Puretone PT01 User manual

SMART EYEWEAR
使用说明
Instructions
运动型智能眼镜
声明
产品型号
产品参数、特点
首先对您使用本公司的产品表示感谢！在使用之前请先阅读此
说明书，正确使用此产品。为了更好的服务，本用户手册的内容可
能变更。因为产品的性能和功能而发生的变更，将不做另行通知。
PT01 EYEWEAR 开放式定向音频智能眼镜，本产品是具有
立体声功能的蓝牙眼镜，操作简便，便于携带。
镜腿颜色 黑色
镜腿材质 TR
镜片材质 尼龙/偏光宝丽莱等可选
蓝牙协议 5.0
充电协议 120min
电池容量 左镜腿110mAh、右镜腿110mAh
充电电压和电流 DC5V,不支持快充,最大充电电流1A
声 道 双喇叭、立体声
*采用炬芯芯片，兼容主流品牌手机和平板电脑等蓝牙设备。
包装清单
操作说明
●支持Ap音频解码技术，达到CD级音质。
●左右双喇叭，定向播放，真正的立体声音效。
①智能音频眼镜√ ②便携式拉链包√
③质感上下盖纸盒√ ④磁吸式充电线√
⑤产品使用说明书√
1.开/关机
2.蓝牙配对连接
①拔下充电器自动开机 。或在关机状态，同时长按左右镜腿下方按键3秒开机:
提示音“Power on”"battery level high/medium/low" 并提示“ Pairing”。
②插上充电器自动关机。或在开机状态，长按任意镜腿下方按键3秒关机；或蓝牙
断开2分钟后自动关机。提示音“Power off”。
眼镜开机后，会出现单侧镜腿红蓝灯交替快闪，表示配对完成，
若出现两侧镜腿同时红蓝灯交替快闪，需要对两镜腿进行重新配对。
打开要连接的设备蓝牙（如手机，MP3播放器，电脑等），搜索并连接蓝牙：PT01，
并自动弹出蓝牙配对窗口，点击：配对，并提示“connected”,蓝牙连接成功。
3.播放音乐
①音乐播放/暂停：单按任意镜腿下方按键。
②音乐切换上一首/下一首：左镜腿外侧触摸区域往前滑动下一首，往后滑动上一首。
⑥保修卡√
指示灯
按键开关
麦克风
磁吸式充电口
出音孔
出音孔
出音孔
充电接口
磁吸式充电器
充电接口
按键开关
按键开关
⑦眼镜布√
③音乐增减音量：右镜腿外侧触摸区域往前滑动增加音量，往后滑动减少音量。
操作方法：同时连续快按两镜腿下方按键4下。
触摸控制区

4.语音助手
6.打电话
7.充电
连续按两下任意镜腿下方按键启动语音助手，例如Siri、小艺、
小爱同学等，单按任意镜腿下方按键关闭语音助手。
①接听电话，单按任意镜腿下方按键。
②挂断电话，单按任意镜腿下方按键。
③拒接来电，长按任意镜腿外侧触摸区域3秒。
①低电报警，每隔2分钟提示一次“ Battery Level Low”；
②低电关机，提示“ Power off”；
③充电时，指示灯常亮红；充电完成，红灯熄灭。
提示
①使用本产品前请仔细阅读说明书，并保留本说明书。
②首次使用，请先将本产品充满电。
③如果产品长期（超过两周）不充电，使用前请对其充电。
④较脏的镜片不要直接擦拭，应先镜片打湿，再用眼镜布拭干。尽
量使用绒面且吸水性较强眼镜布轻轻抹拭干净，注意不要太用力。
擦拭时，眼镜布要朝着同一个方向擦拭，不能来回擦拭，也不能在
镜片上转着圈擦。
⑤当电池温度超出-10°C—60°C的时候，产品将会停止工作。
注意事项
①请勿以任何理由拆除或维修改装本产品，否则可能会导致起火，
电子击穿甚至彻底损坏本产品。
②请勿将设备置于温度过低或过高（0°C以下或45°C以上)环境下。
③请勿将产品接触液体弄湿，或浸泡在液体里。
④不能将眼镜放在阳光下长时间暴晒，否则易变形、老化、折断。
⑤请勿将充电线磁吸端靠近金属物体，防止磁吸金属物体后引起
的短路危险。
重要安全信息
●在使用本设备前， 请先阅读所有安全信息以确保正确和安全使
用。
●使用未经本制造商认可的电源，充电器或电池，可能引发火灾、
爆炸或其他危险。
●请使用本制造商认可且与此型号设备配套的配件。
●建议在温度 0°C-35°C 范围内使用本设备，
当环境温度过高或过
设备故障。
●该设备使用不可拆卸的内置电池，请勿自行更换电池，以免损坏
电池或设备。
●若充电完毕，请断开充电器与本设备的连接，并从电源插座上
拔掉充电器，连续充电时间请勿超过12小时。
●电池禁止拆卸，撞击，挤压或投入火中，若出现严重膨胀，请
勿继续使用。
●请勿置于高温环境中，电池过热可能会引起爆炸。
●请保持设备干燥。
●若设备或其他任何部件不能正常工作，请勿自行维修任何产品。
●连接其他设备时，请参考用户手册的连接方法，不要随意连接
不配套的设备。
警告
●如加油站，油库，化学仓库附近等存储有易燃易爆油气或化学
品的环境，严禁使用设备。
●请勿在医院手术室、急诊室、深切治疗部等场所使用此设备；
为避免干扰医疗仪器工作，使用此设备时请远离心脏起搏器、助
听器、植入耳蜗等医用设备，请保持此设备和起搏器之间超过15
厘米的距离。
●若要在个人医疗设备附近使用此设备，请咨询医师和设备制造
商。
●请遵守有关驾车时使用此设备的所有安全警告和规定。
●雷雨天气时，为避免雷击事故，请勿在室外使用。
●请勿在浴室等高湿度的地方使用充电器，否则会导致触电,人
身伤害，起火和充电器损坏。
●请遵守在任何环境里明确禁止使用的相关法律规定。
为避免听力受损,请勿长时间使用高音量。
请遵循相关法律法规,不要在以下环境使用。
低时，可能会引起
⑥请勿用酒精擦拭本产品，以免发生化学反应。
5.拍照录像(苹果系统不支持)
单按任意镜腿下方按键拍照或开始录像，再次单按停止录像。

Statement
Model name
Product characteristics
Thank you for using our products. Please read the manual
before use. The manual might change because of hardware
or software update.
PT01 eyewear with open directional audio, this product is
a bluetooth glasses with stereo super mini speakers, easy
operation, easy carrying.
Temple color Black
Temple material TR
Lens material Nylon or Polarized,etc.
Bluetooth 5.0
Charging time 120min
Battery capacity 110mAh for each temple
Charging voltage DC 5v, Not compatible with quick
charge,Max charging current 1A
Speakers Dual stereo speakers
*Actions ATS3015, compatible with mainstream brands of
mobile phones, tablets and other bluetooth devices.
1.How to switch on/switch off
2.How to connect
1)switch on the device: when charging, unplug the charger,
it will switch on automatically. Or when it's off, press the
buttons under both temples for 3 seconds to turn it on.By
hearing“Power on”, then accompanied with"battery level
high/medium/low"“Pairing”, your device is on.
2)Switch off: Plug in the charger, the device will be off auto-
matically. Or when the device is on,by press the button under
either temple for 3 seconds; or by disconnect the bluetooth
hearing“power off”,the device is now switched off.
Swith on the device, then the left and right temples start pairing,
red and blue lights on one temple flash alternately. when pairing
is completed,lights are off.
1)Turn on the Bluetooth of the device to be connected，(such as
mobile phones, MP3 players, computers,etc.), search for and
connect to Bluetooth: PT01.
2)And it will automatically pop up the Bluetooth pairing window,
click: pair, and prompt "connected", the Bluetooth connection is
then successful.
3.How to operate
1)Play/pause music: press once the button under either temple
4)Voice control: press twice the button under either temple to wake
up voice assistant, such as Siri. press once to turn it off.
5)Take photos and videos(not supported by Apple): press once either
7)Reject incoming call: Long touch the touch area on the outside of
either temple for 3 seconds.
6)Answer/Hang up call: press once the button under either temple
4.About charging
1)Low battery alarm: you will hear indicating tone“Battery Level
Low”every 2 minutes.
2)when device is run out of power, it will prompt ”Power off”
automatically.
3)When charging, the indicator light is always red; when fully
charged, the red light goes out.
Packing list
Instructions
●Support AptX audio decoding technology, achieve CD-level
sound quality.
●Left and right speakers, audio directed all around you, to
give you real stereo sound effect.
No. 1 Smart Eyewear *1 No. 2 Zipper Case *1
No. 5 User Manual*1
No. 4 Charging Cable*1
No. 3 Paper Box*1
No. 6 Warranty Card*1
indicator
button
microphone
charging ports
speaker
speaker
speaker
charging ports
magnetic charger
charging ports
button
button
No. 7 Cleaning Cloth*1
so the device will switch off in 2 minutes automatically. By
In case the red and blue lights on BOTH temples flash alternately,
need to re-pairing the temples by fast pressing 4 times the buttons
under both temples simultaneously.
2)Previous/next song: slide the touch area on the outside of the
left temple:move forward to the next song, and move backward
to the previous song.
3)Increase/decrease the volume of sound: slide the touch area on
the outside of right temple: move forward to increase the volume,
and move backward to decrease the volume.
touch control area
button to take photos or start recording,press once to stop recording.

Noticement
1)Please read the user manual carefully before using this
product and keep this manual well.
2)For the first time use, please fully charge the product.
3)If the product is not charged for a long time(more than
two weeks), please charge it fully before use.
4)Use cleaning cloth inside the pouch to clear up the dirty
lens. Other cloth might damage your lens.
5)when the battery temperature exceeds -10°C - 60 °C
, the
protuct will automatically shut down.
Matters needing attention
1)Do not unassemble and repair the product for any reason,
otherwise it might cause fire, electronic breakdown or even
complete damage to the product.
2)Do not put the equipment in an environment with too low
or too high temperature(below 0°C or above 45
°C ).
3)Do not put the product under water or other liquid or
humid environment.
4)Do not expose your device in the sun for long time, other-
wise they will be easily deformed, aged and broken.
5)Do not put charger's magnetic suction close to any metal.
Important safety information
●Before using the device, please read all safety informa-
tion to ensure correct use and safe use.
● Use of power supply, chargers or batteries not certified
by the manufacturer may cause fir and explosion or other
hazards.
●Please use the accessories approved by the manufactur-
er and compatible with this type of equipment.
●Please use the equipment within the temperature range
of 0-35 °C.
When the temperature is too high or too low,
it may cause equipment failure.
●The device use a non-removable built-in bettery, do not
replace the battery to avoid damage.
●After fully charged, disconnect the charger from the
device and unplug the charger from the power socket. Do
not charge for more than 12 hours.
● Do not disassemble battery, or bump, squeeze or put the
battery into the fire. If serious expansion occurs, please do
not continue to use.
●Do not put in a high temperature environment, battery
overheating may cause explosion.
●Please keep theequipment dry.
●Do not repair the product by yourself when it cannot work
properly.
●When connecting other devices,please refer to the user
manual for the connection method,do not arbitrarily con-nect
to the equipment that does not match.
Warning
For example, gas stations, oil warehouses, chemical ware-
house and other places where inflammable and explosive
oil and gas or chemicals are stored are prohibited to use
the equipment.
●Do not use the equipment in the operating room, emer-
genry room, intensive care department, etc.
In order to avoid interference the medical devices, please
keep the device away from pacemaker. Please keep at least
15 centimeters distance from the pacemaker.
● If need to use this device near a personal medical device,
consult a physician and device seller.
●Please comply with all safety warnings and regulations
regarding the use of this device while driving.
●Do not use outdoors in thunderstorm, to avoid lightning
strike.
●Do not use the charger in the bathroom where there is
high humidity, or it will lead to electric shock, personal
injury, fire and charger damage.
● Please comply with the relevant laws that clearly prohibit
use in any environment.
To avoid hearing loss, do not use high volume
for a long time.
Please follow the relevant laws and regulations,
do not use in the mentioned environment below. 数字你的视界
Accompanied your eyes
Digital your life
MADE IN CHINA
6)Do not wipe the device with alcohol to avoid chemical reactions

产品三包凭证
三包条例
属于下列情况之一不实行三包
真诚地感谢您购买本产品!
为了更好地享受“三包”权益，请您购买产品后妥善保管
购买发票及三包凭证。购买发票及三包凭证需填写完整正
确。
在三包有效期内，因产品本身质量问题引起的故障，凭购
买凭证和三包凭证，按三包规定将享受下列三包服务：
-自购买之日起7日内，眼镜出现性能故障，消费者可以选
择退货、换货和修理。
-自购买之日起第8日至15日内，眼镜出现性能故障，消费
者可以选择换货和修理。
-自购买之日起第16日至一年内，眼镜出现性能故障，消
费者享受免费修理。
-超过三包有效期的；
-无三包凭证及购买发票的；
-未按产品使用说明书要求使用、维护、保养而造成损的；
-非授权修理者拆动造成损坏的；
-因不可抗力造成损坏的；
-由于使用者使用不当，(如坠落、挤压、进液等)而造成损
坏的。
产品维修记录
产品型号
序号
1
2
3
故障描述 故障原因 处理情况 送修日期
购买日期
校验日期
SMART EYEWEAR
Quick guide | 快速指南
①开机
②自动配对
③连接蓝牙
拔下充电器自动开机，或同时长按左右镜腿下方按键3秒
开机，提示音“ Power on”并提示电池电量级别。
左右镜腿自动配对，红蓝灯交替快闪，配对完成灯熄灭，
提示音“咚”。
打开要连接的设备蓝牙。搜索并连接蓝牙设备:PT01
,提示“咚”并自动弹出蓝牙配对窗口，点击：配对，蓝
牙连接成功。
蓝牙
蓝牙
搜索蓝牙设备
已连接
PT01
SMART EYEWEAR
Quick guide
Turn on
Connect Bluetooth
Press the buttons under both arms for 3 seconds.when
hearing "Power on" indicates the eyewear is working.
Turn on bluetooth on your smart phone or other smart
device,search”PT01”and connect it,when hearing
“connected”,the set-up is done.
PT01 connected
Bluetooth
Bluetooth
Search for Bluetooth devices

③
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device,pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection
against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/ TV technician
for help.
Caution: Any changes or modifications to this device not
explicitly approved by manufacturer could void your
authority to operate this equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
RF Exposure Information
The device has been evaluated to meet general RF
exposure requirement. The device can be used in portable
exposure condition without restriction.
