Omcan Ts-it-0110-s User manual

Revised - 09/08/2020

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: [email protected]

www.omcan.com

Tomato Squeezers

Models TS-IT-0110-S, 0110-M, 0110-L

Items 18901, 18902, 18903

Instruction Manual

2

Page

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 5

-------------------------------------------------------------------------- 6

--------------------------------------------------------------------------------------------- 6

----------------------------------------------------------------------------------------- 7

----------------------------------------------------------------------------- 8 - 10

---------------------------------------------------------------------------- 11

------------------------------------------------------------------------------------------- 12 - 14

---------------------------------------------------------------------------- 15

Table of Contents

Section

General Information

Safety and Warranty

Technical Specications

Operation

Maintenance

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

Model TS-IT-0110-S / Model TS-IT-0110-M / Model TS-IT-0110-L

3

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan

and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or

negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct

operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the

machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of

the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the

external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may

initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save

these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et

Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne

ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour

utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine

ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises

manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents

d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

4

Safety and Warranty

General Information

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the

following:

1. Read all instructions.

2. To protect against risks of electrical shock do not put in water or other liquid.

3. Close supervision is necessary when any appliance is used by or near children.

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations

et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba

Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona

inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido

entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.

Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la

caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre

los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se

muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para

salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5

Safety and Warranty

4. Unplug from outlet when not in use and before putting on or taking off parts and before cleaning.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug or after the appliance malfunction, or if it

is dropped or damaged in any manner. Call Omcan to arrange the examination, repair or electrical or

mechanical adjustment.

7. The use of attachments not recommended or sold by Omcan may cause re, electric shock or injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter.

10. Never feed food or dough by hand. Always use food pusher.

11. Blades are sharp. Handle carefully.

12. Do not use ngers to scrape food away from discharge disc while appliance is operating. Cut type injury

may result.

13. This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety.

14. Acoustic level less than 60 dBA.

1 YEAR PARTS AND LABOUR BENCH WARRANTY

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either

an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see https://omcan.com/disclaimer for complete info.

WARNING:

The packaging components are classied as normal solid urban waste and can therefore be disposed of

without difculty.

In any case, for suitable recycling, we suggest disposing of the products separately (differentiated

waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6

Operation

TOMATO SQUEEZER UNIT

All numbers refer to the “Parts Breakdown” section of the manual.

Tomato squeezer propeller made in acetal resin suitable for food contact, body in cast iron tested for foodstuffs

and treated with epoxy paint for foodstuffs. Nylon tow pin inserted on tin-plated steel. Filter cone, funnel and

drip pan are entirely made of 18/10 stainless steel.

For space requirements, the machine is partially disassembled in the packing; it is necessary to insert the

tow pin with the spring into the hole in the cast iron body (9). Insert the propeller (10) into the cast iron body

tting it onto the square of the tow pin. Then put the lter cone (11) onto the propeller pressing and turning it

counterclockwise to t the tabs of the ring nut into the niches in the cast iron body. Screw the funnel (8) onto

the threaded neck of the cast iron body and hook the drip pan (12) onto the lter cone and onto the cast iron

casing by means of the clips. The machine is then ready for use: the machine must denitely not be run dry

(with no tomato).

If the propeller (10) jams, before taking any further action on the machine put the switch onto the “OFF” (-0-)

position and unplug from the electrical socket. When the work is nished, unscrew the funnel (8), unhook the

drip pan (12), turn the lter cone (11) clockwise to remove the propeller (10) and the tow pin with the spring.

Remove the cast iron casing (9) from the reduction gear cover (6), then wash, carefully dry and eventually

grease all the parts that have come into contact with the food.

Technical Specications

Single-phase asynchronous electric motor for continuous service 500 W. Fan cover cap, switch/capacitor box

and cooling fan made in plastic material. Watertight IP X5 motorization. Axial reduction gear in oil bath. Long-

life oil suitable for occasional food contact.

Model TS-IT-0110-S TS-IT-0110-M TS-IT-0110-L

Power 0.3 HP / 0.22 kW 0.4 HP / 0.3 kW 0.8 HP / 0.6 kW

Worm RPM 110

Electrical 115V / 60Hz / 1

Weight 20 lbs. / 9 kgs. 31 lbs. / 14 kgs. 40 lbs. / 18 kgs.

Packaging Weight 21 lbs. / 10 kgs. 37 lbs. / 17 kgs. 43 lbs. / 20 kgs.

Dimensions 20.5” x 9.5” x 14”

521 x 241 x 356mm

27” x 12” x 13”

686 x 305 x 330mm

28” x 11.5” x 17”

711 x 292 x 432mm

Packaging Dimensions 16” x 9” x 11”

406 x 229 x 279mm

21” x 12” x 13”

553 x 305 x 330mm

21” x 12” x 13”

533 x 305 x 330mm

Item Number 18901 18902 18903

7

Maintenance

• Before carrying out assembly, disassembly, die plate replacement and cleaning operations, switch off the

motor and unplug the unit from the electrical socket, to avoid risks of electric shock.

• After every use disassemble, wash and dry all press parts carefully.

• In case of blockage of the press, disconnect the plug cable from the socket immediately to avoid risks of

damage the machine.

• Close supervision is required when this product is used near children.

REFERENCE

Item Number Model Number Description Manufacturer Model Number

18901 TS-IT-0110-S

Tomato Squeezer 110 RPM

0.3 HP / 224 W 115V/60/1 cTUVus

with 5/8” Hub

9107N

18902 TS-IT-0110-M

Tomato Squeezer 110 RPM

0.4 HP / 298 W 115V/60/1 cTUVus

with 1” Hub

9103N

18903 TS-IT-0110-L

Tomato Squeezer 110 RPM

0.8 HP / 597 W 115V/60/1 cTUVus

with 1” Hub

9101N

8

Parts Breakdown

Model TS-IT-0110-S 18901

Model TS-IT-0110-M 18902

Model TS-IT-0110-L 18903

Motor

9

Parts Breakdown

Model TS-IT-0110-S 18901

Model TS-IT-0110-M 18902

Model TS-IT-0110-L 18903

10

Parts Breakdown

Model TS-IT-0110-S 18901

Model TS-IT-0110-M 18902

Model TS-IT-0110-L 18903

Item No. Description Position Item No. Description Position Item No. Description Position

70082 Electric Motor for 9008N 1 70089 Pestle for 9008N 7 24615 Joint and Spring for 9008N 13

70083 Reduction Gear Flange for 9008N 2 70090 Funnel for 9008N 8 70096 Reduction Gear Cover Oil Seal for

9008N 14

70084 Small Gear for 9008N 3 70091 Cast Iron Casing for 9008N 9 70097 Reduction Gear Internal Seal for 9008N 14A

70085 Twin Gear for 9008N 4 - 5 24616 Propeller for 9008N 10 70098 Base for 9008N 15

40628 Rubber Cap Red for 9008N 5A 24612 Filter for 9008N 11 70099 Splash Guard for 9008N 16

70088 Reduction Gear Cover Black for 9008N 6 70094 Drip Pan for 9008N 12 39340 Rubber Gasket for 9008N

Item No. Description Position Item No. Description Position Item No. Description Position

70063 Electric Motor for 9004N 1 70071 Funnel for 9004N 8 70077 Reduction Gear Cover Oil Seal for

9004N 14

70064 Reduction Gear Flange for 9004N 2 71446 Cast Iron Body for 9004N 9 70078 Reduction Gear Internal Seal for 9004N 14A

27858 SER Gears for 9004N 3 - 5 24596 Worm for 9004N 10 70079 Base for 9004N 15

40628 Rubber Cap Red for 9004N 5A 24611 Filter for 9004N 11 70062 Splash Guard for 9004N 16

70069 Reduction Gear Cover for 9004N 6 44746 Drip Pan for 9004N 12 39339 Rubber Gasket for 9004N

70052 Pestle for 9004N 7 24614 Joint and Spring for 9004N 13

Item No. Description Position Item No. Description Position Item No. Description Position

70045 Electric Motor for 9000N 1 70071 Funnel for 9000N 8 27857 Gear Cover Oil Seal for 9000N 14

70046 Reduction Gear Flange for 9000N 2 70054 Cast Iron Casing for 9000N 9 70060 Reduction Gear Internal Seal for 9000N 14A

27858 SER Gears for 9000N 3 - 5 24596 Worm for 9000N 10 70061 Base for 9000N 15

40628 Rubber Cap Red for 9000N 5A 24611 Filter for 9000N 11 70062 Splash Guard for 9000N 16

70051 Reduction Gear Cover for 9000N 6 44746 Drip Pan for 9000N 12 39339 Rubber Gasket for 9000N

70052 Pestle for 9000N 7 24614 Joint and Spring for 9000N 13

11

Electrical Schematics

Model TS-IT-0110-S 18901

Model TS-IT-0110-M 18902

Model TS-IT-0110-L 18903

12

Notes

________________________________________________________________________________________

13

Notes

________________________________________________________________________________________

14

Notes

________________________________________________________________________________________

15

Warranty Registration

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,

cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la

carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

https://omcan.com/warranty-registration/

or email to: [email protected]

Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No



Por correo en Canadá

Pour postale au Canada

For mailing in Canada

Por correo en los EE.UU.

Pour diffusion aux États-Unis

For mailing in the US

OMCAN

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

Niagara Falls, New York

USA, 14305

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North

American food service industry. Our success over these many years can be attributed to our commitment

to strengthen and develop new and existing relationships with our valued customers and manufacturers.

Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 5,000 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et

matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces

nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles

et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en

Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et

développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros

de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir

a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos

clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan

continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor

excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un

fácil acceso a más de 5,000 productos con origen a nivel mundial.

Omcan TS-IT-0110-S User manual

Popular Kitchen Appliance manuals by other brands
