iConverter GX/TM2 Plug-in Module QUICK START GUIDE
The Omnitron iConverter®GX/TM2 Plug-In media converter and
Network Interface Device (NID) provides 10BASE-T ,100BASE-TX
or 1000BASE-T UTP to 1000BASE-FX fiber media conversion.
The GX/TM2 conforms to Ethernet in the First Mile (EFM) fiber
standards to support Fiber-to-the-X (FTTX) in Metropolitan access
and Enterprise LAN networks. Built-in Operation, Administration
and Maintenance (OAM) functionality enables the GX/TM2 to
operate as a managed demarcation point at the customer premises
and network edge, offering Quality of Service capabilities.
The GX/TM2 module can be managed using Omnitron’s
NetOutlookTMSNMPManagementSoftware,third-partySNMPClient,
Telnet or the Command Line Interface (CLI).
For more information, including the complete User Manual on the GX/TM2 Plug-in
module, access Omnitron’s documentation download web page to view all relevant
documents: http://www.omnitron-systems.com/downloads.php
INSTALLATION PROCEDURE
1) Configure DIP-Switches
2) Install Module in Chassis and Connect Cables
3) Configure Module via Command Line Interface
4) Verify Operation
1) CONFIGURE DIP-SWITCHES
DIP-SWITCH BANK 1
SW1 - FIBER AUTO/MANUAL NEGOTIATION
“AN MAN”
WhenthisDIP-switch is in the LEFT “AN” position
(factory default), the fiber optic port automatically
determines the duplex and pause modes of the
connecting fiber optic device. If the connecting
fiberopticdevicecannotprovidetheproper signal
to indicate its own mode of operation, the DIP-
switchshouldbe settothe RIGHTfiberoptic “Man”
position. When in manual mode, no capabilities
are advertised.
NOTE: The fiber optic port of the GX/TM2 is always in Full-Duplex mode.
SW2 - UTP AUTO/MANUAL NEGOTIATION “AN/MAN”
When this DIP-switch is in the LEFT UTP “AN” position (factory default), the UTP port
automatically determines the Speed, Duplex and Pause mode of the connecting UTP
device. If the connecting UTP device cannot provide the proper signal to indicate its
own mode of operation, then the DIP-switch should be set to “Man” position. Manual
mode requires manually configuring the UTP port to match the Speed and Duplex
mode of the connecting UTP device using the “10/100” and “FDX/HDX” DIP-switches.
Management Options iConverter, Serial Agent
Network Management
1: Chassis and Module Management
2: Set Module Name Preferences
Management Module Preferences
3: IP and Control Preferences
4: SNMP Preferences
5: Abandon Preference Changes
6: Save Preference Changes
7: Restore Factory Defaults
8: Restart Management Module
9: Other Networking Features
Management Module Maintenance
10: Firmware Update
11: Set Date/Time
IP Address = 192.168.1.220
Chassis Number = 1
Enter Choice, <H>elp, E<x>it >
Figure C: Command Line Interface Menu Options
TheCLIinterface allows for thedetailedconfiguration ofthemodule. Itis recommended
to configure the module with an IP address associated with the attached network.
Also, SNMP traphost address should be configured if the module is managed with an
SNMP-based Management System. See the GX/TM2 User Manual for complete
information.
4) VERIFY OPERATION
Oncethemodulehasbeeninstalled
andconfiguredpersteps1-3,verify
themoduleis operational by viewing
the LED indicators.
The Power LED indicates the
module is receiving power from the
chassis.
The Fiber Optic link LED indicates
the fiber optic connection has been
established. Verify the Link Mode
selection is set to Link Segment
(LS). Until a stable link is
established, leave the Link Mode
configured for LS. After a Link
presence is established, the Link
Mode selection can be modified.
The UTP link LED indicates the
module has established a
connection across its UTP port.
Bank 2
Bank 1
Switch 1
Switch 4
Switch 1
Switch 8
Figure A: DIP-Switch Locations
LED Function
"Legend" Color Off State On / Blinking State
Power "Pwr" Green No power On: Module has power
Power Supply
Status # X Green Chassis Power
Supply not installed
On: Power available from
installed Power Supply # X.
Blinking: No power available
from installed Power Supply # X
1000Mbps
Fiber Optics
"FO" Green No Fiber Link On: Fiber Link
Blinking: Fiber Data Activity
Chassis
Management
Master/Slave
"Msr/Slv" Green Chassis in Slave
Mode
On: Chassis Master Mode
Blinking: Operating in OAM
Mode
UTP port
100Mbps
"100" Green Not linked at
100Mbps On: UTP linked at 100Mbps Blinking: UTP Data Activity
UTP port
1000Mbps
"1000" Green Not linked at
1000Mbps On: UTP linked at 1000Mbps Blinking: UTP Data Activity
UTP port
10Mbps
"100" + "1000" Green Not linked at
10Mbps On: UTP linked at 10Mbps Brinking: UTP Data Activity
UTP port
Full-Duplex
"FDX" Green Half-Duplex when
any UTP link is
active
On: Full-Duplex when any UTP
link is active
Figure D: LED Indicators
Form 040-8920N-002 B
Omnitron Systems Technology * 140 Technology Dr.* #500 * Irvine, CA 92618
949.250.6510 tel * 949.250.6514 fax * www.omnitron-systems.com

SW3 - MASTER/SLAVE
When the GX/TM2 module is installed in a chassis with an iConverter management
module such as a 10/100M2, set the DIP-switch to the LEFT “M/SL” position (factory
default), the assignment of mastership is automatically negotiated by the installed
managementmodules. Todesignate the GX/TM2 module as the master ofthechassis,
set the DIP-switch on the module to
theLEFT“M/SL” position, andsetthe
DIP-switch on the other installed
management modules to the RIGHT
“SL” position to enable Slave-Only
mode.
SW4 - RESERVED
This DIP-switch is for factory use only and must always remain in the LEFT position
(factory default).
2) INSTALL MODULE IN CHASSIS AND CONNECT CABLES
a. Carefully slide the module into an open slot in the chassis. Align the module with
the installation guides and ensure that the module is firmly seated against the
backplane. Secure the module by fastening the front panel thumbscrew (push in
and turn clockwise to tighten) to the chassis front. Verify the “Pwr” LED is ON
(indicating the chassis is powered).
b. When using a GX/TM2 SFP model (8939N-0), insert the SFP Fiber transceiver into
the Port 1 SFP receptacle on the GX/TM2.
NOTE: The release latch of the SFP Fiber transceiver must be in the closed
position before insertion.
c. Connect the UTP port via a Category 5 cable to a 10BASE-T, 100BASE-TX or
1000BASE-T Ethernet device.
d. Connect an appropriate multimode or single-mode fiber cable to the fiber port of
the installed module. It is important to ensure that the transmit (Tx) is attached to
the receive side of the device at the other end and the receive (Rx) is attached to
the transmit side. Single-fiber (SF) media converter models operate in pairs. The
Txwavelength mustmatchthe Rxwavelengthat theotherend andtheRx wavelength
must match the Tx wavelength at the other end
3) CONFIGURE MODULE VIA COMMAND LINE INTERFACE
To access the Command Line Interface (CLI), connect the GX/TM2 RS-232 Console
Port to the COM port of a computer equipped with terminal emulation software such as
HyperTerminal. The Console Port (DCE) is a mini DIN-6 female connector which can
be changed to a DB-9 connector with the included adapter. The GX/TM2 Console Port
is a standard asynchronous serial interface.
Start HyperTerminal and select the correct COM Port in the HyperTerminal “Connect
To:” window. Set the serial port to the following:
Bits Per Second 57,600
Stop Bits 1
Data Bits 8
Parity NONE
Hardware Flow Control NONE
Once connected, press <ENTER> to bring up a command line prompt on the attached
PC.
SW3 - UTP SPEED GIGABIT/10-100 “1000/10-100”
When the “1000/10-100” DIP-switch is in the “1000” position (factory default), the
UTP port operates in 10/100/1000Mbps Auto-Negotiation mode. The UTP port
auto-negotiates to a speed of 10Mbps, 100Mbps or 1000Mbps with the connected
UTP device. In this mode, the UTP “AN/Man” and UTP “100/10” DIP-switches have no
effect.
When the “1000/10-100” DIP-switch is in the “10-100” position and the UTP “AN/Man”
DIP-switch is in the “Man” position, the UTP port operates at the Speed and Duplex
modes set by the “100/10” and “FDX/HDX” DIP-switches.
When the “1000/10-100” DIP-switch is in the “10-100” position and the UTP “AN/Man”
DIP-switch is in the “AN” position, the UTP port maximum auto-negotiation setting
for the Speed and Duplex mode is determined by the “100/10” and “FDX/HDX”
DIP-switches.
SW4 - UTP 100/10MBPS “100/10”
WhentheUTP“AN/Man”DIP-switch(described above) is in the manual “Man” position,
the “100/10" DIP-switch determines the speed of operation for the UTP port. Set the
“100/10” DIP-switch to match the speed of the connected UTP device.
SW5 - UTP FULL/HALF DUPLEX “FDX/HDX”
WhentheUTP“AN/Man”DIP-switch(described above) is in the manual “Man” position,
the “FDX/HDX" DIP-switch determines the duplex mode of the UTP port. Set the
“FDX/HDX” DIP-switch to match the duplex mode of the connected UTP device.
SW6, SW7, SW8 - LINK MODES
These three DIP-switches configure the link mode settings. The following table details
possible Link Mode DIP-switch configurations.
Switch Left
(Factory Default) Right SW6 SW7 SW8 Link Mode Selection
SW1 AN:
Fiber Auto-Negotiation Man: Fiber Manual Negotiation Left Left Left Link Segment (LS) (Factory Default)
SW2 AN:
UTP Auto-Negotiation Man: UTP Manual Right Left Left Link Propagate (LP)
SW3 1000:
UTP 1000Mbps 10-100: UTP 10-100Mbps Left Right Left Remote Fault Detect + Link Segment (RFD + LS)
SW4 100:
UTP 100Mbps 10: UTP 10Mbps Right Right Left Remote Fault Detect + Link Propagate (RFD + LP)
SW5 FDX:
UTP Full-Duplex HDX: UTP Half-Duplex Left Left Right Symmetrical Fault Detect (SFD)
SW6
See Link Mode Selection
Right Left Right Asymmetrical Link Propagate
Port 1 to Port 2 (ALP P1-P2)
SW7 Left Right Right Asymmetrical Link Propagate
Port 2 to Port 1 (ALP P2-P1)
SW8 Right Right Right Asymmetrical RFD+LP
Port 1 to Port 2 (ARFDP1-P2)
Figure B: DIP-Switch Bank 1
DIP-SWITCH BANK 2
SW1, SW2 - BACKPLANE ENABLE
When the DIP-switch is in the LEFT “DS” position (factory default), the Backplane Port
oftheGX/TM2isisolatedfromthechassis’Ethernet Backplane. WhenthisDIP-switch
is in the RIGHT “EN” position, the Backplane Port is enabled. This allows Ethernet
Backplane connectivity to an adjacent module via the chassis Backplane Link “A” or
“B” depending on the switch setting.
S
witch Left (Factory Default) Right
SW1 A-DS: Port A Disabled A-EN: Port A Enabled
SW2 B-DS: Port B Disabled B-EN: Port B Enabled
SW3 M/SL:
Master/Slave Auto-Select SL: Slave-Mode Only
SW4 Reserved Reserved
Figure C: DIP-Switch Bank 2
