Omega K9-Sombra Instruction Manual

Page 1
Owner’s Guide
LowBatteryWarring.......................................................................................1
RFID................................................................................................................2
SystemArmed&Activated.............................................................................2
ArmingtheSystem.........................................................................................3
Disarming theSystem....................................................................................4
EmergencyOverride.......................................................................................4
Anti-Carjacking..........................................................................................5-6
ValetMode......................................................................................................7
LEDStatusIndicator.......................................................................................7
AuxiliarySensor&Prewarn............................................................................8
HowToProgramRemoteControls................................................................8
HowToProgramFeatures.............................................................................9
ProgrammableFeatures..........................................................................9-10
Installation Instructions
HowToProgramRemoteControl..................................................................8
HowToProgramFeatures.............................................................................9
ProgrammableFeatures..........................................................................9-10
WiringDiagram.............................................................................................11
DoorLock/UnlockingSystems......................................................................12
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions,(1)This
devicemaynotcauseharmfulinterferenceand,(2)Thisdevicemustacceptanyinterferencereceived,including
interference that may cause undesired operation.
ThemanufacturerisnotresponsibleforanyradioorTVinterferencecausedbyunauthorizedmodificationstothis
equipment. Such modifications could void the user's authority to operate the equipment.
When the Remote Control’s battery voltage is depleted to less than 2.8V, the
system will have the siren emit a series of 8 chirps to alert you that it’s time
to change the battery. This alert will take place when:
a. Approaching the vehicle with the remote control (RFID “On”)
b. During auto lock.
c. When turning vehicle’s ignition “On”.
d. Whenturningvehicle’signition“Off”.
- The alarm will also disable Anti-car-jacking when remote battery is low.
Table of Contents
IMPORTANT !!! (Low Battery Warning)

Page 2
This unit is equipped with a very convenient auto operation mode called RFID.
If selected ON, this feature willArm & lock the vehicle as you walk away and
Disarm & unlock as you return. It works through constant communication be-
tween the remote control & the main module in the vehicle. The operating
distance will vary by type & shape of the car in which the alarm is installed.
This RFID feature also makes the programmable Anti-Carjacking system the
most secure and easiest to use in the industry. This is explained in the Anti-
Carjacking section.
- The RFID feature can be turned ON & OFF by the remote control:
- If while RFID in On, the control experiences no movement for 10 minutes, it
will go into sleep mode to save battery. Will wake up the instant it is moved.
To turn “On” RFID feature: Press & Hold thebuttonontheremote
control for 2 seconds, until the LED on the remote flashes twice.
Toturn“Off” RFID feature: Press&Holdthebuttonontheremote
control for 2 seconds
RegardlessofmethodusedtoArmthealarm,itwillmonitorallprotectedzones,
andifanintrusionattemptisdetecteditwillactivate,or“trigger”.
An activation consists of the following:
•Theelectronicsiren,oroptionallythevehicle’shorn,willstartsounding.
• The exterior parking lights will flash on and off repeatedly.
Anactivationhasa30seconddurationunlessthesystemisdisarmedusingthe
remoteortheValet/Overrideswitch.Ifallprotectedzonesaresecureattheend
of the activation, the system will stop and rearm itself to detect further entry
attempts. If a protected zone is still open at the end of the activation cycle, the
system will continue to reactivate itself for up to six activated cycles before it
resets itself and ignores the violated zone.
System Armed & Activated
RFID
When RFID is ON
LED will flash every 3 seconds

Page 3
The system may be "Armed" by one of 3 methods:
1) RFID Arming: Walk away from vehicle with the Remote Control
- Once the Remote is 2-5 meters from the vehicle the unit will Arm.
- RFID Arming will override Last Door Arming (aka: Passive arming)
THE SIREN WILL
CHIRP ONCE
THE PARKING LIGHTS
WILL FLASH ONCE
THE DOORS WILL LOCK
(IF CONNECTED)
THE SIREN WILL
CHIRP ONCE
THE PARKING LIGHTS
WILL FLASH ONCE
THE DOORS WILL LOCK
(IF CONNECTED)
Arming the Alarm
2) Remote Control Arming: Press & Release the button on the Remote
Upon Arming: • The siren will chirp one time.
• The parking lights will flash once.
• The doors will lock. (If an optional interface is connected)
• The starter interrupt will engage.
• The LED Status Indicator will begin to flash slowly.
- If a zone is open , (for example a car door), when arming, the alarm will still arm
(parking lights will flash 3 times and siren will chirp 3 times), but will bypass the
open zone until the zone is secured.
- If the remote Arms/Disarms the alarm, the RFID feature will be turned off for 1
minute to prevent unit from Re-Arming/Disarming in case remote is still in range.
3) To Passively Arm: Turn Ignition Off, Then Close all Doors.
Automatic “Last Door Arming” is a programmable feature which allows the alarm
to arm itself and, if desired, lock the doors upon arming.
If on, anytime that the ignition is turned off, and then a door is opened & closed:
• The LED Status Indicator will begin to flash rapidly. Thirty seconds later:
• The siren will chirp & the lights will flash once.
• The LED Status Indicator will begin to flash slowly.
• The starter interrupt will engage.
The alarm is now fully armed. The doors will lock at this time, if programmed to
do so, and if the vehicle is equipped.
The system can not Last Door Arm if a protected zone is open. Should a vehicle
door be opened during the arming countdown, the countdown will stop and start
over again when the door is closed. “Automatic Rearming” will re-Arm the
alarm if it is Disarmed as long as a car door is not opened.
...... 2-5 meters ..........
RFID must be “On”
(see previous page)

Page 4
The system may be "Disarmed" by one of 3 methods:
1) RFID Disarming: Approach the vehicle with the Remote Control
- Once the Remote control is 2-5 meters from the vehicle the alarm will Disarm.
2) Remote Control Disarming: Press & Release the Button on
the Remote Control
Upon Disarm: • The siren will chirp twice. (4 chirps if alarm has activated & reset)
• Theparkinglights will flash twice. (4timesif alarm has activated)
• The doors will unlock. (If an optional interface is connected)
• Thestarter interrupt will disengage.
• TheLEDStatus Indicatorwillturn“Off”,orbeginflashingrapidly
if theAutomatic Rearming feature is programmed on.
3) Emergency Override: (Disarming the alarm without the Remote)
Step 1: Withthesysteminthearmedcondition,enterthevehicleviathedriver's
door (be aware that the alarm will activate when the door is opened).
Step 2: Usingyourkey, turn the vehicle’s ignition to the "On" position.
Step 3: Within 20 seconds, enter your PIN code (1-12) by Pressing the Valet/
Override Switch. (i.e.: if pin code is 8, press valet switch 8 times)
-The activated system will disarm one second after code is entered.
THE SIREN WILL
CHIRP TWICE THE PARKING LIGHTS
WILL FLASH TWICE
THE DOORS WILL UNLOCK
(IF CONNECTED)
THE SIREN WILL
CHIRP TWICE THE PARKING LIGHTS
WILL FLASH TWICE
THE DOORS WILL UNLOCK
(IF CONNECTED)
Disarming the Alarm
THEN WITHIN
20 SECONDS
Emergency Override
...... 2-5 meters ..........
RFID must be “On”
(see page 2)
ENTER PIN-CODE

Page 5
The alarm is equipped with an incredibly complete, programmable, Anti-
Carjacking system. The Anti-Carjacking operation may be activated by the
ignition, or a combination of the ignition and a car door. Once activated, the
alarmwilluseitsRFIDcapability(if RFIDis “On”)to verifyifyouarestillinthe
vehicle, or require manual input from the driver trough the use of the Valet
button.
Ifthe programmable Anti-Carjacking featureis “On”:
-thesystemwillinitiatetheAnti-Carjackingsequenceeverytimethevehicle’s
ignitionisturned“On”.
-thesystemwillinitiatetheAnti-Carjackingsequenceeverytimeavehicledoor
isopenedorclosedwhilethevehicle’signitionis“On”.
NOTE: If RFID is On, then all Anti-Carjacking operations will be done by the
remote control, without any need for the user to do anything.
IMPORTANT: IF RFID IS “ON”, IT IS VERY IMPORTANT THAT THE
DRIVERKEEPTHEALARM’SREMOTECONTROLONTHEIRBODY,NOT
TOGETHER WITH THE CAR’S KEYS! THIS WAY IF YOU ARE FORCED
OUTOFTHEVEHICLE,THEANTI-CARJACKINGSEQUENCEWILLBEGIN
ONCE THE REMOTE CONTROL LOSES CONTACT WITH THE CAR.
Anti-Carjacking sequence:
STAGE 1: For the first 45 seconds after the sequence has started, the LED
will blink fast.
IF RFID IS “On”: Within this period, If RFID is “On”, the remote will auto-
matically signal the alarm that you are still in the vehicle and turn Off the
sequence. The alarm will then quietly continue to monitor that you are
still there while the door is open, and continue for 3 minutes after the
door is closed. If during this search time, the alarm losses contact with
the remote control, theAnti-Carjacking sequence will restart.
IF RFID IS “Off”: Within stage 1, If RFID is “Off”, the alarm will be looking
for a manual input press of the Valet button, or a press of the remote
control’s button. Once this input is received, the alarm will cancel the
Anti-Carjacking sequence. If the door is closed after receiving input, the
sequence will restart and require another Valet/Remote control input.
NOTE: Depending on how long the vehicle’s door is open, it may be neces
saryto press the Valet button, or the remote control’s button while the door
is open, and again after it is closed, because the alarm will start to search
for input again once door is closed. This is to protect against the car-jacker
driving away with the door open thinking that it will not trigger the system.
- If vehicle’s ignition is turned “Off” during these 45 seconds,Thealarm will
stopAnti-Carjackingsequencetemporarily. Once the ignition is turned “On”
again, the alarm will continue the countdown where it left off until it receives
user input or goes on to next stage.
Programmable Anti-Carjacking Protection

Page 6
STAGE 2: If the alarm has not made contact with the remote (if RFID is “On”),
or received a Valet/Remote button press input from driver it will enter the
second stage ofAnti-Carjacking sequence. Stage 2 starts at 46 seconds
after the sequence has started through 75 seconds. During this stage,
the LED will blink fast and the siren will chirp once per 1 second.
IF RFID IS “On”: By this time the remote control should have established
contact with the alarm and stopped theAnti-Carjacking sequence, but will
quietly continue to monitor that you are still there while the vehicle’s door
is open, and for 3 minutes after the door is closed. If during this search
time, the alarm losses contact with the remote control, the it will restart
Anti-Carjacking sequence.
IF RFID IS “Off”: Within this period, If RFID is “Off”, the alarm will still be
looking for a manual input press of the Valet button, or a press of the
remote control’s button. Once this input is received, the alarm will cancel
theAnti-Carjacking sequence. If the door is closed after receiving input,
the sequence will restart and require another Valet/Remote control input.
NOTE: Depending on how long the vehicle’s door is open, it may be neces-
saryto press the Valet button, or the remote control’s button while the
door is open, and again after it is closed, because the alarm will start to
search for input again once door is closed. This is to protect against the
car-jacker driving away with the door open thinking that it will not trigger
the system.
- If vehicle’s ignition is turned “Off” during stage 2,The alarm willArm
itself.
STAGE 3: If the Alarm has not received an RFID signal or manual input from
the driver after 75 seconds,Anti-Carjacking mode will enter Full Trigger.
The siren will sound and the parking lights will flash continuously. Once
the vehicle’s ignition is turned “Off”, the unit will activatethestarter
disable.
TO DISARM ANTI-CARJACKING FULL-TRIGGER:
FirstStep:Turn the vehicle’s ignition “Off”.
SecondStep:Turn the vehicle’s ignition back “On”.
Third Step: Within 20 seconds enter your PIN code using the Valet/Override
Switch or Press the button on the Remote control.
- If the remote control battery is low, the alarm will disableAnti-car-jacking.
THEN WITHIN
20 SECONDS
ENTER PIN-CODE

Page 7
Valet Mode
Valet Mode can be entered to only when the alarm is Disarmed.
ValetModeturnsoffallofthealarm’ssecurityfeatures,(includingAnti-Carjack).
Valet Mode is designed for situations in which it is not convenient for the alarm
portionofthesystemto be operational; for example during extended stopovers
for vehicle servicing, loaning others your vehicle, maintenance, valet parking,
washing,etc. Theconveniencefeaturessuchaskeylessentrywillstilloperate.
To Enter Valet Mode (System MUST be Disarmed):
Press & Hold the Valet Switch for 3 Seconds.
- The siren will chirp and the LED Status Indicator will light solid Red to con-
firm Valet Mode. Now the system cannot become armed.
The vehicle's ignition may be "On" or "Off" when entering Valet Mode.
To Exit Valet Mode:Simply Press & Release the Valet Switch.
- The LED Status Indicator will turn off to confirm that the system has exited
Valet Mode and returned to a “standby” mode. Normal arming operations may
be resumed.
Again, the vehicle's ignition may be "On" or "Off" when exiting Valet Mode.
The Red LED Status Indicator visually shows the status of the system and also
provides a high level of visual deterrence. The Red LED Status Indicator Light
isnormallymountedinalocationwhereitcanbeeasilyseenbythedriver,aswell
as from outside the vehicle.
SecuritySystemStatus: TheprimaryfunctionoftheRedLEDStatusIndicator
Light is to indicate the normal operating status of the security system:
Off = The system is disarmed and not performing any automatic functions.
On Constant = The system is in the Valet Mode.
Flashing Slow = The system is fully Armed.
Flashing Fast (while Disarmed) = Last Door Arming or Automatic Rearming.
Flashing Fast (while Armed) = The alarm has been triggered.
AutomaticTransmitterVerification: Forthefirst90secondsafterthevehicle’s
ignitionisturned"On",theLEDStatusIndicatorwillflashanumberoftimesequal
to the number of remote control transmitters which are programmed to operate
thealarm.Thisindicationcanbefrom1Flash/pauseupto3Flashes/pause,as
the system can be operated by just one, or as many as 3 remote transmitters.
The LED Status Indicator

Page 8
Auxiliary Sensor: This security system is equipped with a plug-in port for an
optionalsensortoincreasetheeffectivenessofthesystem. Thecomprehensive
lineofoptionalsensorsofferediscomprisedofimpactsensors,glasstampering
sensors, and microwave/radar sensors which can detect motion inside and
outside the vehicle.
Prewarning Detection: This circuit requires connection to a dual zone sensor
ordetection device. When the sensor’s prewarn zone is triggered the sirenwill
emit a series of chirps.
To program remote controls to operate the alarm:
Step 1: Turn "On" the vehicle's ignition.
Step 2: Within 10 seconds press the Valet/Override Switch 5 times. The alarm
will chirp the siren once to confirm entry into Remote Control Programming
Mode.
Step 3: Within10 seconds,pressthe Buttononeach remotetobeprogrammed.
The siren will chirp to confirm each time a remote has been programed.
If17 secondsexpirewithoutany programmingactivity, or if the vehicle’s ignition
is turned Off, the system will automatically exit Remote Programming Mode.
The siren will emit a long chirp to confirm exit.
NOTE: Up to 3 remote controls can be programed to operate the alarm. When-
ever a remote control, new or existing, is programmed to the system, all exist-
ing codes are erased for security. So all remote controls which are to operate
the system, must be programmed at the same time.
ATV: The LED Status Indicator will show the number of programmed remote
control transmitters for 90 seconds after the vehicle’s ignition is turned On.
Astheinstructionsabove show, programming extra transmitters to any vehicle
security system is easy; the exclusive patented ATV feature protects against
someone programming their own transmitter to operate your system.
Auxiliary Sensor & Prewarning
How to Program Remote Controls to the Alarm

Page 9
Thereare10programmable featureswhichare explainedinthefollowingpages.
To access Features Programming Mode:
Step 1: Turn the vehicle's ignition "On" then "Off".
Step 2: Within10 seconds of turning theignition"Off",press the Valet Switch 5
times.Thesirenwillchirponceconfirmingentry toFeaturesProgrammingMode.
Step 3: Within 7 seconds of entering Features Programming Mode, press the
Valet Switch the number of times equal to the number of the feature to be
programmed. The siren will repeat the feature number with chirps to confirm.
Step 4: After the system acknowledges the feature to be programmed, press
the button on the remote control to turn the feature On (the system’s response
will be 1 chirp), or OFF (the system’s response will be 2 chirps).
- To program more features, simply repeat Steps 3 and 4. If 7 seconds expire
without any programming activity, or if the ignition is turned On, the alarm will
automatically exit Features Programming Mode. The siren will confirm exit.
The system has 10 programmable features which allow the system to be
customizedtosuitemanyindividualneeds. Thefollowingpagesprovideabrief
explanation for each feature, and notes its factory default setting.
Note: Once the feature to be programed is selected, you can toggle the
featurebetweenitssettingsbypressingthebuttonontheremotecontrol.
• =DefaultFactorySetting
1. Pin Code: ( 1-12 , • Default 1 press)
- Allows user to program a pin code between 1-12 presses of the Valet/
Override button for use in Emergency override situations.
a. Enter Features programming mode and select feature #1.
b. Within 10 seconds slowly press and release the remote control’s button
a number of times equal to the desired override pin-code, (The siren will
chirp every time the remote’s button is pressed to confirm that its entry
was registered).
c. 4 seconds after the last press of the remote control’s button, the siren
will chirp the pin code to confirm the number that has been entered.
d. User can program another feature by pressing the Valet button to select
next feature to be programed (step 3).
Programmable Features
How to Program Features

Page 10
2. Anti-Carjacking: (On = 1 siren chirp / •Off = 2 siren chirps)
- Thisfeatureturnsthealarm’sAnti-Carjackingfeature“On”or“Off”.
3. Last Door Arming & Rearm: (•On = 1 siren chirp / Off =2 chirps)
- Configures the alarm to automatically arm itself 30 seconds after the last
doorisclosedwiththeignition“Off”.WillalsoallowthealarmtoRearmitself
if a vehicle door is not opened after the alarm is disarmed.
4. Doors Lock w/ Last Door Arming: (•On = 1 siren chirp /Off = 2 chirps)
- Adds the automatic locking of the vehicle's doors to the previous feature.
5. Ignition Controlled Door Lock: (•On = 1 siren chirp / Off = 2 chirps)
- Configuresthealarmtolockthevehicle'sdoorswhentheignitionisturned
“On”.
6. Ignition Controlled Door Unlock: (•On = 1 siren chirp / Off = 2 chirps)
- Configures the alarm to unlock the vehicle's doors when the ignition is
turned “Off”.
7. Siren Or Horn Honk Output: (•Siren = 1 siren chirp / Horn = 2 chirps)
- Allows the selection of a constant output to sound the electronic siren or a
pulsed output to properly sound the vehicle's horn.
Note:Outputispositive12Volts,needstobecoveredviarelayformosthorn
applications.
8.RFIDDebounceTime:(•4seconds =1sirenchirp/7seconds=2chirps)
- Timethealarmwillwaitafterthevehicle’signitionisturned“Off”before
searching for RFID signal from remote control.
9.LockPulseTime:(•.75seconds=1sirenchirp/3.5seconds=2chirps)
- Determine the length of the door lock/unlock pulse.
10. Return All Features To Default Setting: ( = 1 siren chirp)
- This feature returns all other features to the original factory setting,
including resetting the Pin-Code (feature #1) to 1 press of the Valet/Override
button.
