Omega Excalibur AL-1000SH User manual

COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT INC.1997
"WE'VE GOT THE EDGE ON SECURITY"
MODEL: AL-1000SH
OWNER'S MANUAL

Page - 2
TT
TT
Table Of Contentsable Of Contents
able Of Contentsable Of Contents
able Of Contents
Note: This manual is written under the assumption that an optional door lock interface
and an auxiliary sensor are installed with your Excalibur vehicle security system.
Transmitter Features ........................................................................................4
Transmitter Operations ....................................................................................6
Arming The System Using The Transmitter ....................................................7
Passive System Arming By "Last Door Arming ..............................................8
SecuritySystemArmedAndTriggered ...........................................................9
Disarming The System Using The Transmitter..............................................10
Remote Panic Feature ....................................................................................12
Optional Trunk Release And 3rd Channel Output .........................................13
Using The Easy Valet Switch ........................................................................14
Red LED Status Indicator..............................................................................15
Electronic Siren And Flashing Lights ............................................................17
Backup Battery ..............................................................................................19
Impact And Glass Sensor With Prewarn Feature ..........................................20
ProgrammingTransmitters ............................................................................22
ProgrammableFeatures ........................................................................... 24-31
LimitedLifetimeWarranty .............................................................Back Cover

Page - 3
IntroductionIntroduction
IntroductionIntroduction
Introduction
Congratulations on your purchase of your new Excalibur security system and on
joining over 8 million people worldwide who have trusted their vehicle's security to
thedesignersofOmegaResearch&Development,Inc. Tolearnhowtooperateyour
security system, please become familiar with the following three principal user
components: the Remote Transmitter, the Red LED Status Indicator and the Easy
ValetSwitch.
The Remote Transmitter: Each security system comes with two pre-learned
transmitters, but can learn up to 4 different transmitters. The transmitter has three
buttons: one large button in the middle and two smaller buttons. This system is pre-
programmed,throughabuilt-inlearningroutine,tohavethetransmitterbuttonswork
inthefollowingconfiguration:
The large button is used to arm, disarm and panic the security system.
Thesmallleftbuttonisused,inconjunctionwiththelargebutton,tooperateremote
sensorbypass,remotechirpeliminationandremotevalet.Usedaloneitoperates
the channel #3 output.
The small right button can be used to operate the trunk release feature.
Thisadvancedtransmitterdesign,featuringSurfaceAcousticalWaveTechnology
offers almost twice as much range as conventional systems. This helps overcome
problems encountered in urban areas due to excessive amounts of interference.
Continued Next Page

Advanced System FeaturesAdvanced System Features
Advanced System FeaturesAdvanced System Features
Advanced System Features
AutomaticTransmitter VerificationTM (Patent Pending):Your Excalibur
vehicle security system is protected against a weakness shared by all other systems,
evenfactory-equippedRemoteKeylessEntrysystems:athief'sabilitytocodehisown,
unauthorized transmitter to operate your system for the purpose of stealing your
vehicle or it's contents. Note: For the first 8 hours after your new system is
installed,everytimetheignitionswitchisturned"on",thesirenwillchirprapidly
fortwo seconds. Thiswill also occur in the event ofa new transmitter code being
enteredintothesystem. Also,everytimetheignitionswitchisturned"on",theLED
Status Indicator will flash and pause for ten seconds, the number of flashes between
each pause being equal to, and confirming, the number of transmitters encoded to
operate your system. For example: two flashes and a pause indicate that only two
Page - 4
The EasyValet Switch: This switch prevents the security system from arming
during extended stopovers at service stations, valet parking, car washes, etc. The
ValetSwitchisalsousedtotemporarilyoverrideanddisarmyoursecuritysystemin
theeventyouloseyourtransmitterandtoinitiatethetransmittercodelearningprocess.
TheRedLEDStatusIndicator:Informsyouof12possibleconditionsthesecurity
system can be in and also serves as a visual deterrent to break-ins and theft.

transmitters are coded to operate your system. In the event the system alerts you to
a recent transmitter addition, or if the LED Status Indicator flashes a total different
from the number of transmitters you have programmed to operate your system, you
cannowimmediatelyreprogramyourtransmitters,effectivelyerasinganyunauthorized
transmitters.
Thepatent-pendingAutomaticTransmitterVerificationTM featureistheindustry's
first response addressing the growing problem of a professional thief defeating a
vehicle security system by coding his own transmitter to operate the system.
Previously,garagedooropenerswereduplicatedbyburglarstogainhomeentry. Now
whenyouleaveyourvehicleandkeyswithanyindividualforanyreason,youwillhave
the peace of mind of knowing that only your transmitters will operate the security
system and that no other person has coded extra transmitters to steal your vehicle.
Transmitter Code JumpingTM:Each time you transmit a code to the security
system,thetransmitterandsecuritysystemwilladvancetoanothercodetouseforthe
transmission. The Code JumpingTM Transmitter prevents a thief from using a "code
grabber"devicetorecordandplaybackatransmissionforthepurposeofdisarming
yourvehiclesecuritysystem.Pleasenotethatpressingthetransmitter'sarm/disarm
buttonmanytimeswhileitisoutofrangeofthesecuritysystemcanadvanceitscodes
beyond the range of recognition. If this occurs, simply press the arm / disarm button
afewtimestosynchronizetheCodeJumpingTMsequencebetweenthetransmitterand
thesecuritysystemcontrolmodule. Page - 5

TT
TT
Trr
rr
ransmitter Operansmitter Oper
ansmitter Operansmitter Oper
ansmitter Operationsations
ationsations
ations
Small Right Transmitter
Button- If this button is
pressed and held for 3 sec-
onds, the security system
will activate the trunk re-
lease function.
GreenLEDLight-Illu-
minates and confirms
transmissionwhenevera
button is pressed.
Small Left Transmitter
Button- If this button is
pressed and then the large
button is pressed within 3
seconds, the security system
will arm or disarm without
siren confirmation chirps. If
this button is pressed within
3 seconds after arming the
system, Auxiliary sensor #1
will be turned off and Auxil-
iary sensor #2 will only have
an instant trigger. If this but-
ton is pressed within 3 sec-
ondsafterdisarming,thesys-
tem will enter Remote Valet.
Pressing the small left trans-
mitter button may be used to
activate other optional mod-
ules through the 3rd channel
output (Example: car start-
ing equipment or power win-
dow roll up units).
Large Transmitter But-
ton- Pressing and releasing
thisbuttonwill armanddis-
arm the security system. If
the optional doorlock inter-
face is installed, the doors
will lock upon arming, and
unlock upon disarming. If
you have the optional un-
lock driver's door feature,
then upon disarming only
the driver's door will un-
lock, and if the large button
is pressed again within 5
seconds,allofthedoorswill
unlock. Pressing and hold-
ingthisbuttonfor3seconds
will "Panic" the system-
which will sound the siren,
flash the exterior and inte-
rior lights and also lock the
doors.
Page - 6

ArmingArming
ArmingArming
Arming TT
TT
The System Usinghe System Using
he System Usinghe System Using
he System Using TT
TT
Thehe
hehe
he TT
TT
Trr
rr
ransmitteransmitter
ansmitteransmitter
ansmitter
ArmingTheSecuritySystemUsingTheTransmitter:Thesecuritysystemcan
alwaysbearmedfromthetransmitterprovidedtheignitionkeyis“off”,andthesystem
isdisarmedandnotintheValet Mode. To arm the system, after youexitthevehicle
and closeall of thedoors, simply pressandrelease thelargetransmitter buttononce,
Instantlytheexteriorandinteriorlightswillflashonce,thesirenwill chirp once and
the LED Status Indicator will begin to flash confirming that the system is armed.
Further, the doors will lock and the starter interrupt relay will prevent any attempt
tostart thevehicle.Yoursecuritysystemisnowfullyarmed,andisreadyto respond
if an intrusion attempt is detected.
Arming By-Pass: Upon arming, if any sensor circuit is inoperable, that circuit
will be bypassed. For example, if the trunk is left open, you can still arm the system
normallyfromthe transmitter. Thebypassedcircuitwill automaticallybereinstated
forprotection5secondsafterthatcircuitbecomesoperative,i.e.,thetrunkisclosed.
When a triggered circuit is in a bypassed state, all other operating circuits will be
protectednormally.
SensorBy-Pass:YourExcalibursystemprovidesyouwiththeconvenientoption
of temporarily deactivating the auxiliary sensor (see page 20) without affecting any
other trigger circuit. To deactivate the auxiliary sensor, simply press and release
Page - 7 Continued Next Page

thesmalllefttransmitterbuttonwithin3secondsafterpressingthelarge transmitter
button when arming the system. You will hear a second siren chirp, confirming the
securitysystemhasarmedwithoutthesensorcircuitprotectingthevehicle.Thenext
timeyouarmthesecuritysystem,thesystemwillresettoitsnormalcondition,andthe
optional sensor will again be part of your protection.
You can also pre-select your security system to automatically arm and lock the
doors. This information is described in the following section.
Page - 8
Passive System Arming By "Last Door Arming"Passive System Arming By "Last Door Arming"
Passive System Arming By "Last Door Arming"Passive System Arming By "Last Door Arming"
Passive System Arming By "Last Door Arming"
Yoursecuritysystemcanbeprogrammedtoarmautomaticallywhenthevehicle's
last door is closed. The moment the last door closes, the siren will chirp once, the
parkinglightsanddomelightswillflashonceandtheLEDStatusIndicatorwillbegin
toflashrapidly.Thirtysecondslaterthesirenwillchirpagain,thedoorswilllock(If
thePassive Lockfeaturehasbeenchosen) andtheLEDStatusIndicatorwillslow to
asteadyflash,confirmingthatthesecuritysystemisfullyarmed.However,ifapoint
ofentryisreopenedbeforethesinglechirpat30seconds,thepassivearmingprocess
stops, and will reset to start over again when that point of entry is reclosed.
"Automatic Last Door Arming" offers a high level of security, since it does not
requireyoutoremembertoactivatethesecuritysystemwhenyouleaveyourvehicle.
Additionally,AutomaticLastDoorArmingmayentitleyoutoaninsurancediscount.
Note: Arming By-Pass (page 7) does not operate with the Automatic Last Door
Armingfeature.Thisbypassfeatureisdesignedto workonlywhen armingfromthe

transmitter, because all protected entries must be closed prior to the Automatic Last
Door Arming sequence to start. Note: To prevent the system from automatically
arming while the vehicle is being refueled you should put the system in Valet Mode
(page 14), keep your door open or turn on your dome light switch so that the system
thinksyourdoorisstillopen.Wedonotrecommendleavingyourignitionkeyturned
"on". Note: Passive last door arming does not effect the operation of active arming.
SecurSecur
SecurSecur
Security Systemity System
ity Systemity System
ity System ArmedArmed
ArmedArmed
Armed AndAnd
AndAnd
And TT
TT
Trr
rr
riggerigger
iggerigger
iggereded
eded
ed
While the security system is armed, the LED Status Indicator will be flashing.
Should any intrusion attempt occur, your system will instantly "trigger". Once
triggered, thesecurity system will respond by:
1) The electronic siren will be activated. Once activated, it will change siren
sounds every 5 seconds to attract more attention to the vehicle.
2) The exterior and interior lights will flash.
3) Thedoorswillrelock.Thisfeatureissouniquethatthesecuritysystemeven
knowswhenadoorisopenand,ifso,thesystemwaitsuntilthedoorisclosed,
atwhichtimeitrelocksthedoors,sothatthethiefcannoteasilyregainentry.
The siren and lights will stay activated for 60 seconds, unless you disarm your
systemwiththetransmitterorplacethesysteminValetMode.Ifallprotectedentries
are secure at the end of 60 seconds, the system will rearm automatically to protect
against another entry attempt. However, if there is a protected entry still open or a
Page - 9 Continued Next Page

sensor still in a triggered state at the end of the 60 seconds, the system will retrigger
fortwomore60secondcycles.Shouldthisoccurthesystemwillstopafteratotalof
3minutes,whileignoringonlytheopenentryortriggeredcircuit.Shouldtheentrybe
closed, protection will begin instantly for that circuit.
Afterthesecuritysystemhasbeentriggered,after itresetsthedisarmconfirmation
willno longerbe2chirpsand theexteriorandinteriorlightscomingon immediately
andstayingonfor 30 seconds. Instead,thesystemwillrespond by producing4siren
chirps and flashing the lights 4 times before the lights stay on for 30 seconds. Also,
the LED Status Indicator will indicate which zone activated the system. This is
accomplished by the status indicator flashing one to four times between pauses, as
defined on page 15, until the ignition key is turned "on".
DisarmingDisarming
DisarmingDisarming
Disarming TT
TT
The System Usinghe System Using
he System Usinghe System Using
he System Using TT
TT
Thehe
hehe
he TT
TT
Trr
rr
ransmitteransmitter
ansmitteransmitter
ansmitter
DisarmingTheSystemFromTheTransmitter:Whilethesecuritysystemisin
thearmedstate,pressingandreleasingthelargetransmitterbuttononcewillinstantly
disarmthesystemandunlockthedoors.If youhavetheoptionalunlockdriver'sdoor
feature,thenupondisarmingonlythedriver'sdoorwillunlock,andifthelargetrans-
mitterbuttonispressedagainwithin5secondsorwhileadoorisopen,allofthedoors
willunlock.
Disarming is confirmed by two siren chirps and the exterior and interior lights
Page - 10

turningonfor30seconds,exceptunderthefollowingconditions:1)thelightswillturn
off 10 seconds after a door has been opened, or 2) the lights will turn off instantly if
the ignition switch is turned "on". Note: If the system was triggered and reset while
you are away, the disarm confirmation will change to 4 siren chirps, 4 light flashes,
andthenthelightswillstayonfor30seconds,toilluminate the way to your vehicle.
Thesecurity systemwillhavethisresponse upondisarminguntiltheignitionswitch
is turned "on", which clears the unit's memory. Note: Anytime the security system
triggers, the LED Status Light will indicate which zone triggered the system by
flashingonetofourtimes,pausingbetweenflashes.Thiscodewillcontinuetoflash,
evenafterdisarming.Thesystemcanholdtwodifferentviolationcodesinit'smemory,
which is cleared by turning the ignition switch "on".
YourExcaliburvehiclesecuritysystemoffersaveryhighlevelofpersonalsafety
and convenience with the advanced features utilized upon disarming. The ability to
unlockthedriver'sdooronlypreventsapotentialattackerfromgainingentryintoyour
vehiclefromtheotherdoors,you'llknowinstantlyifyoursystemwastriggeredwhile
you were away, and the exterior and interior light illumination allows you a lighted
approach to your vehicle with the ability to examine the interior before entry. If you
wish,yourdealercanprogramthesystemtoturnontheexteriorandinteriorlightsfor
sixty instead of thirty seconds upon disarming.
AutomaticRearmingFeature:Shouldyouunknowinglyactivateyourtransmitter,
which results in your system disarming, your Excalibur system will automatically
Page - 11 Continued Next Page

rearm itself after 90 seconds and once again lock the doors. This
feature is programmable and in some cases may be turned off. See your Excalibur
dealer or installer for details. Note: Automatic Rearming can be paused by opening
the door or stopped by turning "on" the ignition key. Note: Automatic Rearming is
confirmedbyafastflashingLEDStatusIndicatorafterdisarming,unlessthesystem
was triggered and reset, in which case a Zone Violation code will flash instead.
Remote Valet Activation: Remote Valet allows you to prevent your Excalibur
systemfromautomatically rearmingbyutilizingyour transmitter.Within3 seconds
of hearing the disarm siren chirps, press and release the small transmitter button on
the left, which will activate the Remote Valet. Once the system has entered Remote
Valetmode,theexteriorlightswillflashevery2secondsduringthe30secondperiod
insteadofthelightsstayingon.ThesystemwillstayinRemoteValetmodeuntilarmed
againfromthetransmitteror, if Automatic Last Doorarmingisutilized,untila door
is opened and closed.
Page - 12
Remote Panic FeatureRemote Panic Feature
Remote Panic FeatureRemote Panic Feature
Remote Panic Feature
RemotePanicActivationFromTheTransmitter:Shouldyoufeelthreatened
or the need to attract attention at any time you can activate
yourExcalibur'sRemotePanicfeaturebydepressingthelargetransmitterbuttonfor
3 seconds. Your system will respond by activating the siren, locking the doors and

OptionalOptional
OptionalOptional
Optional TT
TT
Trr
rr
runk Releaseunk Release
unk Releaseunk Release
unk Release And 3rAnd 3r
And 3rAnd 3r
And 3rd Channel Outputd Channel Output
d Channel Outputd Channel Output
d Channel Output
OptionalTrunkRelease:Ifyourvehicleisequippedwithelectrictrunkrelease,
your authorized Excalibur dealer can configure your system to accomplish trunk
releasefromyourtransmitter.Tooperatethisoptionwhenequipped,simplypressand
holdthesmalltransmitterbuttonontherightfor3seconds.Yourvehiclewillrespond
byreleasing thetrunklid,chirpingthe sirentwice,disarmingthesystemandturning
onyourexteriorandinteriorlightsfor30seconds.Note:Thetrunkreleaseoutputwill
not operate with the ignition switch "on" unless the vehicle's door is open.
Ifdesired,yourExcaliburdealercanprogramthesecuritysystemtoremainarmed
when this feature is used.
Optional3rd ChannelOutput: This output's operation is the same as the trunk
releaseoutputexceptforthefollowingitems:Pressthesmalltransmitterbuttononthe
left for 3 seconds to activate the 3rd channel output. The 3rd channel output will
operate regardless of the ignition switch being "on" or "off", and there is no chirp
confirmation.Thisoutputcan be used tooperateoptionalequipmentsuch as remote
car starters or window roll-up modules.
flashing the exterior and interior lights for 60 seconds. Should wish to enter your
vehicle or disengage Remote Panic, simply press and release the large transmitter
button.
Page - 13 Continued Next Page

UsingUsing
UsingUsing
Using TT
TT
The Easyhe Easy
he Easyhe Easy
he Easy
VV
VV
Valetalet
aletalet
alet
TMTM
TMTM
TM
SwitcSwitc
SwitcSwitc
Switchh
hh
h
TheprimaryfunctionoftheEasyValetSwitchistoenteryoursecuritysysteminto
ValetMode,whichpreventsthesystemfromarming.Youwillfindthisusefulwhen
stopping at service stations, having your vehicle serviced, having your car valet
parkedorwhilehavingyourcarwashed.TheEasyValetSwitch,inconjunctionwith
the ignition key, can be used to disarm the system should your transmitter be lost or
becomeinoperable.TheEasyValetSwitchisnormallymountedinahiddenlocation
thatisaccessibletothedriver.BesureyourExcaliburdealerindicatesthelocationof
the Easy Valet Switch to you to avoid potential inconvenience otherwise.
To Turn On The Easy Valet: This unique feature can be activated anytime the
systemisdisarmed.Thispatent-pendingfeatureallowsyoutoentertheValetMode
by simply depressing the Easy Valet switch, provided the system is not armed.
However,ifthesystemisarmedorinthetriggeredstate,theignitionneedstobeturned
"on" and then the Easy Valet Switch pressed within 5 seconds to disarm the system
by entering Valet Mode.
Simply press and hold the Easy ValetSwitch for 2 seconds to activate the Valet
Mode.ThesystemwillconfirmthatitisintheValetModebychirpingthesirentwice,
andthe LEDStatusIndicatorwillilluminate.Thesecuritysystemwillholdmemory
oftheValetModewhentheignitionswitchis"on"or"off".WhileintheValetMode,
althoughthesystemwillnotarm,thetransmitterswillstilloperatetheRemotePanic
Page - 14

feature, the doorlocks, and trunk release; the doors will also lock when the ignition
switch is turned "on" and unlock when it is turned "off"'. Note: While the security
system is in the Valet Mode, every time the ignition switch is turned "off", the siren
will chirp once as a reminder.
ToTurnOffTheEasyValet:SimplypresstheEasyValetSwitch,andinstantly
the security system will exit out of Valet Mode. To confirm that the Valet Mode is
turned off, the LED Status Indicator will turn off.
Disarming The Security System If The Transmitter Is Lost: In the event the
transmitterislost,damaged,oritsbatteriesbecomeexhausted,the EasyValetSwitch
and your ignition key can be used to disarm the system:
STEP 1. Withthesysteminthearmedcondition,enterviathedriver'sdoor(beaware
that the security system will trigger the instant the door is opened).
STEP 2. Use the ignition key to turn "on" the ignition switch.
STEP 3. Within 5 seconds, press the Easy Valet Switch. The security system will
instantlydisarm.
Red LED Status IndicatorRed LED Status Indicator
Red LED Status IndicatorRed LED Status Indicator
Red LED Status Indicator
The LED Status Indicator feature is a visual indicator of what state the security
system is in at any given time. It is normally positioned in a location that is easily
Page - 15 Continued Next Page

observedbythedriver.Thereare12possibleconditionsthatthesecuritysystemcan
be in, and are reflected by the LED Status Indicator:
1) Off = The security system is disarmed and not performing any
automatic functions.
2) On Constant = The security system is in the Valet Mode.
3) Flashing Slow = The security system is Fully Armed.
4) Flashing Fast = The 30 second Last Door Arming feature or 90 second
Automatic Rearming feature is in progress.
AutomaticTransmitterVerificationTM(PatentPending):Aftertheignitionis
turned"on",theLEDStatusIndicatorwillflashtoindicatethenumberoftransmitters
programmed to operate your security system. For example: two flashes and pause
indicatesthatonlytwotransmittersarecodedtooperateyoursystem. Wheneveryou
leave your vehicle and keys with someone, you will now have the peace of mind of
knowing that only your transmitters will operate the security system and that no
additionaltransmittershavebeencodedintoyour system for the purpose of stealing
yourvehicle.Thisfeatureworksfor10secondseverytimethe ignitionswitchisturned
"on".
5) Flash-1x & Pause = 1 transmitter code is stored in the system's memory.
6) Flash-2x & Pause = 2 transmitter codes are stored in the system's memory.
7) Flash-3x & Pause = 3 transmitter codes are stored in the system's memory.
8) Flash-4x & Pause = 4 transmitter codes are stored in the system's memory.
Page - 16

Zone Violation: If the system is triggered, the LED Status Indicator will start to
flash and pause the #9 through #12 sequences to indicate which protected circuit
triggeredthesystem.Thisisseenwhilethesystemisarmed,andafterdisarming,until
theignitionswitch isturned"on", whichwillclear theZoneViolationcodefromthe
securitysystem'smemory.Theunit'memorycanstoretwodifferentviolationcodes.
9) Flash-1x & Pause = The security system was triggered from the current
sensing circuit.
10) Flash-2x & Pause =Thesecuritysystemwastriggeredfromthehood,trunkor
#2 Auxiliary Port circuit.
11) Flash-3x & Pause = The security system was triggered from the door circuit .
12) Flash-4x & Pause = The security system was triggered from the #3 Auxiliary
Sensor Port circuit.
Electronic Siren And Flashing LightsElectronic Siren And Flashing Lights
Electronic Siren And Flashing LightsElectronic Siren And Flashing Lights
Electronic Siren And Flashing Lights
The electronic siren and the vehicle's exterior lights primary function is to attract
attentiontoyourvehicleifthesecuritysystemistriggered.Inaddition,theyarealso
usedtocommunicatewithyou,asawayofconfirmingactionsthathavetakenplace,
or, that may be in process of automatically taking place. A chirp is the short, sharp
sound the siren makes as part of this communication. The exterior lights referred to
are the vehicle's parking lights. We do not recommend flashing the headlights. The
halogenheadlightsfoundinmodernvehiclesarenotdesigned toberapidlyturnedon
Page - 17 Continued Next Page

and off. If connected to the security system, a reduction of their useful life may be
noticed.
SirenChirpWithLightFlashConfirmationForArming,Disarming&Valet
Activation: The following siren chirps and flashing exterior light actions
inform you of these conditions of the security system:
1) One siren chirp and one light flash: The system has armed.
2) One siren chirp after the arming chirp above: The optional sensor circuit is
bypassed.
3) Two siren chirps (and no lights): Trunk release has been activated while the
security system is in Valet Mode.
4) Two siren chirps and lights stay on for 30 seconds: The system has just disarmed.
Note: Activating the Trunk Release feature will also disarm the security system.
5) Two siren chirps & two light flashes: The system is entering the Valet Mode.
6) Three siren chirps and three light flashes: The system is arming with a protected
circuit still open or an optional sensor in a triggered state, and these circuits will
be bypassed.
7) Foursirenchirps&fourlightflashes,thenthelightsstayon30or60seconds:The
security system has just disarmed and was triggered and reset while you were
away.
8) Lightsstartflashingevery2secondsduringthe60seconddisarmingconfirmation:
The system has entered the Remote Valet condition.
Page - 18

9) Siren sounding, changing sounds every 5 seconds, and lights flashing on and off:
The system is in a triggered state.
10) One siren chirp (and no lights) when the ignition switch is turned "off": The
security system is in Valet Mode.
11)Threesirenchirps(andnolights)whilethesecuritysystemisarmed:ThePrewarn
feature has been activated.
12) Aseriesofsirenchirpslastingtwosecondswhentheignitionswitchisturned"on":
The Automatic Transmitter VerificationTM feature has been activated.
Thesirenisalsousedtocommunicateportionsofthetransmittercodelearning,which
is explained in detail on page 22 and programmable features processes.
Page - 19 Continued Next Page
Backup BatteryBackup Battery
Backup BatteryBackup Battery
Backup Battery
This security system includes a 9 volt alkaline battery and a slide bracket holder
which attaches to the security system control module. The 9 volt battery is all that is
required to provide alternative power to operate the system if the vehicle's battery is
disconnected.Abuilt-inprotectioncircuitwillnotallowthe9voltbatterytobackfeed
voltageinto thevehicle'selectricalsystem.
Whileonbackupbatterypower,toconservethebackupbattery,thesystemwillnot
havesomefunctions-flashingexteriorlightsandtheLEDStatusIndicator.Thesiren
will still have full sound output, and all trigger circuits will be active except current
sensingandanyoptionalsensors.TheStarterInterrupt,however,willworkatalltimes
from battery backup. Replacement 9 volt alkaline batteries can be purchased

anywhere batteries are sold. We recommend the battery be replaced with another
alkalinebatteryevery 18monthsor afterthe9 voltbatteryhasoperatedthealarmon
itsownforanylengthoftime.Underthefollowingconditions,anew9voltalkaline
battery's life is anticipated to be approximately:
1. 2 days as the only power source to the system while in the armed condition.
2. 25triggeredcycles. Atriggeredcycleisthe60second periodafterthesecurity
system is triggered, in which the siren is sounding. The cycle ends when the
system automatically resets to the armed state.
3. 50 separate transmitter arm and disarm activations.
4. 18 months if the 9 volt battery circuit has not been activated.
Youmaywanttoasktheinstallingdealerifthisisaservicethattheyprovide,
and if there will be any charge for this service. If you plan on replacing the 9 volt
battery yourself, be sure to have the installer show you how to access the security
system's control unit.
ShocShoc
ShocShoc
Shock Sensork Sensor
k Sensork Sensor
k Sensor WW
WW
With Prith Pr
ith Prith Pr
ith Pree
ee
eww
ww
warn Farn F
arn Farn F
arn Featureatur
eatureatur
eaturee
ee
e
Your Excalibur security system features two ports which allows an auxiliary
sensor to easily be added to increase the effectiveness of your system. Your system
includesaDualZoneAirResonanceshocksensor,whichwilldetectshockorimpact
toyourvehicle.AlightshockorimpacttothevehiclewillinitiatethePrewarnfeature,
while heavier shock or impact will trigger the security system. Other sensors are
Page - 20
