FlexPointTM T1/E1 Copper to Fiber
Converters
User Instructions
Description:
The FlexPoint T1/E1 connects T1 and E1 devices, such as
PBXs,CSUsandrouters,viamultimode(MM) or single-mode
(SM)fiber.Designedto extend thestandardT1/E1 twistedpair
or Coax network distances over fiber, this converter provides
protectionfromenvironmentalnoiseand effectivelyincreases
high-speed network reliability. The following models are
describedhere.
Model # Fiber Type Max Distance
4470/90-x MM, SC, 1310nm 5km
4471/91-x SM, SC, 1310nm 30km
4472/92-x MM,ST, 1310nm 5km
4473/93-x SM, ST, 1310nm 30km
4474/94-x SM, SC, 1310nm, LH 60km
Power Options (-x):
-0 No power adapter included (chassis module)
-1 110 Volt / 60 Hz
-2 110-230 Volt / 50 Hz
Mounting Options
4380 FlexPointWall-Mounting Hardware Kit
4384 FlexPoint 18 to 72VDC Stand-Alone Power Supply
4381 FlexPointDC Converter Wall-MountingKit(for 4384)
4385 FlexPoint14-Unit 48VDCPower-RedundantChassis
4392 FlexPoint 5-Unit Rack-Mounting Shelf
4395 FlexPoint 14-Unit AC Power-Redundant Chassis
Power Adapter Notice
1.When Using in a stand-alone configuration, thisproduct
is intended to be and must be used only with a Listed
Direct Plug-In Power Unit marked “Class 2” and rated
at 9VDC, 1 Amp.
2.This product should always be usedonly with Omnitron
SuppliedPower Unit modelnumbers9113-PSor 9115-PS.
WARNING!
Before inserting the Power Adapter, verify that the
power on the unit is appropriate for your AC line
voltage source.
Mounting instructions:
TheFlexPointFiber Converter can be solo-mounted using
a wall-mounting kit, or rack-mounted using a 5-unit shelf,
or a high-density FlexPoint 14-Unit Power-Redundant
Chassis.
Fiber Optic Cable Attachment:
Connect the fiber cables between the FlexPoint T1/E1
converters. The transmit (Tx) must attach to the receive
sideand the receive (Rx) mustattach to thetransmit side.
Note: Use fiber cables that are compliant with the
specificationsthatareoutlined in fiber cable specifications.
Copper Cable Attachment:
RJ-45/RJ-48 T1/E1 connector
Connect to the RJ-45/48 connector on the FlexPoint T1/
E1 converter via a category 3 or better cable (Category
5 is recomended) and attach the other end to the network
equipment.(Thetwistedpairconnectionrequirestwoactive
pairs in a T1/E1 environment. The active pairs are pins
1&2 and pins 4&5. Only dedicated wire pairs should be
used for the active pins.) Set the UTP DCE / DTE switch
for the RJ-45/48 port to the appropriate setting.
Note: Use copper cables that are compliant with the
specificationsthatare outlined in copper cable specifications.
Coax E1 Connector
AttachtheBNCtotheFlexPointT1/E1converterandattach
the other end of the BNC to the network equipment.
Note: Use copper cables that are compliant with the
specificationsthatare outlined in copper cable specifications.
Switch Settings:
UTP DCE/DTE setting
The UTP DCE/DTE switch is used to eliminate the need for
crossoverand customcablesto connectdevicestogether when
using the RJ-45/48 port. Set this switch to DCE to use a
straight-throughcableand to DTE when a crossover-cable
would be required.
T1/E1 Copper line configuration settings
The T1/E1 copper line codes and line lengths are configured
using dip switches located on the side of the FlexPoint T1/E1
media converter.
Line Type Port Type Distances Switch Positions
1 2 3 4
T1DSX-1 RJ-45/48 0’ - 133’ LL
LL
LLL
LL
LLL
LL
LLL
LL
L
T1DSX-1 RJ-45/48 133’ - 266’ LL
LL
LLL
LL
LLL
LL
LKK
KK
K
T1DSX-1 RJ-45/48 266’ - 399’ LL
LL
LLL
LL
LKK
KK
KLL
LL
L
T1DSX-1 RJ-45/48 399’ - 533’ LL
LL
LLL
LL
LKK
KK
KKK
KK
K
T1DSX-1 RJ-45/48 533’ - 655’ LL
LL
LKK
KK
KLL
LL
LLL
LL
L
T1 DS-1 RJ-45/48 0 dB LL
LL
LLL
LL
LLL
LL
LLL
LL
L
T1 DS-1 RJ-45/48 -7.5 dB LL
LL
LKK
KK
KLL
LL
LKK
KK
K
T1 DS-1 RJ-45/48 -15.0 dB LL
LL
LKK
KK
KKK
KK
KLL
LL
L
T1 DS-1 RJ-45/48 -22.5 dB LL
LL
LKK
KK
KKK
KK
KKK
KK
K
E1 75 ΩCoax/BNC Standard KK
KK
KLL
LL
LLL
LL
LLL
LL
L
E1120ΩRJ-45/48 Standard KK
KK
KLL
LL
LLL
LL
LKK
KK
K
E1 75 ΩCoax/BNC Extended KK
KK
KLL
LL
LKK
KK
KLL
LL
L
E1120ΩRJ-45/48 Extended KK
KK
KLL
LL
LKK
KK
KKK
KK
K
Operational switch settings and functions
The following operational switches located on the front of
the FlexPoint T1/E1 converter are to assist in installation
and fault isolation.
Local loop-back (L/LB)
This switch will set the FlexPoint T1/E1 converter in a
loop-backmodeon both the fiber and copper connections.
By returning the switch to the normal position the unit will
resume to normal operation.
Remote loop-back (R+L/LB)
This switch will allow the entire fiber segment to be tested
ateither of the FlexPoint T1/E1converters without having
to set switches on both units. When set in this mode the
local unit is switched to a local loop-back mode. The fiber
Txport will be further encoded to carry aremote loop-back
protocol. This remote loop-back will set the far end
FlexPointT1/E1 converter to remote loop-back modeand
return a signal to the sending unit. An LED on the local
and remote FlexPoint T1/E1 converters will show a
confirmation that the fiber segment is communicating
properly between devices. By returning the switch to the
normal position it will return to normal operation.
DCE
Twisted
Pair #1
Twisted
Pair #2
RTIP
RRING
TTIP
TRING
RTIP
RRING
TTIP
TRING
1
2
4
5
DTE
Twisted
Pair #1
Twisted
Pair #2
RTIP
RRING
TTIP
TRING
RTIP
RRING
TTIP
TRING
1
2
4
5
Local Dual Loop Back
Remote & Local Loop Back
Force 1’s to Fiber
Force 1’s Copper
Normal
Cu-Rx
Cu-Tx
FO-Tx
FO-Rx
Loopback Enabled
Cu-Rx
Cu-Tx
FO-Tx
FO-Rx
FO-Rx
FO-Tx
Cu-Tx
Cu-Rx
Remote Loop Request
Over Fiber
Copper Cable Specifications:
Twisted-Pair cable for T1
Gauge 22 to 24 AWG
Impedance 100 Ω+ 10%
Impedance characteristic 2.6 dB / 100m @ 1.0 MHz
Maximum distance 6,000 ft
Twisted-Pair cable for E1
Gauge 22 to 24 AWG
Impedance 120 Ω+ 10%
Impedance characteristic 2.6 dB / 100m @ 1.0 MHz
Maximum distance 8,000 ft
Coax cable for E1
Gauge 22 to 24 AWG
Impedance 75 Ω+ 10%
Impedance characteristic 2 dB / 100m @ 1.0 MHz
Maximum distance 8,000 ft
For product specifications refer to the product data sheet.
Technical Support:
For help with this product, contact our Tech. Support:
Phone: [phone]
Fax: [phone]
Address: Omnitron Systems Technology, Inc.
140 Technology Drive, #500
Irvine, CA 92618 USA
E-mail: su[email protected]
URL: http://www.omnitron-systems.com
Local loop-back and Remote loop-back
When both Local and Remote Loop-back are set to the
Normalposition,theFlexPointT1/E1usesthedefault B8ZS
data format. When both switches are turned to their On
position, it uses the AMI data format.
Transmit/force 1’s to fiber
This switch is used to insert an “all ones” pattern into the
data stream being transmitted out of the fiber port on the
FlexPointT1/E1 converter.Databeingreceivedonthecoax
ortwisted pair will be disabled anddata being receivedon
thefiber is passed through to the coaxor twisted pairside.
By returning the switch to the normal position the unit will
resume to normal operation.
Transmit/force 1’s to Coax or UTP
This switch is used to insert an “all ones” pattern into the
data stream being transmitted out of the coax or twisted
pairontheFlexPointT1/E1converter.Data being received
on the fiber will be disabled and data being received on
thecoax or twisted pair is passed throughto the fiberside.
By returning the switch to the normal position the unit will
resume to normal operation.
Alarm Relay Contacts
The FlexPoint T1/E1 features dry relay contacts for
optionally connecting the it into a separate T1/E1 alarm
circuit. The relay closes when a loss of power or when
signal detect is lost to the copper or fiber connection.
Operational rating on relay pins 3 & 6: 0-220VDC max 2A
LED Indicators
LED Color Status Description
Power: Yellow On Power applied
Fiber: Green Off No signal detect
On Signal detect
Blink All ones received
UTP/Coax:
Green Off No signal detect
On Signal detect
Blink All ones received
Test: Green Off Normaloperation
On L/LB orAll 1’s Test mode
Blink R+L/LB Received master
Fast Blink R+L/LB Received slave
Fiber Cable Specifications:
Multimode
Cable: 50/125, 62.5/125, 100/140 μm
Wavelength: 1310nm
Max Distance: 5km
Singlemode
Cable: 9/125 μm
Wavelength: 1310nm
Max Distance: 30km
Singlemode long-haul
Cable: 9/125 μm
Wavelength: 1310nm
Max Distance: 60km
Warning
The operating description in this Instruction Manual is for use
by qualified personnel only.To avoid electrical shock, do not
perform any servicing of this unit other than that contained in
theoperating instructions,unlessyouare qualifiedandcertified
todo so by OmnitronSystems Technology, Inc.
Caution
Alluser-required operationscanbeperformed withoutopening
theunit.Never attempt to open orremovethecoveror tamper
withtheunit. Warranty
This product is warranted to the original purchaser against
defects in material and workmanship for a period of TWO
YEARSfromthe date of shipment.ALIFETIMEwarrantymay
be obtained by the original purchaser by REGISTERING this
productwith Omnitronwithin90 daysfromthe dateofshipment.
TO REGISTER, COMPLETE AND MAIL OR FAX THE
REGISTRATION PORTION OF THIS INSTRUCTION
MANUAL TO THE INDICATED ADDRESS. Or you may
register your product on the Internet at http://www.omnitron-
systems.com.During the warranty period, Omnitronwill, atits
option, repair or replace a product which is proven to be
defective.
Forwarranty service, theproductmustbe sent toanOmnitron
designated facility, at Buyer’s expense. Omnitron will pay the
shipping charge to return the product to Buyer’s designated
USaddress using Omnitron’s standard shipping method.
Limitation of Warranty
The foregoing warranty shall not apply to defects resulting
from improper or inadequate use and/or maintenance of the
equipmentbyBuyer,Buyer-suppliedequipment,Buyer-supplied
interfacing, unauthorized modifications or tampering with
equipment(including removalofequipment coverbypersonnel
notspecifically authorizedandcertified byOmnitron),ormisuse,
or operating outside the environmental specification of the
product (including but not limited to voltage, ambient
temperature, radiation, unusual dust, etc.), or improper site
preparationor maintenance.
Noother warrantyisexpressed orimplied.Omnitron specifically
disclaimstheimplied warranties of merchantabilityandfitness
foranyparticularpurpose.
Exclusive Remedies
The remedies provided herein are the Buyer’s sole and
exclusiveremedies.Omnitron shall notbeliablefor any direct,
indirect,special, incidental,orconsequential damages,whether
basedoncontract, tort, or any legal theory.
Form: 040-04470-002D 11/07
Relay
3
6
RJ-45/RJ-48
User Warranty Registration
Please register on-line at http://www.omnitron-systems.com or complete both sides
and return this form to Omnitron Systems.
Model:_________________________________________________ Serial Number: ______________ Purchase Date: ______________ Purchased From: _________________________________________ Address: ______________________________________________ City: ___________________ State: _______ Zip Code: ________ Country: _______________________________________________ Comments and Suggestions: _______________________________
______________________________________________________ ______________________________________________________
Please complete both sides of this form
