Digital Timer H5AN
DIN-sized (72 x 72 mm) Quartz Timer
with Multiple Functions
Wide time range from 1/100 seconds to 9999 hrs.
Built-in power supply incorporated in timer enables
direct connection of sensors and other compo-
nents.
Draw-out construction allows maintenance without
disconnecting the wiring.
Power supply freely selectable within a range of
100 to 240 VAC; a DC-operated version is also
available.
Control outputs of both contact type and solid-state
type simultaneously available.
Seven operating modes (N, F , C, R, K, P , and Q) are
available.
RC
Ordering Information
Operation system Resetting system No. of digits Backup power
supply function for
memory protection
Model
T ime-limit operation,
inte
g
ratin
g
o
p
eration
Power-OFF resetting
(
excludin
g
-M
)
,
4 digits (switch-selectable):
0.01 to 99.99 s, 0.1 to 999.9 s, 1 to
Not provided H5AN-4D
integrating
operation
(excluding
-M)
,
external resetting,
manual resetting,
automatic resetting
0
.
01
to
99
.
99
s
,
0
.
1
to
999
.
9
s
,
1
to
9999 s, 0.1 to 999.9 min, 0.1 to 999.9 hrs,
1 to 9999 hrs, 1 s to 99 min 59 s,
1 min to 99 hrs 59 min
Provided (approx.
10 years at 20 °C) H5AN-4DM
Note: 1. Specify both the model number and supply voltage when ordering.
2. The T imer is supplied with two mounting fixtures.

H5AN H5AN
2
Specifications
Ratings
Item H5AN-4D/H5AN-4DM
Rated supply voltage H5AN-4D: 100 to 240 V AC (50/60 Hz),
12 to 24, 48, or 100 VDC (permissible ripple: 20% max.)
H5AN-4DM: 100 to 240 V AC (50/60 Hz)
12 to 24 VDC (permissible ripple: 20% max.)
Operating voltage range 85% to 1 10% of rated supply voltage
Power consumption Approx. 10 V A (at 240 V AC, 50 Hz), approx. 5 W (at 24 VDC)
Resetting system and
gate input
Reset by power-OFF: min. power OFF time: 0.5 s
External reset or gate (common to contact and solid-state inputs): min. reset input signal width: 0.02 s
One-shot output time 0.1 to 1 s (adjustable)
Control outputs Contact output: SPDT , 3 A at 250 V AC, resistive load (cosφ = 1)
Solid-state output: Open collector , 100 mA max. at 30 VDC max.
Power supply for
externally connected
components
12 VDC± 10%, 80 mA (permissible ripple: 5% max.)
Note: Inrush current was measured within the range shown below .
Peak value
Inrush current
Measurement
time
Time
Characteristics
Accuracy of operating time ± 0.01% ± 0.05 s max. (power OFF start), ± 0.005% ± 0.03 s max. (reset start) (see note)
Setting error
Influence of voltage
Influence of temperature
Insulation resistance 100 M Ω min. (at 500 VDC) (between current-carrying terminal and exposed non-current
carrying metal parts, between non-continuous contacts)
Dielectric strength 2,000 V AC, 50/60 Hz for 1 min (between current-carrying and non-current-carrying metal
parts)
750 V AC, 50/60 Hz for 1 min (between non-continuous contacts)
V ibration resistance Destruction: 10 to 55 Hz with 0.75-mm double amplitude
Malfunction: 10 to 55 Hz with 0.5-mm double amplitude
Shock resistance Destruction: 300 m/s
2
(approx. 30G)
Malfunction: 100 m/s
2
(approx. 10G)
Ambient temperature Operating: –10° C to 55 °C
Storage: –25°
C to 65 °C
Ambient humidity Operating: 35% to 85%
Life expectancy Mechanical: 10,000,000 operations min. (under no load at 1,800 operations/h)
Electrical: 100,000 operations min. (3 A at 250 V AC, resistive load)
Approved standards UL (File No. E41515), CSA (File No. LR22310)
Weight Approx. 360 g
Note: This value denotes the average of the repeat accuracy , setting error , and variations due to voltage and temperature changes. It in -
cludes the rise time of the power supply , and the operating time of the internal and output circuits.

H5AN H5AN
3
Engineering Data
Switching operations (x 10 )
3
Load current (A)
Switching operations (x 10 )
3
Load current (A)
Reference: A maximum current of 0.15 A can be switched at 125 VDC (cos φ = 1).
Maximum current of 0.1 A can be switched if L/R is 7 ms. In both cases,
a life of 100,000 operations can be expected.
The minimum applicable load is 10 mA at 5 VDC (P reference value).
Nomenclature
7-segment LED display
Front cover
T ime-up indicator
Rated time label af fixing section
(when a rated time label of
99 min 59 s is af fixed)
Reset input indicator
Pushbutton switch for manual reset
Internal unit fixing screw
One-shot time adjustment screw

H5AN H5AN
4
Operation
Timing Chart
Digital Display
UP Display DOWN Display
(See note)
(See note)
(See note)
(See note)
Note: After the set time has elapsed, operation continues according to the mode (N, F , C, R, K, P , or Q).
Operation Mode
(The control output and digital display when the set time is up dif fer in each of the operation modes available.)
Mode UP display DOWN display Operation after the set time is
up
N The control output and digital
display are held until a reset input
is applied.
F In UP mode, the digital display
continues to increment up to
“9999” even after reaching the set
value and then returns to all
zeroes. In DOWN mode, the
digital display continues to up
9999, and then decrements “9998,
9997, ...,” after reaching all
zeroes. The control output is held
until a reset input is applied.
C The digital display returns to the
initial setting once the set time has
elapsed and the timer restarts the
timing operation.
When the set time has elapsed,
the output signal is generated
during the one-shot time. The
timer repeats this cycle.
R The digital display returns to the
initial setting after the one-shot
time and the timer restarts the
timing operation. When the set
time has elapsed, the output
signal is generated during the
one-shot time. The timer repeats
this cycle.

H5AN H5AN
5
Mode Operation after the set time is
up
DOWN display UP display
K In UP mode, the digital display
continues to increment up to
“9999”, even after reaching the set
value and then returns to all
zeroes. In DOWN mode, the
digital display continues up to
9999, and the decrements “9998,
9997, ...,” after reaching all
zeroes. The timer restarts the
timing operation when the
incrementing or decrementing
value reaches the set value.
The output is generated during the
one-shot time. The timer repeats
this cycle.
P For the digital display , the value at
the up is held during the one-shot
time; however , the timing
operation of the timer returns to
the initial setting when the set time
has elapsed and the timer restarts
the timing operation. When the set
time has elapsed, the output
signal is generated during the
one-shot time. The timer repeats
this cycle.
Q In UP mode, the digital display
continues to increment after
reaching the set value during the
one-shot time. In DOWN mode,
the digital display continues to
9999 and then decrements “9998,
9997, ...,” after reaching all zeros
during the one-shot time.
However , in both UP and DOWN
modes, the digital display returns
to the initial setting after the
one-shot time and the timer
restarts the timing operation.
When the set time has elapsed,
the output signal is generated
during the one-shot time. The
timer repeats this cycle.
Note: 1. When a rated time of 99 min 59 s or 99 h 59 min is selected, the overflow values of the digital display when using the DOWN (count -
down)
function will be indicated as 9959, 9958, 9957, ... in modes F , K, and Q.
2. In this timing chart, the number of step advances during the one-shot time varies in accordance with the selected rated time and
duration of the one-shot time.
3. In C and P modes, set time value n should be suf ficiently longer than the one-shot time t.

H5AN H5AN
6
Programming of Specifications
The built-in specifications selector switches are used for program -
ming
UP or DOWN display , rated time, operation mode, and output
level of the solid-state output when the set time has elapsed, etc.
Set
these switches for programming the desired functional specifi -
cations
by referring to “Positions and Functions of Specification Se -
lector Switches”.
Open the front cover .
The internal unit comes out by loosening
the internal unit fixing screw .

H5AN H5AN
7
Positions and Functions of Specification Selector Switches
SW3-1 Manual Reset Selector Switch
Enable
Disable
SW1 T ime Range Selector Switch
SW2 Operation Mode Selector Switch
SW3-2 Solid-state Output Level Selector Switch
H: (Output level changes “low” to “high” when
the set time is up.)
L: (Output level changes “high” to “low” when
the set time is up.)
SW1
Switch position Rated time Setting range
0 99.99 s 0.01 to 99.99 s
1 999.9 s 0.1 to 999.9 s
2 9999 s 1 to 9999 s
3 99 min 59 s 1 s to 99 min 59 s
4 999.9 min 0.1 to 999.9 min
5 99 hrs 59 min 1 min to 99 hrs 59 min
6 999.9 hrs 0.1 to 999.9 hrs
7 9999 hrs 1 to 9999 hrs
8 99.99 s Same as switch
position “0”
9 999.9 s Same as switch
position “1”
Note: Select the appropriate label, from the rated time labels sup -
plied
as accessories, and af fix it on the proper position on
the front panel.
SW2
Switch position Operating mode Display mode
0 N DOWN display
1 F
2 C
3 R
4 K
5 P Note: 1. Same as
it h
6 Q switch
position
“
0
”
7 N (see note 1)
pos
iti
on
“0”
8 N UP display
9 F
A C
B R
C K
D P Note: 2. Same as
it h
E Q switch
position
“
8
”
F N (see note 2)
pos
iti
on
“8”
Dimensions
Note: All units are in millimeters unless otherwise indicated.
Panel Cutouts
(Panel cutout conforms
to DIN 43700)
Two mounting fixtures
M3.5 terminal screws (Horizontally
connecting
N units)
{(n – 1) x 72 + 70 } min.
(including 2-mm clear -
ance between units)
N
67.6 x 67.6

H5AN H5AN
8
Installation
Terminal Arrangement
Note: Specifications for 12- to 24-VDC, 48-VDC, and 100-VDC
models are listed separately in this datasheet.
Gate input
Reset input
(Internally
connected)
External
power
supply
(0 V)
+12 V
+12 V
Contact output
Unused
Power supply
For DC power
Terminal 1: –
Terminal 2: +
Do not use unused
terminals for relaying.
Leave them open.
Unused
Connections
Power Supply Connection
Connect the required supply voltage to terminals 1 and 2.
AC Power Supply DC Power Supply
Load Connection
Terminals 4, 5, and 6 are for contact output while terminals 12 and
13 are for solid-state output. (T erminal 14 is connected to absorb the
surge if an inductive load is connected.)
The control outputs of both contact type and solid-state type are si -
multaneously
available.
Load Operation
When a Load Operates with Contact Output
When a Load Operates with Solid-state Output
Load 1 Load 2
Load 3
(See note.)
Note: Output transistor ON: Low (0 V)
Output transistor OFF: High (12 V)
Note: Connect
a diode when using a Power Supply of 12 V or less.
(See
note.)

H5AN H5AN
9
Connection of Reset and Gate Inputs
For reset input, connect a contact or an open collector type transis -
tor between terminals 8 and 9. The timer resets when contact is
made
or when the transistor is ON. For gate inputs, connect a con -
tact
or an open collector type transistor between terminals 8 and 10.
The timer stops when contact is marked or when the transistor is
ON.
Use a contact of high contact reliability, or an open collector type
transistor with characteristics: VCEO = 20 V min., VCE(S) (residual
voltage)
= 3 V max., I
C
= 50 mA min. and I
CBO
(leakage current) =
0.5 µA max.. Use of a gate input contact with minimum contact
bounce
(chatter) is a must, since the contact bounce time will cause
an error in timer operating time.
When connecting a solid-state circuit not of the open collector type
to the gate or reset inputs as shown below , the voltage of the solid-
state circuit (+V) should be 13 to 30 V , and the V
CE(S)
of the transis -
tor
should be less than 3 V (the current that flows from either termi -
nal
9 or 10 is approximately 10 mA). Moreover , it is essential that the
circuit be ON for gate or reset input, and OFF when there is no input.
Connection of a Power Supply for Externally
Connected Components
The H5AN has a built-in power supply for externally connected com -
ponents
such as sensors for gate or reset input, or loads connected
to the solid-state control output (12 VDC, 80 mA).
Power can be applied to the sensors and loads simultaneously .
Load
(gate) (reset)
Simultaneous Input to a Number of H5AN Tim-
ers with the Same Contact or the Same Open
Collector Transistor
A reset or gate input may be applied to two or more units of H5AN
with only one contact or transistor as shown below . In this case, cau -
tion
is required as a large current flows into the transistor . (The cur -
rent
that flows from H5AN is approximately 10 mA pre unit.)

H5AN H5AN
10
Precautions
Setting of Operating Time
Time Setting Range
Rated time Setting range
99.99 s 0.01 to 99.99 s (see note)
999.9 s 0.1 to 999.9 s (see note)
9999 s 1 to 9999 s
99 min 59 s 1 s to 99 min 59 s
999.9 min 0.1 to 999.9 min (see note)
99 hrs 59 min 1 min to 99 hrs 59 min
999.9 hrs 0.1 to 999.9 hrs (see note)
9999 hrs 1 to 9999 hrs
Note: The decimal point is not shown in the digital display .
1. Since
the H5AN T imer is capable of reading the input data at
any time during normal operation, the set time can be
changed
during power application. This feature sets back the
output from the timer by temporarily setting the longer time or
quickens the output by setting the shorter time. During normal
operation, the set time may be accidentally changed by
touching
a thumbwheel switch, causing the timer to operate
with a dif ferent set time. To prevent this possibility , keep the
front cover closed except when changing the set time.
2. When the set time is all zeroes (e.g., 000.0 s or 00 hrs 00 min),
there will be a momentary control output upon power
application
which can be used to check normal output. When
changing the set time during normal operation, pay special
attention
not to alter the set value to this state.
3. Since the sexagesimal system is adopted, when a rated time
of 99 min 59 s or 99 hrs 59 min is selected, any value set to 6
or more (i.e. 6-9) in the order of x 10 s or x 10 min respectively
will be rated as 5. Some erroneous setting examples are
shown
below .
Examples of Setting/Actual Operating T ime
4. When changing the set time while power is being supplied, an
inadequate push of the thumbwheel switches will display two
numbers in one digital display window , causing the operating
time to drift widely. Therefore, press the thumb-wheel
switches surely. Take particular care in the case when the
other
three digits are all zero, since the improper setting of the
fourth switch to create four zeroes will cause a momentary
output.
(Possible Operating T ime) (Undesirable Setting)
5 min 30 s
00 h 00 min
(momentary
output)
59 s
99 min
59 min
99 hrs
5. When operating the built-in selector switches of the
H5AN-4DM T imer with a backup power supply function for
memory protection, it is necessary to reset (either
externally or manually) the timer at the time the power is
applied.
Also when this type of timer is connected to a device (or
manually) this must also be done when power is applied for
the first time.
Note: If the timer is not reset, it operates in accordance with the
previous specifications or with the factory set specifica-
tions.

H5AN H5AN
11
Resetting of T ype with a Backup Power Supply Function for
Memory Protection
Purchase of H5AN
Is the timer
equipped with
memory protec-
tion?
Drawn out the in-
ternal unit from
the case, or switch
off the power to
reset the timer.
No
Yes
Yes
Yes
No
No
Selection of
specifications
Was the timer
reset after
power applica-
tion?
The timer oper-
ates according to
the factory-set
specifications.
The timer operates ac-
cording to the desired
specifications.
Specifications change in
the middle of operation.
Was the
timer
reset?
The timer operates ac-
cording to the desired
specifications.
The timer operates
according to the
previous specifica-
tions.
6. The type without a backup power supply function for memory
protection operates as shown below depending on the
duration
of the power failure.
(A) Power failure of 0.01 s max.
Note: The timer starts in the initial setting
upon power recovery.
(B)
Power failure of 0.5 s min.
Note: The timer starts in the initial setting
upon power recovery.
(C)
Power failure of 0.01 to 0.5 s.
Note: Either (A) or (B)
The type with a backup power supply function for memory protec-
tion restarts in the status preceding the power failure as shown in
(A),
regardless of the duration of the power failure.
7. The type with backup power supply for memory protection
incorporates a battery for backup power supply which lasts
for about ten years of normal use, meaning data is retained
even during a power failure lasting ten years. (The battery
cannot
be replaced.)
8. When using the timer in operation modes other than N and F
modes (i.e., C, R, K, P , and Q), the control output is available
for the one-shot time only. For this reason, adjust the
one-shot
time by rotating the one-shot time adjustment screw
on the front panel (variable within a range to 0.1 to 1 s).
Mounting
A Mounting Fixture is included with the H5AN. Mount the Unit using
the Mounting Fixture so that the Unit is secure and does not move
Loosen (to the left) the
screws on the Mounting
Fixture sufficiently and
attach
it from the bottom.
Tighten (to the right) the
screws on the Mounting
Fixture completely.
When the screw is tight-
ened
completely , you will
hear it turning freely in
place.
(Y92H-5)

H5AN H5AN
12
A model is also available for vertical gang-mounting (Model
H5AN-4D(M)-300).
Label to cover holes
Fixture
Sunken nut
Specifications label
WARNING
Fire, Explosion, and Severe Burn Hazard
The H5AN has a built-in lithium battery . Be sure to dispose of
the old H5AN properly , as lithium batteries are likely to explode
if incinerated.
ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.
To convert millimeters into inches, multiply by 0.03937. T o convert grams into ounces, multiply by 0.03527.
Cat. No. L050-E1-7B In the interest of product improvement, specifications are subject to change without notice.
Printed in Japan
0301-0.5C (0696)
OMRON Corporation
Industrial Automation Company
Measuring and Supervisory Controls Department
Shiokoji Horikawa, Shimogyo-ku,
Kyoto, 600-8530 Japan
Tel: [phone]/Fax: [phone]
!
