Onyx ONYX-1222 User manual

Slim Medical Panel PC
O N Y X - 1222
ONYX-1222
11.6”LCD with LED Backlight
Intel®Celeron J1900 Quad Core Processor
Slim Medical Panel PC
ONYX-1222 Manual 2nd Ed
Jun., 2016

Slim Medical Panel PC
O N Y X - 1222
Copyright Notice
This document is copyrighted, 2016. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties, which may result
from its use.
The material in this document is for product information only and
is subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, ONYX Healthcare Inc., assumes no liabilities resulting
from errors or omissions in this document, or from the use of the
information contained herein
ONYX Healthcare Inc. reserves the right to make changes in the
product design without notice to its users

Slim Medical Panel PC
O N Y X - 1222
Acknowledgments
Intel®CeleronTM is registered trademarks of Intel®Corporation.
Microsoft®Windows is a registered trademark of Microsoft®
Corporation.
All other product names or trademarks are properties of their
respective owners.

Slim Medical Panel PC
O N Y X - 1222
Packing List
Before you begin installing your Slim Medical Panel PC, please
make sure that the following items have been shipped:
ONYX-1222 Slim Medical Panel PC
Utility DVD-ROM, which contains Drivers and Utilities
Four VESA Screws(M:4mm x P:0.7mm x L:10mm)
Medical Power Adapter 60W/12VDC

Slim Medical Panel PC
O N Y X - 1222
If any of these items are missing or damaged, you should contact
your distributor or sales representative immediately.
Headquarters
Onyx Healthcare Inc.
2F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist.,
New Taipei City 231, Taiwan (R.O.C.)
TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
http://www.onyx-healthcare.com
Worldwide Offices:
Onyx Healthcare, USA Inc.
324W. Blueridge Ave., Orange,, CA 92865, USA
Tel : [phone]
Fax: [phone]
Email: [e-mail]
Onyx Healthcare EUROPE B.V.
Primulalaan 42, 5582 GLWaalre, Netherlands
Tel : [phone]
Email: [e-mail]

Slim Medical Panel PC
O N Y X - 1222
Onyx Healthcare (Shanghai) INC.
20F, unit D, GEM Building, No. 487 Tianlin Road,
Shanghai, China
Tel: [phone]
Fax: [phone]
Email: [e-mail]

Slim Medical Panel PC
O N Y X - 1222
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning.
Do not use liquid or spray detergents for cleaning. Use a damp
cloth.
4. For pluggable equipment, the power outlet must be installed
near the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect
the equipment from overheating. DO NOT COVER THE
OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Warning: To avoid risk of electric shock, this equipment
must only be connected to a supply mains with protective
earth. (Avertissement: Pour éviter tout risque de choc
électrique, cet appareil doit être connecté à une
alimentation secteur avec une prise de terre)
10. Position the power cord so that people cannot step on it. Do
not place anything over the power cord.
11. All cautions and warnings on the equipment should be noted.

Slim Medical Panel PC
O N Y X - 1222
12. If the equipment is not used for a long time, disconnect it from
the power source to avoid damage by transient over-voltage.
13. Never pour any liquid into an opening. This could cause fire or
electrical shock.
14. Never open the equipment. For safety reasons, only
qualified service personnel should open the equipment.
15. Warning: Do not modify this equipment without
authorization of the manufacturer. (Avertissement: Ne pas
modifier cet équipement sans l'autorisation du fabricant)
16. Warning : It is necessary for checking or replacing the
battery pack every year. (Avertissement: Il est nécessaire de
vérifier ou de remplacer la batterie chaque année)

Slim Medical Panel PC
O N Y X - 1222
16. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it
to work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
17. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -20°C (-4°F) OR ABOVE 60°C (140°F). IT MAY
DAMAGE THE EQUIPMENT.
18. External equipment intended for connection to signal
input/output or other connectors, shall comply with
relevant UL / IEC standard (e.g. UL 1950 for IT equipment
and ANSI/AAMI ES 60601-1: 2005 AND CAN/CSA-C22.2 No.
60601-1:08 / IEC 60601 series for systems –shall comply
with the standard IEC 60601-1-1, Safety requirements for
medical electrical systems. Equipment not complying
with UL 60601-1 shall be kept outside the patient
environment, as defined in the standard.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.

Slim Medical Panel PC
O N Y X - 1222
Classification
1. Degree of production against electric shock: not classified
2. Degree of protection against the ingress of water: IPX0
3. Mode of operation: Continuous
4. Type of protection against electric shock: Class I equipment
5. No Applied Part, No AP/APG

Slim Medical Panel PC
O N Y X - 1222
FCC
This device complies with Part 18 FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not
cause harmful interference, and (2) this
device must accept any interference
received including interference that may
cause undesired operation.

Slim Medical Panel PC
O N Y X - 1222
UL Module Description
ONYX-1222 module is developed to suitable
for the Classification Mark requirement

Slim Medical Panel PC
O N Y X - 1222
Safety Symbol Description
The following safety symbols are the further explanations for your
reference.
Medical equipment with respect to electric
shock, fire and mechanical hazards only in
accordance with ANSI/AAMI ES 60601-1:
2005 AND CAN/CSA-C22.2 No.
60601-1:08
Attention, consult ACCOMPANYING
DOCUMENTS.
Stand-by
Ground wire
Protective Ground wire.

Slim Medical Panel PC
O N Y X - 1222
Contents
Chapter 1 General Information
1.1 Introduction..................................................................1-2
1.2 Feature.........................................................................1-3
1.3 Specification................................................................1-4
1.4 Dimension....................................................................1-8
Chapter 2 Hardware Installation
2.1 Safety Precautions ......................................................2-2
2.2 Quick Tour of ONYX-1222............................................2-3
2.3 Mounting…………………………………………………… 2-6
2.4 Turn On and Boot up into Windows…………………….2-6
2.5 Turn off……………………………………………………….2-6
Chapter 3 Driver Installation
Appendix A Miscellanea
A.1 General Cleaning Tips................................................C-2
A.2 Cleaning Tools...........................................................C-3
A.3 Scrap Computer Recycling ......................................C-5

Slim Medical Panel PC
O N Y X - 1222
General
Information
Chapter
1

Slim Medical Panel PC
O N Y X - 1222
Chapter 1 General Information 1-1
1.1 Introduction
ONYX-1222 Slim Medical Panel PC is based on Intel®CeleronTM
J1900 Quad Core processor, which delivers a performance
improvement of more than 100 percent compared to systems
running traditional single-core processors. With four cores
computing engines, ONYX-1222 can simultaneously execute four
computing tasks. It accommodates one 2.5” SATA hard disk
drive/SSD and two DDRIII SODIMM up to 8GB.
The high brightness LCD, zero noise solution, integrated
multimedia functions make them the perfect platform upon which to
build comprehensive lifestyle computing applications.
ONYX-1222 includes all the features of a powerful computer into a
slim and attractive chassis. It has a 11.6” 400 nits TFT display with
1366 x 768 resolution. ONYX-1222 owns a side mounted USB 3.0
port and a smart card reader to support high speed data transfer
and ID check. Combining ONYX-1222 into your system can achieve
both cost-saving and efficient improvements in common
applications including Surgical, Radiology, PACS (Picture Archiving
Communication Systems), LIS (Lab Information Systems) and
Electronic Medical Record. ONYX-1222 is definitely your perfect
choice.

Slim Medical Panel PC
O N Y X - 1222
Chapter 1 General Information 1-2
1.2 Feature
Intel®CeleronTM J1900 Quad Core Processor
Supports Dual Channel DDR3 SODIMM up to 8GB
Built-in RFID and Smart Card Security (Optional)
High Speed USB 3.0 Port
5 Smart Function Keys
Handset with remote control(Optional)
Magnetic Card Reader(optional)
Power over Ethernet Module for LAN1(optional)

Slim Medical Panel PC
O N Y X - 1222
Chapter 1 General Information 1-3
1.3 Specification
Hardware Specifications
Display
11.6”1366x768 LCD
CPU
Intel®CeleronTM J1900 Processor
Disk Drive
Space
2.5” Hard Disk Drive/Solid State Drive, mSATA Solid State
Drive
Expansion
N/A
Function
Key
Power On/Off, Speaker Volume Up/Down, LCD Brightness
Up/Down
I/O
1x Isolated RS-232 port
4x USB 2.0 ports
2x Isolated Gigabit LAN
Sound:
1 x Line-out
1 x Mic-in
LCD Specifications
Display Type
11.6”LCD
Max. Resolution
1366 x 768
Max. Colors
16.7M
Dot Size (mm)
0.1875 x 0.1875
Luminance (cd/m2)
400(TYP)
Back Light Life Time
>15,000 Hrs

Slim Medical Panel PC
O N Y X - 1222
Chapter 1 General Information 1-4
Note:
All ONYX LCD products are manufactured with High precision technology.
However, there are a small number of defective pixels in all LCD panels
that are not able to change color. This is a normal occurrence for all LCD
displays from all manufacturers and should not be noticeable or
objectionable under normal operation. All LCD panels are qualified for
industry standard conditions in the following: total 7 dead pixels on a
screen or if there are 3 within 1 inch square area of each other on the
display.

Slim Medical Panel PC
O N Y X - 1222
Chapter 1 General Information 1-5
Mechanical Specifications
Architecture
Close-frame
Front Bezel
Plastic bezel with resistive touch screen
Color
White
Mounting / Holder
VESA 75/100mm, Screw type:M4*8mm
Construction
3mm ABS + PC TYPE Plastic housing
Dimension (WxHxD)
300mmx 208mm x 39 mm
Net Weight
3.3 lb (1.5 Kg)
Power Supply Specifications
Model
Eljintek Inc. GMPU70A-6
Input Voltage
100-240VAC@ 50-60 Hz
Output Voltage
24V, 2.91A, 70W max.
Model
Adapter ATM065-P120
Input Voltage
100-240VAC @ 50-60 Hz
Output Voltage
12V, 5A, 60W max.
