Onkyo HTP-690 User manual

HTP-690
Front speaker (SKF-690) Center speaker (SKC-690)
Surround speaker (SKR-690)
Front speakers Speaker cables 11 ft.
(3.5 m)
Center speaker
Speaker cable 10 ft.
(3.0 m)
Surround speakers Speaker cables 26 ft.
(8.0 m)
12 rubber stoppers* (For Front/Surround speakers)
4 rubber stoppers*
(White) (Red)
(Green)
(Blue) (Gray)
Powered subwoofer (SKW-780)
Subwoofer
RCA cable 10 ft.
(3.0 m)
4 floor pads
5.1ch Home Theater Speaker Package
Black model
MODEL HTP-690(B)
120V AC, 60HzB MDC
Ref. No. 4310
072011
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR
RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS TO DETERMINE THAT EXPOSED ARTS ARE ACCEPTABLY
INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER.

HTP-690
EXPLODED VIEWS - 1
SKW-780
A
1
2
3
4
5
B C D E F G H
A104
x 2 pcs.
A103
A102
P901
U0011
A105
A0105
x 2 pcs.
A012
E801
A005
x 5 pcs.
A011
U0010
A101
A002
A002
A008
x 2 pcs.
A007
A007 A005
Q515
Q516
Q541
F901
T901
A005
x 2 pcs.
A003
R E F. N O . P AR T N AM E D E SC R IP T IO N Q 'T Y P AR T N O . (S N ) R E M AR K S
S K W -78 0
SP01A SPK SYSTEM ASSY ALL 1 000-SKW780BMDC
SP01B SUBWOOFER ASSY
Without AMP unit and
Power transformer
1 ???
SP02 FOOT 4 D249-W55001B-01
SP03 LED HARNESS Ass'y 1 335-SKW750-01
SP04 WOOFER (ONKYO) OAE(JITRA) 1 W2302B
[S EM I C O N D U C T O R ]
Q515 TR 2SC5359-R 1 2203082
Q515 or TR 2SC5359-O ( 1) 2203083
Q516 TR 2SA1987-R(Q) 1 2203072
Q516 or TR 2SA1987-O ( 1) 2203073GR
Q541 TR 2SC3423-Y 1 2202104
Q541 or TR 2SC3423-O ( 1) 2202103
[C H AS S IS S C R E W ]
A001 HEAT SINK 230 1 27160591
A002 CUSHION --- 2 28141682
A003 CUSHION --- 1 28141691
A007 ISO SHEET AC262 2 223025
A011 RETAINER (PCB) 1 27142025
A012 RETAINER (TRANS)SKW-538 1 27142177A
A101 REAR PANEL
SKW-780DAMP(X)MDD/MDC(S&V)
1 27124183B N
A102 BUSHING S-RELIEF #2271 1 27300750
A103 KNOB (VOL) 1 28326463
A005 SCREW 3TTB+8B(3BC) 10 838430088GR
A008 SCREW 3SMS8W.SW+14B(CU) 2 801634
A104 SCREW 3SMS8W.SW+14B(3BC) 2 801433GR
[T R AN S C O IL]
T901 P TRANS NPT-1578D 1 2301948 !
[S W T R M ]
F901 FUSE 5A-UL/T-233 1 252326GR !
P901 AC CORD AS-UC-2 1 253368BLTK !
P901 or AC CORD AS-UC-2 ( 1) 253368AYUN !
[O T H E R S ]
E801 WIRE TIE BSK-1 1 260208
[T U N E R U N IT ]
U001 U0010 ~ U0012 BAAF-0491-2H * 1 1B139591-2H
U0010 MAIN PCB AS BAAF-0491-2H 1 1B1395491-2H
U0011 POWER SUPPLY PCB AS BAPS-0492-2H 1 1B1395492-2H
U0012 ETC BAETC-0498-2H 1 NSP
SP04
SP03
SP02
x 4 pcs.
----- SP01A (Subwoofer ass’y) (All) -----
----- SP01B (Subwoofer ass’y)
(Without AMP unit, Speaker unit and Power transformer) -----

HTP-648/690
Exploded views - 2
SKF-648/690, SKC-648/690, SKR-648/690
HTP-648/690
A
1
2
3
4
B C D E
a12PSa02PS
a62PSa52PS
SP23a
TERMINAL :
White / Black
TERMINAL :
Red / Black
TERMINAL :
Blue / Black
TERMINAL :
Gray / Black
TERMINAL :
Green / Black
SKF-648/690 <L> SKF-648/690 <R>
SKR-648/690 <L> SKR-648/690 <R>
SKC-648/690

1/10 PAGE
HTP-690
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
HTP-690
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
SKW-780
SP01A SPK SYSTEM ASSY ALL 1 000-SKW780BMDC
SP01B SUBWOOFER ASSY Without AMP unit and
Power transformer 1 ???
SP02 FOOT 4 D249-W55001B-01
SP03 LED HARNESS Ass'y 1 335-SKW750-01
SP04 WOOFER (ONKYO) OAE(JITRA) 1 W2302B
[SEMI CONDUCTOR]
Q515 TR 2SC5359-R 1 2203082
Q515 or TR 2SC5359-O ( 1) 2203083
Q516 TR 2SA1987-R(Q) 1 2203072
Q516 or TR 2SA1987-O ( 1) 2203073GR
Q541 TR 2SC3423-Y 1 2202104
Q541 or TR 2SC3423-O ( 1) 2202103
[CHASSIS SCREW]
A001 HEAT SINK 230 1 27160591
A002 CUSHION --- 2 28141682
A003 CUSHION --- 1 28141691
A007 ISO SHEET AC262 2 223025
A011 RETAINER (PCB) 1 27142025
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.

2/10 PAGE
A012 RETAINER (TRANS)SKW-538 1 27142177A
A101 REAR PANEL SKW-780DAMP(X)MDD/MDC(S&
V
1 27124183B N
A102 BUSHING S-RELIEF #2271 1 27300750
A103 KNOB (VOL) 1 28326463
A005 SCREW 3TTB+8B(3BC) 10 838430088GR
A008 SCREW 3SMS8W.SW+14B(CU) 2 801634
A104 SCREW 3SMS8W.SW+14B(3BC) 2 801433GR
[TRANS COIL]
T901 P TRANS NPT-1578D 1 2301948 !
[SW TRM]
F901 FUSE 5A-UL/T-233 1 252326GR !
P901 AC CORD AS-UC-2 1 253368BLTK !
P901 or AC CORD AS-UC-2 ( 1) 253368AYUN !
[OTHERS]
E801 WIRE TIE BSK-1 1 260208
[TUNER UNIT]
U001 U0010 ~ U0012 BAAF-0491-2H * 1 1B139591-2H
U0010 MAIN PCB AS BAAF-0491-2H 1 1B1395491-2H
U0011 POWER SUPPLY PCB AS BAPS-0492-2H 1 1B1395492-2H
U0012 ETC BAETC-0498-2H 1 NSP
[PACKING]
A601 LABEL LABEL SHEET 1 29360840A
A603 TAPE (SEROHAN)NITTO NO.29 1 29110149
A604 TAPE TAPE(CLOTH-16U) 1 29110083
A903 SHEET 200x150t0.5 1 29095961
[ACCESSARY]
F901C LABEL 5A/125V 1 29360462
HTP-690
PACKING PROCEDURES PARTS LIS
T
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS

3/10 PAGE
HTP-690
PC BOARD PARTS LIS
T
U001 U0010 ~ U0012 BAAF-0491-2H * 11B139591-2H
U0010 MAIN PCB AS BAAF-0491-2H 11B1395491-2H
U0011 POWER SUPPLY PCB AS BAPS-0492-2H 11B1395492-2H
U0012 ETC BAETC-0498-2H 1NSP
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D501 ZENER D MTZJ5.6B 1 224470562T
D601 ZENER D MTZJ3.6B 1 224470362T
D602 ZENER D MTZJ3.6B 1 224470362T
D603 DIODE 1SS133 1 223163T
D605 DIODE 1SS133 1 223163T
D606 DIODE 1SS133 1 223163T
D607 DIODE 1SS133 1 223163T
D651 DIODE 1SS133 1 223163T
D652 DIODE 1SS133 1 223163T
D707 DIODE 1SS133 1 223163T <X MDD>
D708 DIODE 1SS133 1 223163T <X MDD>
D709 DIODE 1SS133 1 223163T <X MDD>
D901 DIODE D3SBA60 1 22380272F
D901 or DIODE RBV402 ( 1) 22380022F
D911 DIODE 1SS133 1 223163T
D913 DIODE 1SS133 1 223163T
D917 DIODE 1SS133 1 223163T
D918 DIODE 1SS133 1 223163T
D919 DIODE RL1N4003 1 22380260T
D920 ZENER D MTZJ9.1B 1 224470912T
Q301 IC NJM4558L-D 1 22240293

4/10 PAGE
Q501 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q502 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q503 TR 2SC2240-BL(TPE2_F) 1 2211406T
Q505 TR 2SA949-O(TPE6_F) 1 2211353T
Q505 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T
Q505 or TR KTA1024-Y ( 1) 2215844T
Q506 TR 2SC2229-O(TPE6_F) 1 2211633T
Q506 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T
Q506 or TR KTC3206-Y ( 1) 2215854T
Q507 TR 2SA949-O(TPE6_F) 1 2211353T
Q507 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T
Q507 or TR KTA1024-Y ( 1) 2215844T
Q509 TR 2SA949-O(TPE6_F) 1 2211353T
Q509 or TR 2SA949-Y(TPE6_F) ( 1) 2211354T
Q509 or TR KTA1024-Y ( 1) 2215844T
Q510 TR 2SC2229-O(TPE6_F) 1 2211633T
Q510 or TR 2SC2229-Y(TPE6_F) ( 1) 2211634T
Q510 or TR KTC3206-Y ( 1) 2215854T
Q513 TR 2SC5171(ONK_Q) 1 2203010
Q513 or TR KTD2061-Y ( 1) 2203434
Q514 TR 2SA1930(ONK_Q) 1 2203000
Q514 or TR KTB1369-Y ( 1) 2203424
Q517 TR 2SA933S-S 1 2213355T
Q517 or TR 2SA933S-R ( 1) 2213354T
Q517 or TR KTA1267-GR ( 1) 2215995T
Q518 TR 2SC2235-Y(TPE6_F) 1 2211654T
Q519 TR 2SA965-Y(TPE6_F) 1 2211644T
Q602 TR KRC103M 1 2215810T
Q602 or TR DTC124ES ( 1) 2213160T
Q603 TR 2SC1740S-S 1 2213285T
Q603 or TR 2SC1740S-R ( 1) 2213284T
Q603 or TR KTC3199-GR ( 1) 2215864T
Q604 TR 2SA933S-S 1 2213355T

5/10 PAGE
Q604 or TR 2SA933S-R ( 1) 2213354T
Q604 or TR KTA1267-GR ( 1) 2215995T
Q605 TR 2SA933S-S 1 2213355T
Q605 or TR 2SA933S-R ( 1) 2213354T
Q605 or TR KTA1267-GR ( 1) 2215995T
Q606 TR KRA103M 1 2215780T
Q606 or TR DTA124ES ( 1) 2212600T
Q607 TR 2SA933S-S 1 2213355T
Q607 or TR 2SA933S-R ( 1) 2213354T
Q607 or TR KTA1267-GR ( 1) 2215995T
Q608 TR 2SC1740S-S 1 2213285T
Q608 or TR 2SC1740S-R ( 1) 2213284T
Q608 or TR KTC3199-GR ( 1) 2215864T
Q610 TR 2SA933S-S 1 2213355T
Q610 or TR 2SA933S-R ( 1) 2213354T
Q610 or TR KTA1267-GR ( 1) 2215995T
Q612 TR 2SC1740S-S 1 2213285T
Q612 or TR 2SC1740S-R ( 1) 2213284T
Q612 or TR KTC3199-GR ( 1) 2215864T
Q703 TR 2SC1740S-S 1 2213285T <X MDD>
Q703 or TR 2SC1740S-R ( 1) 2213284T <X MDD>
Q703 or TR KTC3199-GR ( 1) 2215864T <X MDD>
Q704 TR 2SC1740S-S 1 2213285T <X MDD>
Q704 or TR 2SC1740S-R ( 1) 2213284T <X MDD>
Q704 or TR KTC3199-GR ( 1) 2215864T <X MDD>
Q705 TR 2SA933S-S 1 2213355T <X MDD>
Q705 or TR 2SA933S-R ( 1) 2213354T <X MDD>
Q705 or TR KTA1267-GR ( 1) 2215995T <X MDD>
Q706 TR DTC123JS 1 2213640T <X MDD>
Q901 TR DTC123JS 1 2213640T
Q902 IC 78M05AHF(MPC78M05AHF) 1 222780055NEC
Q902 or IC 78M05(NJM78M05FA) ( 1) 222780055JRC
[TRANS COIL]

6/10 PAGE
T902 P TRANS NPT-1520JQ 1 2301812A <X MDD>
[CAPACITOR]
C301 UPZ C 2AUPZTF221JE 1 376332214T <X MDD>
C302 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C303 TF C ECQ-V50V-223J 1 374722234T <X MDD>
C501 UTSP C CE04W50V 47M(UTSP) 1 397584707T
C503 TF C ECQ-V50V-474J 1 374724744T <X MDD>
C504 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C505 CERA C CC45CH50V-020C 1 345340201T
C506 CERA C CC45CH50V-070D 1 345340702T
C514 UPZ C 2AUPZTF101JE 1 376331014T
C517 VR C CE04W100V-22M(VR) 1 394692207T
C519 TF C ECQ-V50V-224J 1 374722244T
C520 TF C ECQ-V50V-224J 1 374722244T
C526 VR C CE04W100V-22M(VR) 1 394692207T
C527 UTSP C CE04W50V-1M(UTSP) 1 397580107T
C528 VR C CE04W100V-22M(VR) 1 394692207T
C601 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C602 UTSP C CE04W50V-10M(UTSP) 1 397581007T
C603 UTSP C CE04W10V-470M(UTSP) 1 397534717T
C604 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
C605 UTSP C CE04W50V-4.7M(UTSP) 1 397580477T
C704 UTSP C CE04W10V-470M(UTSP) 1 397534717T <X MDD>
C707 TF C ECQ-V50V-223J 1 374722234T <X MDD>
C709 TF C ECQ-V50V-223J 1 374722234T <X MDD>
C903 TF C ECQ-V100V-104J 1 374731044T
C904 TF C ECQ-V100V-104J 1 374731044T
C905 ELECT C CE62W63V-5600M 1 3504399 <X MDD>
C905 or ELECT C CE69W63V-5600M ( 1) 3504481 <X MDD>
C906 ELECT C CE62W63V-5600M 1 3504399 <X MDD>
C906 or ELECT C CE69W63V-5600M ( 1) 3504481 <X MDD>
C907 UTSP C CE04W25V-220M(UTSP) 1 397552217T
C908 UTSP C CE04W25V-220M(UTSP) 1 397552217T

7/10 PAGE
C911 UTSK C CE04W25V-1000M(UTSK) 1 398351027S
C912 UTSK C CE04W25V-1000M(UTSK) 1 398351027S
C914 UTSK C CE04W25V-1000M(UTSK) 1 398351027S
C915 TF C ECQ-V50V-224J 1 374722244T
C916 IS C MKP R46 103M 1 3500202S
C917 UTSP C CE04W50V-22M(UTSP) 1 397582207T
C919 TF C ECQ-V50V-104J 1 374721044T
C921 PLA C MKP R46 104M 1 3800041S <X MDD>
C955 TF C ECQ-V50V-223J 1 374722234T
[RESISTOR]
R301 CARBON R R16J-1K 1 417341024T
R302 VARI R N17RGL20KB15M 1 5151508
R303 CARBON R R16J-47K 1 417344734T
R304 CARBON R R16J-82K 1 417348234T <X MDD>
R305 CARBON R R16J-33K 1 417343334T <X MDD>
R307 CARBON R R16J-270 1 417342714T
R501 CARBON R R16J-1K 1 417341024T
R502 CARBON R R16J-33K 1 417343334T
R503 CARBON R R16J-5.6K 1 417345624T
R504 CARBON R R16J-2.2K 1 417342224T
R505 NF CARBON R R25J-1.0K 1 415471024T
R506 NF CARBON R R25J-1.0K 1 415471024T
R507 CARBON R R16J-33K 1 417343334T
R508 NF CARBON R R25J-47 1 415474704T
R509 CARBON R R16J-1K 1 417341024T
R510 CARBON R R16J-100K 1 417341044T
R511 NF CARBON R R25J-82 1 415478204T
R512 NF CARBON R R25J-68 1 415476804T
R513 NF CARBON R R25J-82 1 415478204T
R514 NF CARBON R R25J-82 1 415478204T
R515 CARBON R R16J-12K 1 417341234T
R516 CARBON R R16J-12K 1 417341234T
R517 CARBON R R16J-3.3K 1 417343324T

8/10 PAGE
R521 CARBON R R16J-220 1 417342214T
R522 CARBON R R16J-220 1 417342214T
R526 METAL O R RS1/2WBJ-82 1 443528204T
R527 CARBON R R16J-270 1 417342714T
R528 METAL O R RS1/2WBJ-390 1 443523914T
R531 METAL PR RF-5EGKR22 1 4000201
R531 or METAL PR RGC55 0.22 ( 1) 4000132
R531 or METAL P R RGC55C 0.22 K ( 1) 4000157
R531 or METAL PR MPR5W+5W 0R22 ( 1) 4000233
R533 METAL R RNU1WCJ-3.3 1 453630334T
R541 NF CARBON R R25J-820 1 415478214T
R542 CARBON R R16J-150 1 417341514T
R543 CARBON R R16J-180 1 417341814T
R544 TRIM R N06HR100BC 1 5210399T
R601 CARBON R R16J-5.6K 1 417345624T
R602 CARBON R R16J-100K 1 417341044T
R603 CARBON R R16J-150K 1 417341544T
R604 CARBON R R16J-180 1 417341814T
R605 CARBON R R16J-22 1 417342204T
R609 CARBON R R16J-39K 1 417343934T
R610 CARBON R R16J-560K 1 417345644T
R611 CARBON R R16J-820K 1 417348244T
R612 CARBON R R16J-39K 1 417343934T
R613 CARBON R R16J-470K 1 417344744T
R614 CARBON R R16J-120K 1 417341244T
R615 CARBON R R16J-22K 1 417342234T
R616 CARBON R R16J-100K 1 417341044T
R617 CARBON R R16J-1K 1 417341024T
R619 CARBON R R16J-22K 1 417342234T
R620 CARBON R R16J-100K 1 417341044T
R621 CARBON R R16J-1K 1 417341024T
R622 CARBON R R16J-10K 1 417341034T
R623 CARBON R R16J-22K 1 417342234T

9/10 PAGE
R624 CARBON R R16J-100K 1 417341044T
R625 CARBON R R16J-180K 1 417341844T
R626 CARBON R R16J-2.2M 1 417342254T
R627 CARBON R R16J-680K 1 417346844T
R628 CARBON R R16J-330K 1 417343344T
R630 CARBON R R16J-10K 1 417341034T
R631 CARBON R R16J-10K 1 417341034T
R651 METAL O R RS1WBJ-10K 1 443621034T
R652 CARBON R R16J-470K 1 417344744T
R653 CARBON R R16J-680K 1 417346844T
R654 CARBON R R16J-330K 1 417343344T
R704 CARBON R R16J-100K 1 417341044T <X MDD>
R714 CARBON R R16J-47K 1 417344734T <X MDD>
R715 CARBON R R16J-10K 1 417341034T <X MDD>
R716 CARBON R R16J-1K 1 417341024T <X MDD>
R717 CARBON R R16J-10K 1 417341034T <X MDD>
R904 METAL R RNU1/2WCJ-0.22 1 453532294T
R905 METAL R RNU1/2WCJ-0.47 1 453534794T
R906 METAL O R RS1/2WBJ-22 1 443522204T
R907 METAL O R RS1/2WBJ-22 1 443522204T
R954 METAL O R RS1/2WBJ-33 1 443523304T
R981 METAL O R RS1WBJ-470 1 443624714T
R982 METAL O R RS1WBJ-470 1 443624714T
R983 METAL O R RS1WBJ-470 1 443624714T
R984 METAL O R RS1WBJ-470 1 443624714T <X MDD>
[SW TRM]
E801 RETAINER KANAGU(EARTH) 1 27141059
F901A FUSE HOL NSCT-1P2506 1 25052609T
F901Aor FUSE HOL NSCT-1P2031 ( 1) 25052133T
F901B FUSE HOL NSCT-1P2506 1 25052609T
F901Bor FUSE HOL NSCT-1P2031 ( 1) 25052133T
P301 PIN JACK NPJ-1PDB581 1 25045801
P301 or PIN JACK NPJ-1PDBL382 ( 1) 25045567

10/10 PAGE
P301 or PIN JACK NPJ-1PDB556 ( 1) 25045774
P531 PLUG NPLG-2P29 1 25055038
P535A SOCKET AS NSAS-2P1852 1 2009991188UL <X MDD>
P631 PLUG NPLG-2P29 1 25055038
P632A PLUG NPLG-3P131 1 25055147
P902A PLUG NPLG-2P632 1 25055676
P903A PLUG NPLG-4P151 1 25055167
P903B SOCKET AS NSAS-7P1834 1 20099900740UL
P908A SOCKET AS NSAS-10P1152 1 2002A391040UL
P908B PLUG NPLG-5P133 1 25055149
RL901 RELAY NRL-1P5A-DC9-179 1 25065669

HTP-690
ONKYO EUROPE ELECTRONICS GmbH (UK BRANCH)
The Coach House 81A High Street, Marlow, Buckinghamshire, SL7 1AB, UK
Tel: [phone] Fax: [phone]
ONKYO U.S.A. CORPORATION
18 Park Way, Upper Saddle River, N.J. 07458, U.S.A.
Tel: [phone] Fax: [phone]
http://www.us.onkyo.com/
ONKYO EUROPE ELECTRONICS GmbH
Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY
Tel: [phone] Fax: [phone]
http://www.eu.onkyo.com/
Technical Support, Service Dept.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN
Tel: [phone] Fax: [phone]
ONKYO SOUND & VISION CORPORATION
ONKYO CHINA LIMITED
Unit 1033, 10/F, Star House, No 3, Salisbury Road, Tsim Sha Tsui Kowloon, Hong Kong.
Tel: [phone] Fax: [phone]
http://www.ch.onkyo.com/
