Omega Altise OAGCH15 User guide

OPERATION, MAINTENANCE
AND SAFETY INSTRUCTIONS
Model - OAGCH15 and OAGCH25
Gas Convection Room Heater

2
IMPORTANT SAFETY INSTRUCTIONS
The OMEGA ALTISE gas space heaters are an automatically operated, portable convection heater for use with
Natural gas or Universal LPG.
The heater is supplied with an approved flexible hose.
Note: A label is attached to the rear of the heater stating the type of gas for which it has been manufactured
and adjusted.
The heater shall be installed in accordance with the manufacturer’s instructions, local gas fitting
regulations, uniform building regulations, municipal building codes, AS/NZS 5601 installation code for gas
burning appliances and equipment and any other relevant statutory regulations.
The heater is intended to be installed as a free standing portable unit, its portability being restricted by
the number of gas outlet points being provided.
DO NOT INSTALL IN A FIREPLACE
Special room ventilation may apply in your particular state. If in doubt, contact your local gas authority.
Locations where strong drafts occur should be avoided as they may cause unsatisfactory operation of the
heater.
The heater should be installed at least 1 meter away from flammable materials, e.g. curtains, and to be
150mm clear of sidewalls.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
Children should be supervised to ensure that they do not play with the appliance.
SERVICING SHALL ONLY BE CARRIED OUT BY AUTHORIZED PERSONS
If the supply cord is damaged, DO NOT use the appliance, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
NOT TO BE CONNECTED TO A L.P.G GAS CYLINDER LOCATED INDOORS
ELECTRICAL AND GAS CONNECTION MUST BE MADE AS PER LOCAL WIRING AND GAS INSTALLATION
REGULATIONS.
DO NOT DISCONNECT THE APPLIANCE WITH WET HANDS OR BARE FEET
DO NOT DISCONNECT THE POWER CORD WITH EXTREME FORCE
TO BE INSTALLED BY AN AUTHORIZED PERSON IF CONNECTING TO FIXED CONSUMER PIPING
WHERE THIS APPLIANCE IS BEING CONNECTED TO AN EXISTING GAS SUPPLY OUTLET FOR THE FIRST
TIME, IT IS RECOMMENDED THE CONNECTION IS MADE BY A LICENSED/AUTHORISED PERSON AND
THE SUPPLY PRESSURE IS VERIFIED FOR THE GAS TYPE.
DO NOT place articles on or against this appliance.
DO NOT use or store inflammable materials near this appliance.
DO NOT spray aerosols in the vicinity of this appliance while it is in operation.
DO NOT use this appliance in a marine environment.
DO NOT modify this appliance.
DO NOT use this appliance outdoors.
DO NOT sit on the heater.
DO NOT put articles such as paper into the louvers of the heater
DO NOT cover the heater or place articles like clothes or blanket on the heater.
DO NOT place articles in front of the louvers, or it can cause damage or a fire.

3
NOTE:
This appliance has been fully function tested prior to packaging.
No adjustment is required or available to the user.
No installation is required apart from connection to gas and electrical supplies. (Fig. 1)
IMPORTANT SAFETY INSTRUCTIONS
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS NEAR THIS
APPLIANCE
DO NOT OPERATE WITH PANELS, COVERS OR GUARDS REMOVED FROM THIS APPLIANCE
DO NOT OPERATE IN A BATHROOM OR BEDROOM
DO NOT OPERATE IN AN UNVENTILATED ROOM
DO NOT OPERATE IN A ROOM WITH A VOLUME LESS THAN THAT SHOWN IN THE TABLE
BELOW
DO NOT CONNECT TO AN U.L.P GAS CYLINDER LOCATED IN DOORS
MINIMUM ROOM SIZE PER MODEL
MODEL
OAGCH25 (25MJ/h)
OAGCH15(15MJ/h)
ROOM VOLUME (NG or ULPG)
37.5m3
62.5m3
DO NOT spray aerosols near this heater while it is in use. Most aerosols contain butane gas which can be a fire
hazard if used near this heater when it is in operation.
DO NOT get the remote controller wet or expose it to direct sunlight. DO NOT place containers of liquid on the
appliance. Water spillage can cause extensive damage to the appliance and create an electrocution hazard.
DO NOT unplug the heater while it is in operation or while the fans are still cycling, or it may damage the
appliance.
DO NOT unplug the power when turn off the heater after use. The fan will keep cycling for 3 minutes until stop.
DO NOT move the heater while it is in operation or while the fans are still cycling.
When the heater is operated for the first time or after long periods of non use a slight odour may be emitted, this is
normal. However if the odours persist after switching off the appliance, please contact the service center.

4
GENERAL HEATER LAYOUT
CONTROL PANEL FUNCTIONS
1. Control Panel
2. ON/OFF Button
3. Handle
4. Remote control IR Receiver
5. Warm Air Outlet
6. Remote control IR Receiver
7. Gas Inlet Connector
8. Temperature Sensor
9. Power Cord
10. Air Filter
11. Power Cord Storage
12. Economy Button
13. Off Timer Set Button
14. Current Room Temperature/Hour Display
15. Minute Digit Display
16. Child Lock Icon
17. Boost Mode Display
18. Set Temperature Display
19. Combustion Condition Display
20. Increase Button
21. Boost Mode Button
22. Auto Mode Button
23. On Timer Setting Button
24. Child Lock Function
25. Room Temperature Icon
26. ECO Display icon
27. ON Timer Icon
28. OFF Timer Icon
29. Set Temperature Icon
30. AUTO Mode Icon
31. Decrease Button
32. ON/OFF Button

5
REMOTE CONTROL FUNCTIONS
Refer to the rating label attached to the rear of each appliance, the gas supply data as well as
the gas type for which the heater has been tested and adjusted for is shown.
OAGCH15 OAGCH25
33. LCD Display
34. ON/OFF Button
35. Increase/Decrease
36. Operating Mode
37. Timer Function ON/OFF
38. Child Lock
39. Battery Compartment
GAS SUPPLY DATA
Gas Type NG ULPG
Nom. Gas Consumption (MJ/h) 15 15
Test Point Pressure (kPa) Boost Mode 0.97 1.38
Main Burner Injector (mm) 1.72 1.2
ODS Injector (mm) 0.3 0.2
Gas Type NG ULPG
Nom. Gas Consumption (MJ/h) 25 25
Test Point Pressure (kPa) Boost Mode 0.97 1.05
Main Burner Injector (mm) 2.2 1.66
ODS Injector (mm) 0.3 0.19
The OAGCH15 is recommended to heat a room area of 52m2 and the OAGCH25 up to 90m2.

6
INSTALLATION INSTRUCTIONS
GAS SUPPLY
Your heater is fitted with a flexible hose and bayonet coupling which enables you to connect or disconnect
it from the gas supply.
ONLY USE THE HEATER WITH THE CORRECT GAS TYPE IT WAS DESIGNED AND ADJUSTED TO.
IF IN DOUBT, CHECK WITH YOUR LOCAL GAS SUPPLIER.
CONNECTING TO GAS SUPPLY
TO DISCONNECT
Apply firm forward pressure to the knurled area, rotate anti clockwise and pull towards you. The hose
should now come away from the wall bayonet fitting. Gas is automatically isolated when the hose is disconnected.
ELECTRICAL SUPPLY
Your heater is fitted with a power supply lead, which should be connected to a standard earthed domestic socket
outlet.
ABNORMAL OPERATION
As the heater heats up or cools down, expansion or contraction takes place and the occasional
‘click’ may be heard. This is normal, however, continuous metallic noises, grinding sounds, the smell of
gas or any of the symptoms listed on the fault finding chart should be investigated immediately. Turn the
appliance off and disconnect the gas and electrical supplies. If the fault cannot be fixed or any doubts
exist, contact your nearest OMEGA ALTISE service agent or contact OMEGA ALTISE on the telephone
number on the rear page of this booklet.
NOTE:
When using the appliance for the first time or after long periods of disuse or storage, ignition may not occur the first
time it is operated as there may be air within the gas supply line. If ignition does not occur after approximately
12 seconds the unit will cease operation automatically and may show an error code E2 or E12. If this occurs press the
ON/OFF button twice to restart. For models that are equipped with a remote control, press the OFF button and then
press the ON button to restart.
If the error continues to occur after 2-3 attempts, consult the troubleshooting guide on page 11
The bayonet plug on the factory fitted flexible hose simply
plugs into your home bayonet fitting by pushing and
rotating 1/4 turn clockwise.

7
OPERATING INSTRUCTIONS
TURNING ON THE HEATER
After the gas and power have been connected and the heater turns to standby mode, press the ON/OFF
button to turn on the heater.
Press the ON/OFF button again to turn off the heater after use. The fan may keep cycling for 3 minutes until cooled
down. DO NOT move nor unplug the heater while the fan is still cycling.
DEFAULT OPERATION
When turning on heater, the initial default operation mode is “AUTO”, and default set temperature is 20°C.
The display ON/Combustion indicator icon and “AUTO” mode indicator icon light up.
SET TEMPERATURE ADJUSTMENT
The set temperature may be raised or lowered by use of the INCREASE and DECREASE buttons.
For models that are equipped with a remote control the increase and decrease buttons may also be used.
Temperature setting adjusts between 16ºC to 30º C in 1ºC steps.
AUTO MODE
The default working mode is Auto mode, or you may press the “Auto” button to turn on the Auto mode after turning on
the heater. Under this mode, the heater outputs its maximum power then it turns to Economic mode automatically, when
the set temperature is reached.
BOOST MODE
When the heater is turned on, press the Boost Mode button to turn on boost heating mode, the display boost
mode icon will light up. Under this mode, the heater outputs maximum power. The combustion process will cut off when
the room temperature reaches the set temperature, and will re-start with maximum output when the room temperature is
2ºC less than set temperature.
ECO MODE
While the heater is on, press the “Eco” button to turn on the Economic Mode. Under this mode, the heater operates
with a reduced output power. The combustion process will cut off when the room temperature reaches the set tempera-
ture, and will re-start with reduced output when the room temperature is 3ºC less than set temperature.
CHILD LOCK
While the heater is on, press the “ON Timer” and “OFF Timer” buttons together for more than 3
seconds to activate the child lock. Once the lock function is on, the child-lock indicator icon lights up on display.
Except for the ON/OFF button, all other buttons are invalid. Press the ON/OFF button under lock function, the heater
turns off and display shows “--:00 ---“, and all the buttons become invalid.
To deactivate the child-lock, press the “ON Timer” and “OFF Timer” buttons together for more than 3 seconds again,
then the child-lock display indicator icon extinguishes and the lock function is off. All the buttons will return to normal
operation.

8
OPERATING INSTRUCTIONS
ON TIMER FUNCTION
With the heater in standby mode, press the ON Timer button , the ON Timer indicator icon lights
up, and timer indicator shows “00:00”, and the hour clock indicator will flash. Press or buttons
to set the hour portion of the clock. Each press of the “UP” or “DOWN” button will increase/decrease by 1 hour.
The hour clock setting range is 0-23 hours. Then press the “ON Timer” button again to confirm the hour setting and
the minute timer portion will start to flash setting. Each press of “UP” or “DOWN” button will increase/decrease
by 5 minutes. The minute clock setting range is 0-55. Then press the ON Timer button again or wait for more than
10 seconds, the ON Timer is set and will remain in the memory. Timer indicator stops flashing and begins to count
down. The heater turns on automatically when the timer reaches “00:00”.
To cancel the ON timer function, press and hold the ON Timer button for 5 seconds and this will cancel the timer
setting and erase the memory, display clock indicator will return to “00:00”.
OFF TIMER FUNCTION
While the heater is on, press the OFF Timer button , the OFF Timer indicator icon lights up, and
timer indicator shows “00:00”, the hour clock indicator will flash. Press or buttons to set the
hour portion of the clock. Each press of “UP” or “DOWN” button will increase/decrease by 1 hour. The hour clock
setting range is 0-23. Then press the “OFF Timer” button again to confirm the hour setting and the minute portion of
the timer will start to flash. Each press of “UP” or “DOWN” button will increase/decrease by 5 minutes. The minute
clock setting range is 0-55. Then press the OFF Timer button again or wait for more than 10 seconds, the OFF Timer
is set and will remain in the memory. Timer indicator stops flashing and begins to count down. The heater will turn
off automatically when the timer reaches “00:00”.
To cancel the OFF timer function, press and hold the OFF Timer button for 5 seconds and this will cancel the timer
setting and erase the memory, display clock indicator will return to “00:00”.

9
MAINTENANCE
The heater needs maintenance, and the following information will help you to keep it looking good and working
efficiently.
It is recommended that this appliance be inspected and serviced every year.
Particular attention should be placed on inspection and cleaning of the rear air filter. This should be checked at
least once a month.
Always unplug the heater before cleaning.
All parts of the heater can be cleaned by using a soft, damp cloth.
DO NOT use solvents to clean any parts.
REMOVING AND CLEANING THE FILTER
Filters require cleaning at least once a week during the heating season
to prevent blockages.
Remove the screws (store the screws in a safe place)
Lift up the filters carefully to remove it from locating tabs.
Remove any dust or lint from the filters with a vacuum cleaner.
Put the filters back into position and fix it with screws.
If the power supply cord or any other components of the heater are damaged, they must be replaced by the manu-
facturer or a suitably qualified person.
Any service or repair work should only be carried out by an authorized person. Service calls for general cleaning,
maintenance and wear and tear are not necessarily covered under the warranty. Service calls of this nature may be
chargeable.
Faults caused by insufficient gas supply, gas quality, installation errors or operation errors are not covered by the
warranty

10
TROUBLE SHOOTING
Use the following chart to help determine whether a service call is required. However if you are unsure about the way
your heater is operating, contact OMEGA ALTISE or your local service agent.
