Omega HX93B Series User manual

HX93B SERIES
Temperature/Relative
Humidity Transmitters
HX93B(*)
HX93BD WALL MOUNT HX93BD(*)-D DUCT MOUNT
EASY M12
CONNECTION
TH-RP remote
probe with 3 m
(10') cable and
M12 connector.
TM
User’s Guide
Shop online
at
omega.com
e-mail: [e-mail]
For the latest product
manuals:
www.omega.com/en-
us/pdf-manuals

The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves
the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, human applications.
Patented: Covered by U.S. and International Patents and Patents Pending.
omega.com [email protected]
Omega Engineering, Inc:
800 Connecticut Ave. Suite 5N01, Norwalk, CT 06854, USA
Toll-Free: 1-800-826-6342 (USA & Canada only)
C
ustomer Service: 1-800-622-2378 (USA & Canada only)
Engineering Service: 1-800-872-9436 (USA & Canada only)
Tel: [phone]
e-mail: [email protected]
Fax: [phone]
Omega Engineering,
Limited:
1 Omega Drive, Northbank,
Irlam Manchester M44 5BD
United Kingdom
Omega Engineering,
GmbH:
Daimlerstrasse 26 75392
Deckenpfronn Germany

Table of Contents
Section Page
1. General Description ............................................................................... 1-1
2. Unpacking ............................................................................................... 2-1
3. Electrical Connection and
Temperature Measuring Range Selection .................................... 3-1
3.1 Electrical Connection ....................................................................... 3-1
3-2 Temperature Measuring Range Selection .................................... 3-1
4. Mounting ................................................................................................. 4-1
5. Temperature Output Calculations ...................................................... 5-1
6. Relative Humidity Output Calculations ............................................ 6-1
7. Calibration ............................................................................................... 7-1
8. Maintenance ............................................................................................ 8-1
9. Specications .......................................................................................... 9-1
i
HX93B Temperature/Relative Humidity Transmitters

HX93B Temperature/Relative Humidity Transmitters
List of Figures
Figure Description Page
Figure 1-1 Transmitter Internal Diagram ...................................................... 1-1
Figure 3-1 Electrical Connection Diagram .................................................... 3-1
Figure 3-2 Temperature Measuring Range Selection Diagram ................ 3-1
Figure 4-1 Wall Mount Model Dimensions................................................... 4-1
Figure 4-2 Duct Mount Model Dimensions .................................................. 4-2
Figure 4-3 Remote Probe Model Dimensions ............................................... 4-2
Figure 8-1 Sensor Probe Replacement ........................................................... 8-1
ii

Section 1 - General Description
The OMEGA®HX93B and HX93BD Series Temperature/Relative Humidity
Transmitters provides a linearized and temperature compensated output signal
of 4 to 20mA, 0 to 1 Vdc, 0 to 5 Vdc or 0 to 10 Vdc depending upon the model
selected for both temperature/relative humidity measurement. The output
signals have been calibrated and scaled –30ºC to 75ºC for temperature and 0
to 100% for relative humidity. The digital temperature and relative humidity
sensorisprotectedbyastainlesssteellterthatiseasilyremovedforcleaning.
The NEMA rated polycarbonate enclosure and cable entry connection provides
weathertight protection. Screws are provided for mounting via internal holes
inside the enclosure.
The HX93BD Series has a dual display with backlit to display both Temperature
and Relative Humidity readings. An on-board slide switch allows the user to
changethetemperaturereadingfrom°Cto°Fasshowningure1-1below.
Figure 1-1. Transmitter Internal Diagram
Most of the models come with a replaceable sensor probe; the process of
replacing the sensor probe is very simple using an M12 connector. See the
“Maintenance” section for details.
The models with a replaceable Sensor Probe are:
HX93BDC, HX93BDV0, HX93BDV1, HX93BDV2, HX93BDC-RP1, HX93BDV0-
RP1, HX93BDV1-RP1, HX93BDV2-RP1, HX93BC, HX93BV0, HX93BV1,
HX93BV2, HX93BC-RP1, HX93BV0-RP1, HX93BV1-RP1, HX93BV2-RP1.
The models without a replaceable sensor probe are:
HX93BDC- D, HX93BDV0-D, HX93BDV1-D, HX93BDV2-D, HX93BC-D,
HX93BV0-D, HX93BV1-D, HX93BV2-D.
1-1
General Description 1
LCD DISPLAY
CONNECTOR
DIGITAL SENSOR
CONNECTOR
DEGREE F/
DEGREE C
SELECTION SLIDE
SWITCH (SW1)
8-PIN M12
CONNECTOR
FOR DIGITAL
SENSOR PROBE
EXTERNAL CONNECTION
TERMINAL BLOCK
(TB1)
F
J5
C
1
3
J4

2-1
Unpacking
2
Section - 2 Unpacking
Remove the packing list and verify that you have received all your equipment.
If you have any questions about the shipment, please call our Customer Service
Department at
1-800-622-2378or203-359-1660.Onthewebyoucanndusat:
www.omega.com e-mail: [email protected]
When you receive the shipment, inspect the container and equipment for any
signs of damage. Note any evidence of rough handling in transit. Immediately
report any damage to the shipping agent.
The carrier will not honor any damage claims unless all shipping
material is saved for inspection. After examining and removing
contents, save packing material and carton in the event reshipment is
necessary.
The following items are supplied in the box with your HX93B Series transmitter.
• HX93BSeriesQuickStartManual,MQS5340(1ea.)
• #6WallAnchorand#6MountingScrew(2ea.)
• DewpointCard(1ea.)
NOTE:

2-2
2.1 HX93B available models and functional description
Model number Description
HX93BDC Digital Display Wall Mount Temperature/Relative Humidity Transmitter, 4 to 20mA.
HX93BDV0 Digital Display Wall Mount Temperature/Relative Humidity Transmitter, 0 to 1 volt.
HX93BDV1 Digital Display Wall Mount Temperature/Relative Humidity Transmitter, 0 to 5 volt.
HX93BDV2 Digital Display Wall Mount Temperature/Relative Humidity Transmitter, 0 to 10 volt.
HX93BDC-D Digital Display Duct Mount Temperature/Relative Humidity Transmitter, 4 to 20mA.
HX93BDV0-D Digital Display Duct Mount Temperature/Relative Humidity Transmitter, 0 to 1 volt.
HX93BDV1-D Digital Display Duct Mount Temperature/Relative Humidity Transmitter, 0 to 5 volt.
HX93BDV2-D Digital Display Duct Mount Temperature/Relative Humidity Transmitter, 0 to 10 volt.
HX93BDC-RP1 Digital Display Remote Probe Temperature/Relative Humidity Transmitter, 4 to
20mA Output with 3 m (10') cable.
HX93BDV0-RP1 Digital Display Remote Probe Temperature/Relative Humidity Transmitter,
0 to 1 volt output with 3 m (10') cable.
HX93BDV1-RP1 Digital Display Remote Probe Temperature/Relative Humidity Transmitter,
0 to 5 volt out put with 3 m (10') cable.
HX93BDV2-RP1 Digital Display Remote Probe Temperature/Relative Humidity Transmitter,
0 to 10 volt output with 3 m (10') cable.
HX93BC Wall Mount Temperature/Relative Humidity Transmitter, 4 to 20mA.
HX93BV0 Wall Mount Temperature/Relative Humidity Transmitter, 0 to 1 volt.
HX93BV1 Wall Mount Temperature/Relative Humidity Transmitter, 0 to 5 volt.
HX93BV2 Wall Mount Temperature/Relative Humidity Transmitter, 0 to 10 volt.
HX93BC-D Duct Mount Temperature/Relative Humidity Transmitter, 4 to 20mA.
HX93BV0-D Duct Mount Temperature/Relative Humidity Transmitter, 0 to 1 volt.
HX93BV1-D Duct Mount Temperature/Relative Humidity Transmitter, 0 to 5 volt.
HX93BV2-D Duct Mount Temperature/Relative Humidity Transmitter, 0 to 10 volt.
HX93BC-RP1 Remote Probe Temperature/Relative Humidity Transmitter, 4 to 20mA output with 3m (10') cable .
HX93BV0-RP1
Remote Probe Temperature/Relative Humidity Transmitter, 4 to 20mA output with 3m (10') cable .
HX93BV1-RP1
Remote Probe Temperature/Relative Humidity Transmitter, 4 to 20mA output with 3m (10') cable .
HX93BV2-RP1
Remote Probe Temperature/Relative Humidity Transmitter, 4 to 20mA output with 3m (10') cable
TH-RP Field replaceable remote probe with 3 m (10') cable and M12 connector.
TH-SP Field replaceable 71.88 L mm (2.83") short probe with M12 connector.
HX92-CAL Calibration Kit and 75% relative humidity standards.
IND-KIT Spare duct mount kit for HX93B(*)-D,HX93B(*)-RP1, HX93BD(*)-D, HX93BD(*)-RP1
Unpacking 2

Section 3 – Electrical Connection and Temperature Measuring
Range Selection
All electrical connections and wiring should be performed by a
suitably trained professional only.
3.1 Electrical Connection
Followtheelectricalconnectiondiagramshowningure3-1belowtosetup
your Temperature/Relative Humidity Transmitter.
Figure 3-1 Electrical Connection Diagram
3.2 Temperature Measuring Range Selection:
ThetemperaturemeasuringrangeoftheHX93Bcanbemodiedbymaking
a minor change to a connector J4. The standard temperature measuring range
is -30 to 75°C (-22 to 167°F) without adding any jumper on connector J4. If
you would like to change the range to -20 to 75°C (-4 to 167°F), add a jumper
on connector J4 pin 1 to pin 2. See the diagram below for the location of the
connector and its pins.
Figure 3-2 Temperature Measuring Range Selection Diagram
3-1
Electrical Connection and
Temperature Measuring Range Selection
3
POWER IN
R/H OUTPUT
TEMPERATURE OUTPUT
GND
GND
CHASSIS
1
2
3
4
5
6
+
+
–
–
+
–
POWER SUPPLY
9-30 VDC
(12-30 VDC FOR
0-10 VDC OUTPUT)
4-20 mA
0-1 VDC
0-5 VDC
0-10 VDC
TB1
INTERNALLY
CONNECTED
TEMPERATURE MEASURING
RANGE SELECTION
CONNECTOR
8-PIN M12 CONNECTOR
FOR DIGITAL SENSOR PROBE
1
3
J4
°F
°C
J5
NOTE:

Section 4 - Mounting
The HX93B and HX93BD series transmitters are designed for wall, duct or
remote probe mounting depending upon the model. Plastic wall anchors and
mounting screws are included for wall mounting and remote probe models. A
duct mounting kit is included with duct mount models.
Seegure4-1,gure4-2andgure4-3forthewallmount,ductmountand
remote probe model dimension for your mounting reference.
Figure 4-1 Wall Mount Model Dimensions
4-1
Mounting 4
MOUNTING HOLES
Ø4.57 (0.18)
TYP. 4 PLACES
DIMENSIONS mm (in)
50.0
(1.97)
80.0
(3.15)
78.2
(3.08)
70.1
(2.76)
82.3
(3.24)

Figure 4-2 Duct Mount Model Dimensions
Figure 4-3 Remote Probe Model Dimensions
Mounting
4
4-2
82.3
(3.24)
48.3
(1.90)
27.9
(1.1)
Ø17.3
(Ø0.68)
FLEXIBLE CABLE
2.9 m (9.5')
54.1
(2.13)
254
(10')
127.3
(5.01)
80.0
(3.15)
DIMENSIONS mm (in)
43.8
24.2 °C
%RH
55.6
(2.19)
128.0
(5.04) Ø15.7
(Ø0.63)
82.3
(3.24)
23.11
(0.91)
19.05
(0.75)
80.0
(3.15)
DIMENSIONS mm (in)
