Omron Sysmac FHV Series User guide

Vision Sensor
FHV Series
Smart Camera
Setup Manual
FHV7£-£££££-£££-££
Z408-E1-06

NOTE
•All rights reserved.
•No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any
form, or by any means, mechanical, electronic, photocopying, recording, or otherwise, without the
prior written permission of OMRON.
•No patent liability is assumed with respect to the use of the information contained herein. Moreover,
because OMRON is constantly striving to improve its high-quality products, the information con-
tained in this manual is subject to change without notice. Every precaution has been taken in the
preparation of this manual. Nevertheless, OMRON assumes no responsibility for errors or omis-
sions.
Neither is any liability assumed for damages resulting from the use of the information contained in
this publication.
Trademarks
•Sysmac and SYSMAC are trademarks or registered trademarks of OMRON Corporation in Japan
and other countries for OMRON factory automation products.
•This software is based in part on the work of the Independent JPEG Group.
•Microsoft, Windows, Windows Vista, Excel, and Visual Basic are either registered trademarks or
trademarks of Microsoft Corporation in the United States and other countries.
•Intel, Core and Pentium are trademarks of Intel Corporation in the U.S. and/or other countries.
•ODVA, CIP, CompoNet, DeviceNet, and EtherNet/IP are trademarks of ODVA.
•The SD, SDHC, microSD, and microSDHC logos are trademarks of SD-3C, LLC.
•QR Code is a registered trademark of DENSO WAVE INCORPORATED.
•MELSEC is a registered trademarks of Mitsubishi Electric Corporation.
Other company names and product names in this document are the trademarks or registered trade-
marks of their respective companies.
Copyrights
Microsoft product screen shots reprinted with permission from Microsoft.

Introduction
Thank you for purchasing the FHV Series Smart Camera.
This manual contains information that is necessary to use the FHV Series Smart Camera.
Please read this manual and make sure you understand the functionality and performance of the FHV
Series Smart Camera before you attempt to use it in a control system.
Keep this manual in a safe place where it will be available for reference during operation.
Intended Audience
This manual is intended for the following personnel, who must also have knowledge of electrical sys-
tems (an electrical engineer or the equivalent).
• Personnel in charge of introducing FA systems.
• Personnel in charge of designing FA systems.
• Personnel in charge of installing and maintaining FA systems.
• Personnel in charge of managing FA systems and facilities.
Applicable Products
This manual covers the following products.
• FHV7£-£££££-£££-££
Part of the specifications and restrictions are given in other manuals. Refer to Relevant Manuals on
Relevant Manuals on page 2 and Related Manuals on page 26.
Introduction
1
FHV Series Smart Camera Setup Manual (Z408-E1)

Relevant Manuals
The following table provides the relevant manuals for this product. Read all of the manuals that are
relevant to your system configuration and application before you use this product.
Information Reference Matrix
Manual
Basic information
Vision System FH/FHV Series User's Manual Vision System FHV Series Smart Camera Setup Manual Vision System FH/FHV Series Processing Item Function Reference Manual Vision System FH/FHV Series User’s Manual for Communications Settings Vision System FH/FHV Series Operation Manual for Sysmac Studio
Overview of FHV7 series l l
Setup and Wiring
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Setup the communication setting of Smart Camera
l l l
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Setup the Smart Camera
l l
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Relevant Manuals
2FHV Series Smart Camera Setup Manual (Z408-E1)

Information Reference Matrix
Manual
Basic information
Vision System FH/FHV Series User's Manual Vision System FHV Series Smart Camera Setup Manual Vision System FH/FHV Series Processing Item Function Reference Manual Vision System FH/FHV Series User’s Manual for Communications Settings Vision System FH/FHV Series Operation Manual for Sysmac Studio
Create and Set the Scene
l l
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Optimizing the Scene Flow
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Connecting the Controller
l l l
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Using Helpful Functions
l
l
EtherCAT
EtherNet/IP
PROFINET
Ethernet
RS-232C
Parallel interface
Troubleshooting and Problem Solving l
Relevant Manuals
3
FHV Series Smart Camera Setup Manual (Z408-E1)

Manual Structure
Page Structure
The following page structure is used in this manual.
4-9
4 Installation and Wiring
NJ-series CPU Unit Hardware User’s Manual (W500)
stinUgnitnuoM3-4
4
stnenopmoCrellortnoCgnitcennoC1-3-4
4-3 Mounting Units
The Units that make up an NJ-series Controller can be connected simply by pressing the Units together
and locking the sliders by moving them toward the back of the Units. The End Cover is connected in the
same way to the Unit on the far right side of the Controller.
1Join the Units so that the connectors fit exactly.
2The yellow sliders at the top and bottom of each Unit lock the Units together. Move the sliders
toward the back of the Units as shown below until they click into place.
Precautions for Correct UsePrecautions for Correct Use
4-3-1 Connecting Controller Components
Connector
Hook Hook holes
Slider
Lock
Release
Move the sliders toward the back
until they lock into place.
Level 1 heading
Level 2 heading
Level 3 heading
Level 2 heading
A step in a procedure
Manual name
Special information
Level 3 heading
Page tab
Gives the current
headings.
Indicates a procedure.
Icons indicate
precautions, additional
information, or reference
information.
Gives the number
of the main section.
The sliders on the tops and bottoms of the Power Supply Unit, CPU Unit, I/O Units, Special I/O
Units, and CPU Bus Units must be completely locked (until they click into place) after connecting
the adjacent Unit connectors.
Note This illustration is provided only as a sample. It may not literally appear in this manual.
Manual Structure
4FHV Series Smart Camera Setup Manual (Z408-E1)

Special Information
Special information in this manual is classified as follows:
Precautions for Safe Use
Precautions on what to do and what not to do to ensure safe usage of the product.
Precautions for Correct Use
Precautions on what to do and what not to do to ensure proper operation and performance.
Additional Information
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Manual Structure
5
FHV Series Smart Camera Setup Manual (Z408-E1)

Manual Structure
6FHV Series Smart Camera Setup Manual (Z408-E1)

Sections in This Manual
1
2
3
4
5
1
2
3
4
5
I
Confirm the Package
Overview of FHV series
Configuration
Handling and Installation Environment
Installation
I
6
7
Index
6
7
Power Supply and I/O Interface
Software Setup
I
Sections in This Manual
7
FHV Series Smart Camera Setup Manual (Z408-E1)

CONTENTS
Introduction .............................................................................................................. 1
Intended Audience...........................................................................................................................................1
Applicable Products .........................................................................................................................................1
Relevant Manuals..................................................................................................... 2
Manual Structure...................................................................................................... 4
Page Structure.................................................................................................................................................4
Special Information ..........................................................................................................................................5
Terms and Conditions Agreement........................................................................ 12
Warranty, Limitations of Liability ....................................................................................................................12
Application Considerations ............................................................................................................................13
Disclaimers ....................................................................................................................................................13
Safety Precautions................................................................................................. 15
Symbols and the Meanings for Safety Precautions Described in This Manual .............................................15
Meanings of Alert Symbols ............................................................................................................................15
Warning..........................................................................................................................................................16
Precautions for Safe Use ...................................................................................... 18
Condition of the Fitness of OMRON Products ...............................................................................................18
Installation Environment ................................................................................................................................18
Power Supply and Wiring ..............................................................................................................................18
Mounting ........................................................................................................................................................19
Others ............................................................................................................................................................20
Precautions for Correct Use ................................................................................. 21
Installation Location .......................................................................................................................................21
Power Supply, Connection, and Wiring..........................................................................................................21
Maintenance ..................................................................................................................................................22
Beam .............................................................................................................................................................22
Image Sensor ................................................................................................................................................22
Communications with Upper Equipment........................................................................................................22
Failsafe Measures .........................................................................................................................................23
Warm-up ........................................................................................................................................................23
Camera Installation........................................................................................................................................23
Others ............................................................................................................................................................23
LED Safety.....................................................................................................................................................24
Regulations and Standards .................................................................................. 25
Using Product Outside Japan ........................................................................................................................25
Conformance to KC Standards......................................................................................................................25
Conformance to EC/EU Directives and UK Legislations ...............................................................................25
WEEE Directive .............................................................................................................................................25
Related Manuals..................................................................................................... 26
Terminology............................................................................................................ 27
Revision History..................................................................................................... 31
Sections in This Manual .......................................................................................... 7
CONTENTS
8FHV Series Smart Camera Setup Manual (Z408-E1)

Section 1 Confirm the Package
1-1 Smart Camera.........................................................................................................................1-2
1-1-1 FHV7£-£££££-C Series........................................................................................................1-2
1-1-2 FHV7£-£££££-S££ Series .................................................................................................1-2
1-1-3 FHV7£-£££££-H££ Series .................................................................................................1-3
1-1-4 FHV7£-£££££-S££-££ Series..........................................................................................1-3
1-1-5 FHV7£-£££££-H££-££ Series..........................................................................................1-4
1-2 Sold Separately ......................................................................................................................1-5
1-2-1 Smart Camera Data Unit.............................................................................................................1-5
1-2-2 Cables .........................................................................................................................................1-5
1-2-3 Modules.......................................................................................................................................1-9
1-2-4 Accessories...............................................................................................................................1-10
1-2-5 Lighting and Lighting Controller ................................................................................................1-12
1-2-6 Software ....................................................................................................................................1-13
Section 2 Overview of FHV Series
2-1 Overview of System...............................................................................................................2-2
2-1-1 Basic System of Measurement ...................................................................................................2-2
2-2 Flow of Use Procedure ..........................................................................................................2-9
Section 3 Configuration
3-1 Smart Camera.........................................................................................................................3-3
3-1-1 FHV Series..................................................................................................................................3-3
3-2 Smart Camera Data Unit......................................................................................................3-13
3-2-1 Specifications ............................................................................................................................3-13
3-2-2 Component Names and Functions............................................................................................3-14
3-2-3 Dimensions ...............................................................................................................................3-15
3-3 Cables ...................................................................................................................................3-17
3-3-1 I/O Cables .................................................................................................................................3-17
3-3-2 Ethernet Cables ........................................................................................................................3-26
3-3-3 Smart Camera Data Unit Cables...............................................................................................3-34
3-3-4 Junction cable for external lighting............................................................................................3-42
3-4 Lens Modules .......................................................................................................................3-43
3-4-1 Specifications ............................................................................................................................3-43
3-4-2 Optical Chart .............................................................................................................................3-46
3-5 C Mount Lenses ...................................................................................................................3-51
3-5-1 Specifications ............................................................................................................................3-51
3-5-2 Meaning of Optical Chart ..........................................................................................................3-61
3-6 Lighting Modules .................................................................................................................3-68
3-6-1 Specifications ............................................................................................................................3-68
3-6-2 Dimensions ...............................................................................................................................3-69
3-7 Optical Filters .......................................................................................................................3-70
3-7-1 Specifications ............................................................................................................................3-70
3-7-2 Dimensions ...............................................................................................................................3-70
3-8 Waterproof Hoods................................................................................................................3-72
3-8-1 Specifications ............................................................................................................................3-72
3-8-2 Dimensions ...............................................................................................................................3-73
3-9 Mounting Fixtures................................................................................................................3-77
3-9-1 Specfications.............................................................................................................................3-77
3-9-2 Dimensions ...............................................................................................................................3-77
3-10 Waterproof Packings ...........................................................................................................3-79
CONTENTS
9
FHV Series Smart Camera Setup Manual (Z408-E1)

3-10-1 Specifications ............................................................................................................................3-79
3-10-2 Dimensions ...............................................................................................................................3-79
3-11 Waterproof Caps ..................................................................................................................3-81
3-11-1 Specifications ............................................................................................................................3-81
3-11-2 Dimensions ...............................................................................................................................3-81
3-12 Lightproof Sheet ..................................................................................................................3-83
3-12-1 Specifications ............................................................................................................................3-83
3-12-2 Dimensions ...............................................................................................................................3-83
3-13 Special Covers .....................................................................................................................3-84
3-13-1 Specifications ............................................................................................................................3-84
3-13-2 Dimensions ...............................................................................................................................3-84
3-14 Replacement Screws for Micro SD Card Cover ................................................................3-86
3-14-1 Specifications ............................................................................................................................3-86
3-14-2 Dimensions ...............................................................................................................................3-86
3-15 Software................................................................................................................................3-87
3-15-1 Remote Operation Tool .............................................................................................................3-87
3-15-2 Simulation Software ..................................................................................................................3-87
3-15-3 Sysmac Studio ..........................................................................................................................3-87
Section 4 Handling and Installation Environment
4-1 Warning...................................................................................................................................4-2
Section 5 Installation
5-1 Assembling Equipment .........................................................................................................5-2
5-1-1 C Mount Lens / IP40 Configuration .............................................................................................5-2
5-1-2 C Mount Lens / IP67 Configuration .............................................................................................5-3
5-1-3 Standard Lens Module / IP40 Configuration ...............................................................................5-5
5-1-4 Standard Lens Module / IP67 Configuration ...............................................................................5-8
5-1-5 High-speed Lens Module / IP40 Configuration .........................................................................5-10
5-1-6 High-speed Lens Module / IP67 Configuration .........................................................................5-13
5-1-7 Lens Module / Internal Lighting / IP67 Configuration ................................................................5-15
5-2 Mounting the Data Unit for the Smart Camera ..................................................................5-19
5-2-1 Mounting to DIN Rail .................................................................................................................5-19
5-3 Installing the Smart Camera ...............................................................................................5-21
5-3-1 How to Connect.........................................................................................................................5-21
5-3-2 When Connecting the Smart Camera to a Lighting Controller ..................................................5-25
Section 6 Power Supply and I/O Interface
6-1 When Turning Power ON and OFF .......................................................................................6-2
6-2 Fail-safe Measures.................................................................................................................6-4
6-3 Precautions for I/O Interface.................................................................................................6-5
6-4 I/O Cable Interface (Power Supply, I/O, RS-232C)...............................................................6-6
6-4-1 Recommended Power Supply for FHV Series ............................................................................6-6
6-4-2 Cables .........................................................................................................................................6-7
6-4-3 Pin Layout .................................................................................................................................6-12
6-4-4 Interface Specifications .............................................................................................................6-14
6-4-5 I/O Interface Input / Output Circuit Diagram..............................................................................6-16
6-4-6 RS-232C Interface ....................................................................................................................6-18
6-5 Ethernet Interface ................................................................................................................6-19
6-5-1 Cables .......................................................................................................................................6-20
CONTENTS
10 FHV Series Smart Camera Setup Manual (Z408-E1)

6-5-2 Pin Layout .................................................................................................................................6-24
6-6 Interface for the Data Unit for Smart Camera....................................................................6-25
6-6-1 Cables / I/O Connectors, and Terminals ...................................................................................6-26
6-6-2 Pin Layout .................................................................................................................................6-28
6-6-3 Parallel Interface Specifications ................................................................................................6-31
6-6-4 I/O Interface Input/Output Circuit Diagrams ..............................................................................6-33
6-6-5 EtherCAT Interface Specifications (FHV-SDU30) .....................................................................6-36
6-7 Inserting and Removing the MicroSD Card.......................................................................6-38
6-7-1 How to Insert / Remove the MicroSD Card ...............................................................................6-38
Section 7 Software Setup
7-1 Setting up the Software.........................................................................................................7-2
7-1-1 Recommended Operational Environment ...................................................................................7-2
7-1-2 Installation ...................................................................................................................................7-2
7-1-3 Windows......................................................................................................................................7-3
7-1-4 Use Procedures ..........................................................................................................................7-4
7-2 Operating the Smart Camera Remotely [Remote Operation Tool] ..................................7-10
7-2-1 Summary...................................................................................................................................7-10
7-2-2 Environment Settings ................................................................................................................7-11
7-2-3 Network Settings for the Remote Operation PC .......................................................................7-11
7-2-4 Network Settings for the Smart Camera ...................................................................................7-12
7-2-5 Network Settings for the Smart Camera with Remote Operation Tool ......................................7-14
7-2-6 Launching the Remote Operation .............................................................................................7-14
7-2-7 Terminating the Remote Operation ...........................................................................................7-17
7-3 Using the Simulation Software [Simulation Software] .....................................................7-18
7-3-1 Introduction ...............................................................................................................................7-18
7-3-2 Available Image Formats...........................................................................................................7-18
7-3-3 Operational Precautions............................................................................................................7-18
Index
CONTENTS
11
FHV Series Smart Camera Setup Manual (Z408-E1)

Terms and Conditions Agreement
Warranty, Limitations of Liability
Warranties
lExclusive Warranty
Omron’s exclusive warranty is that the Products will be free from defects in materials and work-
manship for a period of twelve months from the date of sale by Omron (or such other period ex-
pressed in writing by Omron). Omron disclaims all other warranties, express or implied.
lLimitations
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT
NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF
THE PRODUCTS. BUYER ACKNOWLEDGES THAT IT ALONE HAS DETERMINED THAT THE
PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE.
Omron further disclaims all warranties and responsibility of any type for claims or expenses based
on infringement by the Products or otherwise of any intellectual property right.
lBuyer Remedy
Omron’s sole obligation hereunder shall be, at Omron’s election, to (i) replace (in the form originally
shipped with Buyer responsible for labor charges for removal or replacement thereof) the non-com-
plying Product, (ii) repair the non-complying Product, or (iii) repay or credit Buyer an amount equal
to the purchase price of the non-complying Product; provided that in no event shall Omron be re-
sponsible for warranty, repair, indemnity or any other claims or expenses regarding the Products
unless Omron’s analysis confirms that the Products were properly handled, stored, installed and
maintained and not subject to contamination, abuse, misuse or inappropriate modification. Return
of any Products by Buyer must be approved in writing by Omron before shipment. Omron Compa-
nies shall not be liable for the suitability or unsuitability or the results from the use of Products in
combination with any electrical or electronic components, circuits, system assemblies or any other
materials or substances or environments. Any advice, recommendations or information given orally
or in writing, are not to be construed as an amendment or addition to the above warranty.
See http://www.omron.com/global/ or contact your Omron representative for published information.
Limitation on Liability; Etc
OMRON COMPANIES SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT, INCIDENTAL, OR CON-
SEQUENTIAL DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN ANY
Terms and Conditions Agreement
12 FHV Series Smart Camera Setup Manual (Z408-E1)

WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED IN CONTRACT,
WARRANTY, NEGLIGENCE OR STRICT LIABILITY.
Further, in no event shall liability of Omron Companies exceed the individual price of the Product on
which liability is asserted.
Application Considerations
Suitability of Use
Omron Companies shall not be responsible for conformity with any standards, codes or regulations
which apply to the combination of the Product in the Buyer’s application or use of the Product. At Buy-
er’s request, Omron will provide applicable third party certification documents identifying ratings and
limitations of use which apply to the Product. This information by itself is not sufficient for a complete
determination of the suitability of the Product in combination with the end product, machine, system, or
other application or use. Buyer shall be solely responsible for determining appropriateness of the par-
ticular Product with respect to Buyer’s application, product or system. Buyer shall take application re-
sponsibility in all cases.
NEVER USE THE PRODUCT FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY OR IN LARGE QUANTITIES WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE
HAS BEEN DESIGNED TO ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT(S) IS
PROPERLY RATED AND INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIP-
MENT OR SYSTEM.
Programmable Products
Omron Companies shall not be responsible for the user’s programming of a programmable Product, or
any consequence thereof.
Disclaimers
Performance Data
Data presented in Omron Company websites, catalogs and other materials is provided as a guide for
the user in determining suitability and does not constitute a warranty. It may represent the result of
Omron’s test conditions, and the user must correlate it to actual application requirements. Actual per-
formance is subject to the Omron’s Warranty and Limitations of Liability.
Change in Specifications
Product specifications and accessories may be changed at any time based on improvements and oth-
er reasons. It is our practice to change part numbers when published ratings or features are changed,
or when significant construction changes are made. However, some specifications of the Product may
Terms and Conditions Agreement
13
FHV Series Smart Camera Setup Manual (Z408-E1)

be changed without any notice. When in doubt, special part numbers may be assigned to fix or estab-
lish key specifications for your application. Please consult with your Omron’s representative at any
time to confirm actual specifications of purchased Product.
Errors and Omissions
Information presented by Omron Companies has been checked and is believed to be accurate; how-
ever, no responsibility is assumed for clerical, typographical or proofreading errors or omissions.
Terms and Conditions Agreement
14 FHV Series Smart Camera Setup Manual (Z408-E1)

Safety Precautions
Symbols and the Meanings for Safety Precautions Described in This
Manual
The following notation is used in this manual to provide precautions required to ensure safe usage of a
Sensor Controller. The safety precautions that are provided are extremely important to safety.
Always read and heed the information provided in all safety precautions.
The following notation is used.
WARNING
Indicates a potentially hazardous situation which, if not avoid-
ed, will result in minor or moderate injury, or may result in seri-
ous injury or death.
Additionally there may be significant property damage.
Caution
Indicates a potentially hazardous situation which, if not avoid-
ed, may result in minor or moderate injury or in property dam-
age.
Meanings of Alert Symbols
General Prohibition
Indicates general prohibitions, including warnings, for which there is no specific
symbol
General Caution
Indicates general cautions, including warnings, for which there is no specific sym-
bol.
The filled circle symbol indicates operations that you must do.
The specific operation is shown in the circle and explained in text.
This example shows a general precaution for something that you must do.
Electrical Hazard
Indicates the possible danger of electric shock under specific conditions.
LED light Hazard
Indicates the possible danger of LED radiation or light.
High Temperature Caution
Indicates the possible danger of injury by high temperature under specific condi-
tions.
Safety Precautions
15
FHV Series Smart Camera Setup Manual (Z408-E1)

Warning
WARNING
This product must be used according to this manual and Instruction Sheet.
Failure to observe this may result in the impairment of functions and performance of the
product.
This product is not designed or rated for ensuring the safety of persons.
Do not use it for such purposes.
Never connect the AC power supply with this product. When the AC power supply is con-
nected, it causes the electric shock and a fire.
If you keep watching the LED light, it may have an adverse effect on the eyes, do not stare
directly into the light emitted from the LED. If a specular object is used, take care not to allow
reflected light to enter your eyes.
Do not touch the terminals while the power supply is ON.
Doing so may result in electrical shock.
Please take external safety measures so that the system as a whole should be on the safe
side even if a failure of a smart camera or an error due to an external factor occurred. An
abnormal operation may result in serious accident.
Please take fail-safe measures on your side in preparation for an abnormal signal due to sig-
nal conductor disconnection and/or momentary power interruption.
An abnormal operation may result in a serious accident.
Anti-virus protection
Install the latest commercial-quality antivirus software on the computer connected to the con-
trol system and maintain to keep the software up-to-date.
Security measures to prevent unauthorized access
Take the following measures to prevent unauthorized access to our products.
•Install physical controls so that only authorized personnel can access control systems and
equipment.
•Reduce connections to control systems and equipment via networks to prevent access
from untrusted devices.
•Set strong passwords and change them frequently.
•Scan virus to ensure safety of USB drives or other external storages before connecting
them to control systems and equipment.
Data input and output protection
Validate backups and ranges to cope with unintentional modification of input/output data to
control systems and equipment.
•Checking the scope of data
•Checking validity of backups and preparing data for restore in case of falsification and ab-
normalities
•Safety design, such as emergency shutdown and fail-soft operation in case of data tam-
pering and abnormalities
Data recovery
Backup data and keep the data up-to-date periodically to prepare for data loss.
Safety Precautions
16 FHV Series Smart Camera Setup Manual (Z408-E1)

When using an intranet environment through a global address, connecting to an unauthor-
ized terminal such as a SCADA, HMI or to an unauthorized server may result in network se-
curity issues such as spoofing and tampering. You must take sufficient measures such as re-
stricting access to the terminal, using a terminal equipped with a secure function, and locking
the installation area by yourself.
When constructing an intranet, communication failure may occur due to cable disconnection
or the influence of unauthorized network equipment. Take adequate measures, such as re-
stricting physical access to network devices, by means such as locking the installation area.
When using a device equipped with the USB flash drive or SD Memory Card function, there
is a security risk that a third party may acquire, alter, or replace the files and data in the re-
movable media by removing the removable media or unmounting the removable media.
Please take sufficient measures, such as restricting physical access to the Controller or tak-
ing appropriate management measures for removable media, by means of locking the instal-
lation area, entrance management, etc., by yourself.
Caution
Danger of burns. Do not touch the case while the power is ON or just after power is turned
OFF, since it remains extremely hot.
When mounting the lighting module, lens module, and covers, make sure that the screws are
tightened securely. If not, the product may break or malfunction, or injury may result.
Safety Precautions
17
FHV Series Smart Camera Setup Manual (Z408-E1)

Precautions for Safe Use
Condition of the Fitness of OMRON Products
•Omron products are designed and manufactured as general-purpose products for use in general in-
dustrial applications. They are not intended to be used in the following critical applications. If you are
using Omron products in the following applications, Omron shall not provide any warranty for such
Omron products, unless otherwise specifically agreed or unless the specific applications are intend-
ed by Omron.
a) Applications with stringent safety requirements, including but not limited to nuclear power control
equipment, combustion equipment, aerospace equipment, railway equipment, elevator/lift equip-
ment, amusement park equipment, medical equipment, safety devices and other applications
that could cause danger/harm to people's body and life.
b) Applications that require high reliability, including but not limited to supply systems for gas, water
and electricity, etc., 24 hour continuous operating systems, financial settlement systems and oth-
er applications that handle rights and property.
c) Applications under severe condition or in severe environment, including but not limited to out-
door equipment, equipment exposed to chemical contamination, equipment exposed to electro-
magnetic interference and equipment exposed to vibration and shocks.
d) Applications under conditions and environment not described in specifications.
1. In addition to the applications listed from (a) to (d) above, Omron products (see definition) are not
intended for use in vehicles designed human transport (including two wheel vehicles). Please do
NOT use Omron products for vehicles designed human transport. Please contact the Omron sales
staff for information on our automotive line of products.
2. The above is part of the Terms and Conditions Agreement. Please use carefully read the contents
of the guarantee and disclaimers described in our latest version of the catalog, data sheets and
manuals.
Installation Environment
• Do not use the product in areas where flammable or explosive gases are present.
• Do not install the product close to high-voltage devices and power devices in order to secure the
safety of operation and maintenance.
• Do not install the product to a place where vibrations and/or impacts are expected.
• Do not install the product near to a device causing noises. if the product is installed in a noisy envi-
ronment and operational errors are caused, be sure to take shielding measures.
Power Supply and Wiring
• Make sure to use the product with the power supply voltage specified. If a DC voltage exceeding the
rating or an AC voltage is applied, the circuit parts may be burnt or exploded.
• Do not connect the power supply with polarity reversed.
• Use a DC power supply with safety measures against high-voltage spikes (safety extra low-voltage
circuits on the secondary side).
• Use an independent power source for this product. Do not use a shared power source.
Precautions for Safe Use
18 FHV Series Smart Camera Setup Manual (Z408-E1)
