Onbon BX-YQ3AE User manual

△
△△
△
!
LED Multi-media player
User Manual
Before you use the LED controller, please
read this file first and save it for future
BX-YQ3AE

Statement
Any companies or privates cannot copy, transcribe or translate part or
whole content of this file without our written permission. And cannot
use it on any business or benefit filed with any forms.
The specifications and information which are mentioned on the file is
for reference only, if there’s update, we will not inform you. This file is
only for guidance, and all information will not be for any promises.

CATALOG
Brief Introduction
.....................................................................................................................................................1
About Software
.................................................................................................................................................1
Characteristics
...................................................................................................................................................1
Guiding
........................................................................................................................................................................2
Safety Notes.......................................................................................................................................................... 3
Function instruction
............................................................................................................................................... 4
Technical specifications
.......................................................................................................................................... 8
Shape and parameter specification
.................................................................................................................... 9
Physial dimension
............................................................................................................................................ 9
Back panel diagram
.........................................................................................................................................9
Front panel diagram
..................................................................................................................................... 10

1
Brief Introduction
Thanks for ordering LED control card. The design of the control card is according to the
international and industrial standard, but if the operations are incorrect, it ill probably bring you
personal injury and financial harm. As to avoid these and in more from your equipment, please
obey the specifications of this file.
About Software
Cannot do any modification, decompilation, disassembling, decoding or reverse engineering on our
soft are, it’s illegal.
Characteristics
Big loading area, 4 Gigabit Ethernet port output, 1080p@60 frame, 2*1080p@30 frame .
Support high refresh, excellent photograph effect hile using mobile phone, camera .
The output gray level is from 0-65536.
High performance CPU, hard are decoding, HD video smooth playback .
On board 100M Ethernet port, integrated 4G ireless module, WIFI module, also supports
external USB WIFI module interface. Built in WIFI can be used either as a hot spot (AP) or as a
terminal. Support for external 4G routers.
Onboard EMMC large capacity (4G) flash memory, can store 8 hours of high-definition video, ultra
high-definition video 4 hours.
Indefinite expanding memory.on-board SD card and dual USB interface, USB interface supports
large capacity mobile hard disk (1000G).
Audio input interface: 1 ay DVI input, 1 ay CVBS input, 1 ay AUDIO input
Audio &video output interface: 1 DVI output, 1 AUDIO output, can connect the LCD screen,
advertising machine as the train station, bus stations, hospitals and other cro ded places.
Support USB disk plug and play, and also upload into the memory to play, very suitable for
net orking inconvenience place program released.
Support cluster control, especially suitable for large-scale urban outdoor advertising screen
large-scale deployment, management

2
Easy to upgrade the soft are , you can use pc soft are or cloud platform to remote upgrade it , no
need to the pot.
Support temprature, humity, brightness sensor
Support remote controller, can use the remote to request program and adjust the brightness,
volume, screen test etc..
Can manually adjust the brightness, automatic brightness adjustment, 256.
Support 512 programs, each program support in 8 areas, can edit a very beautiful display effect.
Support Image/text/subtitle/video/lunar/time/dial/timer/temperature/temperature &
humidity/noise/ eather forecast area
Support database,Very suitable for high-speed rail, hospitals, banks and other occasions of
information release.
Working temperature -40°C~80°C
Support the DLL, or the protocol
Flexible control method, single user can choice our PC soft are or iLedcloud platform to edit and
release the soft are, large group of users can use iLedsys to set up there o n server ,set up VPDN
to edit and release the programs.
Guiding
Accessory

3
Safety Notes
Input voltage is 5V, voltage range is from 4.75V-5.25V, please make sure the quality of the po er
supply of YQ series.
Please make sure that all the po er supply cables are plugged off hen you ant to connect or plug
off any signal or controlling cables.
Please make sure that all the po er supply cables and signal cables are plugged off hen you need
to put in or take off the hard are equipment.
Please make sure the environment is clean, dry and ventilated hen you use this product, also, do
not put this product to a high temperature and et environment.
This product is electronic products, please keep a ay from fire, ater source and
flammable&combustible products.
There’s high pressure components in this products, please do not open the box and repair it by
yourself.
Turn off the po er supply immediately hen you find smoking, peculiar smell or something unusual.
And contact ith us soon.

4
Function instruction
Control area
There are t o gigabit output ports, in YQ2A, Each gigabit port can support 1280× 1024 pixels,
the maximum idth ≤1920, the maximum height ≤1024. When the user screen parameter is ≤
1280* 1024, refresh rate =60, video, stunt picture ill be very smooth.
T o gigabit output is consistent, you can connect dual-screen, synchronization display the same
contents. When the refresh rate (equivalent to playing video frame rate) is 60 frames, the display
effects is smoothly.
Support high refresh /Perfect photograph effect
YQ series of controller support high refresh (here refers to the receiving card for LED screen
refresh, users scan) or mobile phone camera shooting LED large screen picture from time to time,
no distortion, no scanning line, the true nature and excellent results.
In the ordinary lo refresh display screen, camera, you can see the stripes, stripes is actually a
scan line, generally horizontal black stripes line, it is caused by the screen refresh rate is lo , is the
camera to capture the present.
Synchronous&asynchronous integration
The controller provides t o modes of operation: synchronous mode and asynchronous mode. In
asynchronous mode, users can edit and release programs by themselves. In synchronous mode,
the controller can receive external input video source equipment, and synchronize the output and
sound of the equipment such as TV set, set-top box, DVD and so on.
Mode s itching can be done by the mode button on the front panel of the controller. When the
button is pressed, the controller sequentially enters the synchronous DVI mode, synchronous CVBS
mode, asynchronous mode.
Multiple communication mode / support net ork topology
Multiple communication mode / support network topology
The controller is equipped ith a 100M net ork interface, internal integrated 4G ireless module, WIFI

module, also supports USB interface, external WIFI module. Built-in WIFI both as a hot spot (AP), but also as
a terminal. Supports external 4G routers.
For the general net ork topology, users can use the net ork cable directly access the router or s itch, and
management PC communication.
For short-range ireless applications, the user can open the controller built-in WIFI, access to their o n
routers, to achieve online control management. Users can also open the controller's WIFI hotspots, access to
their o n PC controller, to achieve management control. For the controller hot spots, the user can set the
pass ord, the rights management.
For outdoor remote screen, because the iring is inconvenient, you can choose the ay of remote ireless,
the user uses the onboard integrated 4G module, insert the phone card, set the server mode or eb mode,
the controller can automatically log management platform. Users can also choose to use the USB interface of
the external 4G router.
For large users, the controller supports VPDN (virtual private dial-up net ork), the screen can cross the
public net ork, distributed in the city's traffic arteries, or bet een the city, constitute a virtual private net ork,
remote groups, security management
Support iLEDCloud platform
We provide different type of control platform, including PC soft are Ledsho YQ, iLEDCloud platform ,
iLEDsys system. Ledsho YQ is used on PC , it can support indo s XP, in7, in10 and other mainstream
operating system. The soft are provides a comprehensive, rich controller configuration, programming,
program release function.
iLEDCloud platform , is a online multimedia information publishing platform, its core server pinned on the
Alibaba cloud, providing excellent reliability and stability. Users only need the bro ser to use the platform, you
can remotely edit program, previe the program, scheduled fixed-point playback. Users can log in via
phone, pad and pc.
iLEDsys system is a high-end customers from the deployment of cloud platform, the platform ill run on the
user's o n computer above, to achieve a more secure, stable and efficient management.
Small users, if it is LAN application environment, you can choose to provide our PC soft are Ledsho YQ for
control management.

6
If the use of small users need to cross the public net ork, you can access iLEDCloud cloud platform,
through the eb bro ser to manage.
Large group users can be managed from the deployment cloud platform iLEDsys system. If you need to
cross the public net ork, you can create VPDN, to achieve across the public net ork of virtual intranet, to
manage.
Large storage capacity / capacity can be expanded
The controller provides high-capacity built-in flash memory, also supports external capacity expansion.
Controller built-in 4G flash memory, you can store 8 hours of high-definition video.it provide SD card slot,
allo ing users to insert large capacity SD card, to expand capacity . When users use large capacity SD card
expansion capacity, please s itch the orking medium to the SD card. The controller also supports
high-capacity mobile hard drives on the USB interface, hich can support up to 1T (1000G) of removable
hard disk hen the mobile hard drive is po ered by a separate adapter. When users use large-capacity
mobile hard disk expansion capacity, the need to s itch the orking medium to USB mode.
Hard decoding / audio & video input / output / double video areas/
zoom / ad machine
The controller uses high-performance CPU, hard are decoding, high-definition video playback smooth.
The controller provides 1 DVI input interface, 1 CVBS input interface, 1 AUDIO input, user-friendly access to a
variety of external video source equipment. The external video can be played as a video area ( ith zoom) to
achieve dual video effects.
External video source can also be full-screen playback, to achieve synchronization effect.
The controller provides 1 channel DVI output, 1 AUDIO output, the user can connect LCD LCD screen or TV
and other equipment, as indoor cro ded places advertising machine operation, such as bus stations, rail ay
stations, high-speed rail stations, banks, hospitals Public places.
Program area/variety
Supported area types are rich in graphic text, subtitles, video, lunar calendar, dial, timing, temperature,
humidity, announcements, eather forecasts.

7
Text areas can be pictures or text, supporting a ealth of special effects, including curtain, pan, laser,
mosaic, shutter and other common effects.
Controller processor built-in GPU (graphics processing unit), you can achieve brilliant 3D effects.
The controller supports a variety of time zones, you can set the font of analog dial, dial point, select the
style, the color set. Also can achieve a text type time display, including the date, hour, and eek, can set the
single or multi line display. The support area, including the day, solar term. Support time zones, such as
"distance from national day, 18 days, 18 hours, 18 minutes, 18 seconds" and the like.
Support remote update/daily record
Controller support remote upgrade, users can use PC soft are Ledsho YQ, cloud platform iLEDCloud,
deployment of cloud platform iLEDsys system for remote upgrade, enhance controller functionality,
performance, solve bug.
The controller has built-in logging function, it can record various important events, and can remotely consult,
analyze and solve the fault.
Support remote controller
The controller supports infrared remote control, can change programme on request , lock program. You can
easily adjust the screen brightness, volume, screen s itch machine, test, experience comparable to the TV
remote control, especially for the convenience of indoor display management.
Time /remote switch controller
Match ith VMF multi-function card,the controller supports remote start, shutdo n control , effectively
reduce the screen po er consumption, saving energy.
Support mutli-type of sensor
Match ith VMF multi-function card.it collect temperature, humidity, brightness, noise and other common
sensor data.
Suppport secondary development
Provides C # / C + + dynamic library, can support edit , release, remote control programs .
Provides JAVA dynamic library, support dynamic zone, synchronization area.

8
Support datebase
The controller supports the database area, supports multi-page display, supports mySQL, sqlserver and
other format database.
Support Android App,easy operator
It can be controlled ith Android APP ledsho , managed easily.
APP support search screen, support multi-language, support dynamic previe , video transcoding function.
Support gesture zoom in and out of partition function.
Technical specifications
Screen parameter
Parameter Specifications
Min Pixels 128 x 64
Max Pixels 1280×1024
Total Pixels 1280K Pixels
Max pixels in
idth 1920
Max pixels in
height 1024
Receiving card BX-V75 receiving card
Specifiction
Working voltage 4.5V ～ 6.5V ； Please be sure the good quality of po er
Maximum po er ≤10W
Working temper
ature -40
℃～ 80 ℃

9
Shape and parameter specification
Physial dimension
Physical dimension
194mm118mm46mm
Back panel diagram

10
Video input / output port
DVI-IN 1080P@30HZ
， 1 HDMI
CV CVBS ， PAL/NTSC
DVI -OUT 1 HDMI
Audio input / output port
AUDIO-IN 1 3.5 mm stereo
AUDIO -OUT 1 3.5 mm stereo
Gigabit Ethernet interface
OUT1 Scan data output port , connect ith full color receiving card
OUT2
Front panel diagram

11
Button description
DC5V 5V Po er interface, DC voltage input,rated voltage 5V, support4.5V ~ 6.5V
IR XH254-3P Infrared receiver interface
SYS Indicator light , it ill blink t ice per minute hen controller orks good ,
NET Net ork and fault indicating lamp
MODE
A/SYNC
Video input mode s itch button,Used to s itch asynchronous programs quickly,CVBS
input, and HDMI input
OK OK button,confirmation button for the interactive menu; a shortcut key for displaying
the information on the display hen the menu is not s itched;
θDo n key, interactive menu focus do n
πUp key, interactive menu focus Up
MENU MENU button
， Interactive menu open / close key
SD-CARD SD slot ， Storage expansion slot
USB USB interface, can be connected U disk, external WIFI module, 4G router, mobile hard
disk and so on
WIFI Connect 2.4GHz WIFI antenna, 3 / 4G ireless module interface
LAN Ethernet interface, Fast Ethernet, connected to the computer

Contact Us
Shanghai ONBON Technology Co.,ltd (Headq arters)
Address: 7 Floor, Tower 88, 1199#, North Qinzhou Road, Xuhui District, Shan hai City,
China
Tel Phone: [phone]
Fax: [phone]
Website: www.onbonbx.com
ONBON (Jiangs ) Optoelectronic Ind strial Co.,LTD
Address: 1299#, Fuchun Jian Road, Kunshan City, Jian su Province, China
Sales Contacts
Tel: [phone] 0086-15800379719
Email: [email protected]
Second Development
Tel: [phone]
Email: [email protected]
iLEDClo d
Website: http://www.iledcloud.com/
Public Wechat
ONBON APP
