Omega PL403A User manual

PL403A
14 place settings
half-load function

With each wash cycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
Load the baskets
Select a programme
Running the dishwasher
Fill the detergent dispenser
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Switchon theappliance
Fordetailed operatingmethod read thecorresponding content onthe instruction manual.
Switch off the appliance
Turn off the water tap,
unload the baskets Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils whilethey are stillhot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lowerbasket.
Changing the programme
Add forgotten dishes in the
dishwasher.
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the applianceusingthe On/Off Button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hot steam may escape
when the door is opened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ..
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the On/Off button to stop washing , Then press this button to reset .
3. Turn the selector to select a new programme.
4. Restart the dishwasher.
1.Press the Start/Pause Button to stop the washing.
2.Open the door a little .
3.After the spray arms stop working, you can open the door
completely.
4.Add forgotten dishes.
5.Close the door
6.Press the Start/Pause Button, the dishwasher will run
after 10 seconds.
Turn on the water tap and press the Start/Pause Button. The machine will start working
after about 10 seconds.
Close the door,turn the Washing Program Selector to select a desired programme.
( See the section entitled Operating instruction )“”
Press the On/Off button to switch on the appliance, Open the door.
ABC

To review the section on troubleshooting Tips
will help you to solve some common problems
by yourself .
Dear Customer,
Please carefully readthismanualbefore usingthe
dishwasher,it will help you to use and maintainthe
dishwasher properly.
Pass it on to anysubsequent owner of the appliance.
Thismanual contains sections on safety Instructions,
Operating Instructions, InstallationInstructionsand
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
development andupdating of the product, may
make modifications without giving prior notice.
Keep it as a refer in the later days.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
This appliance is intended tobe used in household
andsimilarapplications suchas:
-staff kitchen areas in shops, offices and other
working environments;
-farm houses;
-by clients inhotels, motels and other residential
type environments;
-bed and breakfast type environments.
Dishwasher Features.................................... ...2
Attention beforeorafter loading the Dishwasher
Baskets..........................................................6
Filtering System.............................................11
Caring forthe Dishwasher..................... .........12.
A Fill the RinseAid Dispenser............. .. ..3、..... ...
B Function of Detergent .........................4、........
..............7 The Method Loading Normal Dishware
Max. Dishes ...................................................8
Wash CycleTable...........................................9
Turning on theAppliance................................9
Change the Programme.............. ................10....
Atthe End of the Wash Cycle...........................10
Before callingfor service........................... .....20.
Errorcodes.................................... ..............21.
Technical information.............................. .....22..
Control Panel...................................................2
.................................. 13Installation preparation ...14Aesthetic panel's dimensions and installation
..............16Tension adjustment of the door spring
.............................. 16Connection of drain hoses ......................... 17Dishwasher installation steps
AboutElectricity Connecting...........................18
Cold Water Connection.................................. 19
Start of dishwasher................................ ......19..

This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid,
keep child away from the open door of the
dishwasher, there could still be some detergent
left inside.
ren
Donotabuse,siton,orstandonthedoorordish
rack of the dishwasher.
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never usesoap, laundry detergent, or hand
washing detergent in yourdishwasher.Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locate sharp items so that theyare not likely
to damage the door seal;
2 Warning: Knives and other utensils with
sharp points must be loadedin the basket
with their points down orplaced in a
horizontal position.
)
Ifthesupply cordis damaged, itmust bereplaced
bythemanufactureroritsserviceagentora
similarly qualified person in order to avoid a
hazard.
Pleasedispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremely dangerous if swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent comparment is empty
after completion of the wash cycle.
The applianceis to be connected to the water
mains using new hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is 14.
The maximum permissible inlet water pressure is
1Mpa.
The minimum permissible inlet water pressure is
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increase the risk of tripping.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.

beforeusingit for the firsttime.
To get the best performance fromyour dishwasher, read all operating instructions
1. On/Off Button: Toturnon/off the power supply.
2. Delay Button :To Press thebutton to delay the washing time.
6. Delay indicators: to show the delay time (3h/6h/9h )
9Start/PauseButton:Tostarttheselected
washingprogramorpausethewashingprogram
when the machine is working.
3. Option Button:To select Half load and Extradry functions,
these functions can only be used with programmes
Intensive, Heavy, Normal, Glass and 1 Hour.
4. Program indicators: to show whichprogram you have chosen;
10 Washing Program Selector : To Turn the Selector
to select appropriate Program.
7. Rinse aid warning lights:To show
when the dispenser need to be refilled.
Option
5.Half load indicator : To show when you select the
half load function. If you have only about or less than half
of full load dishes of the dishwasher, you can select the
half load function and your desired program according to
the dishes contaminated degree.A program select the
half load function, it can save time, energy, and water
compare to the program hasn’t select the half load function.
After the half load function isselected,all the spray arms
are running, you can load all the baskets.
8:
Extra drying:An increased temperature during the final
rinsetoincreasedryingwell.Thereisaslightincrease
in the energy consumption.
.Extra Dryingindicator
11
12
Back View
1
2
3
4
5
7
89
10
Front view
Lower basket
Dispenser
Cupshelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Upper basket
Cutleryrack
Top spray arm
1
Inner pipe
5
6
7
8
9
10
12
11
3
24
6
Adjuster

Before using your dishwasher for the first time:
A. Filltherinseaiddispenser
B. Fill in detergent
Therinse aid isreleased duringthe finalrinse to preventwaterfrom forming dropletson your dishes, which can
leave spots and streaks. It also improvesdryingby allowing water to rolloff thedishes. Yourdishwasheris
designed to use liquidrinseaids.The rinseaid dispenser islocatedinsidethe door nextto thedetergent dispenser.
To fillthe dispenser, open the capand pour the rinse aidinto the dispenser until the level indicatorturns completely
black.Thevolume ofthe rinseaidcontaineris about 110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during the last rinse,ensuring thorough rinsing, and spot and streakfree drying.
Attention!
Onlyuse branded rinse aid for dishwasher. Never fill the rinseaiddispenserwith any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
As the rinse aid diminishes, the size ofthe black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3/4full
1/2full
1/4full-Shouldrefilltoeliminatespotting
Empty
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color of the
optical level
indicator "C" located next to the cap. When the rinse-aid container is full, the whole indicator will be dark .As the
rinse-aid
diminishes, the size of the dark dot decreases.You should never let the rinse aid get below 1/ 4 full.
When to Refill the RinseAid Dispenser
RINSEAID DISPENSER
To open the dispenser,turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it tothe closed (right) arrow.
Be careful not to overfillthe dispenser,because this could cause over sudsing. Wipe away anyspills
witha damp cloth. Don'tforget to replace thecap before you close dishwasher door.
Attention!
Clean up any rinse aid spilt during filling with an absorbent cloth toavoid excess foaming
during the nextwash.
1
2
3

Adjusting RinseAid Dispenser
The rinse aid dispenser has six or four settings.Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aiddispensedbyremoving thedispenserlidandrotatingthedialto"5".Ifthe
dishes still are not drying properly or are show spots, adjust the dialto the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or
knifeblades.
duringthenextwash. Don't forget to replacethe cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
Detergents with its chemical ingredients are necessary to remove dirt, crush dirt andtransport it out of the dishwasher.
Most of the commercial quality detergents are suitableforthispurpose.
Detergents
There are 3 sorts of detergents
1.With phosphate and withchlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Based on their chemical composition,detergentscan be split in two basic types:
Detergent tablets of different brands dissolve at different speeds. For this reason some
detergent tablets cannotdissolve anddevelop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensurethe completeremoval of detergentresiduals.
The dispenser must be refilled before the start of each wash cycle followingthe instructions
provided in the wash cycle table . Your dishwasheruses less detergent and rinse aid than
Conventional dishwasher. Generally,only one tablespoon of detergent is needed for
a normal wash load.Moreheavilysoiled itemsneedmore detergent.Alwaysaddthe
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
DetergentDispenser
conventional, alkaline detergents with caustic components
low alkalineconcentrated detergents with natural enzymes
Normally new pulveriseddetergent is without phosphate.Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
the hardness of water is only6 dH. Ifdetergents without phosphate are used in the case ofhardwater
often white spots appearon dishes and glasses. In this case please add more detergent to reach
better results. Detergents without chlorine doonly bleacha little. Strong and coloured spots will not
be removedcompletely.Inthis case please choose a programwitha higher temperature.
°

Amount ofDetergenttoUse
ProperUseofDetergent
Use only detergent specifically made for the use in dishwashers. Keep your detergent fresh and dry.
Don't put powdereddetergent into the dispenser until you're ready to wash dishes.
Dishwasher detergentis corrosive! Take care to keepitout of reach of children.
Always add the detergentjust before starting eachwash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Fill the detergent dispenser with detergent.
Themarkingindicatesthedosinglevels ,as
illustratedontheright:
The place of main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturersdosing andstorage
Recommendations as stated on the detergent packaging.
Close the lidand press until itlocks in place.
Ifthedishesare heavily soiled,placean additional
detergent dose in the pre-wash detergent chamber. This detergent will take effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for the single programme on the last page.
Pleaseaware, that according to the level soiling and the specific hardness of water differences are possible.
Pleaseobserve the manufacturer's recommendations on the detergent packaging.
AB

Cutlery withwooden,horn china or
mother-of-pearl handles
Plastic items that arenot heat resistant
Older cutlery with glued parts that arenot
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items madefromsynthetic fibres
Some types of glasses can become
dull aftera large number of washes
Silver and aluminum parts have a
tendencyto discolourduring washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishes and itemsof cutlery mustnot lie insideoneanother, or cover each other.
To avoid damage to glasses, theymust not touch.
Load large items which are most difficult to clean into the lower basket.
The upper basket is designed to holdmoredelicate and lighter dishware such as glasses, coffee
andteacups
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp itemsof cutlery such as carving knives must be positioned
horizontallyin the upper basket.
Please do not overload your dishwasher. This is important forgood results and for
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so that
water cannot collect in the container or a deep base.
Consider buying utensils which are identifiedas dishwasher-proof.
Usea mild detergentthat isdescribedas 'kind to dishes'.If necessary, seek further
information from thedetergent manufacturers.
Forparticular items,select aprogramwithas low a temperature aspossible.
To prevent damage, do not take glassandcutlery out of the dishwasher immediately
after the programme has ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery basketsmay vary from your model.)
Scrape off any largeamounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse thedishes under running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensils are placed in the way that the spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.

The upper basket is designed to holdmore delicate
and lighter dishware such as glasses, coffee and
teacups and saucers, as well asplates, small bowls
andshallowpans (as long astheyare not toodirty).
Positionthedishes andcookware so thatthey will
notgetmoved bythespray ofwater.
We suggest that you place large items and the most difficult
to cleanitems into thelower basket: suchas pots,pans, lids,
serving dishes and bowls, as shown in the figure below.
It is preferable toplace serving dishesand lids onthe side of
the racks in order to avoid blocking the rotation of the top
spray arm.
Pots,servingbowls,etc,mustalwaysbeplacedtopdown.
Deep pots should be slanted to allow water to flow out.
Please be reminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Folding back the cup shelves
For better stacking of pots and pans,
the spikes can be folded down as
showninthepictureright.
Adjusting the Upper Basket
The height of the upper basket can be adjusted in order to
create more space for large utensils both for the upper
/lower basket. The heightof the upperbasketcan be
adjusted byplacing the wheels on different heightof the
rails. Long items, serving cutlery, salad servers and knives
should beplacedon the shelfso thattheydo not obstruct
the rotation of the spray arms..
Folding Spikes of Lower Basket
For better stacking of pots and pans,
the spikes can be folded down as
shown in the picture right.

Cutlery should be placed in the cutlery rackseparately
from each other in the appropriate positions, and do
make sure theutensils donot nest together, this may
cause bad performance.
Max. Dishes
Max. Dishes
Top basket Bottom basket
LowerPositionmax.Φ
Upper Position max.Φ
19cm 25cm
14cm 30cm

NOTE:NOTE:
Turning On the ApplianceTurning On the Appliance
5.Starting a washing program5.Starting a washing program
Wash Cycle TableWash Cycle Table
NOTE:NOTE:
Means: need to fill rinse into the Rinse-Aid Dispenser.
( )
99
* : This program is the test cycle. The information for comparability test
in accordance with , as follows:
Capacity: 14 setting
Position Upper basket: upper wheels on rails
Rinse aid setting: 6
Open the door slightly 50mm to assist in drying of the dishes after every wash
Starting a cyclewash
Draw out thelower and upperbasket, load thedishes and push them back.
It is commended to load the lower basket first, then the upperone (see the section entitled
Loading the Dishwasher ).
Pour in thedetergent (see thesection entitled Detergent and RinseAid ).
Insert the pluginto the socket.The power supply is 220-240VAC /50 HZ, thespecification
of the socket is 10A 250VAC. Make sure that the water supply is turned on to full pressure.
Close the door, press the ON/OFF Button, and the ON/OFF light will turn on.
Turn theprogram Selector clockwise, the wash program will be changed asfollows direction:
Intensive->Heavy->Normal->Glass->1Hour->Quick;
If a programis selected, the response light will light. Press the Start/Pause button, the dishwasher
begins to start.
1
2
3
4
5
Glass
For lightly soiledloads,
such as glasses,
crystal and fine china.
20g
Pre-wash
wash(40 )
Rinse
Rinse(60 )
Drying
115
0.8 14.5
Detergent
pre/main
Detergent
pre/main
Cycle Selection
Information
Cycle Selection
Information
Normal
ProgramProgram
Intensive
Heavy
Running
time(min)
Running
time(min) Water
(L)
Water
(L)
Energy
(Kwh)
Energy
(Kwh)
Rinse
Aid
Rinse
Aid
(Or All in1)
5/27.5g
5/27.5g
(Or All in1)
(Or All in1)
5/27.5g
For normally soiled loads,
such as pots, plates,glasses
and lightly soiled pans.
standard daily cycle.
For the heaviest soiled
loads, such as pots, pans,
casserole dishes and dishes
that have been sitting with
dried food on them for a
while.
A shorter wash for lightly
soiled loads that do not
need drying.
Quick
Pre-wash(50 )
Wash (65 )
Rinse
Rinse
Rinse(65 )
Drying
Pre-wash(45 )
Wash (55 )
Rinse
Rinse (60 )
Drying
Pre-wash
Wash (50 )
Rinse
Rinse(50 )
Drying
Wash (40 )
Rinse
Rinse (45 )
165
160
135
40
1.15
0.87
1.4
0.5
18
14.5
13.6
10.5
Description
of Cycle
Description
of Cycle
1 Hour
Pre-wash(50 )
Wash(60 )
Rinse (55 )
Drying
60 10
0.9
5/27.5g
20g
Daily wash in only 1 hour.
For lightly and normally
soiled plates and pans
for everyday.
(*AS/NZS 2007.1)
For heavily soiled loads,
such as pots, plates, glasses
and lightly soiled pans.

If you open the door , the machine will pause. The program lightwill
stop blinking and the buzzerwill sound every minute unless you close the door .After
you close the door ,the machine will keep on working after 10 seconds.
during a washcycle
Premise:
Acycle that is underway can only be modified if it has only been running for a short time. Otherwise, the
detergent may have already been released,and the appliance may have already drained the wash water.
If this is the case, the detergent dispenser must be refilled (see the section entitled " Loading the
Detergent " ).
Press the On/Off button to stop washing , press this button to reset ,Then you can change the program to
the desired cycle setting (see the section entitled "Starting a wash cycle. .." ).
Then
1
2
When you press the Start/Pause button to pause during washing, the will
stop blinkingand the dishwasher will mooingeveryminute unless you pressthe
Start/Pause button to start.
running indicator
When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the ON/OFF button,shut off the water supply and open the door of the dishwasher.
Wait for afew minutesbefore unloading thedishwasher toavoidhandlingthe dishes and utensils while they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
The program light is on but is not blinking, only in this case the programme has ended.
1.Switch off the dishwasher by pressing the ON/OFF button.
2.Turnoffthewater tap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removing from the appliance.
Open the dishwasher's door, leave it ajar and wait a few minutes before removing the dishes. In this way they
will be cooler and the drying will be improved.
Unloadingthedishwasher
It is normal that the dishwasher is wet inside.
Empty the lower basket first and then the upper one. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
Wash the arms in soapy and warm water and use a soft brush to
cleanthejets. Replace them afterrinsing them thoroughly.
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
It is dangerous to open the door when washing, because the hot water may scald you.
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working, you can open the door
completely.
2
3
Open the door a little .
14
5
6
Press the Start/Pause Button to stop the washing.
Press the , the dishwasher will run
after 10 seconds.
Start/Pause Button

The filter preventslarger remnants of food or other objects from getting inside the pump.
Theresidues may block thefilter, inthis casethey must be removed.
The filter system consists of a coarse filter,a flat (Main filter)
Anda microfilter(Fine filter).
Food and soil particles trapped in thisfilter arepulverizedby a
special jet on the lower spray arm and washed down to drain.
Larger items, such as pieces of bones or glass, that could block
the drainaretrappedin the coarse filter. To remove theitems
caught by the filter, gently squeeze the tap on thetop of this
filterandliftout.
Thisfilter holds soil and food residuesin the sumpareaand
prevents itfrom beingredepositon the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter must be cleaned regularly. this reason, it is a good idea to
remove thelarger food particlestrapped in the filter after each wash cycleby rinsing the semicircular filter and
cup under runningwater. To remove the filter device, pull the cup handle in the upward direction.
removes food particles from the wash water,allowing it to be recycled during the cycle.
For
The dishwasher must never be used without the filters.
Improper replacementof the filter may reduce the performancelevel ofthe appliance
and damage dishesand utensils.
Step 1 Turn the filter in anti-clockwise direction,：
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
1
2

The control panelcan be cleaned by using a lightly dampened cloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use agood appliance polish wax.
Never usesharp objects, scouring pads orharsh cleaners onany part of the dishwasher.
ProtectAgainst Freezing
1.Cut off the electrical power to thedishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottomof the tub and use a sponge to soak up water in the sump.
please take frost protection measures onthe dishwasher in winter.Every fter washing cycles,
please operate as follows time a
：
Cleaning the Filter
CleaningThe Door
To clean the coarse filter and the fine filter, use a cleaning brush. Reassemble the filter parts as shown in the figures
on the last page and reinsert the entire assembly in the dishwasher,positioning it in its seat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, the filters could be
contorted andtheperformance ofthe dishwashercouldbe decreased.
To clean theedge around the door, you should use only a soft warm, damp cloth.
To avoid penetrationof water into the door lock and electrical components, do not
use a spray cleaner of any kind.
Never use a spray cleaner to clean the door panel as it may damage the door lock
and electrical components.
Abrasive agents or some paper towels should not be used becauseof the risk of
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
water chemicalswillclogthe sprayarmjetsandbearings.
- Inspect the filters for blockingafter every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Removeany foodremnants and
cleanthefilters underrunningwater.
Remarks:
The entire filter assembly shouldbe cleaned once a week.
To removethelower sprayarm, pull out the spray armupward.
To remove the upper spray arm, hold the nut, rotate the arm
clockwise toremoveit.
Wash the arms in soapy and warm water and use a soft brush to
clean the jets. Replace them after rinsing them thoroughly.

Itisrecommend that yourun a washcycle with the
dishwasher empty andthen remove the plug from the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealstolastlongerandpreventodours fromforming
withinthe appliance.
If the appliance must be moved, try to keep it in the
verticalposition. If absolutelynecessary,itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remains trapped in the seals.
Periodic cleaning with a damp sponge will prevent this
from occurring.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasivecleaningproducts.
Only use a cloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a cloth dampened withwater an a little
vinegar, or a cleaning product madespecifically for
dishwashers.
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
After every wash, turn off the water supply to the
appliance and leave the doorslightlyopen sothat
moisture and odours are not trapped inside.
After EveryWash
When not in Use for aLongTime
The installation of the pipes
and electrical equipments
should be done by professionals.
Electrical Shock Hazard
Disconnect electrical power before
installingdishwasher.
Failure to do so can result in death or
electrical shock.
The installation position of dishwasher should be near the existing inlet and drain hoses and
powercord.
One side of the cabinetsinkshould be chosen to facilitatethe connection ofdrain hoses of
thedishwasher.
Installation preparation
Note: please check the accompanying installation accessories(hook for aesthetic panel,screw)
●

Please carefully read the installation instruction.
●Illustrations of cabinet dimensions and installation position of the dishwasher
Preparations should be made before moving the dishwasher to the installation place.
Choose a place near the sink to facilitate the installation of inlet and drain hoses
(see figure 1).
If dishwasher is installed at the corner of the cabinet, there should be somespace
(illustrated in figure 2) when the door is opened.
2
1
Minimum space when
the door is opened
【Figure2】
Cabinet dimensions
【Figure1】
Cabinet
Dishwasher
Door of
dishwasher
Minimum space of 50mm
1
The aesthetic wooden panel could be processed according to the Figure 3.
The aesthetic panel should
be processed in accordance
with the illustrated dimensions
【Figure3】
●Aesthetic panel's dimensions and installation
Less than 5mm
between the top
of dishwasher and
cabinet and the
outer door aligned
to cabinet.
90 °
90 °
600 mm
820mm
100
580mm
80
Space between cabinet
bottom and floor
Electrical, drain and
water supply line
entrances
(Unit: mm)

Installationof aesthetic panel
【】Figure4a
2magical paster Aand magical paster B be disjoinedon,magical paster A on the aesthetic wooden paneland
felted magical paster B of theouter door of dishwasher(see figure4a).After positioning of the panel , fix thepanel
ontothe outer door by screws and bolts(See figure 4b)
Installationof aesthetic
woodenpanel
【】Figure4b
.take away the four
short screws
.pinupthefourlong
screws
1
2

Tension adjustment
ofthe door spring
【】Figure5
Tensionadjustment of the door spring
●
Connection of drain hoses
●
The door springs are set at the factory to the proper tension for the outer door.
If aesthetic wooden panel are installed, you will have to adjust the door spring tension.
Rotate the adjusting screw to drive the adjustor to strain or relax the steel cable
(seefigure5).
Door spring tension is correct when
the door remains horizontal in the
fullyopened position yetrises
toaclosewiththeslightliftofa
finger.
，
Insert the drainhose into adrainpipe with aminimum diameter of 40mm,or let it run into the sink, making sure to
avoidbendingor crimping it. The topof the hosemust belessthan 1000mm.
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be less than
1000mm.
φ40mm
B

【Figure 7】
Dishwasher installation steps
●
1
2
.
3.
4.
5.
6
7
8
Install the furniture door to the outer door of the dishwasher using the brackets provided. Refer
to the template for positioning of the brackets.
Adjust the tension of the door springs by using an Allen key turning in a clockwise motion to
tighten the left and right door springs. Failure to do this could cause damage to your dishwasher
(Illustration 2)
Connect the inlet hose to the cold water supply
Connect the drain hose. Refer to diagram (Figure 6)
Connect the power cord
Affix the condensation strip under the work surface of cabinet. Please ensure the condensation
strip is flush with edge of work surface.
Place the dishwasher into position.(Illustration 4)
Level the dishwasher. The rear foot can be adjusted from the front of the dishwasher by turning
the Allen screw in the middle of the base of dishwasher use an Allen key (Illustration 5A). To adjust
the front feet, use a flat screw driver and turn the front feet until the dishwasher is level (Illustration 5B).
9 The dishwasher must be secured in place. There are two ways to do this:
A. Normal work surface:Put the right(left) installation hook into the slotoftheright(left)sideplaneand
secure it to the work surface with two woodscrews (Illustration 6).
B. Marble or granite work top:Bend the right(left) installation hook into right-angle,and put it into the
slot of the right(left) side plane and secure it to the work surface with two woodscrews s (Illustration 7)
.
