SPS -48V Slimline Power Shelf
Models: J2007003L011 - alpha suxes per Slimline Power System Brochure
1. Reposition mounting ears as required - 1 screw each. Torque to 25 in-lb (2.8 Nm) - Phillips screwdriver.
2. Attach shelf to the frame using a minimum of four screws (two on each side) - 12-24 (provided). Torque to 35 in-lb
(4 Nm) - 5/16” socket.
Chassis Ground - 10 AWG min recommended
Lug Landing: #10 double-hole on 5/8-inch center (lug not provided)
Some applications may rely on frame mounting screws for chassis ground, omitting the chassis ground wire.
Torque 10-32 screws to 30 in-lb (3.4 Nm) - 5/16” socket.
DC Reference (CO) Ground - 10 AWG min recommended
Strip 0.6” (15 mm) and insert wire fully into POS RTN block.
L004 - C13 cords (1 or 2). Secure cord with the AC cord retainer (furnished).
L014 - wire to AC terminal blocks. Strip 0.3” (8 mm). Torque to 10 in-lb (1 Nm).
Danger: If blunt cut cords are used ensure AC power is OFF and use appropriate lock-out tag-out procedures before
continuing with ac connections. Follow all local and national wiring rules when connecting to ac mains.
Caution: Route AC cables to avoid contact with sharp or rough surfaces that may damage insulation and cause a short
circuit.
• Sockets - 5/16”, 7/16, etc.
• Screwdrivers - Philips #1 and #2, Flat small
• Wire cutters and strippers
• Wire cutters and strippers
• Cable crimpers
• Torque wrench - 0-65 in-lb (0-10 Nm)
No vertical spacing is required, allow a minimum 2 inch clearance at back of shelf for rectier airow.
Refer to Slimline Power System Brochure for details and accessories.
QUICK START GUIDE

Page 2
2023 OmniOn Power. All rights reserved. SPS Shelf L011_QSG Rev.1.0
Chassis Ground options
DC Outputs - GMT style fused (15A max fuses)
Connect outputs and returns to the terminal blocks.
12 AWG max Strip 0.35” (9 mm)
Torque to 4 in-lb (0.45 Nm)
DC Aux Output - optional
Connect Aux output and return to the terminal blocks.
8 AWG max Strip 0.6” (15 mm)
Insert wires fully into block
Insert small at screwdriver to open clamp..
Battery
Connect outputs and returns to the terminal blocks.
8 AWG max Strip 0.6” (15 mm)
Insert wires fully into block
Insert small at screwdriver to open clamp..
Caution: Verify battery voltage and polarity with a
voltmeter before proceeding.
DC Aux Output
DC Reference
(CO) Ground
Battery
DC Outputs 1-6
GMT style fused
DC Outputs 7-12
GMT style fused
GMT style fuses
15A max fuses
DC Reference (CO) Ground
AC Cord Retainer
Chassis Ground options

Page 3
2023 OmniOn Power. All rights reserved. SPS Shelf L011_QSG Rev.1.0
Connectors are on rear.
1. J1-2 Alarms and Inputs - Connect to ofce alarms and signals. See Information: Alarm Connections for Details
2. J5 LAN - Connect to Ethernet network.
1. Connect 1-Wire Battery Temp and Voltage Monitor to J3
Firmly push the rectier into the rectier slot.
Tighten the thumb screw until the rectier is
seated.
NOTE: When installing a rectier in a powered
system the RUN LED on the rectier will blink
until communication with the controller is
established.
Verify that all AC, DC and Alarm connections are complete and secure. Turn on AC input breakers. If there are no
alarms, make required adjustments to the default settings on the controller for this installation.
Verify and edit controller basic conguration parameters per site engineering instructions.
USB Craft Port
J3 1-Wire Battery Temp
Monitor
J2 Alarm inputs
J5 LAN Port J1 Alarm outputs
Signal Connections

Page 4
2023 OmniOn Power. All rights reserved. SPS Shelf L011_QSG Rev.1.0
Rectiers single phase, hot-pluggable,
fan-cooled
Input Recommended
AC Breaker Output
Vac A2 Feeds C13 Cords or
Terminal Block
1 Feed
C13 Cord Float Vdc WA1
150027894 EP0500-UTEZ: 540W 100-120 6.5 10A 20A 48-58 540 10
CC109165602 EP1000-UTEZ: 1000W 100-120 12 15A - 48-58 1000 20
200-240 610A 15A 48-58 1000 20
CC109165610 EP1600-UTEZ: 1600W 100-120 15 20A - 48-58 1200 24
200-240 7.5 10A 20A 48-58 1600 32
1. Output Current at 54.5V. Outputs are power limited, not current limited.
See the Slimline Power System Brochure for details.
Alarm connections are on the rear of the shelf - J1 is Alarm Outputs and J2 is Alarm Inputs.
Change alarm descriptions via LAN port (Web pages) or Craft port (EasyView2) when required.
Connector J1 - Controller Variants J2 - All Controllers
Pin /Controller Color 0I5R_D - 5 Alarm
Relays 3C3R - 3 Alarm Re- lays 9C0R_USB - 9 Inputs Color All
1BK Output: R3 = Rtn Input: PBT/TR Input: Door Open YInput: SPD Fail
2BR Output: R2 = Rtn Input: Hi Ext.Temp. Input: Surge Protect Fail S-
3ROutput: R1 = Rtn Output: R1 = Rtn Input: Door 2 Open OInput: AUX MAJ
4OOutput: PMN Rtn Output: PMN Rtn Input: Ext DC Gail Major VInput: Air Cond. Fail
5YOutput: PMJ Rtn Output: PMJ Rtn Input: Ext DC Fail Minor WInput: Door Open
6GOutput: R3 = ACF Input: RTNS Input: Returns BL -48V
7BL Output: R2 = RFA Input: Cust. Alrm 1 Input: Retrieve
Generator BR -48V
8VOutput: R1 = BD Output: R1 = BD Input: Battery Fail BK -48V
9SOutput: PMN Output: PMN Input: Air Conditioner
Fail -
10 WOutput: PMJ Output: PMJ Input: External Fan Fail -

Page 5
2023 OmniOn Power. All rights reserved. SPS Shelf L011_QSG Rev.1.0
• Specications and ordering information are in the Slimline Power System Brochure available at omnionpower.com
• External Surge Protective Devices (SPDs) - are required on all AC inputs.
Equipment Safety is Approved in IEC 60664-1 Installation Category II environments.
• Equipment and subassembly ports:
1. are suitable for connection to intra-building or unexposed wiring or cabling;
2.can be connected to shielded intra-building cabling grounded at both ends.
• Grounding / Bonding Network – Connect to an Isolated Ground Plane (Isolated Bonding Network) or an Integrated
Ground Plane (Mesh-Bonding Network or Common Bonding Network).
• Installation Environment - Install in Network Telecommunication Facilities, OSP, or where NEC applies.
• Battery return may be either Isolated DC return (DC-I) or Common DC return (DC-C).
These documents are available at omnionpower.com
Document Title
850035894
CC848815341
Pulsar Edge Controller Family Product Manual
Slimline Power System Brochure
Galaxy Pulsar Edge Quick Start Guide

Page 6
2023 OmniOn Power. All rights reserved. SPS Shelf L011_QSG Rev.1.0
• Do not install this equipment over combustible surfaces.
• Rules and Regulations - Follow all national and local rules and regulations when making eld connections.
• Compression Connectors
• U. S. or Canada installations - use Listed/Certied compression connectors to terminate Listed/Certied eld-
wire conductors.
• All installations - apply the appropriate connector to the correct size conductor as specied by the connector
manufacturer, using only the connector manufacturer’s recommended or approved tooling for that
connector.
• Electrical Connection Securing: Torque to the values specied on labels or in the product documentation.
• Cable Dress - dress to avoid damage to the conductors and undue stress on the connectors.
• Circuit Breakers and Fuses
• Use only those specied in the equipment ordering guide.
• Size as required by the National Electric Code (NEC) and/or local codes.
Safety Tested Limits - Refer to the equipment ratings to assure current does not exceed:
Continuous Load (List 1) - 60% of protector rating
Maximum Load (List 2 - typically end of discharge) - 80% of protector rating.
• GMT Style Fuses - Use only fuses provided with safety caps.
• Field-wired Conductors - Follow all National Electric Code (NEC) and local rules and regulations.
• Insulation rating: 90°C minimum; 105°C (minimum) if internal to enclosed equipment cabinets.
• Size AC eld-wired conductors with 75°C ampacity (NEC) equal to or greater than their panel board circuit
breaker rating.
• AC and DC input disconnect/protection - Provide accessible devices to remove input power in an emergency.
• Alarm Signals - Provide external current limiting protection. Rating 60V, 0.5A unless otherwise noted.
• Grounding - Connect the equipment chassis directly to ground. In enclosed equipment cabinets connect to the
cabinet AC service ground bus. In huts, vaults, and central ofces connect to the system bonding network.

Page 7
2023 OmniOn Power. All rights reserved. SPS Shelf L011_QSG Rev.1.0
• Install, service, and operate equipment only by professional, skilled and qualied personnel who have the
necessary knowledge and practical experience with electrical equipment and who understand the hazards that
can arise when working on this type of equipment.
• Disconnect batteries from outputs and/or follow safety procedures while working on equipment. Batteries may
be connected in parallel with the output of the rectiers. Turning off the rectiers will not necessarily remove
power from the bus.
• Do not disconnect permanent bonding connections unless all power inputs are disconnected.
• Verify that equipment is properly safety earth grounded before connecting power. High leakage currents may be
possible.
• Exercise care and follow all safety warnings and practices when servicing this equipment. Hazardous energy and
voltages are present in the unit and on the interface cables that can shock or cause serious injury. When
equipped with ringer modules, hazardous voltages will be present on the ringer output connectors.
• Use the following precautions in addition to proper job training and safety procedures:
• Use only properly insulated tools.
• Remove all metallic objects (key chains, glasses, rings, watches, or other jewelry).
• Follow Lock Out Tag Out (LOTO) procedures: customer specied, site specic, or general as appropriate.
Disconnect all power input before servicing the equipment. Check for multiple power inputs.
• Wear safety glasses.
• Follow Personal Protective Equipment requirements: customer specied, site specic, or general as
appropriate.
• Test circuits before touching.
• Be aware of potential hazards before servicing equipment.
• Identify exposed hazardous electrical potentials on connectors, wiring, etc.
• Avoid contacting circuits when removing or replacing covers;.
• Use a personal ESD strap when accessing or removing electronic components.
• Personnel with electronic medical devices need to be aware that proximity to DC power and distribution
systems, including batteries and cables, typically found in telecommunications utility rooms, can affect medical
electronic devices, such as pacemakers. Effects decrease with distance.
