Motor Contactor J7KN 25
Motor Contactor
J7KN
Main contactor
• AC & DC operated
• Integrated auxiliary contacts
• Screw fixing and snap fitting (35 mm DIN rail) up to 37 kW
• Range from 4 to 110 kW (AC 3, 380/415V)
• Finger proof (BGV A2)
• System contactors for Fuseless Load Feeders with integrated
link module
Accessories
• front mounted single pole additional auxiliary contacts
(1 NO or 1 NC)
• Side mounted additional auxiliary contacts (1 NO/1 NC)
• Mechanical interlock
• Suppressors (RC and varistor)
• Pneumatic timer modules
• Link modules MPCB - Motor contactor
Approved Standards
Standard Guide No (US,C)
UL NLDX, NLDX7
IEC 947-4-1 see page 95
VDE 0660
EN 60947-4-1

26 Motor Contactor J7KN
Ordering Information
■Model Number Legend
1. Motor Contactors
1) Motor Contactor
2) G: DC solenoid motor contactor
3) Rated Motor Current (AC3 400V)
10: 10A
14: 14A
18: 18A
22: 22A
24: 24A
32: 32A
40: 40A
50: 50A
62: 62A
74: 74A
85: 85A
110: 110A
151: 150A
176: 175A
200: 200A
4) Integrated auxiliary contact
10: 1NO 0NC
01: 0NO 1NC
21: 2NO 1NC
22: 2NO 2NC
: 0NO 0NC
4: 4 main poles
5) Coil voltage (AC operated)
24: AC24V 50/60Hz
48: AC48V 50Hz
90: AC100V 50/60 Hz
110: AC110V 50Hz, AC110-120V 60Hz
180: AC180-210V 50Hz, AC200-240V 60Hz
230: AC220-240V 50Hz, AC240V 60Hz
400: AC380-415V 50Hz, AC415-440V 60Hz
500: AC500-550V 50Hz, AC550-600V 60Hz
Coil voltage(DC operated)
24D: DC24V
48D: DC48V
110D: DC110V
125D: DC125V
Coil voltage(DC solenoid operated - G-type)
24D: DC24V
48D: DC48V
60D: DC60V
110D: DC110V
125D: DC125V
220D: DC220V
Coil voltage(AC & DC operated) for J7KN 151 & J7KN 176 only
24: 24V 50/60Hz, 24VDC
48: 48V 50/60Hz, 48VDC
110: 110-120V 50/60Hz, 110VDC
230: 220-240V 50/60Hz, 220VDC
400: 380-415V 50/60Hz
2. Sytem Contactors for Fuseless Load Feeders with integrated
Link Module
1) Additional reference for LVSG
2) Rated Motor Current (AC 3 400 V)
10: 10 A
14: 14 A
18: 18 A
22: 22 A
3) Integrated Auxiliary Contact
10: 1NO 0NC
01: 0NO 1NC
4) Coil voltage (AC operated)
24: AC24V 50/60Hz
48: AC48V 50Hz
110: AC110V 50Hz, AC110-120V 60Hz
180: AC180-210V 50Hz, AC200-240V 60Hz
230: AC220-240V 50Hz, AC240V 60Hz
400: AC380-415V 50Hz, AC415-440V 60Hz
500: AC500-550V 50Hz, AC550-600V 60Hz
5) Attached link module VK 3
3. Aux. Contact Modules for Motor Contactors
1) Auxiliary Contact Modules
2) B: for motor contactor (4-37kW)
C: for motor contactor (11-37kW)
D: for motor contactor (75-90kW)
E: for motor contactor (110kW)
3) Combination of NO/NC contacts
10: 1NO 0NC
01: 0NO 1NC
11: 1NO 1NC
22: 2NO 2NC
4) S: side mounting for motor contactor (11-37kW and
75-90 kW)
: front mounting for motor contactor (4-37kW)
A: 6A version
F: front mounting for motor contactor (75-90kW)
U: EM and LB version
4. Accessories for Motor Contactors
(Pneumatic Timers)
1) Accessories for Motor Contactors
2) B: Motor Contactor (4-18.5kW)
3) TP: Pneumatic Timer
4) 40: 40 sec
180: 180 sec
5) DA: ON-delayed
IA: OFF-delayed
5. Accessories for Motor Contactors (Mechanical Interlock)
1) Accessories for Motor Contactors
2) B: Motor Contactor (4-18.5kW)
C: Motor Contactor (11-37kW)
D: Motor Contactor (45-55kW)
E: Motor Contactor (75-90kW)
3) ML: Mechanical Interlock
J7KN#-###-##-####
1324
5J7KN-###-##-###-VK3
123
45
J73KN-#-##-#
123
4
J74KN-#-## ### ##
123
45
J74KN-#-##
123

Motor Contactor J7KN 27
6. Accessories for Motor Contactors (RC Suppressor units)
1) Accessories for Motor Contactors
2) A: for Mini Motor Contactor and Motor Contactor
(4-18.5kW)
(between DIN-rail and Contactor)
B: for Mini Motor Contactor and Motor Contactor
(4-55kW)
C: for Motor Contactor (4-37kW) to snap on the contactor
D: for Mini Motor Contactor (4-5.5kW)
3) RC: RC-surge suppressors
4) 48: 24 - 48 VAC/DC (A+B type)
230: 110 - 230 VAC/DC (A+B type)
400: 250 - 415 VAC/DC (A+B type)
24: 12 - 48 VAC/DC (C+D type)
110: 48 - 127 VAC/DC (C+D type)
230: 110 - 250 VAC/DC (C+D type)
7. Accessories for Motor Contactors (4-37 kW) (Varistor units)
1) Accessories for Motor Contactors
2) A: for Motor Contactor (4-11kW) to snap on
to coil terminals
B: for Motor Contactor (4-37kW) to snap on to contactor
3) VG: Varistor Suppressors
4) 230: 110-230VAC/DC
400: 250-415VAC/DC
8. Accessories for Motor Contactors
(Additional Terminals and Terminal Covers)
1) Accessories for Motor Contactors
2) LG-9030: for Motor Contactors (22-37 kW)
Additional Terminal for Single Pole
LG-11224: for Motor Contactors (75-90 kW)
Additional Terminal for Single Pole
LG-10404: for Motor Contactors (75-90 kW)
Terminal Cover for 3 terminals
Marking Systems for contactors J7KNA - J7KN 74 and aux.
contact blocks J73KN-B
P487-1: Marking plate, 2-section without marking, divisible
P245-1: Marking plate, 4-section without marking, divisible
9. Insulated wiring systems for motor contactors
Parallel or reverse contactors
Star-Delta contactors
1) Additional reference for LVSG
2) Wiring system
3) Combination of 2 contactors, type:
21 = J7KN 10 - ..22
41 = J7KN 24 - ..40
Star - delta combination of 3 contactors, type:
22 = J7KN 10 - ..22
J74KN-#-## ###
123
4
J74KN-#-## ###
123
4
J7KN-#######
12
J75-WK-##
1 2 3

28 Motor Contactor J7KN
■List of Models
Contactors 3-pole
•Up to 210A AC3
•Up to 350A AC1
•DIN-rail mounting up to AC3 74A
•International Approvals
•Data according to IEC 947 /
EN 60947
Ratings
AC3 400V Motor 10A 14A 18A 22A 24A 32A 40A 50A 62A 74A
380-400V 4kW 5,5kW 7,5kW 11kW 11kW 15kW 18,5kW 22kW 30kW 37kW
660-690V 5,5kW 7,5kW 10kW 10kW 15kW 18,5kW 18,5kW 30kW 37kW 45kW
AC1 690V at 40°C 25A 25A 32A 32A 50A 65A 80A 110A 120A 130A
Type J7KN-
10-10
J7KN-
14-10
J7KN-
18-10
J7KN-
22-10
J7KN-24 J7KN-32 J7KN-40 J7KN-50 J7KN-62 J7KN-74
Auxiliary contacts 1NO 1NO 1NO 1NO - - - - - -
Type J7KN-
10-01
J7KN-
14-01
J7KN-
18-01
J7KN-
22-01
------
Auxiliary contacts 1NC 1NC 1NC 1NC - - - - - -
Cable cross-section
Solid mm20,75 - 6 1,5 - 25 4 - 50
Flexible mm21 - 4 2,5 - 16 10 - 35
Cables per clamp 2 1 + 1 1 + 1
Auxiliary contact
Ith 40°C A 16 - -
AC15 230V A 12 - -
400V A 4 - -
Power consumption of coils
Inrush VA 33 - 45 90 - 115 140 - 165
Hold VA 7 - 10 9 - 13 13 - 18
Operation range of coils 0,85 - 1,1 0,85 - 1,1 0,85 - 1,1
Mounting 35mm DIN-rail or base
Additional aux. contact blocks
Front mounting
contact configuration 1NO 1NC
maximal 4 J73KN-B..
Additional aux. contact blocks
Side mounting -
contact configuration 1NO+1NC
Overload Relay (thermal)
Single phase protection
Temperature compensation
Trip and alarm contacts
Type J7TKN-B J7TKN-C J7TKN-D
Setting Ranges Setting Ranges Setting Ranges
0,12 - 0,18A 4 - 6A 28 - 42A 40 - 52A
0,18 - 0,27A 6 - 9A 52 - 65A
0,27 - 0,4A 8 - 11A 60 - 74A
0,4 - 0,6A 10 - 14A
0,6 - 0,9A 13 - 18A
0,8 - 1,2A 17 - 24A
1,2 - 1,8A 23 - 32A
1,8 - 2,7A
2,7 - 4A

Motor Contactor J7KN 29
Ratings
AC3 400V Motor 85A 110A 150A 175A 210A
380-400V 45kW 55kW 75kW 90kW 110kW
660-690V 55kW 55kW 75kW 110kW 132kW
AC1 690V at 40°C 150A 170A 230A 250A 350A
Type J7KN-
85-22
J7KN-
110-22
J7KN-151 J7KN-176 J7KN-200-
21
Auxiliary contacts 2NO+2NC 2NO+2NC - - 2NO+1NC
Type -----
Auxiliarycontacts -----
Cable cross-section
Solid mm210 - 70 10 - 70 busbar busbar busbar
Flexible mm216 - 50 16 - 50 18x4 18x4 22x4
Cablesperclamp 11111
Auxiliary contact
Ith 40°C A 16 10
AC15 230V A 12 3
400V A 6 2
Power consumption of coils
Inrush VA 350 - 420 350 350 700
hold VA 23 - 29 5 5 20
Operation range of coils 0,85 - 1,1 0,85 - 1,1
Mounting base
Additional aux. contact blocks
Front mounting - 2NO + 2NC
contact configuration
Additional aux. contact blocks
Side mounting - 1NO + 1NC -
contact configuration
Overload Relay (thermal)
Single phase protection
Temperature compensation
Trip and alarm contacts
Type J7TKN-E J7TKN-F
Setting Ranges Setting Ranges
60 - 90A 100 - 150A
80 - 120A 140 - 220A
Busbar Sets
J74TK-SU-176 J74TK-SU-
200

30 Motor Contactor J7KN
Contactors 3-pole
AC Operated
Ratings Rated
Current
Aux. Contacts Type Pack Weight
AC2, AC3 AC1 Built-in Additional
pcs.
380V
400V
415V
kW
500V
kW
660V
690V
kW
690V
ANO NC
see
page 33
Ty p e
Coil Voltage*1
24 24V 50/60Hz
110 110V 50Hz
230 220-240V 50Hz
*1 Coil voltage range and other coil voltages see page 36
kg/pc.
4
4
5.5
5.5
7.5
7.5
11
11
5.5
5.5
7.5
7.5
10
10
10
10
5.5
5.5
7.5
7.5
10
10
10
10
25
25
25
25
32
32
32
32
1
-
1
-
1
-
1
-
-
1
-
1
-
1
-
1
max. 4
J73KN-B
J7KN-10-10###
J7KN-10-01###
J7KN-14-10###
J7KN-14-01###
J7KN-18-10###
J7KN-18-01###
J7KN-22-10###
J7KN-22-01###
1
1
1
1
1
1
1
1
0.23
0.23
0.23
0.23
0.23
0.23
0.23
0.23
4
4
5.5
5.5
7.5
7.5
11
11
5.5
5.5
7.5
7.5
10
10
10
10
5.5
5.5
7.5
7.5
10
10
10
10
25
25
25
25
32
32
32
32
--- ---
11
15
18.5
15
18.5
18.5
15
18.5
18.5
50
65
80
-
-
.
-
-
-
max. 4
J73KN-B +
2 J73KN-
C-11S
J7KN-24###
J7KN-32###
J7KN-40###
1
1
1
0.48
0.48
0.48
22
30
37
30
37
45
30
37
45
110
120
130
-
-
-
-
-
-
max. 4
J73KN-B +
2 J73KN-
C11S
J7KN-50###
J7KN-62###
J7KN-74###
1
1
1
0.85
0.85
0.85
Ratings Rated
Current
Aux. Contacts Type Pack Weight
AC2, AC3 AC1 Built-in
380V
415V
kW
500V
kW
660V
690V
kW
690V
ANO NC
Coil Voltage*1
230 220-230V 50Hz
400 380-400V 50Hz pcs. kg/pc.
45
55
55
75
55
55
150
170
2
2
2
2
J7KN-85-22###
J7KN-110-22###
1
1
1.8
1.9
75
90
75
90
75
90
230
250
-
-
-
-
max. 3
1 x J73KN-
D22F or
1 x J73KN-
D11F and
2 x J73KN-
D11S
J7KN-151###*2
J7KN-176###*2
*2 AC and DC in one coil
1
1
4
4
110 132 132 350 2 1 J73KN-E-
22
J7KN-200-21###*2 17.3

Motor Contactor J7KN 31
DC Operated
Aux. Contacts
see page 33
Type Coil voltage Pack Weight Accept Overload
Relay
Busbar Set for
Overload Relay
Wiring Diagram
Built-in Additional 24
48
60
110
125
220
24V DC
48V DC
60V DC
110V DC
125V DC
220V DC
page 56 page 57
NO NC Ty p e pcs kg/pc. Ty p e Ty pe
Coil Circuits see page 35
Terminal Markings
1
-
1
-
1
-
1
-
-
1
-
1
-
1
-
1
max. 3
J73KN-B*1
*1 Only 3 additional Aux. Contacts are possible! (See also the wiring diagrammms coil circuit DC operated page 35)
J7KN-10-10###D
J7KN-10-01###D
J7KN-14-10###D
J7KN-14-01###D
J7KN-18-10###D
J7KN-18-01###D
J7KN-22-10###D
J7KN-22-01###D
1
1
1
1
1
1
1
1
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
J7TKN-B -
-
-
-
-
-
-
-
-10
-01
1
-
1
-
1
-
1
-
-
1
-
1
-
1
-
1
max. 4
J73KN-B
J7KNG-10-10###D
J7KNG-10-01###D
J7KNG-14-10###D
J7KNG-14-01###D
J7KNG-18-10###D
J7KNG-18-01###D
J7KNG-22-10###D
J7KNG-22-01###D
1
1
1
1
1
1
1
1
0.53
0.53
0.53
0.53
0.53
0.53
0.53
0.53
J7TKN-B -
-
-
-
-
-
-
-
-10
-01
-
-
-
-
-
-
-
-
-
-
-
-
max. 3
J73KN-B*1
+
2 J73KN-
C-11S
J7KN-24###D
J7KNG-24###D
J7KN-32###D
J7KNG-32###D
J7KN-40###D
J7KNG-40###D
1
1
1
1
1
1
0.55
0.57
0.55
0.57
0.55
0.57
J7TKN-B
J7TKN-C
-
-
-
-
-
-
-
-
-
-
-
-
max. 3
J73KN-B*1
+
2 J73KN-
C-11S
J7KN-50###D
J7KN-62###D
J7KN-74###D
1
1
1
0.9
0.9
0.9
J7TKN-D
Aux. Contacts Type Coil voltage Weight Accept Overload
Relay
Busbar Set for
Overload Relay
Built-in page 56 page 57
NO NC
110
220
110V DC
220V DC kg/pc. Ty p e Type
2
2
1
1
-
-
J7KN-85-21###D
J7KN-110-21###D
1
1
1.8
1.9
J7TKN-E -21/-22
--max.3
1 x J73KN-
D22 or
1 x J73KN-
D11 and
2 x J73KN-
D11S
J7KN-151-###*2
J7KN-176-###*2
*2 AC and DC in one coil
1
1
4
4
J7TKN-F
J7TKN-F
J73TK-SU-176
21 J7KN-200-21###*2 1 7.3 J7TKN-F J73TK-SU-200 -21

32 Motor Contactor J7KN
System Contactors for Fuseless Load Feeders with integrated Link Module (see page 72)
AC Operated
Contactors 4-pole
AC Operated
DC Operated
Ratings Rated
Current
Aux. Contacts Type Pack Weight
AC2, AC3 AC1 Built-in Additional
380V
400V
415V
kW
500V
kW
660V
690V
kW
690V
ANO NC
see
page 33
Ty p e
Coil Voltage*1
24 24V 50/60Hz
110 110V 50Hz
230 220-240V 50Hz
*1 Coil voltage range and other coil voltages see page 36
pcs. kg/pc.
4
5.5
7.5
11
5.5
7.5
10
10
5.5
7.5
10
10
25
25
32
32
1
1
1
1
-
-
-
-
max. 4
J73KN-B
J7KN-10-10 ###-VK3
J7KN-14-10 ###-VK3
J7KN-18-10 ###-VK3
J7KN-22-10 ###-VK3
1
1
1
1
0.25
0.25
0.25
0.25
Ratings Rated
Current
Aux. Contacts
see page 33
Type Pack Weight
AC2,
AC3
AC1 AC1
Built-in Additional
see
below
Ty p e
380V
400V
415V
kW
400V
kW
690V
ANO NC
Coil Voltage*1
24 24V 50/60Hz
110 110V 50Hz
230 220-240V 50Hz
*1 Coil voltage range and other coil voltages see page 36
pcs. kg/pc.
4
5.5
7.5
11
17.5
17.5
22
22
25
25
32
32
-
-
-
-
-
-
-
-
max. 4
J73KN-B
J7KN-10-4 ###
J7KN-14-4 ###
J7KN-18-4 ###
J7KN-22-4 ###
1
1
1
1
0.22
0.22
0.22
0.22
75
90
159
173
230
250
-
-
-
-
max. 3
J73KN-D-11F
J73KN-D-22F
J73KN-D-11S
J7KN-151-4 ###
J7KN-176-4 ###
1
1
4.7
4.7
Ratings Rated
Current
Aux. Contacts
see page 33
Type Pack Weight
AC2,
AC3
AC1 AC1
Built-in Additional
see
below
Ty p e
380V
400V
415V
kW
400V
kW
690V
ANO NC
Coil Voltage*1
24 24V 50/60Hz
110 110V 50Hz
230 220-240V 50Hz
*1 Coil voltage range and other coil voltages see page 36
pcs. kg/pc.
4
5.5
7.5
11
17.5
17.5
22
22
25
25
32
32
-
-
-
-
-
-
-
-
max. 4
J73KN-B
J7KNG-10-4 ###D
J7KNG-14-4 ###D
J7KNG-18-4 ###D
J7KNG-22-4 ###D
1
1
1
1
0.53
0.53
0.53
0.53

Motor Contactor J7KN 33
Auxiliary Contact Blocks for contactors J7KN-10... to -74... type J73KN for low level switching*1
Auxiliary Contact Blocks for contactors J7KN-151... to 176... type J73KN for low level switching
Auxiliary Contact Blocks
for contactors J7KN-24... to KN-74 and J7KN-200... type J73KN for low level switching
Pneumatic Timer for contactors J7KN-10... to -40...
Mechanical Interlocks
1. suitable according to DIN 19240 (test ratings 17V DC, 5mA) Technical data see page 49
Front mounting Rated Operational Current Contacts Type Pack Weight
AC15
230V
AC15
400V
AC1
690V
EM LB
A A A NO NC pcs. kg/pc.
3
3
3
3
6
6
2
2
2
2
4
4
10
10
10
10
25
25
1
-
-
-
1
-
-
1
-
-
-
1
-
-
1
-
-
-
-
-
-
1
-
-
J73KN-B-10
J73KN-B-01
J73KN-B-10U
J73KN-B-01U
J73KN-B-10A
J73KN-B-01A
10
10
10
10
10
10
0.02
0.02
0.02
0.02
0.02
0.02
Rated Operational Current Contacts Type Pack Weight
AC15
230V
AC15
400V
AC1
690V
AAAMounting NO NC pcs. kg/pc.
3
3
2
2
10
10
front 1
2
1
2
J73KN-D-11F
J73KN-D-22F
1
1
0.08
0.08
3 2 10 side 1 1 J73KN-D-11S 10.12
Rated Operational Current Contacts Type Pack Weight
AC15
230V
AC15
400V
AC1
690V
AAAMounting NO NC pcs. kg/pc.
3
3
2
2
10
10
max. 2 side mounting
(J7KN-24-74)
max. 2 front mounting
(J7KN-200)
1
2
1
2
J73KN-C-11S
J73KN-E-22
10
1
0.02
0.12
Function Time range Contacts Ty pe Pack Weight
spcs. kg/pc.
On-delay 0.1 - 40 1 1 - - J74KN-B-TP40DA 10.09
On-delay 10 - 180 1 1 - - J74KN-B-TP180DA 10.09
Off-delay 0.1 - 40 - - 1 1 J74KN-B-TP40IA 10.09
Off-delay 10 - 180 - - 1 1 J74KN-B-TP180IA 10.09
Interlocks contactor with contactor Mounting Type Pack Weight
Ty p e +Type pcs. kg/pc.
J7KN10 - J7KN40 + J7KN10 - J7KN40 horizontal J74KN-B-ML 1 0.006
J7KN24 - J7KN74 + J7KN24 - J7KN74 horizontal J74KN-C-ML 1 0.010
J7KN85 - J7KN110 + J7KN85 - J7KN110 horizontal J74KN-D-ML 1 0.076
J7KN151 - J7KN176 + J7KN151 - J7KN176 horizontal J74KN-E-ML 1 0.076
NO NC NO NC

34 Motor Contactor J7KN
Suppressor Units
Additional Terminals Single Pole
Terminal Covers for terminal protection according DIN 57106, BVG-A2
Marking Systems for contactors J7KNA to J7KN74 and aux. contact blocks J73KN-B
Suitable for Contactors Suitable for Coil Voltages Type Pack
pcs.
Weight
kg/pc.
Varistor
snap on coil
terminals
J7KNA
J7KN10-J7KN22
110 - 230 V AC/DC
250 - 415 V AC/DC
J74KN-A-VG230
J74KN-A-VG400
10
10
0.01
0.01
Varistor
snap on top of
contactor
J7KN10-J7KN74 110 - 230 V AC/DC
250 - 415 V AC/DC
J74KN-B-VG230
J74KN-B-VG400
10
10
0.02
0.02
RC-Unit
snap on
contactor
J7KNA 12 - 48 V AC/DC
48 - 127 V AC/DC
110 - 230 V AC/DC
J74KN-D-RC24
J74KN-D-RC110
J74KN-D-RC230
10
10
10
0.02
0.036
0.036
RC-Unit
snap on
contactor
J7KN10-J7KN74 12 - 48 V AC/DC
48 - 127 V AC/DC
110 - 230 V AC/DC
J74KN-C-RC24
J74KN-C-RC110
J74KN-C-RC230
10
10
10
0.02
0.036
0.036
RC-Unit
to fix via
fixing band or
adhesive strip
with contactor
J7KN85-J7KN110 24 - 48 V AC/DC
110- 250 V AC/DC
250 - 415 V AC/DC
J74KN-B-RC48
J74KN-B-RC230
J74KN-B-RC400
5
5
5
0.04
0.04
0.04
For Contactors Cable Cross-sections to clamp mm² Ty p e Pack Weight
solid or
stranded
flexible flex. with multi-
core cable end
pcs. kg/pc.
J7KN50 - KN74 4 - 35 6 - 25 4 - 25 J74KN-LG-9030 1 0.052
J7KN151 - KN176 16 - 120 --- 16 - 95 J74KN-LG-11224
For Contactors Specification Ty p e Pack Weight
pcs. kg/pc.
J7KN151 - KN176 one unit J74KN-LG-10404 10.12
Description Specification Ty p e Pack Weight
pcs. kg/pc.
Marking Plate 2-section without marking, divisible J74KN-P487-1 100 0.025
Marking Plate 4-section without marking, divisible J74KN-P245-1 100 0.050

Motor Contactor J7KN 35
Insulated wiring systems for motor contactors
■Wiring Diagrams Coil Circuit
*1) 3 Additional Aux. Contacts are possible with the J7KN-.....D
types! (See also page 31)
Description Version
(A)
For contactors Type Pack
pcs
For reversing or parallel
contactors ( 2 parts )
25 J7KN 10 - 22 J75-WK-21 1
40 J7KN 24 - 40 J75-WK-41 1
For star-delta combination
(3 parts)
25 J7KN 10 - 22 J75-WK-22 1
AC operated DC operated
with double winding coil*1
J7KN-10...
to
J7KN-110...
J7KN-10...D
to
J7KN-22...D
J7KN-24...D
to
J7KN-74...D
J7KN-110...D
J7KNG
A2-
A1+
AC and DC operated
J7KN-151...
to
J7KN-176...
J7KN-200-21 ~/
~
~+
-
A1
A2~/
L1 L2
32
31

36 Motor Contactor J7KN
Specifications
■Coil Voltages
Type-suffix for contactor types J7KN-10... to J7KN-74...
Type-suffix for contactor types J7KN-85... to J7KN-110...
Type-suffix for contactor types J7KN-151... to J7KN-200...
Suffix
to contactor
type e.g.
Voltage Marking Rated Control Voltage Us
at the coil range for
50Hz 60Hz
J7KN-10-10-24 for 50Hz
V
for 60Hz
V
min
V
max
V
min
V
max
V
24 24 24 22 24 24 27
48 48 48 44 48 48 52
110 110 110-120 100 110 110 122
180 180-210 200-240 180 210 200 240
230 220-240 240 220 240 240 264
400 380-415 415-440 380 415 415 460
500 500-550 550-600 500 550 550 600
Standard voltages in bold type letter
Suffix
to contactor
type e.g.
Voltage Marking Rated Control Voltage Us
at the coil range for
50Hz 60Hz
J7KN-85-22-24 for 50Hz
V
for 60Hz
V
min
V
max
V
min
V
max
V
20 20 24 20 22 24 26
24 24 24 27 29 32
48 48 60 47 52 56 62
90 90 110-120 90 100 108 120
110 110-120 110 122 132 146
180 180-200 208-240 180 200 208 240
230 220-240 277 220 240 264 288
400 380-415 460-480 380 415 455 498
500 500-550 600-660 500 550 600 660
Standard voltages in bold type letter
Suffix Voltage Marking Rated Control Voltage Us
to contactor
type e.g.
at the coil range for
50Hz 60Hz DC
J7KN-151-230 for 50 Hz
V
for 60 Hz
V
min
V
max
V
min
V
max
V
max
V
24 24 24 24 24 24 24 24
48 48 48 48 48 48 48 48
110 110 120 110 120 110 120 110
230 220-240 220-240 220 240 220 240 220
400 380-415 380-415 380 415 380 415 -
Standard voltages in bold type letter

Motor Contactor J7KN 37
■Engineering data and characteristics
Approximate Values for three-phase Motors
Motor Full Load Currents
Approximate values of motor F.L.C. and minimum „slow blow“ respectively „gL“ short-circuit fuse
The motor F.L.C. be valid for standard internal and surface cooled three-pole
motors with 1500 min-1. The fuses values be valid for the motor F.L.C. shown in
the table and D.O.L.-start: starting current max. 6x motor F.L.C., starting time
max. 5s; star-delta-start: starting current max. 2x motor F.L.C., starting time
max. 15s. For motors with higher F.L.C., higher starting current and / or longer
starting time, larger short-circuit fuses are required.
The maximum admissible value is dependent on the switchgear
respectively thermal overload relay.
Motor rating 220-230V Motor 240V Motor 380-400V Motor 415V Motor 500V Motor 660-690V Motor
Range according to BS for 415V Value of fusing at
motor start
Value of fusing at
motor start
Value of fusing at
motor start
Value of fusing at
motor start
Value of fusing at
motor start
Value of fusing at
motor start
kW PS~hp hp cos %
F. L . C .
A
D.O.L.
A
YD
A
F. L . C .
A
D.O.L.
A
YD
A
F. L . C.
A
D.O.L.
A
YD
A
F. L . C .
A
D.O.L.
A
YD
A
F. L . C .
A
D.O.L.
A
YD
A
F. L . C .
A
D.O.L.
A
YD
A
0.06 0.08 - 0.7 59 0.38 1 1 0.35 1 1 0.22 11- - -0.1611- - -
0.09 0.12 - 0.7 60 0.55 2 2 0.5 2 2 0.33 11- - -0.2411- - -
0.12 0.16 - 0.7 61 0.76 2 2 0.68 2 2 0.42 22- - -0.3311- - -
0.18 0.24 - 0.7 61 1.1 2 2 1 2 2 0.64 22- - -0.4611- - -
0.25 0.34 - 0.7 62 1.4 4 2 1.38 4 2 0.88 22- - -0.5922- - -
0.37 0.5 - 0.72 64 2.1 4 4 1.93 4 4 1.22 4 2 - - - 0.85 2 2 0.7 2 2
0.55 0.75 - 0.75 69 2.7 4 4 2.3 4 4 1.5 42- - -1.2420.922
0.75 1 1 0.8 74 3.3 6 4 3.1 6 4 24 4 2 4 4 1.48 4 2 1.1 2 2
1.1 1.5 1.5 0.83 77 4.9 10 6 4.1 6 6 2.6 442.5442.1441.542
1.5 2 2 0.83 78 6.2 10 10 5.6 10 10 3.5 643.5642.6442 44
2.2 3 3 0.83 81 8.7 16 10 7.9 16 10 510 6 5 10 6 3.8 6 6 2.9 6 4
2.5 3.4 - 0.83 81 9.8 16 16 8.9 16 10 5.7 10 10 - - - 4.3 6 6 - - -
3 4 4 0.848111.620 1610.620 16 6.6 16 10 6.5 16 10 5.1 10 10 3.5 6 4
3.75 5 0.848214.225 2013 25 16 8.2 16 10 7.5 16 10 6.2 16 10 - - -
4 5.5 - 0.84 82 15.3 25 20 14 25 20 8.5 16 10 - - - 6.5 16 10 4.9 10 6
5.5 7.5 7.5 0.85 83 20.6 35 25 18.9 35 25 11.5 20 16 11 20 16 8.9 16 10 6.7 16 10
7.51010 0.868527.4353524.8353515.5 25 20 14 25 16 11.9 20 16 9 16 10
8 11 - 0.86 85 28.8 50 35 26.4 35 35 16.7 25 20 - - - 12.7 20 16 - - -
11 15 15 0.86 87 39.2 63 50 35.3 50 50 22 35 25 21 35 25 16.7 25 20 13 25 16
12.5 17 - 0.86 87 43.8 63 50 40.2 63 50 25 35 35 - - - 19 35 25 - - -
15 20 20 0.86 87 52.6 80 63 48.2 80 63 30 50 35 28 35 35 22.5 35 25 17.5 25 20
18.5 25 25 0.86 88 64.9 100 80 58.7 80 63 37 63 50 35 50 50 28.5 50 35 21 35 25
20 27 - 0.86 88 69.3 100 80 63.4 80 80 40 63 50 - - - 30.6 50 35 - - -
22 30 30 0.87 89 75.2 100 80 68 100 80 44 63 50 40 63 50 33 50 50 25 35 35
25 34 - 0.87 89 84.4 125 100 77.2 100 100 50 80 63 - - - 38 63 50 - - -
30 40 40 0.87 90 101 125 125 92.7 125 100 60 80 63 55 80 63 44 63 50 33 50 35
37 50 50 0.87 90 124 160 160 114 160 125 72 100 80 66 100 80 54 80 63 42 63 50
40 54 - 0.87 90 134 160 160 123 160 160 79 100 100 - - - 60 80 63 - - -
45 60 60 0.88 91 150 200 160 136 200 160 85 125 100 80 100 100 64.5 100 80 49 63 63
51 70 - 0.88 91 168 200 200 154 200 200 97 125 100 - - - 73.7 100 80 - - -
55 75 - 0.88 91 181 250 200 166 200 200 105 160 125 - - - 79 125 100 60 80 63
59 80 80 0.88 91 194 250 250 178 250 200 112 160 125 105 160 125 85.3 125 100 - - -
75 100 100 0.88 91 245 315 250 226 315 250 140 200 160 135 200 160 106 160 125 82 125 100
90 125 125 0.88 92 292 400 315 268 315 315 170 250 200 165 200 200 128 160 160 98 125 125
110 150 150 0.88 92 358 500 400 327 400 400 205 250 250 200 250 250 156 200 200 118 160 125
129 175 175 0.88 92 420 500 500 384 500 400 242 315 250 230 315 250 184 250 200 - - -
132 180 - 0.88 92 425 500 500 393 500 500 245 315 250 - - - 186 250 200 140 200 160
147 200 200 0.88 93 472 630 630 432 630 500 273 315 315 260 315 315 207 250 250 - - -
160 220 - 0.88 93 502 630 630 471 630 630 295 400 315 - - - 220 315 250 170 200 200
184 250 250 0.88 93 590 800 630 541 630 630 340 400 400 325 400 400 259 315 315 - - -
200 270 - 0.88 93 626 800 800 589 800 630 370 500 400 - - - 278 315 315 215 250 250
220 300 300 0.88 93 700 1000 800 647 800 800 408 500 500 385 500 400 310 400 400 - - -
250 340 - 0.88 93 803 1000 1000 736 1000 800 460 630 500 - - - 353 500 400 268 315 315
257 350 350 0.88 93 826 1000 1000 756 1000 800 475 630 630 450 630 500 363 500 400 - - -
295 400 400 0.88 93 948 1250 1000 868 1000 1000 546 800 630 500 630 630 416 500 500 - - -
315 430 - 0.88 93 990 1250 1250 927 1250 1000 580 800 630 - - - 445 630 500 337 400 400
355 483 - 0.89 95 - - - - - - 636 800 800 - - - 483 630 630 366 500 400
400 545 - 0.89 96 - - - - - - 710 1000 800 - - - 538 630 630 410 500 500

38 Motor Contactor J7KN
Approximate values of motor F.L.C. according to CSA and UL
Motor
rating
Motor F.L.C. at 110-120V Motor F.L.C. at 220-240V*1
*1 Determine the motor current for 200V and 208V by increasing the values for 220-240V at 200V about 15% and for 208V about 10%.
Motor F.L.C. at 440-480V Motor F.L.C. at 550-600V
1-phase 2-phase 3-phase 1-phase 2-phase 3-phase 1-phase 2-phase 3-phase 1-phase 2-phase 3-phase
hp AAAAAAAAAAAA
½ 9.8 4.0 4.4 4.9 2.0 2.2 2.5 1.0 1.1 2.0 0.8 0.9
¾ 13.8 4.8 6.4 6.9 2.4 3.2 3.5 1.2 1.6 2.8 1.0 1.3
1 16.0 6.4 8.4 8.0 3.2 4.2 4.0 1.6 2.1 3.2 1.3 1.7
1½ 20.0 9.0 12.0 10.0 4.5 6.0 5.0 2.3 3.0 4.0 1.8 2.4
2 24.0 11.8 13.6 12.0 5.9 6.8 6.0 3.0 3.4 4.8 2.4 2.7
3 34.0 16.6 19.2 17.0 8.3 9.6 8.5 4.2 4.8 6.8 3.3 3.9
5 56.0 26.4 30.4 28.0 13.2 15.2 14.0 6.6 7.6 11.2 5.3 6.1
7½ 80.0 38.0 44.0 40.0 19.0 22.0 21.0 9.0 11.0 16.0 8.0 9.0
10 100.0 48.0 56.0 50.0 24.0 28.0 26.0 12.0 14.0 20.0 10.0 11.0
15 135.0 72.0 84.0 68.0 36.0 42.0 34.0 18.0 21.0 27.0 14.0 17.0
20 - 94.0 108.0 88.0 47.0 54.0 44.0 23.0 27.0 35.0 19.0 22.0
25 - 118.0 136.0 110.0 59.0 68.0 55.0 29.0 34.0 44.0 24.0 27.0
30 - 138.0 160.0 136.0 69.0 80.0 68.0 35.0 40.0 54.0 28.0 32.0
40 - 180.0 208.0 176.0 90.0 104.0 88.0 45.0 52.0 70.0 36.0 41.0
50 - 226.0 260.0 216.0 113.0 130.0 108.0 56.0 65.0 86.0 45.0 52.0
60 - - - - 133.0 145.0 - 67.0 77.0 - 53.0 62.0
75 - - - - 166.0 192.0 - 83.0 96.0 - 66.0 77.0
100 - - - - 218.0 248.0 - 109.0 124.0 - 87.0 99.0
125-----312.0-135.0 156.0 - 108.0 125.0
150-----360.0-156.0 180.0 - 125.0 144.0
200-----480.0-208.0 240.0 - 167.0 192.0
250-----602.0--302.0 - - 242.0
300--------361.0 - - 289.0
350--------414.0 - - 336.0
400--------477.0 - - 382.0
500--------590.0 - - 472.0

Motor Contactor J7KN 39
Contactors
Data according to IEC 947-4-1, EN 60947-4-1, VDE 0660
Main Contacts Type J7KN-10 J7KN-14 J7KN-18 J7KN-22 J7KN-24 J7KN-32 J7KN-40 J7KN-50 J7KN-62 J7KN-74
Rated insulation voltage Ui
*1 V AC 690 690 690 690 690 690 690 690 690 690
Making capacity Ieff at Ue = 690V AC A 200 200 200 200 400 500 500 700 900 900
Breaking capacity Ieff 400V AC A 180 180 200 200 380 400 400 600 800 800
J7KN-10 to J7KN-22 cosϕ= 0,65 500V AC A 150 150 180 180 300 370 370 500 700 700
J7KN-24 to J7KN-72 cosϕ= 0,35 690V AC A 100 100 150 150 260 340 340 400 500 500
1000VACA---------
Utilization category AC1
Switching of resistive load
Rated operational current Ie(=Ith) at 40°C, open A25253232506580110120130
Rated operational power
of three-phase resistive loads
50-60Hz, cosϕ= 1
220V kW 9,5 9,5 12,2 12,2 19,0 24,7 30,4 41,9 45,7 49,5
230V kW 9,9 9,9 12,7 12,7 19,9 25,9 31,8 43,8 47,7 51,7
240V kW 10,4 10,4 13,3 13,3 20,8 27,0 33,2 45,7 49,8 54,0
380V kW 16,4 16,4 21,0 21,0 32,9 42,7 52,6 72,3 78,9 85,5
400V kW 17,3 17,3 22,1 22,1 34,6 45,0 55,4 76,1 83,0 90,0
415V kW 17,9 17,9 23,0 23,0 35,9 46,7 57,4 79,0 86,2 93,3
440V kW 19,0 19,0 24,4 24,4 38,1 49,5 60,9 83,7 91,3 99,0
500V kW 21,6 21,6 27,7 27,7 43,3 56,2 69,2 95,2 103,8 112,5
660V kW 28,5 28,5 36,5 36,5 57,1 74,2 91,3 125,6 137,0 148,4
690V kW 29,8 29,8 38,2 38,2 59,7 77,6 95,5 131,3 143,2 155,2
1000VkW----------
Rated operational current Ie(=Ithe)at60°C,enclosedA2525323240556590100110
Rated operational power
of three-phase resistive loads
50-60Hz, cosϕ= 1
220V kW 9,5 9,5 12,2 12,2 15,2 20,9 24,7 34,3 38,1 41,9
230V kW 9,9 9,9 12,7 12,7 15,9 21,9 25,9 35,8 39,8 43,8
240V kW 10,4 10,4 13,3 13,3 16,6 22,8 27,0 37,4 41,5 45,7
380V kW 16,4 16,4 21,0 21,0 26,3 36,2 42,7 59,2 65,7 72,3
400V kW 17,3 17,3 22,1 22,1 27,7 38,1 45,0 62,3 69,2 76,1
415V kW 17,9 17,9 23,0 23,0 28,7 39,5 46,7 64,6 71,8 79,0
440V kW 19,0 19,0 24,4 24,4 30,4 41,9 49,5 68,5 76,1 83,7
500V kW 21,6 21,6 27,7 27,7 34,6 47,6 56,2 77,9 86,5 95,2
660V kW 28,5 28,5 36,5 36,5 45,7 62,8 74,2 102,8 114,2 125,6
690V kW 29,8 29,8 38,2 38,2 47,7 65,7 77,6 107,4 119,4 131,3
1000VkW----------
Minimum cross-section of conductor
at load with Ie(=Ith)
mm²4 4 6 6 101625355050
Utilization category AC2 and AC3
Switching of three-phase motors
Rated operational current Ie
open and enclosed
220VA121518222430405063 74
230VA11,514,518222430405062 74
240VA11141822243240506274
380-400VA10141822243240506274
415V A 9 14 18 22 23 30 40 50 62 74
440V A 9 14 18 22 23 30 40 50 62 74
500VA7 9 9 9 17,52121334242
660-690V A 6,5 8,5 8,5 8,5 17 20 20 31 40 40
1000VA--- ------
Rated operational power
of three-phase motors
50-60Hz
220-230V kW 3 4 5 6 6 8,5 11 12,5 18,5 22
240V kW 3 4 5 7 7 9 11,5 13,5 19 23
380-400V kW 4 5,5 7,5 11 11 15 18,5 22 30 37
415VkW4,56 8,512121620243340
440VkW4,56 8,512121620243340
500V kW 5,5 7,5 10 10 15 18,5 18,5 30 37 45
660-690V kW 5,5 7,5 10 10 15 18,5 18,5 30 37 45
1000VkW--- ------
Utilization category AC4
Switching of squirrel cage motors, inching
Rated operational current Ie(=Ith)
open and enclosed
220V A121518182430405063 63
230V A11,514,518182430405062 62
240V A11141818243240506262
380-400VA10141818243240506262
415V A 9 14 18 18 23 30 37 45 60 60
440V A 9 14 18 18 23 30 37 45 55 55
500V A 9 12 16 16 17,5 21 21 33 42 42
660V A7 9 9 9 172020314040
690V A 6,5 8,5 8,5 8,5 17 20 20 31 40 40
1000VA--- ------

40 Motor Contactor J7KN
Utilization category AC4
Switching of squirrel cage motors, inching
Rated operational power
of three-phase motors
50-60Hz
220-230V kW 3 4 5 5 6 8,5 11 12,5 18,5 18,5
240VkW34557911,513,51919
380-400V kW 4 5,5 7,5 7,5 11 15 18,5 22 30 30
415V kW 4,5 6 8,5 8,5 12 16 20 24 33 33
440V kW 4,5 6 8,5 8,5 12 16 20 24 33 33
500V kW 5,5 7,5 10 10 15 18,5 18,5 30 37 37
660-690V kW 5,5 7,5 10 10 15 18,5 18,5 30 37 37
1000VkW--- ------
Utilization category AC 5a
Switching of gas discharge lamps
Rated operational current Ieper pole at 220/230V
Fluorescent lamps,
uncompensated and serial compensated A 20 20 25 25 40 52 64 88 96 104
parallel compensated A 7 9 9 9 18 22 22 30 40 45
dual-connection A 22,5 22,5 28 28 45 58 72 98 108 117
Metal halide lamps*2,
uncompensated A12151919303948667278
parallel compensated A 7 9 9 9 18 22 22 30 40 45
Mercury-vapour lamps*3,
uncompensated A22,525282845587299108117
parallel compensated A 7 9 9 9 18 22 22 30 40 45
Mixed light lamps*4 A202025254052648896104
Utilization category AC 5b
Switching of incandescent lamps*5
Rated operational current Ieper pole at 220/230V A 12,5 12,5 12,5 12,5 25 31 31 43 56 56
Utilization category AC 6a
Transformer primary switching
atinrush n30303030303030303030
Rated operational current Ie400V A 4,5 5,5 7,5 7,5 10,5 13,5 13,5 20 27 33
Rated operational power
dependent on inrush n
220-230V kVA 1,8 2,2 3 3 4,2 5,4 5,4 8 10,7 13
240V kVA 1,9 2,3 3,1 3,1 4,3 5,6 5,6 8,3 11,2 13,5
380-400V kVA 3,1 3,8 5,2 5,2 7,3 9,3 9,3 13,5 18,5 22,5
For different inrush-factors x
use the following formula:
Px=Pn*(n/x)
415-440V kVA 3,4 4,2 5,7 5,7 8 10,2 10,2 15 20,5 25
500V kVA 3,9 4,8 6,5 6,5 9 11,5 11,5 17 23 28
660-690V kVA 5,4 6,5 9 9 12,5 16 16 24 32 39
Utilization category AC 6b
Switching of three-phase capacitor banks
Maximum inrush current (peak val-
ue) as multiple k of the capacitor
rated current
k35252020252525252520
Rated operational current Ie500V A8 1215,515,52332324560 70
Rated operational power
(sin 1)
220-230V kVAr 3 4,5 6 6 8,5 12 12 17 24 28
240V kVAr 3,5 5 6,5 6,5 9,5 13 13 18,5 25 29
380-400V kVAr 5 7,5 10 10 15 20 20 29 39 46
For different multiples x
use the following formula:
Px=Pk*(k/x)
415-440V kVAr 5,5 8 11 11 16 22 22 32 43 50
500V kVAr7 10131320262639 5058
660-690VkVAr7 101313202626405058
Switching of detuned capacitors
Rated operational current Ie690V A 8 13 18 20 28 36 42 48 72 105 1)
Rated operational power 220-230V kVAr 2,9 5 7 7,5 11 14 16 20 28 33
240V kVAr 3,1 5,4 7 8 11 14 17 20 28 36
380-400V kVAr 5 9 12,5 13 20 25 27,5 33,3 50 75 1)
415-440V kVAr 5,5 9,5 13 14 22 27 30 36 53 75 1)
500V kVAr6 111517253036406075
660-690VkVAr8 1520223341485582100
Utilization category DC1
Switching of resistive load
Time constant L/R 1ms
Rated operational current Ie1 pole24V A 20 25 32 32 50 65 80 110 120 130
60V A 20 25 32 32 50 65 80 110 120 130
110VA6 6 6 6 101010121212
220V A 0,8 0,8 0,8 0,8 1,4 1,4 1,4 1,4 1,4 1,4
3 poles in series 24V A 20 25 32 32 50 65 80 110 120 130
60V A 20 25 32 32 50 65 80 110 120 130
110VA20253232506580110120130
220VA16202020303535638080
Main Contacts Type J7KN-10 J7KN-14 J7KN-18 J7KN-22 J7KN-24 J7KN-32 J7KN-40 J7KN-50 J7KN-62 J7KN-74

Motor Contactor J7KN 41
Utilization category DC3 and DC5
Switching of shunt motors and series motors
Time constant L/R 15ms
Rated operational current Ie1 pole24V A 20 25 32 32 50 65 80 110 120 130
60V A 6 6 6 6 30 30 30 60 60 60
110V A 1,2 1,2 1,2 1,2 1,8 1,8 1,8 1,8 1,8 1,8
220V A 0,2 0,2 0,2 0,2 0,2 0,2 0,2 0,25 0,25 0,25
3 poles in series 24V A 20 25 32 32 50 65 80 110 120 130
60V A 20 25 32 32 40 40 40 80 80 80
110VA20202020404040808080
220V A 2,5 2,5 2,5 2,5 4 4 4 5 5 5
Maximum ambient temperature
Operation open °C -40 to +60 (+90)*6
enclosed °C -40 to +40
with thermal overload relay open °C -25 to +60
enclosed °C -25 to +40
Storage °C -50 to +90
Short circuit protection
for contactors without thermal overload relay
Coordination-type "1" according to IEC 947-4-1
Contact welding without
hazard of persons
max.fusesize gL(gG)A63636363808080160160160
Coordination-type “2” according to IEC 947-4-1
Light contact welding accepted
max.fusesize gL(gG)A25353535505050100125125
Contact welding not accepted
max.fusesize gL(gG)A16161616253535506363
For contactors with thermal overload relay the device with
the smaller admissible backup fuse (contactor or thermal
overload relay) determines the fuse size.
Cable cross-sections
for contactors without thermal overload relay
main connector solid or stranded mm² 0,75 - 6 1,5 - 25 4 - 50
flexible mm² 1 - 4 2,5 - 16 10 - 35
flexible with multicore cable end mm² 0,75 - 4 1,5 - 16 6 - 35
Cables per clamp 2 1 1
solid or stranded mm² 6+(1-6) / 4+(0,75-4) 16+(2,5-6) / 10+(4-10) 50+4 / 35+6 / 25+(6-16)
2,5+(0,75-2,5) / 1,5+(0,75-1,5) 6+(4-6) / 4+(2,5-4) 16+(6-16) / 10+(6-16)
flexible mm² 6+(1,5-6) / 4+(1-4) 16+(2,5-6) / 10+(4-10) 50+(4-10) / 35+(4-16)
2,5+(0,75-2,5) / 1,5+(0,75-1,5) 6+(4-6) / 4+(2,5-4) 25+(4-25) / 16+(4-16)
Cables per clamp 2 2 2
main connector solid AWG 18 - 10 16 - 10 12 - 10
flexible AWG 18 - 10 14 - 4 10 - 0
Cables per clamp 2 1 1
solid AWG 10+(16-10) / 12+(18-12) 10+(16-10) / 12+(18-12) 10+(12-10) / 12+12
14+(18-14) / 16+(18-16) 14+(18-14) / 16+(18-16)
flexible AWG 10+(14-10) / 12+(18-12) 4+(18-12) / 6+(18-8) 1+(12-10) / 2+(8-12)
14+(18-14) / 16+(18-16) 8+(18-8) / 10+(18-12) 3+(12-8) / 4+(10-6)
Cables per clamp 2 2 2
Frequency of operations z
Contactors without thermal overload relay
without load 1/h 10000 10000 10000 10000 7000 7000 7000 7000 7000 7000
AC3, Ie1/h 600 600 600 600 600 600 600 400 400 400
AC4, Ie1/h 120 120 120 120 120 120 120 120 120 120
DC3, Ie1/h 600 600 600 600 600 600 600 400 400 400
Mechanical life
AC operated S x 10610 10 10 10 10 10 10 10 10 10
DC operated S x 10610 10 10 10 10 10 10 10 10 10
DC solenoid operated S x 10650 50 50 50 50 50 50 - - -
Short time current 10s-current A 96 120 144 176 184 240 296 360 504 592
Power loss per pole at Ie/AC3 400V W 0,21 0,35 0,5 0,75 0,7 1,3 2 2,2 3,9 5,5
Resistance to shock acc. to IEC 68-2-27
Shock time 20ms sine-wave NO g 10 10 10 10 8 8 8 8 8 8
NCg6666------
*1 Suitable at 690V for: earthed-neutral systems, overvoltage I to IV, pollution degree 3 (standard-industry): Uimp = 8kV.
Data for other conditions on request.
*2 Metal halide lamps and sodium-vapour lamps (high- and low-pressure lamps)
*3 High-pressure lamps
*4 Blended lamps, containing a mercury high-pressure unit and a tungsten helix in a flourescent glass bulb (daylight lamps)
*5 Current inrush approx. 16 x Ie
*6 With reduced control voltage range 0,9 up to 1,0 x Usand with reduced rated current Ie/AC1 according to Ie/AC3
Main Contacts Type J7KN-10 J7KN-14 J7KN-18 J7KN-22 J7KN-24 J7KN-32 J7KN-40 J7KN-50 J7KN-62 J7KN-74

42 Motor Contactor J7KN
Main Contacts Type J7KN-85 J7KN-110 J7KN-151 J7KN-176 J7KN-200
Rated insulation voltage Ui*1 V AC 750 750 690 690 690
Making capacity Ieff at Ue = 690V AC A 1100 1200 1500 1800 1700
Breaking capacity Ieff 400V AC A 950 1100 1200 1400 1600
J7KN-10 to J7KN-22 cosϕ= 0,65 500V AC A 850 1000 1200 1400 1600
J7KN-24 to J7KN-72 cosϕ= 0,35 690V AC A 600 600 700 800 1200
1000V AC A - - - - -
Utilization category AC1
Switching of resistive load
Rated operational current Ie(=Ith) at 40°C, open A 150 170 230 250 350
Rated operational power
of three-phase resistive loads
50-60Hz, cosϕ= 1
220V kW 57 64 87 95 133
230V kW 59 67 91 99 139
240V kW 62 70 95 103 145
380V kW 98 111 151 164 230
400V kW 103 117 159 173 242
415V kW 107 122 165 179 251
440V kW 114 129 175 190 266
500V kW 130 147 199 216 303
660V kW 171 194 262 285 400
690V kW 179 203 274 298 418
1000V kW - - 398 433 -
Rated operational current Ie(=Ithe) at 60°C, enclosed A 100 125 180 200 280
Rated operational power
of three-phase resistive loads
50-60Hz, cosϕ= 1
220V kW 38 47 68 76 106
230V kW 40 49 71 79 111
240V kW 41 52 74 83 116
380V kW 65 82 118 131 184
400V kW 69 86 124 138 193
415V kW 71 89 129 143 201
440V kW 71 95 137 152 213
500V kW 86 108 155 173 242
660V kW 114 142 205 228 320
690V kW 119 149 215 239 334
1000V kW - - - - -
Minimum cross-section of conductor
at load with Ie(=Ith)
mm² 50 70 95 120 185
Utilization category AC2 and AC3
Switching of three-phase motors
Rated operational current Ie
open and enclosed
220V A 85 110 150 175 210
230V A 85 110 150 175 210
240V A 85 110 150 175 210
380-400V A 85 110 150 175 210
415V A 85 110 150 175 210
440V A 85 110 150 175 210
500V A 60 60 150 175 210
660-690V A 57,5 57,5 120 140 150
1000V A - - 60 70 -
Rated operational power
of three-phase motors
50-60Hz
220-230V kW 25 33 40 50 60
240V kW 27 35 45 55 65
380-400V kW 45 55 75 90 110
415V kW 49 63 80 95 115
440V kW 49 63 85 100 125
500V kW 55 75 90 100 132
660-690V kW 55 55 110 132 132
1000V kW - - 75 90 -
Utilization category AC4
Switching of squirrel cage motors, inching
Rated operational current Ie(=Ith)
open and enclosed
220V A8598556385
230V A8598556385
240V A8598556385
380-400V A 85 85 55 63 85
415V A8585556385
440V A8585556385
500V A8585- - -
660V A6060- - -
690V A 57,5 57,5 - - -
1000VA-----

Motor Contactor J7KN 43
Rated operational power
of three-phase motors
50-60Hz
220-230V kW 25 30 15 18,5 25
240V kW 27 32 15,5 19 26
380-400V kW 45 45 25 30 45
415V kW 49 49 25 33 45
440V kW 49 49 30 34 48
500V kW 55 55 25 30 55
660-690V kW 55 55 25 30 55
1000V kW - - - - -
Utilization category AC 5a
Switching of gas discharge lamps
Rated operational current Ieper pole at 220/230V
Fluorescent lamps,
uncompensated and serial compensated A 100 120 120 140 180
parallel compensated A 55 70 85 100 120
dual-connection A 112 144 120 140 180
Metal halide lamps*2,
uncompensated A 85 90 95 110 140
parallelcompensated A55707585110
Mercury-vapour lamps*3,
uncompensated A 112 144 120 140 180
parallelcompensated A55707585110
Mixed light lamps*4 A 100 120 100 120 160
Utilization category AC5b
Switching of incandescent lamps*5
Rated operational current Ieper pole at 220/230V A 69 75 100 120 160
Utilization category AC6a
Transformer primary switching
atinrush n3030303030
Rated operational current Ie400V A3850658090
Rated operational power
dependent on inrush n
220-230V kVA 15 20 25 30 34
240V kVA 15,5 20,5 27 33 37
380-400V kVA 26 34 45 55 60
For different inrush-factors x
use the following formula:
Px=Pn*(n/x)
415-440V kVA 29 38 46 57 63
500V kVA3343556975
660-690V 45 60 56 69 100
Utilization category AC6b
Switching of three-phase capacitor banks
Maximum inrush current (peak val-
ue) as multiple k of the capacitor
rated current
k2020202015
Rated operational current Ie500V A 87 100 120 155 195
Rated operational power
(sin 1)
220-230V kVAr 33 38 45 60 75
240V kVAr 36 42 52 62 78
380-400V kVAr 57 65 80 100 130
For different multiples x
use the following formula:
Px=Pk*(k/x)
415-440V kVAr 60 70 95 110 135
500V kVAr 70 80 100 130 170
660-690V kVAr 70 80 100 130 170
Switching of detuned capacitors
Rated operational current Ie690V A 98 105 115 140 200
Rated operational power 220-230V kVAr 35 40 43 53 76
240V kVAr 39 43 45 55 80
380-400V kVAr 68 75 75 90 130
415-440V kVAr 71 77 80 100 140
500V kVAr 85 90 95 120 170
660-690V kVAr 110 120 125 150 200
Utilization category DC1
Switching of resistive load
Time constant L/R 1ms
Rated operational current Ie1 pole24V A 150 170 - - -
60V A 150 170 - - -
110V A 20 25 - - -
220V A 2 2,5 - - -
3 poles in series 24V A 150 170 - - -
60V A 150 170 - - -
110V A 150 170 - - -
220V A 100 160 - - -
Main Contacts Type J7KN-85 J7KN-110 J7KN-151 J7KN-176 J7KN-200

44 Motor Contactor J7KN
Utilization category DC3 and DC5
Switching of shunt motors and series motors
Time constant L/R 15ms
Rated operational current Ie1 pole24V A 150 170 - - -
60V A 85 110 - - -
110V A 2 2,5 - - -
220V A 0,5 0,5 - - -
3 poles in series 24V A 150 170 - - -
60V A 100 110 - - -
110V A 100 110 - - -
220V A 7 8 - - -
Maximum ambient temperature
Operation open °C -40 to +60 (+90)*6 -25 to +55 (+70)*7
enclosed °C -40 to +40 -25 to +40
with thermal overload relay open °C -25 to +60 -25 to +55
enclosed °C -25 to +40 -25 to +40
Storage °C -50 to +90 -55 to +80
Short circuit protection
for contactors without thermal overload relay
Coordination-type "1" according to IEC 947-4-1
Contact welding without hazard of persons
max. fuse size gL (gG) A 250 250 250 315 400
Coordination-type “2” according to IEC 947-4-1
Light contact welding accepted
max. fuse size gL (gG) A 160 200 200 250 315
Contact welding not accepted
max. fuse size gL (gG) A 100 125 160 200 250
For contactors with thermal overload relay the device with
the smaller admissible backup fuse (contactor or thermal
overload relay) determines the fuse size.
Cable cross-sections
for contactors without thermal overload relay
main connector solid or stranded mm² 10 - 70*8 10 - 70*8 95 120 185
flexible mm² 6 - 50*8 16 - 50*8 screw screw screw
flexible with multicore cable end mm² 10 - 35 10 - 35 M8 M8 M8
Cables per clamp
solid or stranded mm²
flexible mm²
Cables per clamp
main connector solid AWG 10 10
flexible AWG 6 - 0 6 - 0
Cables per clamp 1 1
solid AWG
flexible AWG
Cables per clamp
Frequency of operations z
Contactors without thermal overload relay
without load 1/h 3000 3000 1200 1200 1200
AC3, Ie1/h 300 300 - - -
AC4, Ie1/h 120 120 - - -
DC3, Ie1/h 300 300 - - -
Mechanical life
AC operated S x 1065 5 10 10 8
DC operated S x 1065 5 10 10 8
Short time current 10s-current A 680 880 1200 1400 1800
Power loss per pole at I
e
/AC3 400V W4,3 6,0 8 11 8
Resistance to shock acc. to IEC 68-2-27
Shock time 20ms sine-wave NO g 7 7 - - -
NC g 5 5 - - -
*1 Suitable at 690V for: earthed-neutral systems, overvoltage I to IV, pollution degree 3 (standard-industry):
Uimp = 8kV. Data for other conditions on request.
*2 Metal halide lamps and sodium-vapour lamps (high- and low-pressure lamps)
*3 High-pressure lamps
*4 Blended lamps, containing a mercury high-pressure unit and a tungsten helix in a flourescent glass bulb
(daylight lamps)
*5 Current inrush approx. 16 x Ie
*6
With reduced control voltage range 0,9 up to 1,0 x U
s
and with reduced rated current I
e
/AC1 according to I
e
/AC3
*7 With reduced control voltage range 1,0 x Usand with reduced rated current Ie/AC1 according to Ie/AC3
*8 Maximum cable cross-section with prepared conductor
Main Contacts Type J7KN-85 J7KN-110 J7KN-151 J7KN-176 J7KN-200
