Onkyo HTP-640 User manual

En
5.1ch Home Theater Speaker Package
HTP-640
SKW-540 POWERED SUBWOOFER
SKF-640F FRONT SPEAKER
SKC-640C CENTER SPEAKER
SKM-640S SURROUND SPEAKER
Instruction Manual
Thank you for purchasing an Onkyo home theater
speaker package. Please read this manual thoroughly
before using your new speakers. Following the
instructions in this manual will enable you to obtain
optimum performance and listening enjoyment from
your speaker package.
Please retain this manual for future reference.
Contents
Getting Started
Important Safety Instructions ...........2
Precautions........................................3
Package Contents..............................3
Getting to knowYour Speaker
Package ...................................... 4
Installing & Using
Connecting the Speakers...................5
About Home Theater ........................6
Connecting the Power Cord..............6
Adjustment........................................6
Appendix
Caring for Your Speakers..................7
Troubleshooting................................7
Specifications........... Back cover page
HTP-640En.fm 1ページ ２００６年６月２２日 木曜日 午前１１時９分

2
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are pro-
vided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience recepta-
cles, and the point where they exit from the appara-
tus.
11. Only use attachments/accessories specified by the
manufacturer.
12.
Use only with the cart, stand,
tripod, bracket, or table spec-
ified by the manufacturer, or
sold with the apparatus.
When a cart is used, use cau-
tion when moving the cart/
apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. Damage Requiring Service
Unplug the apparatus from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
A. When the power-supply cord or plug is dam-
aged,
B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry
Never push objects of any kind into the apparatus
through openings as they may touch dangerous volt-
age points or short-out parts that could result in a
fire or electric shock.
The apparatus shall not be exposed to dripping or
splashing and no objects filled with liquids, such as
vases shall be placed on the apparatus.
Don’t put candles or other burning objects on top of
this unit.
17. Batteries
Always consider the environmental issues and fol-
low local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation,
such as a bookcase or rack, ensure that there is ade-
quate ventilation.
Leave 20 cm (8") of free space at the top and sides
and 10 cm (4") at the rear. The rear edge of the shelf
or board above the apparatus shall be set 10 cm (4")
away from the rear panel or wall, creating a flue-like
gap for warm air to escape.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
HTP-640En.fm 2ページ ２００６年６月２２日 木曜日 午前１１時９分

3
Precautions
1. AC Fuse —The AC fuse inside the unit is not user-
serviceable. If you cannot turn on the unit, contact
your Onkyo dealer.
2. Care —Occasionally you should dust the unit all
over with a soft cloth. For stubborn stains, use a soft
cloth dampened with a weak solution of mild deter-
gent and water. Dry the unit immediately afterwards
with a clean cloth. Don’t use abrasive cloths, thin-
ners, alcohol, or other chemical solvents, because
they may damage the finish or remove the panel let-
tering.
3. Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE
FIRST TIME, READ THE FOLLOWING SEC-
TION CAREFULLY.
AC outlet voltages vary from country to country.
Make sure that the voltage in your area meets the
voltage requirements printed on the unit’s rear panel
(e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
The power cord plug is used to disconnect this unit
from the AC power source. Make sure that the plug
is readily operable (easily accessible) at all times.
Auto standby function does not fully shutdown the
SKW-540. If you do not intend to use the SKW-540
for an extended period, remove the power cord from
the AC outlet.
For Canadian Models
For models having a power cord with a polarized plug:
CAUTION:
TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
Modèle pour les Canadien
Sur les modèles dont la fiche est polarisée:
ATTENTION:
POUR ÉVITER LES CHOCS ÉLEC-
TRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRE-
SPONDANTE DE LA PRISE ET POUSSER
JUSQU’AU FOND.
Package Contents
Make sure your box contains all of the items below. If
anything is missing, contact the nearest Onkyo dealer.
The alphabet displayed at the end of the product name
found in catalogs and on package represents the color of
HTP-640. Though the color varies, the specifications
and operations are the same.
• Front speakers
(SKF-640F)
• Speaker cable for front
speakers 15 ft. (4.5 m)
(Red) (White)
• Center speaker
(SKC-640C)
• Speaker cable for center
speaker 10 ft. (3 m)
(Green)
• Surround speakers
(SKM-640S)
• Speaker cables for sur-
round speakers 30 ft.
(9 m)
(Blue) (Gray)
• Subwoofer (SKW-540)
• RCA cable for sub-
woofer connection
• Rubber spacers [20]
(For the speakers)
• Base for horizontal
mounting
(For the center speaker)
■ Using Rubber Spacers with the Speakers
We recommend using the supplied rubber spacers to achieve
the best possible sound from your speakers. The rubber spac-
ers prevent the speakers from moving, providing a more stable
setup.
Rubber
spacers
Bottom of
the speaker
HTP-640En.fm 3ページ ２００６年６月２２日 木曜日 午前１１時９分

4
Getting to know Your Speaker Package
A
Speaker terminals
These push terminals
are for connecting the
speaker to your AV
Receiver, amp, or
other receiver with the
supplied speaker
cables. The supplied
speaker cables are
color-coded for easy
identification. Simply
connect each cable to
the same-colored posi-
tive speaker terminal.
B
Speaker mount/bracket inserts
These threaded inserts can be used to attach the
speaker to a speaker mount or bracket.
Note:
Use commercially available 1/4" screws to attach
the speaker to a speaker mount or bracket.
C
Keyhole slots
These keyhole slots can be used to wall-mount the
speaker.
Use the center speaker base to mount the center speaker
horizontally. If you place the speaker and its base on top
of a TV or an entertainment center, adjust the angle of
the speaker so that it faces toward the listening position.
The center speaker should be installed on the base
securely. If the speaker is loose, try adjusting the posi-
tion so that it sits securely on the base.
The cradle surface of the base features two stoppers to
prevent the speaker from moving. Therefore, you can
tilt the speaker toward the front by up to 15 degrees.
■ Using the included rubber spacers
We recommend using the
supplied rubber spacers to
achieve the best possible
sound from your speak-
ers. The rubber spacers
prevent the speakers from
moving, providing a more
stable setup.
The speakers can easily be wall mounted by using the
keyhole slots. To prevent the speaker from vibrating
against the wall, attach four of the supplied rubber spac-
ers to the rear of each speaker.
■ Mounting vertically
To mount the speakers vertically, use the one keyhole
slot shown to hang each speaker on the screw that is
securely screwed into the wall.
■ Mounting horizontally
To mount the speakers horizontally, use the two keyhole
slots shown to hang each speaker on two screws that are
securely screwed into the wall.
The plaque of each speaker rotates so that you can posi-
tion the speakers upside down.
Caution:
A mounting screw’s ability to support a speaker
depends on how well it’s anchored to the wall. If you
have hollow walls, screw each mounting screw into a
stud. If there are no studs, or the walls are solid, use
suitable wall anchors.
Use screws with a head diameter of 3/8" or less and a
shank diameter of 1/8" or less. With hollow walls, use a
cable/pipe detector to check for any power cables or
water pipes before making any holes.
Leave a gap of 1/4"–5/16"
between the wall and the
base of the screw head, as
shown.
(We recommend that you
consult a home installation
professional.)
Front, Center & Surround speakers
(SKF-640F, SKC-640C, SKM-640S)
Center Speaker Base
3
1
2
Rear Panel
15˚
SKC-640C
Base for horizontal
mounting
Stoppers
Rubber spacer
Bottom of
the bass
Wall Mounting
Rubber spacer
Keyhole slot for
wall mounting
Keyhole slot for wall
mounting
Rubber spacers
Wall
1/4"–5/16"
HTP-640En.fm 4ページ ２００６年６月２２日 木曜日 午前１１時９分

5
A
STANDBY/ON indicator
Red: Subwoofer in standby mode
Green: Subwoofer on
With the Auto Standby function, the SKW-540
automatically turns on when an input signal is
detected in Standby mode. When there’s no input
signal for a while, the SKW-540 automatically
enters Standby mode.
B OUTPUT LEVEL control
This control is used to adjust the volume of the sub-
woofer.
C LINE INPUT
This RCA input should be connected to the sub-
woofer preout on your AV receiver, amp, or other
receiver with supplied RCA cable.
Note:
The Auto Standby function turns the subwoofer on
when the input signal exceeds a certain level. If the
Auto Standby function does not work reliably, try
slightly increasing or decreasing the subwoofer out-
put level on your receiver or amp.
Connecting the Speakers
Read the following before connecting your speakers:
• Turn off your amp before making any connections.
• Disconnect the power cord from the wall outlet before
making any connections.
• Pay close attention to speaker wiring polarity. Connect
positive (+) terminals to only positive (+) terminals,
and negative (–) terminals to only negative (–) termi-
nals. If the speakers are wired incorrectly, the sound
will be out of phase and will sound unnatural.
• Be careful not to short the posi-
tive and negative wires. Doing so
may damage your amp.
Use the cables to connect each speaker’s input
terminals to the corresponding speaker output
terminals on your receiver.
To make a connection, while pressing
the terminal lever, insert the wire into
the hole, and then release the lever.
Make sure that the terminals are grip-
ping the bare wires, not the insulation.
Using the supplied RCA cable, connect the sub-
woofer’s LINE INPUT to your receiver’s SUB-
WOOFER PREOUT.
Subwoofer (SKW-540)
1
23
■Rear
To AC outlet
■Front
Connecting the Speaker Cables
Connecting the Subwoofer
PRE OUT
SUB
WOOFER
LINE INPUT
Subwoofer Center
speaker
Front left
speaker
Front right
speaker
Surround
right
speaker
Surround
left
speaker
Red White Green
Gray
Blue
HTP-640En.fm 5ページ ２００６年６月２２日 木曜日 午前１１時９分

6
About Home Theater
The HTP-640’s great sound means that you can enjoy surround sound with a real sense of movement in your own
home—just like being in a movie theater or concert hall.
Connecting the Power
Cord
Notes:
• Before connecting the power cord, connect all of your
speakers and AV components.
• Turning on the SKW-540 may cause a momentary
power surge that might interfere with other electrical
equipment on the same circuit. If this is a problem,
plug the SKW-540 into a different branch circuit.
Adjustment
To set the level of the subwoofer, use the OUTPUT
LEVEL control. Set it so that bass sounds are evenly bal-
anced with the treble sounds from the other speakers.
Because our ears are less sensitive
to very low bass sounds, there’s a
temptation to set the level of the
subwoofer too high. As a rule of
thumb, set the subwoofer level to
what you think is the optimal level,
and then back it off slightly.
Enjoying Home Theater
13
13
13
Corner
1/3 room
length
Front left and right speakers (SKF-640F)
These output the overall sound.Their role in a home theater is
to provide a solid anchor for the sound image.They should be
positioned facing the listener at about ear level, and equidis-
tant from the TV. Angle them inward so as to create a triangle,
with the listener at the apex.
Center speaker (SKC-640C)
This speaker enhances the front left and right
speakers, making sound movements distinct and
providing a full sound image. In movies it’s used
mainly for dialog.
Position it close to your TV facing forward at about
ear level, or at the same height as the front left and
right speakers.
Put it somewhere where it won’t slide around or fall.
Subwoofer (SKW-540)
The subwoofer handles the bass sounds
of the LFE (Low-Frequency Effects)
channel. The volume and quality of the
bass output from your subwoofer will
depend on its position, the shape of your
listening room, and your listening posi-
tion. In general, a good bass sound can
be obtained by installing the subwoofer
in a front corner, or at one-third the width
of the wall, as shown.
Surround left and right speakers (SKM-640S)
These speakers are used for precise sound positioning
and to add realistic ambience. Position them at the
sides of the listener, or slightly behind, about 2–3 feet
(60–100 cm) above ear level. Ideally they should be
equidistant from the listener.
Right
Left
Setting the Subwoofer Level (SKW-540)
OUTPUT
LEVEL
MAX
MIN
HTP-640En.fm 6ページ ２００６年６月２２日 木曜日 午前１１時９分

7
Caring for Your Speakers
Placement
• The subwoofer cabinet is made out of wood and is
therefore sensitive to extreme temperatures and
humidity, do not put them in locations subject to direct
sunlight or in humid places, such as near an air condi-
tioner, humidifier, bathroom, or kitchen.
• Do not put water or other liquids close to the speakers.
If liquid is spilled over the speakers, the drive units
may be damaged.
• Speakers should only be placed on sturdy, flat surfaces
that are free from vibration. Putting them on uneven or
unstable surfaces, where they may fall and cause dam-
age, will affect the sound quality.
• Subwoofer is designed to be used in the upright verti-
cal position only. Do not use it in the horizontal or
tilted position.
• If the unit is used near a turntable or CD player, howl-
ing or slipping of sound may occur. To prevent this,
move the unit away from the turntable or CD player
otherwise lower the unit’s output level.
Using Close to a TV or Computer
TVs and computer monitors are magnetically sensitive
devices and as such are likely to suffer discoloration or
picture distortion when conventional speakers are placed
nearby. To prevent this, the SKF-640F, SKC-640C and
SKM-640S speakers feature internal magnetic shielding.
In some situations, however, discoloration may still be
an issue, in which case you should turn off your TV or
monitor, wait 15 to 30 minutes, and then turn it back on
again. This normally activates the degaussing function,
which neutralizes the magnetic field, thereby removing
any discoloration effects. If discoloration problems per-
sist, try moving the speakers away from your TV or
monitor. Note that discoloration can also be caused by a
magnet or demagnetizing tool that’s too close to yourTV
or monitor.
Operating Precautions
The HTP-640 speakers can handle the specified input
power when used for normal music reproduction. If any of
the following signals are fed to them, even if the input
power is within the specified rating, excessive current may
flow in the speaker coils, causing burning or wire breakage:
1. Interstation noise from an untuned FM radio.
2. Sound from fast-forwarding a cassette tape.
3. High-pitched sounds generated by an oscillator,
electronic musical instrument, and so on.
4. Amplifier oscillation.
5. Special test tones from audio test CDs and so on.
6. Thumps and clicks caused by connecting or discon-
necting audio cables (Always turn off your amplifier
before connecting or disconnecting cables.)
7. Microphone feedback.
Speaker care
Wipe the cabinet occasionally with a dry silica or soft
cloth. For heavier dirt, after dampening a soft cloth in a
weak solution of mild detergent and water and wringing
it out dry, wipe off the dirt. Then, dry immediately with
a clean cloth. Do not use rough material, thinners, alco-
hol or other chemical solvents or cloths since these could
damage the finish, remove the panel lettering, or cause
discoloration. If you are using a chemical cloth, always
follow the instructions that come with the cloth. For dust
accumulated on grilles, use a vacuum cleaner or brush it
off.
Troubleshooting
Symptom Possible cause Remedy
There’s no sound coming
from certain speakers?
The speaker cables are not connected properly. Check the speaker cables and correct as necessary.
The number of speaker channels is not set to 5ch
on the receiver.
Set the number of speaker channels to 5ch.
The subwoofer does not
turn on?
The power plug is not fully inserted into the wall
outlet.
Insert the power plug fully into the wall outlet.
The subwoofer produces
no sound?
The OUTPUT LEVEL control is set to minimum. Turn up the OUTPUT LEVEL control.
The RCA cable is not properly connected to the
subwoofer’s LINE INPUT.
Make sure that the RCA cable is properly connected to
the subwoofer’s LINE INPUT.
The level of the input signal was too low and the
subwoofer entered Standby mode.
Slightly increase the subwoofer preout output level on
your amp.
On the receiver, the subwoofer mode is set to SW
Off.
Set the subwoofer mode to something other than SW
Off.
The subwoofer produces
hardly any sound?
The source material contain little or no bass con-
tent.
Choose source material with more bass content.
A humming sound can be
heard from the sub-
woofer?
The RCA cable is not properly connected to the
subwoofer’s LINE INPUT.
Make sure that the RCA cable is properly connected to
the subwoofer’s LINE INPUT.
External interference from a TV or other elec-
tronic device is being picked up.
Move the subwoofer and RCA cable away from the
interference source. Make sure your audio system is
grounded properly.
HTP-640En.fm 7ページ ２００６年６月２２日 木曜日 午前１１時９分

8
SN 29344293
Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone]
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone] http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: [phone] Fax: [phone] http://www.eu.onkyo.com/
ONKYO EUROPE UK Office
Suite 1, Gregories Court, Gregories Road, Beaconsfield, Buckinghamshire, HP9 1HQ
UNITED KINGDOM Tel: [phone] Fax: [phone]
ONKYO CHINA LIMITED
Unit 1 & 12, 9/F, Ever Gain PlazaTower 1, 88, Container Port Road, Kwai Chung,
N.T., Hong Kong Tel: [phone] Fax: [phone]
http://www.ch.onkyo.com/
(C) Copyright 2006 ONKYO CORPORATION Japan. All rights reserved.
* 2 9 3 4 4 2 9 3 *
http://www.onkyo.com/
HOMEPAGE
D0606-1
Specifications
■ Powered Subwoofer (SKW-540)
Type: Bass-reflex
Input sensitivity/impedance: 330 mV / 100 k
Ω
Maximum output power: 230 W (Dynamic Power)
Frequency response: 25 Hz–150 Hz
Cabinet capacity: 1.36 cubic feet
Dimensions (W
× H × D): 10-13/16" × 18-5/8" ×
16-7/8"
Weight: 25.4 lbs.
Drivers unit: 10 inch Cone Woofer
Power supply: AC 120 V, 60 Hz
Power consumption: 140 W
Other: Auto Standby function
■ Front/Center/Surround Speaker
(SKF-640F/SKC-640C/SKM-640S)
Type: 2 Way Bass-reflex
Impedance: 8
Ω
Maximum input power: 110 W
Output sound pressure level: 82 dB/W/m
Frequency response: 65 Hz–35 kHz
Crossover frequency: 5 kHz
Cabinet capacity: 0.09 cubic feet
Dimensions (W
× H × D): 6-5/16" × 13-3/8" × 3-11/16"
Weight: 4.2 lbs.
Drivers unit: 3-1/8" Cone (Woofer)
× 2
1 inch Balanced Dome
(Tweeter)
Terminal: Spring type color-coded
Other: Magnetic shielding
Specifications and appearance are subject to change
without prior notice.
HTP-640En.fm 8ページ ２００６年６月２２日 木曜日 午前１１時９分
