Omron 3G3M1-STD User manual

3G3M1-STD Snabbstart V1.0.1
3G3M1-STD
Snabbstarts Manual

2
CONTENTS
INTRODUCTION .......................................................................................................................................................................3
1.1. INTENDED READERS ..............................................................................................................................................................3
1.2. NOTICE..............................................................................................................................................................................3
1.3. TERMS AND CONDITIONS AGREEMENT ......................................................................................................................................4
1.4. SAFETY PRECAUTIONS ...........................................................................................................................................................5
REVISIONSHISTORIK ..........................................................................................................................................................................12
1. SPECIFIKATION..............................................................................................................................................................13
1.1. MODELLBETECKNING ..........................................................................................................................................................13
2. MEKANISK INSTALLATION .............................................................................................................................................17
2.1. INSTALLATION,ORIENTERING OCH DISTANSER............................................................................................................................17
3. DIMENSIONER...............................................................................................................................................................18
4. INKOPPLING..................................................................................................................................................................24
4.1. TERMINAL ÖVERSIKT ...........................................................................................................................................................24
4.2. ANSLUTNINGSDIAGRAM.......................................................................................................................................................25
4.3. DIP SWITCHAR ...................................................................................................................................................................26
4.4. VÄLJ INPUT CONTROL LOGIC PNP(SOURCE) /NPN(SINK)......................................................................................................26
4.5. MULTIFUNKTIONSINGÅNGAR ................................................................................................................................................27
4.5.1. NPN (SINK)...........................................................................................................................................................27
4.5.2. PNP (SOURCE)......................................................................................................................................................27
4.6. MULTIFUNKTIONSUTGÅNGAR................................................................................................................................................29
4.6.1. NPN (Sink)............................................................................................................................................................29
4.6.2. PNP (SOURCE)......................................................................................................................................................29
5. MANÖVERPANELS FUNKTIONER ...................................................................................................................................30
5.1. DELARNAS NAMN OCH BESKRIVNINGAR ...................................................................................................................................30
5.2. MANÖVRERING AV OPERATÖRSPANELEN..................................................................................................................................32
5.2.1. Operation Mode ..................................................................................................................................................32
5.2.2. Program Mode ....................................................................................................................................................33
6. FABRIKSÅTERSTÄLLNING AV 3G3M1 .............................................................................................................................35
7. SNABBSTART.................................................................................................................................................................36
7.1. GRUNDLÄGGANDE MOTORPARAMETERINSTÄLLNINGAR ...............................................................................................................36
7.2. AUTO-TUNING...................................................................................................................................................................37
7.3. PARAMETERTABELL.............................................................................................................................................................40
7.3.1. Frekvensreferens och kör kommando..................................................................................................................40
7.3.2. Hastighetsprofil ...................................................................................................................................................40
7.3.3. Digitala in- och utgångar.....................................................................................................................................41
7.3.4. Analog utgång.....................................................................................................................................................41
7.3.5. Andra bra att ha parametrar...............................................................................................................................41
7.1. INSTÄLLNINGS EXEMPEL .......................................................................................................................................................42
7.1.1. Direkt körning från 3G3M1 operatörspanel ........................................................................................................42
7.1.2. Start och stopp av 3G3M1 via en knapp..............................................................................................................43
7.1.3. Start, stopp och riktning av 3G3M1 (3-wire Input Function) ...............................................................................46
7.1.4. Analog styrning av frekvensen via en extern 0-10V eller en potentiometer ........................................................50
8. SÄKERHETS FUNKTIONALITET........................................................................................................................................54
8.1. AKTIVERA SÄKERHETSFUNKTIONER..........................................................................................................................................55
8.2. INKOPPLING ......................................................................................................................................................................55

3
Introduction
Thank you for using the QuickStart guide: 3G3M1-STD Snabbstart V1.0.0
Use it when programming with the automation software Sysmac Studio.
This manual contains information that is necessary to use the product as is and/or together with
Sysmac Studio.
1.1. Intended Readers
This manual is intended for the following personnel.
Those who have knowledge of electrical systems (an electrical engineer or the equivalent) and
also are qualified for one of the following:
• Personnel in charge of introducing the control equipment
• Personnel in charge of designing the control systems
• Personnel in charge of installing and maintaining the control equipment
• Personnel in charge of managing the control systems and facilities
1.2. Notice
This manual describes the necessary information to get started with the 3G3M1. Refer also to
the following manual’s for more information.
Name
Catalog
No.
Model
Application
Description
Sysmac Studio Version
1 Operation Manual
W504
SYSMACSE2
□□□
To learn about how to
operate Sysmac
Studio and its
features.
Describes how to operate Sysmac
Studio.
Sysmac Studio Version
V1 Drive Functions
Operation Manual
I589
SYSMACSE2
□□□
To learn about how to
set and adjust the
servo driver.
Describes how to operate
Sysmac Studio.
3G3M1 Standard Type
User's Manual
I669
3G3M1 STD
Multi-function
Compact Inverter
Describes the installation/wiring of
the 3G3M1 Series Inverter, and
parameter setting method which is
required for the operation, as well
as troubleshooting and inspection
methods.
Please read and understand this manual before using the 3G3M1 Standard Type. Keep this
manual in a safe place where it will be available for reference during operation.

4
1.3. Terms and Conditions Agreement
1 NO WARRANTY
1）The functions and function block Library is distributed as a sample in the hope that it will
be useful, but without any warranty. It is provided “as is” without warranty of any kind, either
expressed or implied, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose. The entire risk as to the quality and performance of
the function block is with you. Should the function block prove defective, you assume the
cost of all necessary servicing, repair or correction.
2）In no event unless required by applicable law the author will be liable to you for damages,
including any general, special, incidental or consequential damages arising out of the use
or inability to use the function block (including but not limited to loss of data or data being
rendered inaccurate or losses sustained by you or third parties or a failure of the function
block to operate with any other programs), even if the author has been advised of the
possibility of such damages.
2 LIMITATION OF LIABILITY
1) OMRON SHALL HAVE NO LIABILITY FOR DEFECT OF THE SOFTWARE.
2) OMRON SHALL HAVE NO LIABILITY FOR SOFTWARE PARTS DEVELOPED BY THE
USER OR ANY THIRD PARTY USING THE FUNCTION BLOCK DESCRIBED ON THIS
MANUAL.
3 APPLICABLE CONDITIONS
USER SHALL NOT USE THE SOFTWARE FOR THE PURPOSE THAT IS NOT
PROVIDED IN THE ATTACHED USER MANUAL.
4 CHANGE IN SPECIFICATION
The software specifications and accessories may be changed at any time based on
improvements and other reasons.
5 ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate;
however, no responsibility is assumed for clerical, typographical, or proofreading errors, or
omissions.

5
1.4. Safety Precautions
Definition of Precautionary Information
The following notation is used in this manual to provide precautions required to ensure safe
usage of 3G3M1 Standard Type.
The safety precautions that are provided are extremely important to safety. Always read and
heed the information provided in all safety precautions.
The following notation is used.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury. Additionally,
there may be severe property damage.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury, or property
damage.
Precautions for Safe Use
Indicates precautions on what to do and what not to do to ensure safe usage of the
product.
Precautions for Correct Use
Indicates precautions on what to do and what not to do to ensure proper operation and
performance.
Additional Information
Additional information to read as required.
This information is provided to increase understanding or make operation easier.
Explanation of Symbols
This symbol indicates a prohibited item (an item you must not do).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “non-specific general prohibitions.”
This symbol indicates a prohibited item (an item you must not do).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “disassembly prohibited.”
This symbol indicates caution and warning.
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates "Caution against electric shock."
This symbol indicates caution and warning.
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “Caution against fire.”

6
This symbol indicates caution and warning.
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates “general caution.”
This symbol indicates caution and warning.
The specific instruction is indicated inside as well as by using text.
The symbol shown to the left indicates “risk of hot surface.”
This symbol indicates a compulsory item (an item that must be done).
The specific instruction is indicated using an illustration or text inside or near .
The symbol shown to the left indicates a “general compulsory item.”
This symbol indicates a compulsory item (an item that must be done).
The specific instruction is indicated inside as well as by using text.
The symbol shown to the left indicates “grounding required.”

7
Warning list
Be sure to ground the ground terminal of the inverter. (200-V class: type-D grounding, 400-
V class: type-C grounding) Not doing so may result in a serious injury due to an electric
shock or fire.
Do not remove the surface cover during inverter power supply and for 10 minutes after
power shut off.
Doing so may result in a serious injury due to an electric shock.
Switch various switches, change wiring and perform inspections at least 10 minutes after
the power supply has been shut off
There is a risk of severe injury due to electric shock.
Wiring work must be carried out only by qualified personnel. Do not touch cables when the
power supply is turned ON. Additionally, only designated personnel should perform
maintenance or inspections, or replace parts.
There is a risk of severe injury due to electric shock.
After confirming that the power supply is OFF, wait at least 10 minutes and then perform
wiring.
Do not operate the Operator or switches with wet hands. Also, remove metal objects
(watches, rings, etc.) before starting work, and use insulating tools when using tools.
Not doing so may result in a serious injury due to an electric shock.
Do not touch the cooling fins, braking resistors and the motor, which become too hot
during
the power supply and for some time after the power shut off.
Doing so may result in a burn.
Inspection of the inverter must be conducted after the power supply was turned off.
Not doing so may result in a serious injury due to an electric shock.
The main power supply is not necessarily shut off even if the safety stop function is
activated.
There is a risk of severe injury.
Do not enter the operating area during operation.
There is a risk of severe injury due to electric shock.
Do not perform maintenance while the power supply is ON.
Although this product is manufactured under strict quality control, install equipment to
ensure safety when used with applications in which serious accidents or property damage
can be anticipated in the event of its failure.
Not doing so may result in accidents.
The Multi-function Compact Inverter (3G3M1 Series) is designed to drive a three-phase
induction motor and synchronous motor. Do not use it for single-phase motors or for other
purposes.
Doing so may result in fire or accident.

8
Install the inverter on a non-flammable material such as metallic wall. Also, do not place
flammable object nearby.
Doing so may result in fire.
Be sure to perform wiring after installing the inverter unit. Also, tighten terminals with
specified torque.
Not doing so may result in injury, electric shock or fire.
Ensure that the specifications of the input power of the product match the power supply to
which the product is to be connected.
Not doing so may result in fire or accidents.
Be sure to use the wire of specified size.
Not doing so may result in fire.
When wiring each inverter to the power supply, install a molded-case circuit breaker or
earth leakage circuit breaker (with overcurrent protection function). Use recommended
moldedcase circuit breakers or earth leakage circuit breakers that do not exceed the
recommended current capacity.
Not doing so may result in fire.
If no suitable equipment to detect leakage is installed in the upstream power supply line, in
order to avoid the entire power supply system's shutdown due to operation of devices such
as earth leakage circuit breaker as this is undesirable to operation, install an earth leakage
circuit breaker individually to inverters to break the individual inverter power supply lines
only.
Not doing so may result in fire.
When the capacity of the power transformer is 500 kVA or more and 10 times or more than
the rated capacity of the inverter, ensure that a DC reactor is connected.
Not doing so may result in fire.
Never connect the power lines to the inverter output terminals U, V, or W.
Doing so may result in fire.
When connecting a braking resistor, do not connect it to any terminal other than terminals
P(+) and DB.
Doing so may result in fire or accident.
Do not bundle multiple cables as one cable.
Doing so may result in fire.
Do not connect a surge suppressor to the output lines of the inverter.
Doing so may result in fire.
In general, sheaths of the control signal wires do not use reinforced insulation, therefore if
a control signal wire comes into direct contact with a live part of the main circuit, the
insulation of the sheath might break down. In these cases, there is a danger of the control
signal wire being exposed to high voltage from the main circuit, therefore ensure that the
control signal wires will not come into contact with live parts of the main circuit.
Not doing so may result in electric shock or accidents.

9
Even if the inverter has interrupted power to the motor, if the voltage is applied to the
main circuit input terminals L1/R, L2/S and L3/T, voltage may be output to inverter output
terminals U, V and W.
This may result in a serious injury due to an electric shock.
Even if the motor is stopped due to DC braking or pre-excitation, voltage is output to
inverter output terminals U, V and W.
This may result in a serious injury due to an electric shock.
Starting auto-tuning involves motor rotation. Sufficiently check that motor rotation carries
with it no danger beforehand.
Not doing so may result in injury or accidents.
The inverter may operate with acceleration/deceleration time or speed different from as
set due to stall prevention function. Design the machine so that safety is ensured even in
such cases.
Not doing so may result in accidents.
The inverter can easily have high-speed operation set. When changing the speed setting,
carefully check the specifications of motors or machine beforehand.
Additionally, set the parameters only after fully understanding the User’s Manual. If the
user recklessly changes the parameters and then operates the inverter, the motor may
rotate at a torque or speed not permitted for the machine.
This may result in injury.
If you enable the “Restart mode after momentary power failure” (F014 = 3 or 4), then the
inverter automatically restarts running the motor when the power is recovered. Design the
machine so that safety is ensured even after such restarts.
Not doing so may result in injury or accidents.
The STOP key on the Operator may be disabled due to parameter setting, etc. Provide an
emergency stop switch separately.
Not doing so may result in accidents.
If the motor stops as a result of a trip, the inverter may automatically restart and drive the
motor depending on the parameter setting. Design the machine so that human safety and
the safety of surroundings is ensured at the time of restarting.
Not doing so may result in accidents.
Remove any cause of the protective functions operating, then check the RUN command is
OFF and cancel the alarm. Canceling the alarm when the RUN command is ON means that
the inverter will supply power to the motor, which may start rotation thus posing a danger.
This may result in accidents.
When switching start methods or speed by external input, the motor may start suddenly or
the speed may abruptly change.
This may result in injury or accidents.
Input terminals have functions such as run, stop and speed change. If the parameters are
changed while signals are input to the input terminals, the motor operation may suddenly
change. Ensure that you change parameters only after fully securing safety.
Not doing so may result in injury or accidents.
The branch circuit protection being open may indicate an interruption in the fault current.
In order to reduce the danger of fire and electric shock, inspect energized parts and other
controller components, and replace if damaged.
In the event of the overload relay current element burning out, the entire overload relay
must be replaced.
Not doing so may result in a serious injury due to an electric shock or fire.

10
Output terminals (ROA, ROB) use relays, and may remain ON, OFF or undetermined when
their lifetime is reached. For safety, equip the inverter with an external protective function.
Not doing so may result in fire or accidents.
Do not dismantle, repair or modify the product.
Doing so may result in injury or electric shock.
Always carry out the daily and periodic inspections described in the User’s Manual. Use
ofthe inverter for long periods of time without carrying out regular inspections could result
inmalfunction or damage of the inverter, and an accident or fire could occur.
This may result in fire or accident.
It is recommended that parts for periodic replacement be replaced in accordance with the
standard replacement frequency indicated in the User's manual. Use of the inverter for long
periods of time without replacement could result in malfunction or damage of the inverter,
and an accident or fire could occur.
This may result in fire or accident.
It is recommended that periodic inspections be carried out every one to two years,
however, they should be carried out more frequently depending on the usage conditions.
Not doing so may result in fire or accident.
When using a DC reactor, AC reactor, braking resistor or noise filter, etc., there is the
possibility that a human body may touch the main circuit terminal block (live parts). In such
cases, take measures such as installing the inverters in a location not easily accessible by
humans.
Not doing so may result in a serious injury due to an electric shock.
There are conditions for compliance with the EU Low Voltage Directive and Machinery
Directive. Strictly observe the conditions listed in the instruction manual or user's manual.
Not doing so may result in a serious injury due to an electric shock or fire.

11
Caution list
If connecting a commercially available braking resistor or regenerative braking unit, this
may result in a moderate burn due to the heat generated in the braking resistor or
regenerative braking unit.
In case of a braking resistor, install a thermal relay that monitors the temperature of the
resistor. Configure a sequence that enables the inverter power to turn OFF when
unusual over heating is detected in the braking resistor or regenerative braking unit.
The inverter has high voltage parts inside which, if short-circuited, might cause damage
to itself or other property.
Place covers on the openings or take other precautions to make sure that no metal
objects such as cutting bits or lead wire scraps go inside when installing and wiring.
Install a stop motion device to ensure safety. Not doing so might result in a minor injury.
(A holding brake is not a stop motion device designed to ensure safety.)
Be sure to confirm safety before conducting maintenance, inspection or parts
replacement.
A breakdown of the built-in braking transistor could result in braking resistor heating or
damage to the inverter's internal units. Shut off the main power of the inverter using
Braking transistor broken signal (DBAL).
A breakdown of the built-in braking transistor or misconnection of the braking resistor
could result in braking resistor heating or damage to the inverter's internal units.
If the inverter does not start up or continue being undervoltage (LU) after the main
power of the inverter is turned ON, shut off the main power of the inverter.
When installing the product, use only the specified screws.
Not doing so may result in fire or accidents.
Do not install or operate an inverter with damaged external or internal components.
Doing so may result in injury, fire or accidents.
Prevent lint, paper fibers, sawdust, dust, metallic chips, or other foreign materials from
getting into the inverter or from accumulating on the cooling fin.
Not doing so may result in fire or accidents.
Support the inverter case or cooling fin instead of the surface cover during
transportation.
Not doing so may result in injury due to the inverter dropping.
The inverter, motor and wiring generate electric noise. Be careful about malfunction of
the nearby sensors and devices. Take noise control measures to prevent them from
malfunctioning.
Not doing so may result in accidents.
The inverter has an overload protection function. Set the protection level using
parameters.

12
The brake function of the inverter does not provide any holding mechanism. Provide a
separate holding brake if necessary.
Not doing so may result in injury.
Comply with the local ordinance and regulations when disposing of the product.
Not doing so may result in injury.
UL and cUL compliance is subject to conditions. Strictly observe the conditions listed in
the instruction manual or user's manual.
Not doing so may result in fire or accidents.
Revisionshistorik
Version
Reviderat datum
Innehåll
1.0.0
November 2022
Original
1.0.1
Juli 2023
Rättelse av bilder

13
1. Specifikation
1.1. Modellbeteckning
Enfas 200-V Klass
HHD: Heavy load, HND: Light load
1 fas 3G3M1-AB
001
002
004
007
015
022
037
Maximal
tillämplig
motorkapacitet
kW
HHD
0.1
0.2
0.4
0.75
1.5
2.2
3.7
HND
0.2
0.4
0.55
1.1
2
2.7
-
HP
HHD
1/8
1/4
1/2
1
2
3
5
HND
1/4
1/2
3/4
1 1/2
3
4
-
Nominell
uteffekt [kVA]
200 V
HHD
0.3
0.6
1
1.7
2.8
3.8
6.1
HND
0.4
0.7
1.2
2.1
3.3
4.2
-
240 V
HHD
0.4
0.7
1.2
2.1
3.3
4.6
7.3
HND
0.5
0.8
1.5
2.5
4
5
-
Ingångsspänning /frekvens
1 fas: 200V -10% ~ 240V+10%, 50/60Hz +/- 5%
Ingångsström [A]
HHD
1.8
3.3
5.4
9.7
16.4
22
45.4
HND
3.3
4.9
7.3
13.8
20.2
26
-
Utgångsspänning [V]
3 fas: 200-240 V (med AVR (Automatisk Volt Regulator))
Utgångsström [A]
HHD
1
1.6
3
5
8
11
17.5
HND
1.2
1.9
3.5
6.0
9.6
12
-
Minimum utgående frekvens
0.0Hz
Maximum utgående frekvens
590Hz
Kylningsmetod
Självkylande
1st Fläkt
Självkylande
Förlust vid 0 % belastning av
märkströmmen [W]
10
10
10
10
12
12
12
Förlust vid 100 % belastning av
märkströmmen [W]
12
22
30
48
79
104
154

14
Trefas 400-V Klass
HHD/HD: Heavy load, HND/ND: Light load
3 fas 3G3M1-A4
004
007
015
022
030
040
055
075
110
150
185
220
Maximal
tillämplig
motorkapacitet
kW
HD
0.75
1.1
2.2
3
4
5.5
7.5
11
15
18.5
22
30
ND
0.75
1.5
2.2
3
4
5.5
11
15
18.5
22
30
37
HHD
0.4
0.75
1.5
2.2
3
4
5.5
7.5
11
15
18.5
22
HND
0.75
1.1
2.2
3
4
5.5
7.5
11
15
18.5
22
30
HP
HD
1
1 1/2
3
4
5
7 1/2
10
15
20
25
30
40
ND
1
1 1/2
3
4
5
7 1/2
10
15
20
25
30
40
HHD
1 1/2
1
1 1/2
3
4
5
7 1/2
10
15
20
25
30
HND
1
1 1/2
3
4
5
7 1/2
10
15
20
25
30
40
Nominell
uteffekt [kVA]
380 V
HD
1.2
2.2
3.3
4.1
5.8
7.3
12
15
20
25
30
39
ND
1.4
2.7
3.6
4.5
6.1
7.9
14
19
24
29
39
47
HHD
1.2
2.2
3.2
3.6
4.7
6.1
9.7
12
16
20
26
30
HND
1.4
2.7
3.6
4.5
5.8
7.3
12
15
20
25
30
39
480 V
HD
1.5
2.8
4.2
5.2
7.3
9.2
15
19
26
32
37
50
ND
1.7
3.4
4.6
5.7
7.6
10
18
24
31
37
49
60
HHD
1.5
2.8
4
4.6
6
7.6
12.3
15
20
26
32
37
HND
1.7
3.4
4.6
5.7
7.3
9.2
15
19
26
32
37
50
Ingångsspänning /frekvens
3 fas: 380V -15% ~ 480V+10%, 50/60Hz +/- 5%
Ingångsström [A]
HD
2.7
3.9
7.3
11.3
14.2
16.8
23.2
33
43.8
52.3
60.6
77.9
ND
2.7
4.8
7.3
11.3
14.2
16.8
33
43.8
52.3
60.6
77.9
94.3
HHD
1.7
3.1
5.9
8.2
11.3
14.2
17.3
23.2
33
43.8
52.3
60.6
HND
2.7
3.9
7.3
11.3
14.2
16.8
23.2
33
43.8
52.3
60.6
77.9
Utgångsspänning [V]
3 fas: 200-240 V (med AVR (Automatisk Volt Regulator))
Utgångsström [A]
HD
1.8
3.4
5
6.3
8.8
11.1
17.5
23
31
38
45
60
ND
2.1
4.1
5.5
6.9
9.2
12
21.5
28.5
37
44
59
72
HHD
1.8
3.4
4.8
5.5
7.2
9.2
14.8
18
24
31
39
45
HND
2.1
4.1
5.5
6.9
8.8
11.1
17.5
23
31
38
45
60
Minimum utgående frekvens
0.0Hz
Maximum utgående frekvens
590Hz
Kylningsmetod
Självkylande
1 Fläkt
2 Fläktar
Förlust vid 0 % belastning av
märkströmmen [W]
10
10
12
12
12
12
14
14
19
19
--
--
Förlust vid 100 % belastning av
märkströmmen [W]
35
56
96
116
125
167
229
296
411
528
--
--

15
Trefas 200-V Klass
HHD: Heavy load, HND: Light load
3 fas 3G3M1-A2
001
002
004
007
015
022
037
055
075
110
150
185
Maximal
tillämplig
motorkapacitet
kW
HHD
0.1
0.2
0.4
0.75
1.5
2.2
3.7
5.5
7.5
11
15
18.5
HND
0.2
0.4
0.75
1.1
2.2
3
5.5
7.5
11
15
18.5
22
HP
HHD
1/8
1/4
1/2
1
2
3
5
7 1/2
10
15
20
25
HND
1/4
1/2
1
1 1/2
3
4
7 1/2
10
15
20
25
30
Nominell
uteffekt [kVA]
200 V
HHD
0.3
0.6
1
1.7
2.8
3.8
6.1
8.7
11
16
21
26
HND
0.5
0.7
1.2
2.1
3.3
4.2
6.8
10
14
19
24
30
240 V
HHD
0.4
0.7
1.2
2.1
3.3
4.6
7.3
10
14
20
25
32
HND
0.5
0.8
1.5
2.5
4.0
5.0
8.1
12
17
23
29
37
Ingångsspänning /frekvens
3 fas: 200V -15% ~ 240V+10%, 50/60Hz +/- 5%
Ingångsström [A]
HHD
1.1
1.8
3.1
5.3
9.5
13.2
22.2
31.5
42.7
60.7
80
97
HND
1.8
2.6
4.9
6.7
12.8
17.9
28.5
42.7
60.7
80
97
112
Utgångsspänning [V]
3 fas: 200-240 V (med AVR (Automatisk Volt Regulator))
Utgångsström [A]
HHD
1
1.6
3
5
8
11
17.5
25
33
47
60
76
HND
1.3
2
3.5
6
9.6
12
19.6
30
40
56
69
88
Minimum utgående frekvens
0.0Hz
Maximum utgående frekvens
590Hz
Kylningsmetod
Självkylande
1 Fläkt
2 Fläktar
Förlust vid 0 % belastning av
märkströmmen [W]
10
10
10
10
12
12
12
14
14
19
19
--
Förlust vid 100 % belastning av
märkströmmen [W]
12
22
30
48
79
104
154
229
313
458
625
--
3G3M1 STD Standard gemensamma specifikationer
Funktionalitet
Startmoment
•150% min. / Rated speed of 10%
V/f control (IM motor)
V/f control (slip compensation)
V/f control with sensor (IM motor)
•200% min./0.5 Hz
Sensorless vector control (dynamic vector control)
V/f control with sensor (auto torque boost)
Sensorless vector control
•200% min./0.0 Hz (0 Hz torque control)
Vector control with sensor (IM motor)
Vector control with magnetic pole position sensor (PM motor)
To obtain 200% starting torque at low speed, consider raising the capacity of the
inverter to the next higher capacity.
•200% min. / Rated speed of 10%
Magnetic pole position sensorless vector control (PM motor)
To obtain these starting torques at low speed, the capacity of the inverter and motor
must be taken into consideration.
The maximum torque that can be used is limited when the current capacity matched
to the mode is exceeded. Current capacity of 200% in HHD mode, 150% in HD mode, and
120% in HND and ND modes
Överbelastning (1 minut)
Heavy load rating (HHD): 150% av den nominella utgångsströmmen i 60 sekunder eller
200% av den nominella utgångsströmmen i 0.5 sekunder.
Heavy load rating (HD): 150% av den nominella utgångsströmmen i 60 sekunder.
Light load rating (HND/ND): 120% av den nominella utgångsströmmen i 60 sekunder.
Val av regleringsmetod
V/f control (no slip compensation), Dynamic torque vector control, V/f control (with slip
compensation), V/f control with speed sensor, Dynamic torque vector control with speed
sensor, Sensorless vector control, Vector control with speed sensor, Torque control (vector
control with speed sensor)
Digital ingång
7x (DI1 till DI7, programmerbara ingångar)
Digital utgång
2x (DO1 till DO2, programmerbara transistorutgångar)
1x (SPDT-kontakt (ROA, ROB, ROC), programmerbar reläutgång)
Pulsingång
1x (A, B, Z faser kan matas in, max. 32 kHz, 5 till 24 VDC)

16
Analog ingång
2x (spänning AI1 terminal: 10 bitar/-10 till 10 Vdc, spänning AI2 (AIV) terminal: 10 bitar/0 till
10Vdc, ström AI2 (AII) terminal: 10 bitar/4 till 20mA eller 0 till 20mA)
Analog utgång /
Pulsutgång
1x (AO (AOV) plint: Spänning 10 bitar / 0 till 10Vdc, AO (AOI) plint: Ström 10 bitar / 4 till
20mA eller 0 till 20mA, AO (PO) plint: Max 32 kHz, 0 till 11Vdc)
Kommunikation RS485
RJ45 kontakt (för Digital Operator)
Kommunikation RS485
Modbus RTU kommunikationsprotokollet är inbyggt.
Max 115.2 kbps
USB
USB 2.0, Micro-B kontakt
Skyddsfunktioner
Överström
200 % i HHD-läge
150 % i HD-läge
120 % i HND- och ND-lägen
Överspänning
200V klassen: Stannar när DC-busspänningen är mer än 410 V
400V klassen: Stannar när DC-busspänningen är mer än 820 V
Underspänning
Enfas 200 V-klass: Stannar när DC-busspänningen minskar till mindre än 160 V
Trefas 200 V-klass: Stannar när DC-busspänningen minskar till mindre än 190 V
Trefas 400 V-klass: Stannar när DC-busspänningen minskar till mindre än 380 V
Täthetsgrad
IP20
Standard
Applicable standard
CE
UKCA
EMC
EN 61800-3:2004/A1:2012
Functional safety
IEC 61800-5-2:2016
IEC/EN 61800-5-2 :2017 STO SIL3
EN ISO 13849-1:2015, Cat.3 / PLe
Electrical safety
EN 61800-5-1:2017
UL
US
UL61800 -5-1, Edition 1, 2012
CA
CSA-C22.2 No.274, 2017
K
KS-C9800-3
EAC
-
RCM
EN 61800-3:2004+A1:2012

17
2. Mekanisk Installation
2.1. Installation, orientering och distanser
Montera 3G3M1-seriens växelriktare vertikalt på en vägg med produktens längre sidor upprätt så att
modellen kan läsas korrekt. Lämna utrymme kring enheten för att få lämplig kylning enligt bilden
nedan.
A- Vertikal installation
B- Horisontell installation
C- Roterad installation
Standard installation
Installation med flera frekvensomriktare ”Side-by-Side”
A
B
C

18
3. Dimensioner
Spänning
Frekvensmodell
W [mm]
H [mm]
D [mm]
D1 [mm]
Enfas 200 V
3G3M1-AB001
3G3M1-AB002
68
127
98
8
3G3M1-AB004
120
23
3G3M1-AB007
165
48
Trefas 200 V
3G3M1-A2001
3G3M1-A2002
98
8
3G3M1-A2004
113
23
3G3M1-A2007
145
48

19
Spänning
Frekvensmodell
W [mm]
H [mm]
D [mm]
D1 [mm]
Enfas 200 V
3G3M1-AB015
110
130
166
58
Trefas 200 V
3G3M1-A2015
3G3M1-A2022
156
Trefas 400 V
3G3M1-A4004
132
38
3G3M1-A4007
3G3M1-A4015
3G3M1-A4022
156
58

20
Spänning
Frekvensmodell
W [mm]
H [mm]
D [mm]
D1 [mm]
Enfas 200 V
3G3M1-AB022
140
130
158
58
Trefas 200 V
3G3M1-A2037
Trefas 400 V
3G3M1-A4030
3G3M1-A4040
