Omega HH507 User manual

OMEGA
HH507
Digital Thermometer

OMEGAnetSM On-Line Service
http://www.omega.com
Internet e-mail
[email protected]
Servicing North America:
USA: ISO 9001 Certified Canada:
One Omega Drive, Box 4047 976 Bergar
Stamford, CT 06907-0047 Laval (Quebec) H7L5A1
Tel: [phone] Tel: [phone]
FAX: [phone] FAX: [phone]
e-mail: [email protected] e-mail: [email protected]
omega.com
TM
For immediate technical or application assistance:
USA and Canada: Mexico and Latin America:
Sales Service: 1-800-826-6342 / 1-800-TC-OMEGASM Tel: (95) 800-TC-OMEGASM
Customer Service: 1-800-622-2378 / 1-800-622-BESTSM FAX: [phone]
Engineering Service: 1-800-872-9436 / 1-800-USA-WHENSM En Español: [phone]
TELEX: 996404 EASYLINK: 62968934 CABLE: OMEGA e-mail: [email protected]
Servicing Europe:
Benelux: Germany/Austria:
Postbus 8034, 1180 LA Amstelveen, Daimlerstrasse 26, D-75392
The Netherlands Deckenpfronn, Germany
Tel: [phone] FAX: [phone] Tel: [phone] FAX: [phone]
Toll Free in Benelux: 06 0993344 Toll Free in Germany: 0800 82 66342
e-mail: [email protected] e-mail: [email protected]
Czech Republic: United Kingdom: ISO 9002 Certified
ul. Rude armady 1868, 733 01 Karvina- One Omega Drive
Hranice, Czech Repubic Riverbend Technology Centre Northbank, Irlam,
Tel: [phone] FAX: [phone] Manchester, M44 5EX, England
e-mail: [email protected] Tel: [phone] FAX: [phone]
France:
9, rue Denis Papin, 78190 Trappes Toll Free in England: 0800-488-488
Tel: [phone] FAX: [phone] e-mail: [email protected]
Toll Free in France: 0800-4-06342
e-mail: [email protected]
It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification
of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.
The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no liability for any errors it contains,
and reserves the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, patient connected application.

1
The symbol on the instrument indicates that the operator must refer to an
explanation in this manual.
WARNING
To avoid electrical shock, do not use this instrument when working
voltages at the measurement surface over 24V AC or DC.
WARNING
To avoid damage or burns, do not make temperature
measurement in microwave ovens.
CAUTION
Repeated sharp flexing can break the thermocouple leads. To prolong
lead life, avoid sharp bends in the leads, especially near the connector.
INTRODUCTION
This instrument is a 4½ digit, compact-sized portable digital thermometer
designed to use external K/J/T/E/R/S/N-type thermocouples as temperature
sensor.TemperatureindicationfollowsReferenceTemperature/VoltageTables
(N.I.S.T. Monograph 175 Revised to ITS-90) for K/J/T/E/R/S/N-type thermo-
couples. One K-type thermocouple are supplied with the thermometer.
SAFETY INFORMATION
Itisrecommendedthatyoureadthesafetyandoperationinstructionsbefore
using the thermometer.

2
SPECIFICATIONS
ELECTRICAL
Temperature Scale: Celsius or Fahrenheit user-selectable
Measurement Range:
Thermocouple Range
K-TYPE -200°C to 1372°C, -328°F to 2501°F
J-TYPE -210°C to 1050°C, -346°F to 1922°F
T-TYPE -200°C to 400°C, -328°F to 752°F
E-TYPE -210°C to 790°C, -346°F to 1454°F
R-TYPE 0°C to 1767°C, 32°F to 3212°F
S-TYPE 0°C to 1767°C, 32°F to 3212°F
N-TYPE -50°C to 1300°C, -58°F to 2372°F
Resolution:
K-TYPE 0.1°C, 0.1°F (0°F to 700°F)
0.2°F on other range
J-TYPE 0.1°C, 0.1°F (0°F to 500°F)
0.2°F on other range
T-TYPE 0.1°C, 0.1°F (0°F to 600°F)
0.2°F on other range
E-TYPE 0.1°C, 0.1°F (0°F to 450°F)
0.2°F on other range
R-TYPE 1°C , 1°F
S-TYPE 1°C , 1°F
N-TYPE 0.1°C , 0.2°F

3
Accuracy:Accuracyisspecifiedforoperatingtemperaturesovertherangeof
18°C to 28°C (64°F to 82°F), for 1 year, not including thermocouple error.
K/J/T/E-TYPE ±(0.05% rdg + 0.3°C) -50°C to 1370°C
±(0.05% rdg + 0.7°C) -50°C to -210°C
±(0.05% rdg + 0.6°F) -58°F to 2498°F
±(0.05% rdg + 1.4°F) -58°F to -346°F
N-TYPE ±(0.05% rdg + 0.7°C) -50°C to 0°C
±(0.05% rdg + 0.3°C) 0°C to 1300°C
±(0.05% rdg + 1.4°F) -58°F to 32°F
±(0.05% rdg + 0.6°F) 32°F to 2372°F
R/S-TYPE ±(0.05% rdg + 2°C) 0°C to 1767°C
±(0.05% rdg + 4°F) 32°F to 3212°F
Temperature Coefficient: 0.1 times the applicable accuracy specification
per°Cfrom0°Cto18°Cand28°Cto50°C(32°Fto64°Fand82°Fto122°F).
Input Protection: 24V dc or 24V ac rms maximum input voltage on any
combination of input pins.
Reading Rate: one time per second.
InputConnector:Acceptsstandardminiaturethermocoupleconnectors(flat
blades spaced 7.9mm, center to center).

4
ENVIRONMENTAL
Ambient Operating Ranges: 0°C to 50°C (32°F to 122°F) <80% R.H.
Storage Temperature: -20°C to 60°C (-4°F to 140°F) <70% R.H.
GENERAL
Display:4½digitliquidcrystaldisplay(LCD)withmaximumreadingof9999.9.
Overload: "----.-" is display.
Battery: Standard 9V battery.
Battery Life: 100 hours typical with carbon zinc battery.
Auto power off: The meter key switch inactive for more than 30 minutes,
press power key to resume operation.
Dimensions: 192mm(H) x 91mm(W) x 52.5mm(D).
Weight: 365g.

5
OPERATING INSTRUCTIONS
Power Switch
The key turns the thermometer on or off. In the MIN MAX record mode
can not power off, must leave MIN MAX record mode then power off.
°C/°F Selecting the Temperature Scale
Readings are dual displayed in either degrees Celsius(°C) or degrees
Fahrenheit(°F). When the thermometer is turned on, it is set to the
temperature scale that was in use when the thermometer was last turned
off. To change the temperature scale, press the °C/°F key.
HOLD Mode (only Main display)
Pressing the HOLD key to enter the Data Hold mode, the "HOLD" annun-
ciator is displayed. When HOLD mode is selected, the thermometer held
the present readings and stops all further measurements.
PressingtheHOLDkeyagaintocancelHOLDmodecausing thermometer
to resume taking measurements.
In the MIN/MAX recording mode, press HOLD key to stop the recording.
Press HOLD key again to resume recording. (Previously recorded reading
are not erased).
2
3
1

6
TIMER STOP-WATCH Mode
Press TIMER STOP-W key to enter stop-watch mode stop-watch is
displayedinseconddisplay.Pressstart/stopkeytotogglestop-watchstarts
and stops (Time goes up to 99 minutes & 59.9 seconds). In the this mode
the automatic power-off feature is disabled.
Pess Clear key to zero the stop-watch.
Press TIMER STOP-W key again to exit the stop-watch mode.
K/J/T/E/R/S/N T1 Input Thermocouple Type Select (Main
display)
The TYPE key circulating selects the K/J/T/E/R/S/N type thermocouple as
input.
When the thermometer is turned on, it is set to the type selected that was
in use when the thermometer was last turned off.
MIN MAX with Time record Mode (only Main display)
Press MIN MAX key to enter the MIN MAX Recording mode, (displays the
Maximum reading with time, Minimum reading with time and Average
reading stored in record mode). In the this mode the automatic power-off
feature is disabled and key, °C/°F key, REL key, SET key, Hi/Lo Limits
key and TYPE key are disabled.
The beeper emits a tone when a new minimum or maximum value is
recorded.
5
6
4

7
Push MIN MAX key to cycle through the Max/Min/Avg/Present readings.
If an overload is recorded, the averaging function is stopped and average
value display"----.-".
The true average of all the reading taken over at least 22 hours preiod can
be displayed. If 22 hours is exceeded, new averages are no longer
calculated.Thelastcalcalatedvalueisretainedastheaveragereading,but
the actual minimum and maximum reading will continue to be captured.
In the this mode, press HOLD key to stop the recording of readings, all
values are frozen, press again to restart recording.
TopreventaccidentallossofMIN,MAXandAVGdata,inthismodecanonly
becancelledbypressingand holddowntheMINMAXkeyfor2secondsto
exit and erased recorded readings.
REL Relative mode (only Main display)
Pressing REL key to enter the Relative mode, zero the display, and store
the displayed Reading as a reference value and annunciator REL is
displayed. Press REL key again to exit the relative mode.
The relative value can also be entered by the user. (See "SET mode" later
in this manual.)
WhenthedesiredRelativevaluehasbeenentered,pressRELkeytoenter
the Relative mode, press SET key use set Relative value as a reference
value. Press REL key again to exit the relative mode.
In the Relative mode, the value (can not >±3000.0 counts) shown on the
LCDisalwaysthedifferencebetweenthestoredreferenceandthepresent
reading.
7

Hi/Lo LIMITS mode (only Main display)
Press Hi/Lo LIMITS key to enter the Hi/Lo Limits comparative mode,
"LIMIT" is displayed. In the this mode the automatic power-off feature is
disabled and REL key, HOLD key, MAX/MIN key are disabled, when input
temperaturevalueexceedHi.Thebeeperemitsacontinuitypulsetoneand
"Hi" is displayed, and when input temperature value exceed Lo value. The
beeperemitsadiscontinuouspulsetoneand"Lo"isdisplayed.PressHi/Lo
LIMIT key again to exit the Hi/Lo LIMIT mode.
SET mode (Relative value set, Time set and Hi/Lo Limits value
set and Time set)
1. Press SET key to enter Relative valuse SET mode (Press ENTER key can
escape relative valuse set mode), REL set mode. = = = =.= is displayed in
maindisplay.Relativevalueisenteredviaoverlaynumbers,whenyouwant
togetnegativevaluespush(-0)keyforendofnumbers,thenpressoverlay
ENTER key, stored the relative value, enter Hi/Lo Limits value set mode.
2. Hi Limit value set mode, (Press ENTER key can escape Hi Limit value set
mode), = = = =.= is displayed in main display, Hi Limit value is entered via
overlay numbers, when you want to get negative values push (- 0) key for
endofnumbers,then press overlay ENTER key, storedthe HiLimitvalue,
enterLoLimitvaluesetmode(Press ENTERkeycanescapeLoLimitvalue
set mode), = = = =.= is displayed in main display, Lo Limit value is entered
via overlay numbers, when you want to get negative values push (- 0) key
for end of numbers, then press overlay ENTER key, stored the Lo Limit
value, enter Time set mode.
8
9
8

3. Time set mode, (Press ENTER key can escape Time set mode) = = : = =
= = is displayed in third display. Time (hours, minutes, seconds) value is
entered via overlay numbers, then press overlay ENTER key. Time start
from set time value and exit set mode.
Relative value Recall display mode
PressRELRECALLkeytodisplaytheRelativesetvalueonseconddisplay.
Press REL RECALL key again to exit this mode.
Hi/Lo Limits value Recall display mode
PressHi/LoRECALLkeytodisplaytheHisetLimitvalueonseconddisplay.
PressHi/LoRECALLkeyagaintodisplaytheLoLimitssetvalueonsecond
display. Press Hi/Lo RECALL key again to exit this mode.
"" Button
Press" "button totoggle onandoffofbacklight. Thebacklightwillswitch-
off automatically after 60 seconds.
9
10
11
12

10
OPERATOR MAINTENANCE
WARNING
To avoid possible electrical shock, disconnect the thermocouple
connectors from the thermometer before removing the cover.
Battery Replacement
Powerissuppliedbya9volt"transistor"battery.The" "appearsontheLCD
display when replacement is needed. To replace the battery, remove the two
screws from the back of the meter and lift off the battery cover. Remove the
battery from battery contacts.

1
HH 506(R)/HH 507(R) CALIBRATION PROCEDURE
Note: The following calibration procedure should perform only by qualified technicians
who have access to the items as following.
Equipment: The class of calibrator had better 10 times greater than the measured meter.
1. Set the jumper position on J1 position.
2. Input DCV 17mV to the T1 after the display is stabilized (forward 4 digits), then
press “ HOLD “ key and "0.0" is displayed in main display.
3. Input DCV 60mV after the display is stabilized (first 4 digits), then press
“ HOLD “ key and "0.1" is displayed in main display.
4. Input 0°C (K-type) after the display is stabilized (first 4 digits), then press
“ HOLD “ key and "0.2" is displayed in main display.
5. Don't push any key and the meter will turn off automatically after 20 seconds.
6. After adjustment set the jumper back to J3 position.
7. Turn on the meter then input 0°C (K-type). The display reading reads 0°C if
the calibration procedure is right.

WARRANTY / DISCLAIMER
OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months
from date of purchase. OMEGA Warranty adds an additional one (1) month grace period to the normal one (1) year product
warranty tocoverhandlingandshipping time.Thisensuresthat OMEGA'scustomers receivemaximumcoverage oneach product.If
the unit should malfunction, it must be returned to the factory for evaluation.OMEGA's Customer Service Department will issue an
Authorized Return (AR) number immediately upon phone or written request.Upon examination by OMEGA, if the unit is found to
be defective it will be repaired or replaced at no charge.OMEGA'sWARRANTY does not apply to defects resulting from any action
of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair,
orunauthorizedmodification.ThisWARRANTY isVOIDif the unit showsevidenceofhaving been tampered withor showsevidence
of being damaged as a result of excessive corrosion;or current, heat moisture or vibration; improper specification;misapplication;
misuse or other operating conditions outside of OMEGA's control.Components which wear are not warranted, including but not
limited to contact points, fuses, and triacs.
OMEGA is pleased to offer suggestions on the use of its various products.However,OMEGA neither assumes responsibility
for any omissions or errors nor assumes liability for any damages that result from the use of its products in accordance
with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by it
will be as specified and free of defects.OMEGA MAKES NO OTHERWARRANTIES OR REPRESENTATIONS OF ANY KIND
WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE AND ALL IMPLIED WARRANTIES INCLUDING ANY
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED.
LIMITATION OF LIABILITY:The remedies of purchaser set forth herein are exclusive and the total liability of OMEGA with
respect to this order,whether based on contract, warranty,negligence, indemnification, strict liability or otherwise, shall
not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for
consequential, incidental or special damages.
CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used:(1) as a "Basic Component" under 10
CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any
Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way,
OMEGA assumes no responsibility as set forth in our basicWARRANTY / DISCLAIMER language, and additionally, purchaser will
indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in
such a manner.
RETURN REQUESTS / INQUIRIES
Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY
PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA'S
CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS).The assigned AR number should then
be marked on the outside of the return package and on any correspondence.
The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.
FOR WARRANTY RETURNS, please have the following
information available BEFORE contacting OMEGA:
1. P.O. number under which the product was PURCHASED.
2. Model and serial number of the product under warranty, and
3. Repair instructions and/or specific problems relative to the
product.
FOR NON-WARRANTY REPAIRS, consult OMEGA for
current repair charges.Have the following information
available BEFORE contacting OMEGA:
1. P.O. number to cover the COST of the repair.
2. Model and serial number of product , and
3. Repair instructions and/or specific problems relative to the
product.
OMEGA's policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest
in technology and engineering. OMEGA is a registered trademark of OMEGA ENGINEERING, INC. © Copyright 1999 OMEGA ENGINEERING,
INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or
machine-readable from, in whole or in part, without prior written consent of OMEGA ENGINEERING, INC.

M-2813/0799
Where Do I Find Everything I Need for
Process Measurement and Control?
OMEGA...Of Course!
TEMPERATURE
þThermocouple, RTD & Thermistor
Probes, Connectors, Panels & Assemblies
þWire: Thermocouple, RTD & Thermistor
þCalibrators & Ice Point References
þRecorders, Controllers & Process Monitors
þInfrared Pyrometers
PRESSURE/STRAIN AND FORCE
þTransducers & Strain Gauges
þLoad Cells & Pressure Gauges
þDisplacement Transducers
þInstrumentation & Accessories
FLOW/LEVEL
þRotameters, Gas Mass Flowmeters
& Flow Computers
þAir Velocity Indicators
þTurbine/Paddlewheel Systems
þTotalizers & Batch Controllers
pH/CONDUCTIVITY
þpH Electrodes, Testers & Accessories
þBenchtop/Laboratory Meters
þControllers, Calibrators, Simulators
& Pumps
þIndustrial pH & Conductivity Equipment
DATA ACQUISITION
þData Acquisition &
Engineering Software
þCommunications-Based
Acquisition Systems
þPlug-in Cards for Apple, IBM
& Compatibles
þDatalogging Systems
þRecorders, Printers & Plotters
HEATERS
þHeating Cable
þCartridge & Strip Heaters
þImmersion & Band Heaters
þFlexible Heaters
þLaboratory Heaters
ENVIRONMENTAL
MONITORING AND CONTROL
þMetering & Control Instrumentation
þRefractometers
þPumps & Tubing
þAir, Soil & Water Monitors
þIndustrial Water & Wastewater
Treatment
þpH, Conductivity & Dissolved Oxygen
Instruments
