Omnimount Lift30 User manual

1 of 14
888-61-054-W-00 rev. E • 10/13
User's Guide
OM1100604
Lift30
User's Guide - English
Guía del usuario - Español
Manuel de l’utilisateur - Français
Gebruikersgids - Nederlands
Benutzerhandbuch - Deutsch
Guida per l’utente - Italiano
Användarhandbok - svenska
ユーザーガイド: 日本語
用户指南 : 汉语
www.omnimount.com
ENGLISH
Table of Contents
TV/Display Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Safety Hazard Symbol Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Determine mounting location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Mount Glide to wall:
OptionA: wood stud walls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Option B: solid concrete walls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Attach TV/Display to Glide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
OptionA: no VESAadapter needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Option B, C, D: with VESAadapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Quick Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Test Range of Motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Adjust according to applied load and desired user force . . . . . . . . . . . . . . . . . . . . .13
Screen Capacity Lift Rotation VESA
27”- 42” 12 - 30 lbs
(5.5 - 13.6 kg) ≥10” (25.4mm) Yes 100 x 100 100 x 200
200 x 200
200 x 100
300 x 300
400 x 400

2 of 14
888-61-054-W-00 rev. E • 10/13
M4 x 15mm
M6 x 15mm
M5x 15mm
M8x 15mm
M4 x 30mm
M6 x 30mm
M5 x 30mm
M8 x 30mm
4x
4x
4x
4x
4x
4x
4x
4x
4x1x 1x
M6-M8
x 5mm
spacer
M6-M8
x 10mm
spacer
M4-M5
washer M6-M8 washer
4x 4x 4x 4x
M8M5 kit
4x
M8M5 Converter
Conversor M8M5
Convertisseur M8M5
M8M5-Konverter
M8M5 Convertor
Convertitore M8M5
M8M5 konverterare
M8M5サイズ変換ネジ
M8M5 转接件
M5 x 20mm
4x
2x 2x
M8 anchorM6 x 70mm
8x M4 x 6mm
ENGLISH
Components
These symbols alert users of a safety condition
that demands attention.All users should be able
to recognize and understand the significance of
the following Safety Hazards if encountered on the
product or within the documentation. Children who
are not able to recognize and respond appropriately
to SafetyAlerts should not use this product without
adult supervision!
Hazard Symbols
Review Symbol Signal Word Level of Hazard
NOTE A NOTE indicates important information that helps you
make better use of this product.
CAUTION
A CAUTION indicates either potential damage to
hardware or loss of data and tells you how to avoid the
problem.
WARNING A WARNING indicates either potential for property dam-
age, personal injury, or death.
ELECTRICAL
An Electrical indicates an impending electrical hazard
which, if not avoided, may result in personal injury, re
and/or death.

3 of 14
888-61-054-W-00 rev. E • 10/13
3/8”1/8”
3/8” 9.5-10mm
1/8” 3.2mm
3-1/8”
80mm
3-1/8”
80mm
10 mm
ENGLISH
Tools Needed

4 of 14
888-61-054-W-00 rev. E • 10/13
1
2.5”
(66mm)
7.3”
(184mm)
2.8”
(72mm)
ENGLISH
Lift range of motion
at highest position
Lift range of motion
at lowest position
Determine mounting location.
CAUTION: Before proceeding with this installation consult your TV/large display product guide for
manufacturer recommendations on choosing a mounting location that will ensure optimum TV/large
display performance. Location considerations might include: TV/large display height and viewing
angle - based on height and distance of seating, room dimensions and size of TV/large display; access
to power outlets; cable connections for speakers and other devices; protection from glare and heat,
(windows, lamps, replace, air ducts) and vibration.
Locate the wall mount bracket on the wall using the dimensions below, as a guide.
Wall mount bracket

5 of 14
888-61-054-W-00 rev. E • 10/13
2
a
d
e
bc
M6 x 70mm
2x
1/8”
1/8” 3.2mm
80mm
3-1/8”
10mm
ENGLISH
Mount bracket to wall
OptionA: wood stud walls
NOTE: make sure extension bracket is
level before tightening bolts. Go to Step
3 on the page 7.

6 of 14
888-61-054-W-00 rev. E • 10/13
abc
d
e123
3/8”
3/8” 9.5-10mm
3-1/8”
80mm
2
10mm
2x 2x
M8 anchorM6 x 70mm
ENGLISH
WARNING:
Anchors that are not fully set in solid concrete will not support the applied load
resulting in an unstable, unsafe condition which could lead to personal injury and/or
property damage. Consult a construction professional if you have any doubt about
what this means in regard to your particular situation.
WARNING:
Mounting holes must be at least 3-1/8” (80mm) deep and
must be located within solid concrete, not mortar or cov-
ering material. If you drill into an area of concrete that is
not solid, reposition mounting holes until both anchors
can be fully inserted into solid concrete!
NOTE: make sure extension bracket is
level before tightening bolts. Go to Step
3 on the page 7.
Mount bracket to wall

7 of 14
888-61-054-W-00 rev. E • 10/13
4
Ø
3
ab
ENGLISH
Determine TV/large display mount fasteners
NOTE: If a stand is already attached to your TV/large display, remove it according to TV/large display manu-
facturer directions. Place the display on a clean, flat, padded surface or, if you prefer, lean the TV/large display against a
stable, vertical surface.
Several sizes of screws and spacers have been provided for mounting the Glide brackets to your TV/large display-
choose those that best match the depth and diameter of the mounting holes on the back of your TV/large display, along
with the design of the area surrounding the mounting holes (Flat, Curved or Inset).
TV/Display Style
If your TV/large display has a curved or inset mounting hole configuration, you may need to use the provided spacers or
washers with the screws.
Hole Depth and Diameter
Four sets of display bracket screws have been provided, each of a different diameter: 4mm, 5mm, 6mm, and 8mm.
Compare the screws with the diameter of the mounting holes at the back of your TV/large display to find the same size.
NOTE: WasherAis provided for use with the 4mm and 5mm screws while Washer B works with 6mm and 8mm screws.
Test screw diameters and lengths until you find the right match to your TV/large
display.
Ensure the bracket is level.

8 of 14
888-61-054-W-00 rev. E • 10/13
5
100mm
100mm
100 x 100
100 x 200
200 x 200
300 x 300
400 x 400
200 x 100
400mm
200mm
300mm
100mm
200mm
100mm
200mm
400mm
200mm
300mm
ENGLISH
Determine if VESAadapters are needed betweenTV/display and Glide LD
Check the shape and size of your TV/large display mounting hole configuration against the VESAcon-
figurations shown below. Choose VESAoption that matches and continue to Step 6 on the next page.
OptionA
Option B
Option C
Option D
VESAMounting Hole ConfigurationsTV/large display Mounting Hole Configurations

9 of 14
888-61-054-W-00 rev. E • 10/13
6
6mm
6mm
6mm
6
ENGLISH
Continue to
Step 7 on
page 12.
Step 6 details
continued on the
next page.
Options B, C, and D
Attach VESAAdapters to Glide.
OptionA:AttachTV/large display to the Glide LD using fasteners
determined in step 4 and spacers if needed

10 of 14
888-61-054-W-00 rev. E • 10/13
a
b
8x M4 x 6mm
ENGLISH
VESAMounting Hole
Configurations
Rotate VESAplate to access mounting holes.
Step 6
continued
on the
next
page.
Option B Option C Option D

11 of 14
888-61-054-W-00 rev. E • 10/13
6mm
6mm
6mm
6
c
ENGLISH
Options B, C, and D (cont.)
Attach TV/large display to the Glide LD using fasteners determined
in step 4 and spacers if needed

12 of 14
888-61-054-W-00 rev. E • 10/13
7
ab
ENGLISH
Mount Lift30 (with attached TV/large display) to bracket on wall.
Quick-release instructions: to remove from the wall, pull
down on the strap below the extension.

13 of 14
888-61-054-W-00 rev. E • 10/13
8
10mm
ENGLISH
Adjust lift up and down.
Adjustment Step
Increase Lift Strength
If the mounted weight is too heavy or
this product does not stay up when
raised, then you'll need to increase
Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or
this product does not stay down when
lowered, then you'll need to decrease
Lift Strength:
Important! You will need to adjust this product after installation is complete. Make sure all your equipment is
properly installed on the product before attempting adjustments. This product should move smoothly and easily
through the full range of motion and stay where you set it. If movements are too easy or difficult or if product
does not stay in desired positions, follow the adjustment instructions to create smooth and easy movements.
Depending on your product and the adjustment, it may take many turns to notice a difference.Any time
equipment is added or removed from this product, resulting in a change in the weight of the mounted load, you
should repeat these adjustment steps to ensure safe and optimum operation.

14 of 14
888-61-054-W-00 rev. E • 10/13
Disclaimer – OmniMount, Inc. has extended every eort to ensure to accuracy and completeness of this manual. However, OmniMount, Inc. does not claim that the information covers all installation
or operational variables. e information contained in this document is subject to change without notice or obligation of any kind. Regarding the information contained herein, OmniMount, Inc.
makes no representation of warranty, expressed or implied, and assumes no responsibility for accuracy, suciency, or completeness of the information contained in this document.
Wall Mounts
WARNING: FAILURE TO READ, THOROUGHLY UNDERSTAND, AND FOLLOW ALL INSTRUCTIONS CAN RESULT IN SERIOUS PERSONAL INJURY, DAMAGE TO PERSONAL PROP-
ERTY, OR VOIDING OF FACTORY WARRANTY!
It is the responsibility of the installer to ensure all components are properly assembled and installed using the instructions provided. If you do not understand these instructions or have any questions
or concerns, please contact customer service at 1-800-668-6848 or [e-mail].
Do not attempt to install or assemble this product if the product or hardware is damaged or missing. In the event that replacement parts or hardware are needed, please contact Customer Service at
1-800-668-6848 or [e-mail]. International customers needing assistance should contact the Dealer from which they purchased the product.
All trademarks are the property of their respective companies. OmniMount is a registered trademark of OmniMount, Inc. © 2012
OmniMount, Inc.
4409 East Baseline Road, Suite 130,
Phoenix, AZ 85042
1-800-MOUNT-IT (1-800-668-6848)
www.omnimount.com
NEED HELP? PLEASE CALL
Thank you for purchasing an OmniMount product
ENGLISH
