Omega OBO691GG User manual



OPERATINGANDINSTALLATIONINSTRUCTIONS
FOR


OBO691GG
M
2


2





































3

INSTALLATION,OPERATIONANDMAINTENANCEINSTRUCTIONS 
FOROMEGABUILT‐INELECTRICOVENRANGE
OBO691GGBUILT‐INELECTRICOVEN



CONGRATULATIONS

Thankyouforchoosingoneofourmanyfantasticbuiltinovens.Weareconfidentthatyouwillnowbe
abletomeetyourcookingneeds.Beforeyouusetheovenwestronglyrecommendthatyouread
thoughthewholeusermanualwhichprovidesthedescriptionofthisproductandtheproperuseofits
functions.
Toavoidtheever‐presentrisksinvolvedwithusinganelectricalapplianceitisvitalthattheovenis
installedcorrectlyandthatyoureadthesafetyinstructionscarefullytoavoidmisuseandhazards.Itis
importantthatyouretaintheseinstructionsandyourproofofpurchasealongwithanyotherimportant
documentsaboutthisproductforfuturereference.



CONTENTS


SECTION PAGENO.
ImportantSafetyInstructions………….. 4
ApplianceDetails………………………… 5
ElectricalConnections………………..…. 5‐6
Installation………………………………… 7‐8
OperatingInstructions…………………… 9‐14
Cleaning………………………………….. 15
Troubleshooting………………………….. 15
Transportation……………………………. 16
CookingGuides...….………………….…. 17‐18




DISPOSALINFORMATION

 Mostofthepackingmaterialsarerecyclable.Pleasedisposeofthosematerialsthroughyour
localrecyclingdepotorbyplacingtheminappropriatecollectioncontainers.
 Ifyouwishtodiscardthisproduct,pleasecontactyourlocalauthoritiesandaskforthe
correctmethodofdisposal.



4


IMPORTANTSAFETYINSTRUCTIONS
IMPORTANT:Readtheassemblyinstructionsectionandsafetyprecautionsofthisbookletcarefullybeforeremovingthe
contentsofthiscarton.
1. Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryormentalcapabilities,or
lackofexperienceorknowledge,unlesstheyhavebeengivensupervisionorinstructionconcerningtheuseoftheappliance
byapersonresponsiblefortheirsafety.Childrenshouldbesupervisedtoinsurethattheydonotplaywiththeappliance.
2. Incertaincircumstanceselectricalappliancesmaybeadangerhazard.
3. Donotplaceheavyobjectsinorontheseappliances,oruseforstorage,orletchildrenplayorswingfromthedoor.These
appliancesaredesignedforcookingfoodonly.
4. Thisapplianceisdesignedfordomestichouseholduseonlyandforthecookingofdomesticfoodproducts.Useasa
commercialappliancewillvoidthewarranty.Itshouldnottobeusedinamarineenvironmentoroutdoors.
5. Theovensaresuppliedwithasetofcablesforsinglephaseconnection.Thisisahighpoweredapplianceandisrequiredtobe
installedbyanauthorisedperson.
6. Iftheelectricalsupplycordisdamaged,eitherwhenbeinginstalledorafterinstallation,itmustbereplacedbythe
manufacturer,itsservicecentreorsimilarlyqualifiedpersonsinordertopreventahazard.
7. Theelectricalconnectionmustbeaccessibleafterinstallation.Theappliancemustbeelectricallyisolatedbeforeany
maintenancecanbeperformed,whichincludeschangingalamp.
8. Electricalconnectionmustbemadeasperlocalwiringrulesandregulations.Donotdisconnecttheappliancewithwethands
orbarefeet,anddonotdisconnectthepowercordwithextremeforce.
9. Alwaysgrasptheovendoorinthecentreofthehandleastheareasaroundthedooredgesmaybehotduetotheescapeofhot
air.
10. Ensurethatthekitcheniswellventilatedormechanicalventilationisinusewhilecookinginthisappliance.
11. Donotstoreoruseflammablematerialsoraerosolsneartheoven.Itemsmadefromaluminium,plasticorplasticfilm
shouldalsobekeptawayfromtheappliance,astheymayfusetothesurface.
12. Neverlinetheovenbottomwithaluminiumfoil,astheconsequentaccumulationofheatcouldcompromisethecookingand
evendamagetheenamel.
13. WARNING‐Theovenwillbecomehotduringanddirectlyafteruse.Donottouchanycomponentsduringthistime,astheymay
behotandcancauseburns.Donottouchtheheatingelementsinsidetheoventoavoidburns.Childrenshouldbekeptaway.
Useheatresistantcookinggloveswhere‐everpossiblewhenmovingfoodandcookingutensilsinandoutoftheoven.
14. Cleaningmayonlybecommencedontheapplianceonceithascooleddown(bestslightlywarm).Theapplianceshouldbe
disconnectedfromthepoweroutletorturnedoffatyourisolationswitchbeforecommencinganycleaningprocess.Donotuse
asteamjetoranyotherhighpressurecleaningequipmenttocleantheappliance.Followovencleanerdirectionsiftheseare
beingused.
15. Washallaccessoriesinhotsoapywaterorinadishwasher,wipedrywithapaperorclothtowel.Ifyouuseyourovenforan
extendedperiodoftime,condensationmayform.Dryitusingasoftdrycloth.
16. Whentheapplianceisnotbeingused,theknobsmustbekeptinthe‘OFF’position.
17. Wherethisapplianceisinstalledinacaravan,itshallNOTbeusedasaspaceheater.
18. Donotmodifythisappliance.
19. Donotuseharshabrasivecleanersorsharpmetalscraperstocleantheovendoorglassasitcanscratchthesurface,whichmay
resultintheglassshattering.Cleantheglassdoorusingwarmdampclothanddryitwithasoftcloth.
20. Allcabinetryandmaterialsusedintheinstallationmustbeabletowithstandaminimumtemperatureof50°Cabovethe
ambienttemperatureoftheroomitislocatedin,whilstinuse.Certaintypesofvinylorlaminatekitchenfurnitureare
particularlypronetoheatdamageordiscolourationattemperaturesoutsidetheguidelinesgivenabove.Anydamagecaused
bytheappliancebeinginstalledwithoutadheringtothetemperaturelimitssetoutabovewillbetheliabilityoftheowner.
21. Thisappliancemustbecorrectlyinstalledbyasuitablyqualifiedperson,strictlyinaccordancewiththemanufacturer’s
instructions.Pleaseseethespecificsectionofthisbookletthatreferstoinstallation.
22. Theappliancemustbeinstalledandputinoperationbyanauthorisedtechnicianundertheconditionsprovidedbythe
manufacturerinthismanual.Themanufacturercannotbeheldresponsibleforanydamagethatmightoccurduetofaulty
installation.
23. Thevaluesindicatedontheprinteddocumentsfoundontheproductarevaluesobtainedinlaboratoryenvironment
accordingtorelevantstandards.Thesevaluesmayvaryaccordingtotheusageandenvironmentconditionsofproduct.










5

APPLIANCEDETAILS

ELECTRICALDETAILS:

OVENS:OBO691GG
RatedVoltage: 220‐240Vac50Hz
MaxRatedInputs: 2400‐2800W
Thisinformationcanbefoundontheratingplate(datalabel)affixedtotheinsideofthedoorjamb.
SIZES:

RelevantSizes: LENGTH(mm) WIDTH(mm) HEIGHT(mm)
ExternalOvensize 595 575 595


ELECTRICALCONNECTIONS

LOCALAUTHORITYREQUIREMENTS
Installation is only permitted by a licensed electrician, and carried out according to instructions
provided by the manufacturer. Incorrect installation might cause harm and damage which the
manufactureracceptsnoresponsibility.
ELECTRICALINSTALLATIONFORTHELICENSEDELECTRICIAN
Thisovenmustbeconnectedtoa220‐240V50Hzpowersupply.Itisearthedviathecord.
Beforecarryingouttheconnectiontothepowersupply,thevoltageratingoftheappliance(stampedonthe
applianceidentificationplate)mustbecheckedforcorrespondencetotheavailablemainssupplyvoltage,andthe
mainselectricwiringshouldbesuitablefortheoven’spowerrating(alsoindicatedontheapplianceidentification
plate).Acircuitbreakerwithacontactopeningofatleast3mmmustbeinstalledinsidethesupplycircuit.
Theswitchedoutletmustbeconnectedtoasuitableearthwiring,inconformitytocurrentsafetyregulations.
Itshouldnotbelocatedabovetheapplianceandnomorethan1.25mawayfromit.Thepowersupplycordmust
nottouchagainstanyhotsurfacesandmustbeplacedsothatitstemperaturedoesnotexceed75°Catanypoint
alongitslength.
Afterhavinginstalledtheappliance,theswitchedoutletmustalwaysbeinanaccessibleposition.
NOTE:Forconnectionstothemainspowersupply,neveruseadapters,reductionsormultiplepowerpointsas
thesemayoverheatandcatchfire.
Themainsterminalblockislocatedonthebackoftheovenandtheterminalsareaccessiblebyopeningthe
terminalblockcover.Note:Theterminalcovershouldnotbeopenedwhenthemainspowerisstillconnectedto
theapplianceandneverbyanunauthorizedperson.

Theelectricalsafetyofthisappliancecanonlybeguaranteediftheoven
iscorrectlyandefficientlyearthed.Themanufacturerdeclinesall
responsibilityfordamageresultingfromaninstallationwhichhasnot
beenearthedcorrectly.
Theuseofadapters,multiplesocketsand/orextensions,isnotallowed.


6

OVENLAMPREPLACEMENT

 Theappliancemustfirstbedisconnectedfromthepoweroutletorturnedoffatyourisolationswitch.
 Unscrewtheglasscoverattachedtothelampholder;anti‐clockwise.
 Unscrewthelampandreplaceitwithanotherhigh‐temperaturelampwiththefollowingcharacteristics:

Type:E14

Voltage:AC220V‐240V
Wattage:25WTemperaturerating:300°
 Remounttheglasscoverandreconnecttheappliancetothepowersupply

NOTE:Shouldyouexperienceanydifficultypleasecontactyournearestafter‐salesservicecentre.





7
 





INSTALLATION


Theadjacentfurnituremust be able to withstand a minimumtemperatureriseof100°Cabovethe
ambient temperature of the room it is located in, during periods of use. The power supply to the
appliancemustbecutoffbeforeanyadjustmentsormaintenanceworkisdoneonit.

PREPARATIONFORINSTALLATIONANDUSE
Manufacturedwithbestqualitypartsandmaterials,thismodern,functionalandpracticalovenwillmeetyour
needsinallrespects.Makesuretoreadthemanualtoobtainsuccessfulresultssoasnottoexperienceany
problemsinthefuture.Theinformationgivenbelowcontainsrulesthatarenecessaryforcorrectpositioningand
serviceoperations.Theyshouldbereadwithoutfail,especiallybythetechnicianwhowillpositiontheappliance.

CHOOSINGAPLACEFORTHEAPPLIANCES
There are several points to pay attention to when choosing a place for your oven. Make sure to take into
accountourrecommendationsbelowinordertopreventanyproblemsanddangeroussituations,whichmight
occurlater!
Whenchoosingaplacefortheoven,attentionshouldbepaidthattherearenoflammableorcombustible
materialsintheclosevicinity,suchascurtains,oil,clothetc.whichquicklycatchfire.
Furnituresurroundingtheovenorcooktopmustbemadeofmaterialsresistanttotemperaturesabove100C°.
Requiredchangestowallcabinetsandexhaustfansaboveabuilt‐incooktopaswellasminimumheightsfromthe
ovenboardareshowninFigure1.Accordingly,theexhaustfanshouldbeataminimumheightof65cmfromthe
cooktop.Ifthereisnoexhaustfantheheightshouldnotbelessthan70cm.




8

INSTALLATIONOFBUILTINOVEN
Inserttheovenintocabinetpartlybypushingitforward.Opentheovendoorandinsert2screwsintotheholeson
theovenframe.Whiletheproductframetouchesthewoodensurfaceofthecabinet,tightenthescrews.If
installedunderacooktop,theremustbeatleast50mmbetweenthetwoappliances,andthedistancebetweenthe
worktopandthetopofthecontrolpanelmustbeaminimumof25mm.
Thedimensionsandmaterialofthecabinetinwhichtheovenwillbeinstalledmustbecorrectandresistantto
increasesintemperature.Inacorrectinstallation,contactwithelectricalorinsulatedpartsmustbeprevented.
Insulatingpartsneedtobefittedinawaytoensurethattheycannotberemovedbyusinganykindoftool.
Installingtheapplianceintheclosevicinityofarefrigeratororadeep‐freezerisnotrecommendedasthe
performanceoftheabove‐mentionedapplianceswillbenegativelyaffectedduetoemanatingheat.After
removingyourovenfromitspackaging,besurethattheovenisnotdamaged.Ifyoususpectanydamagetothe
appliance,donotuseit;immediatelycontactanauthorisedServiceCentre.




9
 

OPERATINGINSTRUCTIONS


INTERNALVIEWS:














01.ControlPanel. 05.OvenLamp.
02.OvenDoor. 06.WireGrill.
03.Handle. 07.ShallowTraywithgrillinsert.
04.GrillElement 08.80mmDeepTray.

Whenyoufirstrunyourovenacertainsmellwillbeemanatedarisingfromtheinsulationmaterialsandtheheater
elements.Forthisreason,beforeusingyouroven,runitemptyatmaximumtemperaturefor45minutes.Atthe
sametimeyouneedtoproperlyventilatetheenvironmentinwhichtheovenisinstalled.
Inordertocookinyouroven,theovenfunctionandtemperaturesettingcontrolsneedtobeadjustedandtheoven
timer,ifavailable,needstobeprogrammed.Otherwise,theovenwillnotoperate.
Unplugyourappliancewhenitisnotinuse.
Protectyourappliancefromatmosphericeffects.Donotleaveitundertheeffectsofthesun,rain,snow,dustetc.

7-8


  10 

CONTROLS











OVENFUNCTIONCONTROL
Theovenfunctioncontrolknobisusedtoselectthedifferentfunctions.Eachisexplainedindetail.Toselecta
function,turnthecontrolknobtothedesiredovenfunctionandthensetthetemperaturewiththethermostat
control.

OVENTHERMOSTATCONTROL
Theoventhermostatcontrolknobisusedtoselectthedesiredtemperatureforcooking.Whenthetemperature
insideyourovenreachesthevalueset,thethermostatwillcutthecircuitandthethermostatlightwillgooff.When
thetemperaturefallsbelowthesetvalue,thethermostatwillagainbeturnedonalongsidethethermostatlight.It
isnormalforthistooccurduringthecookingprocess,particularlywhenthedoorhasbeenopened.





11

OVENFUNCTIONCONTROLCHART





Duringheatedovenfunctionsacoolingfaninthetopoftheovenwilloperateinordertocooldowntheovendoor
andkitchencabinetaswellasreducingcondensationintheoven.Therewillthenbeaslightreleaseofwarmair
fromthetopoftheclosedovendoor.Thisisnotaleakinheatfromtheovencavity.

Theappliancecomeswith2designatedpositionsforthetelescopicrunnerstobeattached.Refertotheimage
below:



12

OVENFUNCTIONCONTROLS


DefrostFunction:




FanForcedFunction:
ThisFanForcedfunctionusestheturboheater(locatedinthebackoftheoven)toevenlydispersetheheatinthe
oven.Thisfunctionissuitableforcookingmultipledishesonvariousovenshelves.Adjustthefunctioncontrolknob
soitindicatestheFanForcedfunctionsymbol.Adjustthethermostatcontrolknobofyouroventoatemperature
recommendedonthecookingtableforthecookingoperationyouwishtoperform.
Preheatingoftheovenforabout10minutesisrecommended.Placethefoodinasuitablecontainer,thenplace
intoovenandcookfortherequiredtime.
Ifyouaregoingtocookusingtwotraysatthesametime,whileadjustingthecookingtemperature,selectthe
temperaturethatisthelowestamongthelevelssuitableforyourfoodofchoice,asshownonthetable.
Cookingwithtwotraysrequiresadditionalcookingtimecomparedtocookingwithonetray.Usually,thefoodon
eachtraydoesnotfinishatthesametimesoyoumayneedtotakethetrayofcookedfoodoutoftheoven,and
continuethecookingoperationfortheremainingtray.
Aftercooking,turnofftheovenfunctionandtemperaturecontrolknobsandcancelthetimerprogramifinuse.
Takethecookedfoodoutoftheovenandplaceitinasafeheatproofsurface.Astheovenwillbehot,worknear
withcautionandkeepchildrenawayfromthecoolingoven.


ConventionalCookingFunction

Thisfunction,ConventionalCooking,allowsheattoradiateevenlyfromthelowerandupperelementsintothe
ovenensuringevencookingofbothsidesofthefood.AdjustthefunctioncontrolsoitindicatestheConventional
Cookingfunctionsymbol.Adjustthethermostatcontrolknobofyouroventoatemperaturerecommendedonthe
cookingtableforthecookingoperationyouwishtoperform.Preheatingoftheovenforabout10minutesis
recommended.Placefoodinasuitablecontainer,thenplaceintoovenandcookfortherecommendedtime.This
functionispreferredformakingcakes(cupcakes,othercakesandsponges),biscuits,pastry,bakedpasta(e.g.
lasagne),casserolesandmoistdishes,roastsandovenchips.
Aftercooking,turnofftheovenfunctionandtemperaturecontrolknobsandcancelthetimerprogramifinuse.
Takethecookedfoodoutoftheovenandplaceitonasafeheatproofsurface.Astheovenwillbehot,workwith
cautionandkeepchildrenawayfromthecoolingoven.

Youcanstartthedefrostoperationbyputtingthefrozenfood
intoovenandbringingthefunctioncontrolknobtothe
indicatedmark.Thisfunctionwillnotcook/bakethefood;itonly
helpstodefrostitwithinashorttime.
Putthefoodtobedefrostedonthewirerackthatyouwillplace
onthemiddleracksupportfromthebottom(Figure13).To
collectthewaterthataccumulatesduetothemeltingice,insert
anoventrayontoalowerrack.Thisfunctionisperfectfor
finishingoffthedefrostprocessforfrozenfoodthathasbeenin
therefrigeratorfromtheeveningbeforeandmaynotbe
completelythawedout.


13

FanAssistFunction:

Thisisthefunctionwheretheaircomingfromthelowerandupperheatingelementsiscirculatedintotheovenby
thefanmotorandblade
AdjustthefunctioncontrolknobsoitindicatestheFanAssistFunctionsymbolandadjusttheoventimertothe
recommendedtimeforcooking.Adjustthethermostatcontrolknobtothetemperaturerequiredonthecooking
tablefortheFanAssistFunctionandpreheatovenfor10minutes.Basedontheconventionalcookingfunction,
thiscombinationoffeaturesincreasestheeffectivenessofthethermalradiationoftheheatingelementsthrough
forcedaircirculationoftheheatthroughouttheoven.Thishelpspreventfoodfromburningonthesurface,
allowingtheheattopenetrateintothefood.Foodbakedonthisfunctionsuchaspastryoftenbrownfasterthan
onconvectionfunctionalone.
Aftercooking,turnofftheovenfunctionandtemperaturecontrolknobsandcancelthetimerprogramifinuse.
Takethecookedfoodoutoftheovenandplaceitonasafeheatproofsurface.Astheovenwillbehot,workwith
cautionandkeepchildrenawayfromthecoolingoven.

GrillFunction:
Thisfunctionisusedforgrilling.AdjustthefunctioncontrolknobsoitindicatestheMid‐Grillfunctionsymboland
adjusttheoventimertotherecommendedtimeforcooking.Settheoven’sthermostatcontrolknobtothe
requiredtemperature.Afterapreheatingperiodof10minutes,putyourfoodintotheoven.Forgrilling,putthe
foodonthegrillrackandsitintothetray.Placethetrayononeofthehighestshelves.Placingtherackwithinthe
oventrayprovidedwillensurethatanymarinade,fatoroildroppingfromthefoodwillbecollected.Whengrilling,
theovendoormustbeclosed.Onthisfunction,themiddleheatingelements/coilsofthegrilloperate.
Thissettingisidealfortoastingbread,cheesemeltsandmeltingcheesetoppeddishesorfinishingoffadishto
lightlybrownonthesurface.Alsousedforherbandgarlicbread.
Aftercooking,turnofftheovenfunctionandtemperaturecontrolknobsandcancelthetimerprogramifinuse.
Takethecookedfoodoutoftheovenandplaceitinasafeheatproofsurface.Astheovenwillbehot,worknear
withcautionandkeepchildrenawayfromthecoolingoven.


Maxi‐GrillFunction:

Thisfunctionisusedforfastergrillingandforgrillswithalotoffood.Adjustthefunctioncontrolknobsoit
indicatestheMaxi‐Grillfunctionsymbol.Settheoven’sthermostatcontrolknobtotherequiredtemperature.
Afterapreheatingperiodof10minutes,putyourfoodintotheoven.Forgrilling,putthefoodonthegrillrackand
sitintothetray.Placethetrayononeofthehighestshelves.Placingtherackwithintheoventrayprovidedwill
ensurethatanymarinade,fatoroildroppingfromthefoodwillbecollected.Whengrilling,theovendoormustbe
closed.Onthisfunction,alloftheheatingelements/coilsofthegrilloperate.
Thehighergrilltemperatureandfunctionisidealforcookingandbrowningmeat(suchaslamborporkchopsand
cutlets),chickenandseafood(suchasfishfillets,cutlets,tunasteaksorAtlanticsalmon).Thissettingisalsogood
forbrowningfruitcrumblesorcrumbtoppeddishes.
Aftercooking,turnofftheovenfunctionandtemperaturecontrolknobsandcancelthetimerprogramifinuse.
Takethecookedfoodoutoftheovenandplaceitonasafeheatproofsurface.Astheovenwillbehot,workwith
cautionandkeepchildrenawayfromthecoolingoven.

ENERGYSAVING

Choosecookwareofanappropriatesize.Usingalidwillreducecookingtimes.
Minimizetheamountofliquidorfattoreducecookingtimes.
Ovendoorshouldnotbeopenedoftenduringcookingperiod


16

USINGTHEDIGITALTIMER
TimeofDayAdjustment:
Thetimemustbeadjustedbeforestartingtousetheoven.Followingpowersupplyto
theoven,thesymbol(A)andthethree“0”onthescreenwillbegintoflash.Pressthe
(+)and(‐)keyssimultaneously.TheCookingsymbol( )willappearonthescreen
andthedotinthemiddleofthescreenwillbegintoflash.Usingthe(+)and(‐)keys,
adjustthedays’timewhilethisdotisflashingbypressingeitherthe(+)or(‐)keys.
Aftertheadjustment,thedotwillremaincontinuouslylit.

KeyLock:
TheKeyLockonthetimerautomaticallyactivatesafter5secondsofinaction.Tounlockthetimerfunctions,press&hold
theModebuttonfor3seconds.

MinuteMinder:
Thisfunctioncanbeusedtoreceiveanaudiblewarningafterapre‐settime.Itisused
asareminder&doesnotaffectthecookingfunctions.
PresstheMODEkeyinthemiddle.Thetimersymbol( )andthree“0”swillflashon
thescreen.WhiletheTimersymbolisflashing,adjustthedesiredtimeperiod
(HH:MM)forthewarningbyusing(+)and(‐)keys.Shortlyafterthecompletionofthe
adjustment,theTimersymbolwillbelitcontinuouslyandthecurrentdays’timewillbe
displayed.WhentheTimersymbolbeginstolightcontinuously,theminuteminder
hasbeenset.
Theminutemindercanbesettoatimebetweenthetimerangeof0and23.59.
Whenthesettimeisup,thetimergivesanaudiblewarningandtheTimersymbolbeginstoflashonthescreen.Pressing
anykeywillstoptheaudiblewarningandtheTimersymboldisappearsfromthescreen.
Theovenwillnotbeturnedoffwiththisaudiblewarningfunction.
Thereare3differentauditablewarninglevelsavailable.Tochoosebetweenthem,startwiththetimershowingthetime
ofday.Pressthe“‐“(minus)buttonfor1‐2secondsandthetimerwillgiveanaudiblesignalbeep.Atthisstage,each
timethe“‐“buttonispressed,thetimerwillsoundthenextaudiblewarning(signalbeeps)inthesequence.Oncethe
desiredsoundisheard,donotpressanyfurtherbuttons,andthetimerwillsavethelastselectedsignalwarningsound.
Thisneedstoberesetintheeventofapowerfailure.

Semi‐AutomaticTimeAdjustmentAccordingtoCookingTime:
Thisfunctionisusedtocookforasetduration.Thefoodtobecookedisputinto
theovenandtheovenisadjustedwiththecontrolknobstothedesiredcooking
functionandtemperaturedependingonthefood/dishtobecooked.Nextkeep
pressingontheMODEbuttonuntil“dur”appearsonthetimerscreen.Whenyou
see“dur”onthetimerscreen,thesymbol(A)willbegintoflash.Adjustthecooking
timeforthefoodyouwishtocookbyusingthe(+)and(‐)keyswhilethetimerisin
thisposition.Shortlyaftertheadjustmentoperationiscompleted,thecurrent
days’timewillappearagainonthescreenandthesymbols(A)andCookingsymbol
willbecontinuouslylitonthescreen.Theovenwillcontinuetooperateonyour
chosenfunctionandthetimerwillbegin.Tocancelandreturntheoventomanual
operation,pressthe(+)and(‐)keysatthesametime.
Acookingtimebetween0and10hourscanbeset.Atthecompletionoftheprogrammedcookingtime,thetimerwill
stoptheovenoperationandgiveanaudiblewarning.Also,thesymbol(A)willbegintoflashonthescreen.Pressingany
buttonofthetimerwillendtheaudiblewarningandtheovenwillreturntoamanualusefunction.Thisfunctionis
perfectforsettingacookingtimeremainingforfoodthatisalreadycookingintheoven(e.g.–30minutes)priorto
leavingthehouseorgoingintothegardenasexamples.Whenthistimeisup,theovenwillstopoperatingandthe
internalovenlightwillgoout.Onlyafteradjustingtheovenfunctionandthermostatcontrolknobstotheiroff(0)
positionswilltheovenbefullyturnedoff.






15

Semi‐AutomaticProgrammingAccordingtoFinishTime:
Thisfunctionisusedtocookaccordingtodesiredfinishingtime.Thefoodto
becookedisputintotheovenandtheovenisadjustedtothedesired
cookingfunctionandtemperaturedependingonthefood/dishtobe
cooked.NextkeeppressingontheMODEbuttonuntil“end”appearsonthe
timerscreen.Whenthishappens,thesymbol(A)andthecurrentdays’time
willrespectivelybegintoflash.
Adjustthefinishingtimeforthefoodyouwishtocook,byusingthe(+)and
(‐)keyswhilethetimerisinthisposition.Shortlyaftertheadjustment
operationiscompleted,thecurrentdays’timewillappearagainonthe
screenandthesymbols(A)andCookingsymbolwillbecontinuouslyliton
thescreen.Theovenwillcontinuetooperateonyourchosenfunctionand
thetimerwillstart.

Youcansetanendtimeforupto10hoursinthefuture.Atthecompletionofthesetduration,thetimerwillstopthe
ovenandgiveaudiblewarning.Alsothesymbol(A)willbegintoflashonthescreen.Afteradjustingtheovenfunction
andthermostatcontrolknobstotheiroff(0)positions,pressinganybuttonofthetimerwillendtheaudiblewarningand
thetimerwillreturntoamanualusefunction.
Thisfunctionisperfectforsettingacookingcompletion“timeofday”forfoodthatisalreadycookingintheoven(e.g.–
Finishat5.00PM)priortoleavingthehouseorgoingintothegardenasexamples.Whenthistimeisuptheovenwill
stopoperatingandtheinternalovenlightwillgoout.Onlyafteradjustingtheovenfunctionandthermostatcontrol
knobstotheiroff(0)positionswilltheovenbefullyturnedoff.

Full‐AutomaticProgramming:
Thisfunctionisusedtocookforasetduration,startingafterapre‐setdelay.Thefoodtobecookedisputintotheoven
andtheovenisadjustedtothedesiredcookingfunctionandtemperaturedependingonthefood/dishtobecooked(the
ovenwillturnon).
FirstStep,CookingDuration:KeeppressingtheMODEbuttonuntil“dur”appearsonthetimerscreen.Whenyousee
“dur”onthetimerscreen,thesymbol(A)willbegintoflash.Adjustthecookingperiod/timeforthefoodyouwishto
cookbyusingthe(+)and(‐)keyswhilethetimerisinthisposition.Shortlyaftertheadjustmentoperationiscompleted,
thecurrentdays’timewillappearagainonthescreenandthesymbols(A)andCookingsymbolwillbecontinuouslyliton
thescreen(asforasemi‐automatictimeadjustmentaccordingtocookingperiod).
Acookingperiodbetweenthetimerangeof0and10hourscanbeset.

SecondStep,CookingEndTime:KeeppressingtheMODEbuttonuntil“end”appearsonthetimerscreen.Whenthis
happens,thesymbol(A)andtheendtime(currenttime+durationof0minutes)willrespectivelybegintoflash.Adjust
thefinishingtimeforthefoodtobecookedbyusingthe(+)and(‐)keyswhilethetimerisinthisposition.Theovenwill
nowturnoff(asastarttimedelayhasbeenset).Shortlyaftertheadjustmentoperationiscompleted,thecurrentdays’
timewillappearagainonthescreenandthesymbol(A)willbecontinuouslylightonthescreen.Themaximumtimethat
canbesetis23hours,59minutes.Itisrecommendedforfoodsafetythatperishablefoodisnotplacedintotheoven
morethan2hourspriortothestarttime.

Theovenstarttimecanbecalculatedbydeductingthecookingperiodfromthesetfinishingtime,andwillstopattheset
finishingtime.Thetimerwillgiveanaudiblewarningandthesymbol(A)willbegintoflash.Pressinganybuttonofthe
timerwillendtheaudiblewarningandtheovenwillreturntoamanualusefunction.
Thisfunctionisperfectforsettingacookingtimetobeginwhenyouarenotathomeoraroundtoturntheovenon.
Foodtobecookedisplacedintotheovenforexampleat3.00PMtobegincookingat4.00PMandtocompletecookingat
5.30PMbeforeyougethomeatsay6.00PM.Whenthistimeisuptheovenwillstopoperatingandtheinternaloven
lightwillgoout.Onlyafteradjustingtheovenfunctionandthermostatcontrolknobstotheiroff(0)positionswillthe
ovenbefullyturnedoff.









16

ACCESSORIES

Itisrecommendedthatyouusethecontainersindicateddependingonthefoodyouwillcookinyouroven.Youcan
alsouseglasscontainers,cakepansandspecialoventrayssuitableforuseinyouroven(availableinkitchenware
shops).Payattentiontotheinformationgivenbythesupplierforuseofthiscookware.Theinformationgiven
belowshouldbeimplementedforenamelledcontainers.

Ifthefoodtobecookeddoesnotcompletelycovertheoventray,ifthefoodistakenoutofthedeep‐freezerorif
thetrayisusedtocollectthedrippingjuicesofthefoodsduringthegrilloperation,deformationmightbe
observedonthetrayovertimeduetohightemperaturesformingduringthecooking/bakingoperation.Thisisa
normal,physicalstatethatresultsduringtheheattransfer.Donotleaveaglasstrayorcontainerinacold
environmentimmediatelyaftercookinginthem.Donotplacethemoncoldandwetsurfaces.Ensurethatthey
slowlycooloffbyplacingthemonadrypieceofclothorwoodenboard,otherwise,theglasstrayorcontainer
mightbreak.Ifyouaregoingtousethelargewireovenrack/grill,insertatrayintooneofthelowerracksto
collectfatoroil.Tomakecleaningeasier,addsomewaterintothistray.Inagrillingoperation,usetheshelfin
oneofthetoppositions.

Eachwiregridcomeswithabuilt‐insafetyfeaturetohelpminimisethembeingaccidentallypulledfullyout.This
comesinthewayofa“step”,positionedpart‐wayinfromtherearoftheaccessory.
Tofitthemintotheoven,pushthewiregridortraypartwayintotheovenuntilthestep“catches”,thenangle
thepartoverthestep&fullyinsert.Toremove,repeattheoperationinreverse.

















17

CLEANING

NOTE:Cleaningandmaintenanceoperationsmustonlybecarriedoutwhentheoveniscool.
Theapplianceshouldbedisconnectedfromthepoweroutletorturnedoffatyourisolationswitch
beforecommencinganycleaningprocess.

Cleaningtheovenexterior:
Beforestartingtocleanyouroven,besurethatallcontrolbuttonsareoffandyourappliancehascooledoff.Unplug
theappliance.
Donotusecleaningmaterialscontainingparticlesthatmightscratchtheenamelledandpaintedpartsofyouroven.
Usecreamcleanersorliquidcleaners,whichdonotcontainparticles.Asthesecleanersmaydamagethesurfaces,
donotusecausticcreams,abrasivecleaningpowders,roughwirewoolorhardtools.Intheeventofanyexcess
liquidsspillingoveryourovensurfaceduringcleaning,cleanupimmediatelysoastopreventpossibledamageto
theenamelormetalsurface.Donotusesteamcleanersforcleaningtheoven.
Cleaningtheinterioroftheoven:
Makesuretounplugtheovenbeforestartingtocleanit.Youwillobtainbestresultsifyoucleantheoveninterior
whiletheovenisslightlywarm(theovenshouldnotbeoperating).Removetheinternalwireshelvesbyunclipping
themfromthesides(thesecanbewashedinsoapywaterbutdonotuseadishwasher).Wipeyourovenwithasoft
pieceofcloth(e.g.dishcloth)dampenedwithwarmsoapywateraftereachuse,rinseclothinwarmwaterthen
wipeovenagainandthenfinishbywipingwithadrycloth.Foracompletecleaningprocess,usedryandpowder
typeovencleaners,followingtheovencleaningproduct’sinstructions.Re‐fitthewireshelves.

TROUBLESHOOTING

Iftheovendoesnotoperate:
 Theovenmaybeunpluggedfromthepowersourceorswitchedoffatthepowersource.
 Thehouseholdfusehasblownorhouseholdpowersupplyisoff.
 TheTimer(ifavailable)maynotsetcorrectly.

Iftheovendoesnotheat:
 Theheatmaynotbesetcorrectlywiththeoven’stemperaturesetting.

Iftheinteriorlightinglampdoesnotlight:
 Thelampsaredefective.Iftheyaredefective,youcanchangethemfollowingtheinstructionswithinthis
manual.

Cooking(iflower‐upperpartdoesnotcookequally):
 Controltheshelflocations,cookingperiodandheatvaluesaccordingtothemanual.

Unitsmokingwhenfirstused:
 Thisisaresultofprotectiveoilsbeingremovedandistobeexpectedwithafirstuse.

Ovenfanisstillrunningeventhoughknobsinoffposition:
 Thecoolingfanhasactivatedtocooldownthecontrol,thisisnormalandmaystayonforsometime.

ClockFlashingonDisplay
 Powerfailureorinterruption

Ifyouhaveanyfurtherproblemswithyourproduct,pleasecallyourAuthorisedServiceCentre.


18

TRANSPORTATION

Keeptheoriginalcartonoftheproductandusethispackagingiftheitemneedstobetransported.Followthe
transportsignsonthecarton.
Placeapaperbetweentheuppercoverandcookingpanel,covertheuppercover,thantapetothesidesurfaces
ofoven.
Tapecardboardorpaperontotheinsidefaceoftheglassasitwillbesusceptibletodamagefromthetrays.Use
cardboardcoversforthewiregrillandtraysinyouroven.Alsotapetheoven’scoverstothesidewalls.

Iftheoriginalcartonisunavailable,takemeasurestoprotecttheexternalsurfaces(glassandpaintedsurfaces)of
ovenagainstpossibleblows,aswellastheabove.


21

RECOMMENDEDCOOKINGTIMES



















































FOOD
LOWER‐UPPERHEAT–(Conventional) LOWER‐UPPERHEAT+FAN(FanAssist)
Thermostat
pos.(°c)
Rack
pos.
CookingPeriod
(min)
Thermostat
pos(°c)
Rack
pos. CookingPeriod(min)
SconesPlainorfruit 220 2‐3 10‐15 210 2‐3 10‐15
Cake‐Buttercake
(deep) 180 2‐3 40 170 2‐3 40
Cake‐Sponge 180 2‐3 25‐30 170 2‐3 25‐30
Cake–Cupcakes 180 2‐3 10‐15 170 2‐3 10‐15
Cookies–Chocchip 180 2‐3 15‐20 170 2‐3 15‐20
Biscuits‐Anzac 180 2‐3 15‐20 170 2‐3 15‐20
Brownie 180 2‐3 30‐40 170 2‐3 30‐40
BananaLoaf 180 2‐3 40‐50 170 2‐3 40‐50
Pavlova 110 2‐3 90 100 2‐3 90
Meringues‐Hard 110 2‐3 90 100 2‐3 90
Pastry(pre‐rolled
frozen) 190‐200 2‐3 20‐30 180‐190 2‐3 20‐30
Pastry‐Savoury
homemade 180‐200 2‐3 20‐30 170‐190 2‐3 20‐30
Pastry–Sweet
homemade 180‐190 2‐3 20‐30 170‐180 2‐3 20‐30
Pizza‐homemade 220 2‐3 10‐15 220 1 10‐15
Chips‐Ovenbaked 220 2‐3 30‐40 210 1 30‐40
FOOD
LOWER‐UPPERHEAT–(Conventional) LOWER‐UPPERHEAT+FAN(FanAssist)
Thermostat
pos.(°c)
Rack
pos.
CookingPeriod
(min)
Thermostat
pos(°c)
Rack
pos. CookingPeriod(min)
RoastPork 230+190 2‐3
20+45/50minper
kilo 220+180 2‐3 20+45/50minperkilo
RoastChicken 190‐200 2‐3 50‐60minperkilo 180‐190 2‐3 50‐60minperkilo
RoastBeef‐rare 190‐200 2‐3
15‐20minsper
500g 180‐190 2‐3 15‐20minsper500g
RoastBeef‐medium 190‐200 2‐3 25minsper500g 180‐190 2‐3 25minsper500g
RoastBeef‐welldone 190‐200 2‐3 30minsper500g 180‐190 2‐3 30minsper500g
RoastLamb‐medium 190‐200 2‐3 20minsper500g 180‐190 2‐3 20minsper500g
RoastLamb‐welldone 190‐200 2‐3 30minsper500g 180‐190 2‐3 30minsper500g
RoastTurkey 180 2‐3 40‐45minsperkilo 170 2‐3 4‐45minsper500g
RoastDuck 180‐200 2‐3
30‐35minsper
500g 170‐190 2‐3 30‐35minsper500g
RoastVeal–welldone 180 2‐3 30minsper500g 170 2‐3 30minsper500g
Bakedwholefish 180 2‐3 15‐20minperkilo 170 2‐3 15‐20minperkilo
Casserole/moistdishes 180 2‐3 60‐80mins 170 2‐3 60‐80mins
RoastPumpkin 220 2‐3
20‐40minsdepends
onsizeofpieces 200 2‐3
20‐40minsdependson
sizeofpieces


20


COOKINGGUIDES


 Foroptimumcookingkeepedgesofbakingdishesandpansatleast4cmfromthesidesoftheoven.This
allowsfreeheatcirculationandensuresevencooking.
 Wherepossibleremovelargecutsofmeat1kgoroverfromthefridge1hourpriortocooking.Allow,to
standcoveredandawayfromdirectsun/heat.Thisprocesswilltakethe“chill”ofthefridgeawayfromthe
foodandassistinmoreevencooking.


RoastingMeat,CookingChickenandFish

 Ideally,meatshouldbeatleast1Kgormorewhenroastinginordertopreventitfromdryingout.
 Whencookingwhitemeat,poultryandfish,usetemperaturesettings(180°C‐220°C).
 Forredmeatthatshouldbewelldoneontheoutsidewhiletenderandjuicyontheinside,itisagoodidea
tostartwith
ahightemperaturesetting(200°C‐220°C)forashorttime,thenturntheovendownafterwardsandfinish
off.
 When larger cuts of meat, poultry or fish have finished cooking, ideally remove the food from oven and
coverwithfoilandstandfor10‐20minutes(dependingonsize).Thiswillhelpretainthejuiceswhenthe
meatiscarved.
 Whencookinglargewholefish1kgorlargeitisrecommendedthatthefleshbescoredorslashed2‐3
timesoneithersidetoassistinmoreevencooking.Todothiscutintothethickfishfleshbehindthehead
throughtothebone.Thesescoredareasalsoallowyoutocheckeasilytoseeifthefishiscooked.
 Itisagoodideatoeithermeasuretheinsideofyourovenforwidthandeitherwritethisdowninbookyou
mayhavewithyouwhenshoppingoryoucancutapieceofstringtheovenwidththismakesiteasierto
knowifyourfishwillfitintotheoven.Lookscanbedeceivingandthefishlookssomuchbetterwholewith
itsheadandtail.Ifitdoesn’tfityouwillprobablyneedtoremovetheheadpriortobaking.
