Installation
CAUTION:
1. INCORRECT ELECTRICAL CONNECTIONS CAN, IN CERTAIN CIRCUMSTANCES, DESTROY THE ELECTRONIC OUTPUT
CIRCUIT.
2. BEFORE APPLYING ELECTRICAL POWER, MAKE SURE THE SUPPLY VOLTAGE IS TO THE CORRECT RATING.
3. THIS AVERY SENSITIVE SENSOR. ONLY APPLY PRESSURE WITHIN THE PRESSURE RANGE.
Mounting
Two M5 threaded holes in the base of the sensor provide mounting points.
Note: The screws must not enter the holes more than 0.472" into the sensor body.
The installed position of the sensor should be away from sudden temperature variations,
shocks and vibrations and should not be close to strong electromagnetic fields
(transformers, motors etc.). The sensor can be mounted in any position, but mounting at
an angle may require zero adjustment.
terminal
block zero adjustment (fine)
zero adjustment
(coarse)
span adjustment
cable gland
Internal detail
Electromagnetic Interference
To avoid electrical interference, use shielded cable with the shield connected to the earth
ground at both ends. The ground of the sensor can be the casing or the ground terminal
screw.
Electrical Connections
PX838 Series (current output)
The maximum allowable load resistance is calculated to
formula: R Max = 0.05 (V supply - 10) kW
Where: R Max in kWand V in Volts
Minimum load 2kW
Note: Connections 5 and 6 are common.
If the output cable passes through an area of electrical
disturbance, use a recommended load impedance of
between 2 kWand 10 kW. Connect the load resistance
between the wires corresponding to signal and - terminal at
a point furthest from the sensor; this produces a circulating
current.
PX838 Series (Unidirectional voltage output)

PX838 Series bidirectional operation using
bipolar power supply (±12Vdc) with bidirectional
output (0±5 Vdc or 0±2.5 Vdc)
SIGNAL0
Purging or de-gassing the sensor
Two 5 mm hexagonal socket bleed screws are located on the outer casing and can be
loosened to bleed the two pressure connections. Make sure that these screws are
tightened after this operation.
Note: It is possible to changeover the bleed screws and pressure connections enabling
easier access or for installation in a difficult position.
Adjustments
The following equipment is required to carry out the adjustments:
rPower supply
rVoltmeter or
rMilli-ammeter
rPressure standard
uConnect the sensor as shown in Installation. The sensor should be put in its normal
operating position (vertical or horizontal). Remove the cover to gain access to the zero
and span adjustment potentiometers.
Zero adjustment
uZero adjustment is carried out with no pressure applied.
uDepending on the model, set the zero adjustment to: 0.00 V, 2.50 V, 4.00 mA or 12.00 mA
Span adjustment
uSpan adjustment is carried out with the required span pressure applied to the +
pressure connector.
uDepending on the model, set the span adjustment to: 5.00 V, 10.00 V or 20.00 mA.
uRelease the pressure.
Completion
Check the output at zero pressure and if necessary, repeat the zero and span adjustments.
rRelease the pressure and disconnect the equipment.
rRefit the cover.
Specification
Pressure range:..........................................................................................4inH2Oto±150 psid
Pressure media:
X750 diaphragm Any fluids, compatible with stainless steel (316L),
X750 Inconel, 600 Inconel and viton.
Beryllium copper diaphragm Any fluids, compatible with stainless steel (316L),
beryllium copper, brass and soft solder and viton.
Accuracy:...............................................................................................................±0.25%FSBSL
(includinglinearity, hysteresisandrepeatability)
Long term stability:.....................................±0.3%over 1 year at stabilized temperature
Weight
(approximate) ...........................................................................................................3.3lbs
Dimensions.......................................................................................................................seebelow
Power supply
......................................................................................................................................10to30Vd.c.
PX838(0 to10Voutput)........................................................................................16to30V d.c.
PX838(0 to±5Voutput)................................................................................................±12Vd.c.
Dimensions
Connect the power supply to + for positive,
- for negative, and 0 for neutral; connect the output
to signal for positive and 0 for negative signal.
0.68 0.26
High
Low
Pressure Ports:
3.11 Pg7 Cable
Gland
G1/8 Female via
welded adapter
Mounting:
2xM5 holes x 0.472 DP
on 2.66 centers
Purge Ports:
High Pressure
Low Pressure
2.80
