassemble, repair, or modify the product. Attempts to do so may
cause malfunctions, re, electrical shock, personal injury, and product damage. Contact
Olympus customer support for any needed repairs.
06
BATTERY USE AND CARE
• The product contains a lithium battery. To prevent battery leaks or damage, carefully
follow all instructions regarding the use and charging of batteries. Lithium batteries
contain potentially toxic materials. Never attempt to disassemble or modify a battery in
any way.
• Use only the battery, battery charger, and AC adapter provided with the product. Using a
battery, battery charger, or AC adapter other than those provided may result in charging
failures, product malfunction, re, damage, explosions, or battery leaks.
• Use the battery charger with the specied power source and voltage. Unplug the battery
charger when not in use. Do not use the battery charger if the power cord is damaged or
broken.
• Do not charge the battery near any place at which ammable items are stored, such as a
gas station. Prior to visiting such places, remove the battery from the device.
• Do not overcharge batteries. If the battery does not recharge within 3 hours, stop charging
and remove the battery from the device.
• Do not store battery where it will be exposed to direct sunlight or subjected to high
temperatures.
• Do not allow battery to come into contact with any metal objects such as jewelry, pins,
fasteners, keys, etc. Doing so may cause a short circuit that will result in overheating,
burning, re, or explosions.
• Do not use a battery that is deformed, swelling, leaking, wet, or has a strange odor. Doing
so may result in overheating, burning, bursting, or re.
• If the liquid inside of the battery touches the skin or clothing, immediately rinse with water.
If the liquid gets into the eyes, ush with water and see a doctor immediately.
• Do not dispose of batteries in re.
• Keep the battery and small parts out of reach of children. Should a child swallow a battery
or a small part, see a doctor immediately.
• This symbol [crossed-out wheeled bin Directive 2006/66/EC Annex II] indicates
separate collection of waste batteries in the EU countries.
Please do not throw the batteries into the domestic refuse.
Please use the return and collection systems available in your country for the
disposal of the waste batteries.
• Please recycle OLYMPUS batteries to help save our planet's resources.
When you throw away dead batteries, be sure to cover their ＋, －, T, and always observe
local laws and regulations.
07
▎PRECAUTIONS
EYEWEAR
• Always wear the product with safety glasses, prescription glasses, or other eye protection
to prevent the eye from coming into contact with the product’s viewer. Otherwise, a
sudden impact may cause the product to strike and injure the eye. Use the enclosed
attachments to secure the visual display to your glasses or eye protection before use.
• If you wear bifocals, trifocals, or progressive lenses, or if you have had laser eye surgery,
consult your eye doctor before using this product.
• If you wear contact lenses that are designed to allow one eye to see close up and the other
eye to see far away, consult your eye doctor before using this product.
• Do not overly widen the headband when wearing and removing the headband. Do not
allow the display unit to touch your eye when wearing and removing the display unit.
OTHER USAGE PRECAUTIONS
• Always be sure you can see the screen and entire image clearly during use. Do not use the
device when the image cannot be properly focused, or the image does not appear clear
and stable, or if you cannot see the whole image clearly.
• The screen of the device partially blocks one eye. Remove the device if you need to see
with both eyes or if the device interferes in any way with your safety.
• If the product causes your skin to feel irritated or uncomfortable, remove the product from
your head and consult a dermatologist.
• Avoid extended use of the product. If during use you encounter eye pain or eye fatigue,
blurry vision, double vision, nausea, headache, or dizziness, neck or shoulder pain, fatigue,
anxiety, or discomfort, discontinue use and rest until you recover. Do not walk, move
around, or operate equipment or a vehicle until these symptoms go away.
• If during use or charging the product emits smoke, strange odors, or sounds, or generates
excessive heat, discontinue use, unplug the charger and Power Pack Adaptor, and contact
Olympus customer support.
08
CONNECTIONS, APPLICATIONS AND DATA UPLOADS
• Do not connect, upload or install any connection site, applications or data onto this
product where the safety and security of such connection, application or data has not been
provided, approved or authorized by Olympus.
• Please use this product only after ensuring that your system maintains safety and total
system reliability.
09
Precautions for using wireless functions (Bluetooth, Wireless LAN)
FCC Notice
• This device has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules.
• These limits are designed to provide reasonable protection against harmful interference in
a residential installation.
• This device generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
• However, there is no guarantee that interference will not occur in a particular installation.
• If this device does cause harmful interference to radio or television reception, which can be
determined by turning the device o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
a. Reorient or relocate the receiving antenna.
b. Increase the separation between the device and receiver.
c. Connect the device into an outlet on a circuit dierent from that to which the receiver
is connected.
d. Consult the dealer or an experienced radio/TV technician for help.
e. To connect the device to USB enabled personal computer, use the enclosed ferrite
cores.
FCC/IC Caution
• Changes or modications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the device.
• This transmitter must not be co-located or operated in conjunction with any other antenna
or transmitter.
• The available scientic evidence does not show that any health problems are associated
with using low power wireless devices.
10
• There is no proof, however, that these low power wireless devices are absolutely safe.
• Low power Wireless devices emit low levels of radio frequency (RF) energy in the
microwave range while being used.
• Whereas high levels of RF can produce health eects (by heating tissue), exposure of
low-level RF that does not produce heating eects causes no known adverse health eects.
• Many studies of low-level RF exposures have not found any biological eects.
• Some studies have suggested that some biological eects might occur, but such ndings
have not been conrmed by additional research.
• EI-10 has been tested and found to comply with FCC/IC radiation exposure limits set forth
for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules.
• The Wireless LAN (IEEE 802.11a/n) of this product uses 5 GHz bands. By the Radio Law,
outdoor use of the 5.2 GHz band and the 5.3 GHz band is prohibited. The channels used by
this product are as follows:
- 5.2 GHz band : 36, 40, 44, 48
- 5.3 GHz band : 52, 56, 60, 64
- 5.6 GHz band : 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140
For customers in the United States
This device complies with Part 15 of the FCC rules and Industry Canada's licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Declaration of Conformity
Model Number : EI-10
Trade Name : OLYMPUS
Responsible Party : OLYMPUS AMERICA INC.
Address : 3500 Corporate Parkway, P.O. Box 610, Center Valley,
PA 18034-0610, U.S.A.
Telephone Number : 484-896-5000
Tested To Comply With FCC Standards
FOR HOME OR OFFICE USE
11
Before Use
Unpacking the box contents
Protection case
Instruction manual
Warranty card
Smart Glasses
EI-10
Ferrite Core
Battery Charger
EI-CS1
Small x2
Midium x2
Large x2
(EI-CH1) (UN312-0520)
Headband & Clips
EI-HB1
Battery
WHB-001 x2
12
Names and functions of components
• Button and sensor functionality vary depending on the application.
• ”Hold down a button" means to release after pressing and holding the button for
approximately 2 seconds.
NOTE
Voice functions
This device is not equipped with a speaker. In order to play back voice, connect the earphone or a headset
to the 4-pole mini jack. In addition, to have two-way communication through the device, connect the
headset.
NOTE
When connecting an earphone or a headset to the 4-pole mini jack,
make sure that the connected unit is fully inserted. If not, interference
may occur.
Touch sensor
allows for touch operation.
Camera
takes pictures and videos.
Prism
Button❶
shows the home screen.
Micro-USB port
for connection via
Micro-USB cable.
Connector
locks the device to the
headband holder.
Power LED
indicates the current
status of the device.
Button❷
Button❸
operate dierently
depending on the
application.
Power button
turns on the power, turns on/o
sleep mode and other modes.
4-pole mini jack
for connecting devices such as
headsets or earphones.
Display
shows the screen.
Microphone
USB
Flexible arm
adjusts display position.
13
Charging the batteries
Fully charge the battery prior to rst use, and recharge the battery when it is drained.
Charging the battery for the rst time will take approximately 2.5 hours.
Be careful with the
battery direction.
Charge indicator
LED
Insert the plug into an outlet.
• The LED may blink red when a battery is inserted into the charger. If this happens, remove the
battery, wait for several minutes and insert again.
• If a fully charged battery is inserted into the charger, the LED may not turn on.
Battery Maintenance
If the battery terminal becomes dirty, clean with a soft, dry cloth. Getting nger oil, sweat, or dust on the
terminal may prevent proper charging. Do not use organic solvents (benzene, thinner, and like), acids, or
alkalis.
This product cannot be charged internally via the Micro-USB port. Please use the external battery charger.
The plug-in type AC adapter (UN312-0520) shall be correctly mounted to a plug socket perpendicularly.
Battery charge indicator
Charging state Charge indicator
LED state
No battery inserted Not lit
Charging Green light
Charging complete Blinking green light
Temperature over range
Blinking red light
Abnormal charge Red light
NOTE
14
Inserting and replacing batteries
Insert
1. Move down the lock and open the cover.
2. Move the battery stopper and insert the battery.
Replace (Hot swap)
The battery can be replaced without turning o the power.
1. Hold down the power button for approximately 2 seconds.
2. The power LED starts blinking. After a few seconds, it switches to the slow blinking state
with intervals of approximately 2 seconds.
3. Remove the battery. Then within 10 seconds, insert the charged battery. When the hot
swapping succeeds, the power LED starts blinking in 2-second intervals again. If the hot
swapping fails, the power LED turns o.
4. Press the power button.
Resume the paused application from where it is stopped.
USB
Power LED
Hold down the button
Lock
Cover
Battery
Be careful with the
battery direction.
Battery stopper
15
How to Wear the Device
Use the provided headband.
1. Slide the device connector to insert it into the headband holder.
2. While wearing the glasses, attach the clip to the temple of the glasses.
3. Adjust display position.
Always wear the device with safety glasses,
prescription glasses, or other eye protection.
Otherwise, an injury may cause such as by hurting the eye by
the display.
Warning
Regarding clip size (Small, Medium, Large)
Clips can be replaced to t the width of the
temples. They can be used oriented either
inward or outward.
This product is designed assuming that it will be attached to the right-side holder
of the headband. Attachment to the left-side holder is possible, however, the
headset of a separately sold accessory cannot be used, and the screen may not
appear correctly in some applications which do not support rotation of the screen,
thus use this product after confirmation.
Do not bend Flexible arm forcedly.
Bending Flexible arm may cause squeakiness, but it is not a malfunction.
Connector
Holder
Clip
Ear hook
16
approximately 2 seconds
Basic Operations
The user can operate this device intuitively by using the touch sensor.
When a user is wearing gloves, the touch sensor does not respond.
Examples of major operations
• Swipe from back to front
• Swipe from front to back
• Two-nger swipe from back to front
• Two-nger swipe from front to back
• Single tap
• Double tap
• Holding down. (To release after touching the touch sensor for approximately 2 seconds.)
• Display the applications sequentially (counterclockwise order) on the
Home screen.
• Display the next image.
• Play back the next video.
• Zoom in the displayed image/video in Camera and Video Recorder.
• Display the applications sequentially (clockwise order) on the Home
screen.
• Display the previous image.
• Play back the previous video.
• Zoom out the displayed image/video in Camera and Video Recorder.
• Zoom in the displayed image/video in Camera and Video Recorder with large
steps.
• Zoom out the displayed image/video in Camera and Video Recorder
with large steps.
• Play/stop the video in Video Player.
• Start-up of the application.
• Return the zoom in Camera and Video Recorder.
Single
Double
17
Turning On/Off the Power
Turning on the power
Press the power button.
The power LED turns on, and the startup screen appears on the display.
*Note that holding down the button does not turn on the power.
*After ashing of the power LED, it takes about 20 seconds until the screen appears.
Turning off the power
To turn o the power, remove the battery.
1. Hold down the power button for approximately 2 seconds.
The power LED starts blinking. After a few seconds, it switches to the slow blinking state
with intervals of approximately 2 seconds.
2. Then remove the battery.
*Hold down the power button for longer than 7 seconds for forcing a shutdown.
Sleep mode
In the sleep mode, the display turns black, which disables unintended touch operation. In addition,
the battery power will be conserved when using this mode while the operation is in pause.
Hold down the power button for approximately 2 seconds.
The power LED starts blinking. After a few seconds, it switches to the slow blinking state with
intervals of approximately 2 seconds.
The power LED continues blinking while in the sleep mode.
Pressing the power button again releases the sleep mode.
USB
Power LED
Press
USB
Power LED
Hold down the button
USB
Power LED
Hold down the button
18
Turning on/off the display
The display can be switched between on/o.
Even when the display is o, the application is continuously running. Therefore, consumption
of the battery power continues. To save the power, shift to the sleep mode.
Press the power button.
The display turns o.
Pressing the power button again recovers the display.
USB
Press
19
• About the display
Due to the characteristics of the material used in the OLED panel, permanent burn-in or
reduction in brightness may occur.
For the OLED display used in this product, continuously displaying static images in the
same position on the screen or repeatedly displaying the same image may cause
irreversible burn-in.
Performing the operations detailed in 1 to 3 below reduces the risk of burn-in.
1. Do not display the same image for a long time.
Be careful not to continuously display the same image, such as a static image, a
temporarily halted video or continuously running the same software without any
operations.
2. Turn o the display when not in use.
When not in use or when display is unnecessary, turning o the screen and putting
the screen to sleep are recommended.
3. Do not unnecessarily increase the brightness of the display.
Keeping the necessary mild brightness of the screen is recommended.
• About use in a high-temperature environment
Continuous use in a high-temperature environment, due to the structure of the OLED
display and characteristics of the materials, may cause an afterimage, burn-in, a stain, a
line and reduction of brightness.
Since there is a danger of faster degradation of the display panel, avoid continuous use
and storage in a high-temperature and high-humidity environment, such as in a sealed
space and near an air conditioner. Especially, leaving this product inside an automobile
where direct sunshine increases the temperature therein and near a heating appliance
may result in uneven screen brightness causing a variation to be seen.
In addition, avoid using with a sudden temperature change, since it results in dew
condensation inside the product causing degradation of the display.
• About bright spots and dark spots
The display of this product is manufactured with a very high accuracy technique,
however, dark spots (black spot, lack of a pixel) and constantly lit bright spots (red,
blue, green) may exist. Further, depending on the viewing angle, streaks may be seen.
Due to the characteristics of the display, these phenomena may occur after long-term
use. These phenomena are due to the structure of the display and not malfunctions.
Please use this product with an understanding of these facts.
• Other precautions
* Do not press or pull strongly, scratch, or place an object on the prism especially the
surface of the display. It results in malfunctions of the screen or causes failure.
* Leaving the display facing the sunlight may result in damage of the screen. Please
be careful especially when placing the product near windows or in outdoors.
20
Home Screen
On this screen, applications can be selected and started both by touching and by
operating buttons.
Displayed information
①Battery
②Wireless LAN
③Bluetooth
①
Icon Battery Level
Over 50%
20% or more and less than 50%
Less than 20%
Icon Signal strength
Strong
Weak
Poor
no display Wireless LAN ON
disconnected
Wireless LAN OFF
Icon Bluetooth status
ON
OFF
②③
Table of contents
Other Olympus Smart Glasses manuals
