Omega DP24-T User manual

www.omega.com
e-mail: [email protected]
User’s Guide
DP24-T
Thermocouple Meter
®
®
Shop on line at
RoHS 2 Compliant

It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply.
OMEGA is constantly pursuing certification of its products to the European New Approach Directives.
OMEGA will add the mark to every appropriate device upon certification.
The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no liability for
any errors it contains, and reserves the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, patient connected applications.
This device is marked with the international caution symbol. It is important to read the Setup Guide before
installing or commissioning this device as it contains important information relating to safety and EMC.
Servicing North America:
USA: One Omega Drive, P.O. Box 4047
ISO 9001 Certified Stamford CT 06907-0047
TEL: [phone] FAX: [phone]
e-mail: [email protected]
Canada: 976 Bergar
Laval (Quebec) 7L 5A1
TEL: [phone] FAX: [phone]
e-mail: [email protected]
For immediate technical or application assistance:
USA and Canada: Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA®
Customer Service: 1-800-622-2378 / 1-800-622-BEST®
Engineering Service: 1-800-872-9436 / 1-800-USA-W EN®
Mexico and TEL: (001)800-TC-OMEGA® FAX: [phone]
Latin American: En Español: [phone]-7803
e-mail: [email protected]
Servicing Europe:
Benelux: Postbus 8034, 1180 LA Amstelveen, The Netherlands
TEL: [phone] FAX: [phone]
Toll Free in Benelux: 0800 0993344
e-mail: [email protected]
Czech Republic: Frystatska 184, 733 01 Karviná
TEL: [phone] FAX: [phone]
e-mail: [email protected]
France: 11, rue Jacques Cartier, 78280 Guyancourt
TEL: [phone] FAX: [phone]
Toll Free in France: 0800 466 342
e-mail: [email protected]
Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfronn, Germany
TEL: [phone] FAX: [phone]
Toll Free in Germany: 0800 639 7678
e-mail: [email protected]
United Kingdom: One Omega Drive
ISO 9002 Certified River Bend Technology Centre
Northbank, Irlam Manchester M44 5BD United Kingdom
TEL: [phone] FAX: [phone]
Toll Free in England: 0800 488 488
e-mail: [email protected]
OMEGAnet® On-Line Service
www.omega.com
Internet e-mail
[email protected]
®
®

Table of Contents
Section Page
1 SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1.1 Customer Service . . . . . . . . . . . . . . . . . . . . . . . . .1
1.1.2 Inspecting Your Shipment . . . . . . . . . . . . . . . . .1
1.1.3 What You Will Need . . . . . . . . . . . . . . . . . . . . . .2
1.2.1 Basic Features . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.2.2 Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.3 Sa ety Considerations . . . . . . . . . . . . . . . . . . . . .4
1.4 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.4.1 Mount the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.4.2 Connect Sensor Input . . . . . . . . . . . . . . . . . . . . .7
1.4.3 Connect the AC Power Cord . . . . . . . . . . . . . . .8
1.4.4 Turn On the Unit . . . . . . . . . . . . . . . . . . . . . . . . .9
2 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
2.2 Meter Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.3 Display Descriptions . . . . . . . . . . . . . . . . . . . . .12
2.4 Menu Con igurations . . . . . . . . . . . . . . . . . . . .12
3 DEFAULTS SPECIFICATIONS . . . . . . . .21
3.1 Back o the Meter . . . . . . . . . . . . . . . . . . . . . . . .21
3.2 Main Board AC Power Jumpers . . . . . . . . . . .24
3.3 S51,-S4 Jumpers . . . . . . . . . . . . . . . . . . . . . . . . .26
3.4 Speci ications . . . . . . . . . . . . . . . . . . . . . . . . . . .28
4
INFORMATION . . . . . . . . . . . . . . . . . . . .31

List of Figures
Figure Page
1.1 Panel Cut-out Dimensions . . . . . . . . . . . . . .5
1.2 Thermocouple Input Connection . . . . . . . . .7
3.1 Connectors (ac-powered) . . . . . . . . . . . . . .21
3.2 Connectors (dc-powered) . . . . . . . . . . . . . .22
3.3 115Vac Jumpers (De ault) . . . . . . . . . . . . . .25
3.4 230Vac Jumpers . . . . . . . . . . . . . . . . . . . . . . .25
3.5 S51.-S4 Jumpers . . . . . . . . . . . . . . . . . . . . . . .27
3.6 Meter Dimensions . . . . . . . . . . . . . . . . . . . .30
List of Tables
Table Page
1.1 AC Power Wire Color & Connections . . . . .8
2.1 Meter Buttons . . . . . . . . . . . . . . . . . . . . . . . .11
2.2 Display Desriptions . . . . . . . . . . . . . . . . . . .12
3.1 Connector Descriptions . . . . . . . . . . . . . . . .23
3.2 S51-S4 Jumpers . . . . . . . . . . . . . . . . . . . . . . .26

1.1 Before You Begin
If you need assistance, please contact the
Customer Service Department nearest
you.
Remove the packing slip and verify that
you have received everything listed,
including:
1 Indicator/controller ith all applicable
connectors attached
1 O ner’s Manual
If you ordered any of the available
options (except the “BL” blank Lens
option), they will be shipped in a
separate container to avoid any damage
to your indicator/controller.
1.1.2
Inspecting
Your
Shipment
1.1.1
Customer
Service
SETUP
1
1

Inspect the container and equipment for
signs of damage as soon as you receive
the shipment. Note any evidence of
rough handling in transit. Immediately
report any damage to the shipping
agent. The carrier will not honor
damage claims unless all shipping
material is saved for inspection. After
examining and removing the contents,
save the packing material and carton in
the event reshipment is necessary.
In addition to the meter and connectors,
you ill need the follo ing items to setup
your unit:
115VAC three-prong po er cord
1/8" flat head scre driver
1.1.3 What
You Will
Need
Warning!
SETUP
1
2

SETUP
1
3
1.2 Features and Options
Your meter has several basic features,
some of hich are listed belo . For more
detailed information on specifications and
factory defaults, see Part 3: Defaults &
Specifications.
4 digit, 7 segment LED display ith
programmable decimal point
Nonvolatile memory — no battery backup
necessary
115Vac or 230Vac 50/60 Hz po er source
The unit is available ith an optional
NEMA-4 front panel cover. Please contact
Customer Service for a list of additional
products and accessories.
1.2.2
Options
1.2.1 Basic
Features

1.3 Safety Considerations
The unit is protected in accordance ith
Class II of IEC 348 and VDE 0411.
Remember that the unit has no po er-on
s itch. It ill be in operation as soon as
you connect it to a po er source.
Do not expose the unit to rain or moisture.
Do not operate your unit in flammable or
explosive atmospheres. As with any
electronic instrument, you may encounter
high voltage exposure when installing,
calibrating, or removing parts. Be careful
when working near conductors carrying
large currents. Use twisted-pair
connections to the unit. Use magnetic
shielding materials, or move the unit away
from the current source to reduce
magnetic field problems. Do not exceed
power rating on label located on the top of
the controller housing. Failure to follow
all instructions and warnings may result
in injury!
Warning!
SETUP
1
4

1.4 Getting Started
Follo these steps to start using your unit
right a ay:
Mount the unit
Connect Sensor Input
Connect the AC po er cord
Turn on the unit
1. Remove the t o nuts at the back of
the unit, hich hold the mounting
sleeve. Remove the sleeve.
2. Cut a hole in your panel, as sho n.
Figure 1.1 — Panel Cut-out Dimensions
0.03 [0.8] MIN
0.25 [6.4] MAX
4 PLCS
0.06
[1.5]
[92.00 +0.81/-0.00]
3.622 +.032/-.000
1.772 +.024/-.000
PANEL
THICKNESS:
R[45.00 +0.61/-0.00]
1.4.1
Mount the
Unit
Overview
SETUP
1
5

3. Insert the unit into the hole. Be sure
the front bezel is flush to your panel.
Slide on the mounting sleeve from the
rear of the panel and tighten the unit
until snug, using the t o nuts.
SETUP
1
6
PanelCutout

Figure 1.2 — Thermocouple nput Connection
1.4.2
Connect
Sensor
Input
SETUP
1
7
J1
J2
J4 1
2
RED

1. Locate the connector pins. (see Figure 3.1)
Do not connect AC power to your unit until
all input and output connections have been
properly established. Failure to do so may
result in injury.
2. Insert the correct ire in each terminal and tighten the
lockdo n scre . See Table 1.1 for ire color
definitions. Tug gently on the ires to verify that the
connections are secure.
Connection Europe USA
AC-High Brown Black
AC-Low Blue White
AC -Ground Green/Yellow Green
Table 1.1 — AC Power Wire Color & Connections
1.4.3
Connect the
AC Power
Cord
SETUP
1
8
Warning!

1. Plug the unit into a properly grounded
115V po er supply. The unit ill
initialize, scrolling the follo ing three
messages on the front panel:
Idt
code
r 0I
(r 0I equals the revision code of
the micro controller. Keep track
of the revision code for future reference.)
2. The present value of the
Thermocouple should be displayed. If
a value is not displayed, follo these
steps:
Unplug the unit
Verify the po er and TC connections
Check your po er source
Plug the unit in again
1.4.4 Turn
On the Unit
SETUP
1
9

2.1 Introduction
The unit has t o different modes of
operation. The first, Run Mode, is used to
display process value and display or clear
peak and valley values. The other mode,
Configuration Mode, is used to navigate
through the menus options and configure
the meter.
The S51 jumper must be removed ( hich
is the factory setting) and the S4 jumper
must be installed ( hich is not the factory
setting) for all menu configuration options
to be available. (See page 34 for further
jumper information.)
This part of the manual, Operation, ill
explain both the Run Mode and the
Configuration Mode and is divided into
the follo ing sections:
Meter Buttons
Display Descriptions
Menu Configurations
Overview
0PERATION
2
10

2.2 Meter Buttons
Button Description
RESET Reset the peak and
valley values
MENU Enter Configuration
(Menu) mode
/MIN Display the valley value
(flashing)
/MAX Display the peak value
(flashing)
C/F Toggle display between
°C and °F
Table 2.1 — Button Functions
0PERATION
2
11

2.3 Display Descriptions
Display
Message Description
nnnn Peak value to follow
uuuu Valley value to follow
0l Open thermocouple input
rst Peak/Valley Reset
Table 2.2 — Display Descriptions
2.4 Menu Configurations
2.4.1 Selecting the Input
Thermocouple Type
The unit is designed to handle up to eight
different thermocouple types. To select the
thermocouple type, follo these steps:
1. Press the MENU button. The meter ill
momentarily displays:
TYPE
TYPE
OPERATION
2
12

2. Press the /MIN button. You may
scroll through the follo ing choices:
Displayed as:
Jj
K+
Tt
Ee
Nn
DIN J di n j
Rr
Ss
2. Press the /MIN button to scroll
through available choices
3. Press the MENU button to store and
activate your selection.
2.4.2 Selecting the Decimal Point
The unit can display temperatures in 1° or
0.1° resolution. When using type R or S
the meter will only be indicating with 1°
resolution. The DEc.P menu item will not
be available for these two types of
thermocouples.
1. Press MENU until display displays:
dEc.P
dEcp
OPERATION
2
13

2. After a moment the display ill
indicate the currently selected decimal
point (resolution) configuration.
3. AUTO ill be displaced if the meter is
configured to display any temperature
bet een -100° and 1000° ith 0.1
resolution (meter ill s itch to 1°
resolution above and belo these
temperatures automatically.)
4. 1dEg ill be displayed hen the
meter is configured for 1° resolution.
5. Pressing the /MIN button allo s you
to toggle bet een these choices:
AUTO (0.1°/1°)
1dEg (1°) resolution
6. Press the MENU button to save and
activate your selection.
OPERATION
2
14

2.4.3 Meter Cold-Junction Offset
Calibration procedure
This menu item ill allo you to adjust the
cold junction offset calibration.
1. Press MENU until meter flashes:
C.J. Z (cold junction zero)
2. Connect the proper thermocouple to
the input at J4 and using a
thermocouple calibrator apply 0.0°C.
3. Press /MAX to display the cold-
junction offset. (If the meter reading at
this point is more than 5.0 recheck your
Thermocouple connections and make
sure 0.0°C is applied.)
4. The Cold-junction calibration on the
unit is semi-automatic. Press MENU to
activate the internal compensation. The
display ill begin to flash and
automatically adjust the offset reading
on the display to 0.0 (± 0.1)
OPERATION
2
15

This automatic cold junction calibration
should be all that is necessary to calibrate
the CJ offset, ho ever if you ant to
additionally adjust the offset manually, the
/MAX and /MIN buttons at this point
can be used to manually increase (/MAX)
or decrease (/MIN) the display 0.1° each
time /MAX or /MIN is pressed. After
each press allo several seconds to let the
display stabilize. Press MENU to save and
activate the calibration. (Meter ill briefly
display tor.)
The following menu items will only be
available with S4 installed.
CNFG CF=0 DEFAULT
CNFG cf=1,2 Functions not available
LINE 50H 60H 60H DEFAULT
CAL = For use only by qualified
personnel with accurate calibration
equipment.
OPERATION
2
16
