Omega ODW707WB User manual

ODW707WB/ODW707XB
14 place settings
Alt function

Witheachwashcycle.
Compartment
For programmes with pre-wash only.
(Follow the user instructions!)
Electric indicator on control panel (if provided).
Check the rinse aid level
Load the baskets
Select a programme
Close the door, turn on the water tap and press the Start/Pause button. The machine will start working
after about 10 seconds.
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid handling
the dishes and utensils while they are still hot and more susceptible to break.
They will also dry better.Unload the appliance, starting from the lower basket.
Changing theprogramme
Add forgotten dishes in the
dishwasher.
Scrape off any large amount of leftover food. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
Press the Programme button until the selected programme lights up.
( See the section entitled Operationg instruction )“”
When the working cycle has finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the Power button.
If the appliance is switched
off during a wash cycle.
Open the door carefully.
Hotsteam may escape
when thedoorisopened!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance Press the Power switch button to switch on the appliance, Open the door.
1.Open the door a little to stop the dishwasher.
2.After the spray arms stop working, you can open the door completely.
3.Add the forgotten dishes.
4.Close the door, the dishwasher will start running again after 10 seconds.
For detailed operating method read the corresponding content on the instruction manual.
1. Arunning cycle canonly be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If this is the case, the detergent
dispenser must be refilled.
2. Press the Start/Pause button ,than press the program button morethan 3 seconds to cancelthe
running programme.
3. Select a new programme.
4. Restart thedishwasher.

To review the section on troubleshooting Tips
will help you tosolve some common problems
by yourself .
Dear Customer,
Please carefully readthismanualbefore usingthe
dishwasher, itwill help you touse andmaintainthe
dishwasher properly.
Pass it on toany subsequentowner of the appliance.
Thismanual contains sections on safety Instructions,
Operating Instructions, InstallationInstructionsand
Troubleshooting Tips, etc.
The manufacturer, following a policy of constant
developmentandupdating of the product, may
make modifications without giving prior notice.
Keep it as arefer in the later days.
If you can not solvethe problems by yourself ,
please ask for the help of professional technicians.
This appliance isintended tobe usedin household
andsimilarapplications suchas:
-staff kitchen areas in shops,offices and other
working environments;
-farm houses;
-byclients inhotels, motels and otherresidential
type environments;
-bed and breakfast type environments.
Dishwasher Features.................................... ...2
AttentionbeforeorafterloadingtheDishwasher
Baskets..........................................................6
Filtering System.............................................10
Caring for the Dishwasher..................... .........11.
A Fill the RinseAid Dispenser............. .. ..3、..... ...
B Functionof Detergent .........................4、........
..............7
The Method Loading Normal Dishware
Wash CycleTable...........................................8
Turning on theAppliance................................8
Change the Programme.............. ................9....
At theEne of the Wash Cycle...........................9
PositioningtheAppliance................... ..........12..
Water Connection.................................. .......13.
AboutPowerConnection........................ .......12.
Startof dishwasher................................ ......14..
Before calling for service........................... .....15.
Errorcodes.................................... ..............16.
Technical information.............................. .....17..
Control Panel...................................................2

This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce
the risk of anelectric shock by providing a path of
least resistance of electric current. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet
that is installed and grounded in accordance with
all local codes and ordinances.
Keep children away from detergent and rinse aid, keep
child away from the open door of the dishwasher,
there could still be some detergent left inside.
ren
Donotabuse,siton,orstandonthedoorordish
rack of the dishwasher.
Do not touch the heating element during or
immediately after use.
(This instruction is only applicable to machines
with a visual heating element.)
Do not wash plastic items unless they are marked
dishwasher safe or the equivalent. For plastic items
not so marked, check the manufacturer's
recommendations.
Use only detergent and rinse additives
designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand
washing detergent in your dishwasher. Keep
these products out of the reach of children.
During installation, the power supply must not
be excessively or dangerously bent or flattened.
Do not tamper with controls.
Do not place any heavy objects the
door when it is open. The appliance could tip
forward.
on or stand on
When loading items to be washed:
1) Locate sharp items so that they are not likely
to damage the door seal;
2 Warning: Knives and other utensils with
sharp points must be loadedinthe basket
with their pointsdown or placed in a
horizontalposition.
)
When using your dishwasher, youshould
prevent plastic items from coming into contact
with the heating element.(This instruction is only
applicable to machines with a visual heating
element.)
Ifthesupplycord isdamaged, itmustbe replaced
bythemanufactureroritsserviceagentora
similarly qualified person in order to avoid a
hazard.
Please dispose of packing materials properly.
Use the dishwasher only for its intended function.
Remove the door to the washing compartment when
removing an old dishwasher from service or discarding it.
Dishwasher detergents are strongly alkaline, they
can be extremelydangerous if swallowed.Avoid
contact with skin and eyes and keep children away
from the dishwasher when the door is open.
Check that the detergent comparment isempty
after completion of thewash cycle.
The appliance is to be connected to the water
mains usingnew hose sets and that old hose-sets
should not be reused.
The maximum number of place settings to be
washed is14.
The maximum permissible inlet water pressure is
1Mpa.
The minimum permissible inlet water pressure is
0.04Mpa.
Children should be supervised to ensure that they do
not play with the appliance.
This appliance is not intended for use by persons
(including children with reduced physical, sensory or
mental capabilities, or lack of experience and
knowledge ,unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
)
When using your dishwasher, follow the precautions listed below:
The door should not be left open,
since this could increasethe riskof tripping.
Improper connection of the equipment-grounding
conductor can result in the risk of an electric shock.
Check with a qualified electrician or service
representative if you are in doubt whether the
appliance is properly grounded. Do not modify the
plug provided with the appliance; If it does not fit
the outlet. Have a proper outlet installed by a
qualified electrician.
Do not operate your dishwasher unless all
enclosure panels are properly in place. Open
the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.

beforeusing it for the first time.
To getthe best performance from yourdishwasher, read all operating instructions
10 11
Back View
1
2
3
4
5
6
7
89
Front view
Lower basket
Dispenser
Cupshelf
Spray arms
Filter assembly
Inletpipeconnector
Drain pipe
Upperbasket
Cutlery rack
Top spray arm
1
Inner pipe
5
6
7
8
9
11
10
3
24
3
13 1
6.Start /Pause button: To start the selected
washing program orpause the washing program
when the machine isworking.
5.Power Button:To turn on/off the power supply.
8.Child lock button: press the two buttons
simultaneouslyto lock the program.
4.DelayButton :To Pressthebutton to delay.
3.Program Button : To Press thebutton toselect
appropriateProgram.
1. Program indicators: to show which
program you have chose;
2.Display screen:to showthe remindingtime
and the state(runningstate,delaytime etc )
7.Alt Button: Dual zone wash function, press the button
to select either upper basket or lower basket loaded, and
the response indicator will blinking.

Before usingyour dishwasher for the first time:
A. Fill therinse aiddispenser
B. Fill in detergent
Therinse aid isreleasedduring the finalrinse to prevent water from forming dropletson your dishes, which can
leave spots and streaks. It also improvesdrying by allowing water to roll off thedishes. Yourdishwasher is
designed to useliquidrinseaids.The rinseaid dispenser islocated inside the door next to thedetergent dispenser.
Tofillthe dispenser,open thecapand pour the rinse aidinto thedispenser until the levelindicator turns completely
black.Thevolume ofthe rinseaidcontaineris about110ml.
RinseAid Dispenser
Function of RinseAid
Rinse aid is automatically added during thelast rinse, ensuring thorough rinsing, and spot and streakfree drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinseaid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
As the rinseaid diminishes, the size of the black dot
on the rinse aidlevel indicator changes, as illustrated below.
Full
3/4full
1/2full
1/4full-Shouldrefilltoeliminatespotting
Empty
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color of the
optical level
indicator "C" located next to the cap. When the rinse-aid container is full, the whole indicator will be dark .As the
rinse-aid
diminishes, the size of the dark dot decreases. You should never let therinse aid get below 1/ 4 full.
When to Refill the RinseAid Dispenser
RINSEAID DISPENSER
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pourthe rinse aid into the dispenser, being careful notto overfill.
Replace the cap by inserting italigned with "open" arrow and turning it tothe closed (right) arrow.
Be carefulnotto overfillthe dispenser,because thiscould cause over sudsing.Wipe away anyspills
witha damp cloth. Don't forget toreplace thecap before you close dishwasher door.
Attention!
Clean up any rinse aid split during filling with an absorbent cloth toavoid excessfoaming
during the nextwash.
1
2
3

Adjusting RinseAid Dispenser
The rinse aid dispenserhassix orfour settings.Always start with the dispenser
set on "4". If spots and poor drying are a problem,increase the amount of rinse
aiddispensedbyremoving thedispenserlidandrotatingthedialto"5".Ifthe
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase the dose if thereare drops of wateror limespots on the dishes after washing.
Reduce itif there are sticky whitishstains on your dishes or a bluish film on glassware or
knifeblades.
during thenextwash. Don'tforgetto replacethe cap before you closedishwasher door.
Cleanup any rinse aid spilled while duringfillingwith an absorbent cloth to avoid excessive foaming
Detergentswith its chemical ingredients arenecessary toremove dirt, crush dirt and transport it outof the dishwasher.
Most of the commercial quality detergents are suitableforthispurpose.
Detergents
There are 3 sorts of detergents
1.With phosphate and withchlorine
2.With phosphate and without chlorine
3.Without phosphate and without chlorine
Based on their chemicalcomposition,detergentscan be split in two basic types:
Theuse of normal washing programs in combination with concentrated detergents
reducespollutionand is good foryourdishes;these wash programsarespecificallymatched
to the dirt-dissolvingproperties ofthe enzymes oftheconcentrated detergent.Forthis reason
normal wash programs inwhich concentrated detergents are used can achieve the same
results that canotherwise onlybeachieved using intensive programs.
“”
“”
“”
Detergent tablets ofdifferentbrands dissolve at different speeds. For this reason some
detergenttabletscannotdissolveanddevelop their full cleaning power during short
programs. Therefore please use long programs when using detergent tablets, to
ensurethe completeremovalof detergentresiduals.
The dispenser mustbe refilled before thestart of each wash cycle following the instructions
provided in the washcycle table .Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoonof detergent is needed for
a normal wash load.More heavilysoiled items needmore detergent.Always add the
detergent just before startingthedishwasher, otherwise it couldget damp and will not
dissolve properly.
Concentrated Detergent
DetergentTablets
DetergentDispenser
conventional, alkalinedetergents with caustic components
low alkalineconcentrated detergents with natural enzymes
Normally new pulveriseddetergent is withoutphosphate.Thus the water softener function of
phosphate is not given. In this case we recommend to fill salt in the salt container even when
thehardness ofwater is only6 dH.Ifdetergentswithout phosphate are used inthe case ofhardwater
often whitespots appearon dishes and glasses.In this case please add more detergentto reach
better results. Detergents without chlorine doonlybleacha little. Strong and coloured spots willnot
be removedcompletely.In this case please choose a programwitha higher temperature.
°

Amount ofDetergentto Use
ProperUseofDetergent
Use only detergent specifically madefor the usein dishwashers. Keep your detergent fresh and dry.
Don't put powdereddetergent into the dispenser untilyou're ready to wash dishes.
Dishwasher detergent is corrosive! Take care tokeep itout of reach of children.
Always add the detergentjustbefore starting eachwash cycle.
Only use branded detergent aid for dishwasher.
If the lid is closed: press release button. The lid will spring open.
Detergent tablet
Detergent powder
Fill the detergentdispenser with detergent.
Themarkingindicatesthedosinglevels , as
illustratedontheright:
The placeof main wash cycle detergent placed.
The place of pre-wash cycle detergent placed.
Please observe the manufacturers dosing andstorage
Recommendations as stated on the detergent packaging.
Close the lid and press until itlocks in place.
Ifthedishesare heavily soiled, placean additional
detergent dose in thepre-wash detergent chamber. This detergent willtake effect during the pre-wash phase.
A
B
Fill in Detergent
You find information about the amount of detergent for the single programme on the last page.
Pleaseaware, that according to the level soiling andthespecifichardness of water differences are possible.
Pleaseobserve the manufacturer'srecommendations on the detergent packaging.

Cutlery with wooden,horn china or
mother-of-pearl handles
Plasticitems that arenotheat resistant
Older cutlerywith glued partsthat are not
temperatureresistant
Bonded cutlery items or dishes
Pewter or cooper items
Crystal glass
Steel items subject to rusting
Wooden platters
Items made fromsynthetic fibres
Some types of glassescan become
dull aftera large number of washes
Silver and aluminum parts have a
tendency to discolourduring washing
Glazed patterns may fade if machine
washed frequently
Are not suitable Are oflimited suitability
Dishes and items ofcutlery mustnotlie insideoneanother, orcover each other.
To avoid damage to glasses,theymust not touch.
Load large itemswhich are mostdifficult to clean into the lower basket.
The upper basket isdesigned to hold moredelicate and lighter dishware such as glasses,coffee
andteacups
Long bladed knives stored in an upright positionare a potential hazard!
Long and/or sharp itemsof cutlery such as carving knives must be positioned
horizontallyin the upperbasket.
Please do not overload your dishwasher. This is importantfor goodresultsandfor
reasonable consumption of energy.
Load hollow items such as cups, glasses, pans etc. With the opening facing downwardsso that
water cannot collect in the container or a deep base.
Consider buyingutensils which are identifiedas dishwasher-proof.
Usea mild detergent thatis describedas 'kind todishes'. Ifnecessary, seek further
information from the detergentmanufacturers.
Forparticular items,select aprogramwithaslowa temperature aspossible.
To prevent damage, do not take glassandcutlery out of the dishwasher immediately
after the programmehas ended.
(For best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery basketsmay vary from your model.)
Scrape off any largeamounts of leftover food. Soften remnants of burnt food inpans.
It is not necessary to rinse the dishesunder running water.
Place objects in the dishwasher in following way:
1.Items such as cups, glasses, pots/pans, etc. are faced downwards.
2.Curved items, or ones with recesses, should be loaded aslant so that water can run off.
3.All utensils are stacked securely and can not tipover.
4.All utensils are placed in the way thatthe spray arms can rotate freely during washing.
Very small items should not be washed in the dishwasher as they could easily fall out of the basket.
To prevent water dripping from the upper basket into the lower basket, we recommend that you
empty the lower basket first and then the upper basket.

Theupper basket is designed to holdmore delicate
and lighter dishware such as glasses, coffee and
teacups and saucers, as well asplates, small bowls
andshallow pans (as long astheyare not toodirty).
Position thedishes andcookwareso thatthey will
notgetmoved bythespray ofwater.
We suggest that you place large items and the most
difficult to cleanitemsaretobe placedintothelower
basket: suchas pots, pans, lids, serving dishes and
bowls, as shown in the figure below. It is preferable to
place serving dishes and lids on the side of the racks
in order to avoid blocking the rotation of the top spray
arm.
Pots,servingbowls,etc,mustalwaysbeplacedtopdown.
Deep pots should be slanted to allow water to flow out.
Please bereminded that:
The Bottom Basket features folding spikes so that larger or more pots and pans can be loaded.
Folding Spikes of Lower Basket
Forbetter stacking of pots and pans,
the spikescan be folded down as
show in the picture right.
Folding back the cup shelives
For better stacking of pots and pans,
the spikes can be folded down as
show in the picture right.
Cutleryshouldbe placed inthecutlery rackseparately
from each other in the appropriate positions, and do
make sure theutensils do not nest together, this may
causebadperformance.
Fora top quality cleaning, place the silverware in the basket
makingsurethat:
They donot nest together.
Silverware is placed with the maleface up.
Long utensils in the middle.
Adjusting the Upper Basket
The height of the upperbasket can be adjustedin order to
createmore space for largeutensils both for the upper
/lower basket.The height of the upperbasket can be
adjusted by lift up the basket for the upper position, and up
pressthe handle tolower theupper basket,see thepicture
below:
Lift the basket
for upper postion
Up press the handle
to lower the basket

Normal
Intensive
Heavy
(OrAll )in1
5/27.5g
5
(OrAll )
/27.5g
in1
(OrAll )in1
5/27.5g
Fornormally soiled loads,
suchas , plates,glasses
and lightly soiledpans.
standarddailycycle.
pots
For theheaviest soiled
loads, suchas pots, pans,
casserole dishes and dishes
thathavebeensittingwith
driedfood on them for a
while.
Ashorterwashforlightly
soiled loadsthat do not
need drying.
Quick
Pre-wash(50 )
Wash (65 )
Rinse
Rinse
Rinse(55 )
Drying
℃
℃
℃
Pre-wash(45 )
Wash (55 )
Rinse
Rinse (60 )
Drying
℃
℃
℃
Pre-wash
Wash (45 )
Rinse
Rinse(50 )
Drying
℃
℃
Wash (40 )
Rinse
Rinse (45 )
℃
℃
175
160
165
35
1.2
0.71
1.4
0.5
16.5
13.5
13
10
60 Min
Pre-wash(50 )
Wash(60 )
Rinse (50 )
Drying
℃
℃
℃
60 9
0.85
5/27.5g
20g
Daily wash in only 1 hour.
For lightly and normally
soiledplates and pans
foreveryday.
Ashorterwashforlightly
soiled loadsthat do not
need drying.
Soak
Pre-wash
80.1
3.5
Means: need to fill rinse into the Rinse-Aid Dispenser.
()
(*AS/NZS 2007.1)
For heavily soiled loads,
suchas pots, plates,glasses
and lightly soiled pans.
* : This program is the test cycle. The information for comparability test
in accordance with , as follows:
AS/NZS 2007.1
AS/NZS 2007.1
Capacity: 14 setting
Position Upper basket: upper wheelson rails
Rinse aid setting: 6
Open the door slightly 50mm to assistin drying of the dishes after every wash
Starting a cycle wash
1 Draw out the lower and upper basket, load the dishes and push them back.
Itiscommended to load thelower basket first, then the upperone(see the section entitled
Loading the Dishwasher ).
2 Pour in the detergent (see the section entitled Detergent and RinseAid ).
3 Insert the plug intothe socket. The power supply is 220-240 VAC /50 HZ, the specification
of thesocket is 10A 250VAC. Makesure that the water supply is turned on to full pressure.
4 Close the door, press the P button,to switchonthe machine.
5 Press the program button , the wash program will be changed as follows direction:
If a program is selected, the response lightwill light.Then press the Start/Pause button, the
dishwasher beginsto start.
“”
“”
ower
Intensive->Heavy->Normal->60min->Rapid ;->Soak

When the working cycle has finished, the buzzer of the dishwasher will sound for 8 seconds, then stop. Turn off
the appliance using the Power switch button, shut off the water supply and open the door of the dishwasher.
Wait for afew minutes before unloading the dishwasherto avoidhandlingthe dishes and utensilswhile they
are still hot and more susceptible to breakage. They will also dry better.
Switch Off the Dishwasher
The program light is on but is not blinking, only in this case the programmehas ended.
1.Switch off the dishwasher by pressing the Power button.
2.Turnoffthewatertap!
Open the door carefully.
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes
before removingfrom the appliance.
Open thedishwasher's door, leave it ajar and wait a few minutes beforeremoving the dishes. In this way they
will be cooler andthe drying will be improved.
Unloadingthe dishwasher
It is normal that the dishwasher is wet inside.
Empty thelower basket first and thenthe upperone. This will avoid water dripping from the upper Basket onto
the dishes in the lower one.
If you open the door , the machine will pause. The program light will
stop blinking and the buzzer will mooing every minute unless you close the door . After
you close the door ,the machine will keepon workingafter 10 seconds.
during awash cycle
Premise:
1 Acycle that is underway can only be modified if it has only been running for a short time. Otherwise, the
detergent may have alreadybeen released, and the appliancemay have already drained the wash water.
If this is the case, the detergent dispenser must be refilled (see the sectionentitled " Loading the
Detergent " ).
2 Press the Start/Pause button , the machinewill be in standby state, press the program button more than
3s then you can change the program to thedesired cycle setting (see the section entitled " Starting awash
cycle. . ." ).
Aforgotten dish can be added any time before the detergent cup opens.
Add forgotten dishes.
Close the door
After the spray arms stop working,you can open the door
completely.
2
3
Open the door a little to stop the washing.
14
5
6
Press the Start/Pause button
Press the button, the dishwasher will run
after 10 seconds.
Start/Pause
When you press the Start/Pause button to pause during washing, the running indicator will
stop blinking and the dishwasher will mooing every minute unless you pressthe
button to start.Start/Pause
Wash the arms in soapy and warm water and use a soft brush to
cleanthejets. Replace them afterrinsing them thoroughly.
When following this procedure from step1 to step 3, the filter system will be removed;
when following it from Step 3 to Step 1, the filter system will be installed.
It is dangerous to open the door when washing, because the hot water may scald you.

The filter preventslarger remnantsof food or other objects from getting inside the pum.
Theresidues may blockthe filter, inthis casethey must be removed.
The filter system consists of a coarse filter,a flat (Main filter)
And a microfilter(Fine filter).
Food and soil particles trapped in thisfilter arepulverizedbya
special jet on the lower spray arm and washed down todrain.
Larger items, such as pieces of bones or glass, that couldblock
the drainaretrappedin the coarse filter. To remove theitems
caught by the filter, gently squeeze the tap on thetop of this
filterandliftout.
Thisfilter holds soil and food residues in the sumpareaand
preventsitfrom being redepositon the dishes during wash cycle.
Main filter
1
Coarse filter
2
Fine filter
3
2
3
1
Filterassembly
Thefilter efficiently
For best performance and results, the filter mustbe cleaned regularly. this reason, it isa goodidea to
remove thelarger food particles trapped in the filter aftereach washcycleby rinsing the semicircular filter and
cup under running water. To remove the filter device,pull the cup handle in the upward direction.
removes food particles from the wash water, allowing it to be recycledduring the cycle.
For
The dishwasher must never be used without the filters.
Improper replacementof the filter may reduce the performancelevel of the appliance
and damage dishesandutensils.
Step 1 Turn the filterin anti-clockwisedirection,：
Step 2 lift the filter assy up：
When following this procedure from step1 to step 2, the filter system will be removed;
when following it from Step 2 to Step 1, the filter system will be installed.
1
2

The control panel can be cleaned by using a lightly dampenedcloth.
After cleaning, make sure to dry it thoroughly.
For the exterior, use agood appliance polish wax.
Never usesharp objects, scouring pads orharsh cleaners onany part ofthe dishwasher.
ProtectAgainst Freezing
1.Cut off the electricalpower to the dishwasher.
2.Turn off the water supply and disconnect the water inlet pipe from the water valve.
3.Drain the water from the inlet pipe and water valve. (Use a pan to gather the water)
4.Reconnect the water inlet pipe to the water valve.
5.Remove the filter at the bottomof the tub and use a spongeto soak up water in the sump.
please take frost protection measuresonthe dishwasher in winter.Every fter washingcycles,
please operate as follows time a
：
Cleaning the Filter
CleaningThe Door
To clean the coarsefilter and the fine filter, use a cleaning brush. Reassemble the filter parts as shown in the figures
on thelast page and reinsert the entire assembly in the dishwasher, positioning itin itsseat and pressing downwards.
When cleaning the filters, don't knock on them. Otherwise, thefilters could be
contorted and theperformance ofthe dishwashercouldbe decreased.
To clean theedge around the door, you shoulduseonly a soft warm, dampcloth.
To avoid penetrationof waterinto the door lock and electrical components,do not
use a spray cleaner of any kind.
Never use a spray cleaner toclean the door panel as it may damage the door lock
and electricalcomponents.
Abrasive agentsor some paper towels should not be used because of the riskof
scratching or leaving spots on the stainless steel surface.
Cleaning the SprayArms
If your dishwasher cannot work because of the ice,
please contact professional service persons.
It is necessary to clean the spray arms regularly for hard
waterchemicalswillclogthesprayarmjetsandbearings.
- Inspect the filters for blockingafter every time the dishwasher has been used.
- By unscrewing the coarse filter, you can remove the filter system. Removeanyfoodremnants and
cleanthefilters underrunningwater.
Remarks:
The entire filter assembly shouldbe cleaned once a week.
Toremovethelower sprayarm, pull out the spray arm upward.
To remove the upper sprayarm, hold the nut, rotate the arm
clockwisetoremoveit.
Wash the arms in soapyand warm water and use a soft brush to
clean thejets. Replace them after rinsing them thoroughly.

Itisrecommend thatyourun awashcycle withthe
dishwasher empty andthen remove the plugfrom the
socket, turn off the water supply and leave the door of
the appliance slightly open. This will help the door
sealstolastlongerandpreventodoursfromforming
withinthe appliance.
If the appliance must be moved, tryto keep it in the
verticalposition.Ifabsolutely necessary, itcanbe
positioned on its back.
Oneofthefactorsthatcauseodourstoforminthe
dishwasher is food that remainstrapped in the seals.
Periodic cleaning with adamp sponge will prevent this
from occurring.
Ensure the voltage and frequency of the power being corresponds to
those on the rating plate. Only insert the plug into anelectricalsocket which isearthed
properly. If the electrical socket to which the appliance must be connected is not
appropriate fortheplug, replace the socket, ratherthan usinga adaptors or thelike as
they couldcause overheating andburns.
Pleaselook at therating label to knowthe rating voltage and connect the dishwasher to the appropriate power supply.
Use the required fuse 10 amp,timedelayfuse or circuitbreakerrecommended and provide separate circuit serving
only this appliance.
Position the appliance in the desired location. The back should rest against thewall behindit, and the sides,
along the adjacent cabinets or walls. The dishwasher is equippedwith water supply and drain hoses that can
be positioned either tothe right or the leftsides to facilitate proper installation.
Once the applianceis positioned for levelling, the height of the dishwasher
may be altered via adjustment of the screwing level ofthe feet. In any case,
theappliance should notbeinclined more than 2 .
For personal safety:
DO NOT USEAN EXTENSION CORD ORAN ADAPTER PLUG WITH THIS APPLIANCE.
DO NOT, UNDERANY CIRCUMSTANCES, CUT OR REMOVE THE EARTHING
CONNECTION FROM THE POWER CORD.
Before cleaning or performing maintenance, always
remove the plug from the socket.
Tocleantheexteriorandrubberparts ofthedishwasher,
donot use solventsor abrasive cleaning products.
Only use acloth with warm soapy water.
To remove spots or stains from the surface of the
interior, use a clothdampened withwater ana little
vinegar, ora cleaning product madespecificallyfor
dishwashers.
Remove the Plug
No Solvents orAbrasive Cleaning Moving theAppliance
Seals
After every wash, turn off the water supply to the
appliance and leave the doorslightly open so that
moisture and odours arenot trapped inside.
After EveryWash
When not in Use for aLongTime
This appliance must be earthed. In the event of a malfunction or breakdown, earthing will reduce the risk of
electric shock by providing a path of least resistance for the electric current. This appliance is equipped with a
cord having an equipment-earthing conductor and an earthing plug. The plug must be plugged into an
appropriate outlet that is installed and earthed in accordance with all local standards and requirements.

Insert the drainhose into adrain pipe with aminimum diameterof 40mm, or let it run into thesink,making sureto
avoid bendingor crimping it. The top of the hosemust be less than 1000mm.
A
Counter
Front
Drain pipe
NOTE
The top of the hose
must be less than
1000mm.
φ40mm
B
Ahose that attachesto asink spraycanburst ifit is installedon the same water line asthedishwasher. If your sink has
one, it is recommended thet the hose be disconnected and the hole plugged.
Pull The safety supply hoses completely out from storage compartment located at rear of dishwasher.
Turn water fully on before starting the dishwasher.
1
Tighter the screws of the safety supply hose to the faucet with thread 3/4inch.
The safety supply hose consists of the double walls. The hose's system guarantees its intervention by blocking the
flow of waterincase of the supply hosebreakingandwhen the air space betweenthe supply hose itself and theouter
corrugatedhoseisfullofwater.
Turn off the water.
Release the water pressure by depressing the pressure release button. This relieves water pressure and protects you, and the
room, from severe splashing.
Unscrew The safety supply hose from the faucet..
3
2
1
2
3
The appliance must be connected to thewater mains using new hose-sets.
Theold hose-setsshould not bereused.
Waterpressure must bebetween 0,04 MPa and 1 MPa. Ifthe pressure is below the minimum
consult ourServiceDepartment for advice.
Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place.
Ifthe water pipes are new orhave not been usedfor anextended periodoftime,let the water runto makesurethat the
water is clear and free of impurities. If this precaution is not taken,there is a risk that the water inlet can get blocked
and damage theappliance.
The water supply to the appliance can also be connectedto the house hot water line (centralized system, heating
system),aslong as it does not exceed atemperature of 60 C. In thiscase, thewash cycle timewillbe shortened by
about15 minutesandthe wash efficiency slightly reduced.
The connection must be made to thehot water line following thesameprocedures as those for the connection to the
cold water line.

The followingthingsshould be checked beforestarting the dishwasher.
The content of this manual is very helpfulto theusers.
After installation, please make sure to keep this manual.
1
The dishwasher is leveland fixed properly
2 The inlet valve is open
3 There is a leakage at theconnections ofthe conducts
4 The wires are tightly connected
5 The power is switched on
6 The inlet and drain hoses are knotted
7 Allpackingmaterialsand printings shouldbe taken out from the dishwasher
Extension Hose
Ifyouneeda drainhoseextension,makesure tousea similar drain hose.
It must beno longer than 4metres; otherwise the cleaning effectof the dishwasher could be reduced.
Water Outlet
Connect the waterdrain hose.The drain hose mustbe correctlyfitted to avoidwater leaks.
Ensure that thewater drain hose is not kinked or squashed.
If the sink is 1000 higher from the floor, the excess water in hoses cannotbe drained directly
into the sink.Itwillbe necessary todrainexcesswater fromhoses into abowlorsuitable
container that is held outside and lower thanthesink.
How to Drain Excess Water From Hoses
Syphon Connection
The waste connection must be at a height less than 1000mm (maximum) from thebottom of the dish.
The waterdrain hose should befixed .

Fuse blown, or the
circuit breaker acted Replace fuse or reset circuit breaker. Remove any other appliances sharing the same circuit with the dishwasher
Spilled rinse-aid Always wipe up rinse-aid spills immediately.
Hard water minerals
The affected items are
not corrosion resistant.
The lid of the softer
is loose
Aspayarmis
knocking against
an item in a basket
r
Items of crockery
are loose in the
wash cabinet
This may be caused
by on-site installation
or the cross-section of
the piping.
A programme was not
run after dishwasher
salt was added.
Traces of salt have
gotten into the wash cycle.
To clean the interior, use a damp sponge with
dishwasher detergent and wear rubber gloves.
Never use any other cleaner than dishwasher
detergent for the risk of foaming or suds.
Always run the quick wash programme .
without any crockery in the dishwasher and
without selecting the Turbo function (if present),
after adding dishwasher salt.
Check the lip .Ensure the fix is fine.
Interrupt the programme, and rearrange the items
which are obstructing the sp ay arm.r
Interrupt the programme,
and rearrange the items of crockery.
This has no influence on the dishwasher function.
if in doubt, contact a suitably qualified plumber.
Detergent with
colourant was used Make sure that the detergent is the one without colourant.
Improper detergent
Make sure the dishwasher is turned on and the door is
closed securely.
Check that the water supply is connected properly and
the water is turned on.
Make sure to close the door properly and latch it.
Makesure the power cord is properly plugged into the
wall socket.
Power supply is not
turned on
Error code:E1;
Water pressure is low
Door of dishwasher
not properly closed.
Kink in drain hose
Filter clogged
Kitchen sink clogged
Check drain hose.
Check coarse the filter
(see section titled )" Cleaning The Filter "
Check the kitchen sink to make sure it is draining well.
If the problem is the kitchen sink not draining ,you may
need a plumber rather than a serviceman for dishwashers.
Use only the special dishwasher detergent to avoid suds.
If this occurs, open the dishwasher and let suds evaporate.
Add 1 gallon of cold water to the tub. Close and latch the
dishwasher, then select any cycle. Dishwasher willdrain
out the water at the first step.Open the door after draining
is stop and check if the suds is disappeared.
Repeat if necessary.

The dishes were not
loaded correctly. See notes in " Loading the Dishwasher Baskets ".
Select a more intensive programme.
See" Wash Cycle Table ."
Use more detergent, or change your detergent.
Rearrange the items so that the sp ay can rotate freely.r
Clean and/or fit the filter combination correctly.
Clean the sp ay arm jets. See "Cleaning the Spray
Arms". r
Use less detergent if you have soft water and select
a shortest cycle to wash the glassware and to get
them clean.
Use a mild abrasive cleaner to eliminate those marks.
Re-loading the dishes properly.
Load the dishwasher as suggested in the directions.
Increase the amount of rinse-aid/refill the rinse-aid
dispenser.
Do not empty your dishwasher immediately after
washing. Open the door slightly so that the steam can
escape. Begin unloading the dishwasher only once t
he dishes are barely warm to the touch. Empty the low
basket first. This prevents water form dropping off
dishes in the upper basket.
In short program the washing temperature is lower.
This also lowers cleaning performance. Choose
a program with a long washing time.
Water drainage is more difficult with these items.
Cutlery or dishes of this type are not suitable for
washing in the dishwasher.
The programme was
not powerful enough.
Not enough detergent
was dispensed.
Items are blocking
the path of sp ay arms.r
The filter combination
inthebaseofwash
cabinet is not clean or
is not correctly fitted.
This may cause
the sp ay arm jets
to get blocked.
r
Combination of soft
water and too much
detergent.
Aluminum utensils
have rubbed against
dishes.
Dishes block
detergent cups.
Improper loading
Too little rinse-aid
Dishes are removed
too soon
Wrong program
has been selected
Use of cutlery with
a low-quality coating
Overflow.
When some malfunctions come on, the appliance will display error codes to warn you:
Longer inlet time.
Faucets is not opened, or water intake is
restricted,or water pressure is too low.
Some element of dishwasher leaks .
E4
E1
E8
Open circuit or break of distributary valve. Failure of orientation of distributary valve.

Height : 845mm
Width : 598mm
Depth : 600mm
Water pressure: 0.04-1.0MPa
Hot water connection : max 60 ℃
Power supply: see rating label
Capacity: 14place settings
If overflow occurs, turn off the main water supply before calling a service.
If there is water in the base pan because of an overfill or small leak,
the water should be removed before restarting the dishwasher.
