Omcan 23835 User manual

Revised - 3/28/2016

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: [email protected]

www.omcan.com

Jerky Shooters

Items 23835, 23836

Instruction Manual

2

Page

--------------------------------------------------------------------------- 3 - 4

------------------------------------------------------------------------------- 4

-------------------------------------------------------------------------- 5

----------------------------------------------------------------------------------------- 5 - 6

----------------------------------------------------------------------------------------- 6

------------------------------------------------------------------------------- 6 - 7

-------------------------------------------------------------------------------------------- 8 - 10

---------------------------------------------------------------------------- 11

Table of Contents

Section

General Information

Safety and Warranty

Technical Specications

Operation

Maintenance

Parts Breakdown

Notes

Warranty Registration

Item 23835 / Item 23836

3

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan

and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or

negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct

operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the

machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of

the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the

external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may

initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et

Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne

ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour

utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine

ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises

manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents

d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba

Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona

inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido

entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.

Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

4

General Information

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la

caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre

los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se

muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Safety and Warranty

• Do not let children use the unit unsupervised.

• Fully read all instructions before using the unit.

• Do not have any loose jewelry, hair or clothing during the operation of this unit.

6 MONTHS PART AND LABOUR BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either

an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see www.omcan.com/warranty.html for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of

without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated

waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

5

Technical Specications

Operation

The meat should be as lean as possible. Using lean meat will help the meat dry faster and aid in cleanup

by decreasing fat drippings. Ground meat should be 80% to 95% lean. Jerky seasonings are available for

all tastes or you can be creative and make your own. Ground turkey, venison, buffalo and elk are excellent

choices for jerky. There are many books and recipes to help create your own jerky. When making jerky, you

should cure the mixture with sodium nitrate. The cure is used to help prevent botulism while drying at low

temperatures. Follow the manufacturer’s directions on the cure packet.

DIRECTIONS FOR MAKING JERKY

1. Clean the Jerky Gun thoroughly before use (See directions in “Maintenance” section).

2. Mix jerky with desired meat. Follow the directions on the seasoning mix (not included).

3. Pull the plunger back until in the full retracted position.

4. Wet hands and form a log shape with the mixture and drop log into the barrel of the jerky gun.

5. Repeat step 4 until the barrel of the jerky gun is lled 1” from the top (Note: Press mixture rmly into the

barrel to squeeze out trapped air).

6. Select a nozzle for the desired style of jerky and secure in place by screwing hold down nut clockwise until

nger tight (Note: Flat nozzle is used for jerky. Round style is used for snack sticks).

COOKING INSTRUCTIONS

1. Preheat oven to 200°F.

2. Place the drying rack on the cooking sheet (Note: The drying rack helps to decrease drying time).

3. Pull trigger repeatedly until jerky begins to extrude.

4. Place the nozzle end of the jerky gun close to the far end of the drying rack, pull trigger to extrude jerky. As

you extrude the jerky, pull the jerky gun towards you until a strip of jerky has been extruded across the full

length of the drying rack.

5. Continue extruding strips of jerky until the rack is lled. Be sure to leave a small space between strips of

jerky.

6. Place the cooking sheet and drying rack in the preheated oven (Approximate drying time for one rack of

jerky is 75 minutes).

7. Remove rack from oven and turn jerky over.

8. Return rack and jerky to oven for additional 60 minutes.

9. Check for desired dryness. If jerky is not dry enough, replace rack and jerky to oven and check at 5 minute

Item Number 23835 23836

Material Aluminum Plastic

Chamber Dimensions 13.25” x 1.75” / 337 x 45mm

Packaging Dimensions 22” x 8” x 3” / 559 x 203 x 76mm

Weight 2.7 lbs. / 1.2 kgs. 2.4 lbs. / 1.1 kgs.

6

Operation

intervals until desired dryness is achieved.

10. Allow jerky to cool.

11. Place jerky in a tightly sealed bag and refrigerate.

Maintenance

DIRECTIONS FOR CLEANING

1. Unscrew the nozzle by turning the hold down nut counterclockwise.

2. Unscrew the barrel counterclockwise from the plunger assembly.

3. Clean all parts with warm soapy water. Dry all pieces thoroughly.

4. Reassemble the jerky gun and store for next usage.

Parts Breakdown

Item 23835

Item No. Description Position Item No. Description Position Item No. Description Position

74518 Screw for BR131 1 74525 Plastic Washer for BR131 8 74532 Nut GB/T923 M6 for BR131 15

74519 Handle Plate for BR131 2 74526 Hand Screw for BR131 9 74533 Barrel for BR131 16

74520 Small Spring Washer for BR131 3 74527 Knob of Lid for BR131 10 74534 Flat Nozzle for BR131 17

74521 Small Spring for BR131 4 74528 Rod for BR131 11 74535 Washing Brush for BR131 18

74522 Big Spring Washer for BR131 5 74529 Nut GB/T6170 M6 for BR131 12 74536 Round Nozzle for BR131 19

74523 Big Spring for BR131 6 74530 Washer for BR131 13

74524 Trigger for BR131 7 74531 Piston for BR131 14

Item 23836

Item No. Description Position Item No. Description Position Item No. Description Position

74500 Screw for BR135 1 74506 Trigger for BR135 7 74512 Washer for BR135 13

74501 Handle Plate for BR135 2 74507 Plastic Washer for BR135 8 74513 Piston for BR135 14

74502 Small Spring Washer for BR135 3 74508 Hand Screw for BR135 9 74514 Nut GB/T923 M6 for BR135 15

74503 Small Spring Washer for BR135 4 74509 Knob of Lid for BR135 10 74515 Barrel for BR135 16

74504 Big Spring Washer for BR135 5 74510 Rod for BR135 11 74516 Flat Nozzle for BR135 17

74505 Big Spring for BR135 6 74511 Nut GB/T6170 M6 for BR135 12 74517 Round Nozzel for BR135 18

7

Parts Breakdown

Item 23835

Item 23836

8

Notes

________________________________________________________________________________________

9

Notes

________________________________________________________________________________________

10

Notes

________________________________________________________________________________________

11

Warranty Registration

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,

cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la

carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

OMCAN INC.

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

www.omcan.com/warrantyregistration.html

Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):



Por correo en Canadá

Pour postale au Canada

For mailing in Canada

Por correo en los EE.UU.

Pour diffusion aux États-Unis

For mailing in the US

OMCAN

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

Niagara Falls, New York

USA, 14305

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North

American food service industry. Our success over these many years can be attributed to our commitment

to strengthen and develop new and existing relationships with our valued customers and manufacturers.

Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 3,500 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et

matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces

nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles

et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en

Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et

développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 3500

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros

de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir

a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos

clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan

continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor

excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un

fácil acceso a más de 3,500 productos con origen a nivel mundial.

Omcan 23835 User manual

Popular Kitchen Appliance manuals by other brands
